iLiving ILG8WD24-2P User manual

Washdown Rated Stainless Steel
Pedestal and Wall Mounted Fan
MODEL: ILG8WD24-2P ILG8WD24-1W
ILG8WD30-2P ILG8WD30-1W
Owner’s Manual
PLEASE READ AND
SAVE THESE INSTRUCTIONS

2
TABLE OF CONTENTS
Important Instructions………………………………………. 3-4
Specifications……………………..………………………….. 4
Parts of the fan.............................................................. 5-6
Installing Instructions……………………….…………..… 7-9
Electrical Wiring ........……………………….………....… 10-12
Maintenance and Cleaning………………………………. 12
Troubleshooting……………………………………………. 13

3
IMPORTANT INSTRUCTIONS
CAUTION: Please read and save these instructions. Read carefully before attempting to assemble,
install, operate or maintain the product described. Do not use the fan if any part is damaged or
missing.
Protect yourself and others by observing all safety information. Failure to comply with instructions
could result in personal injury and/or property damage!
Retain instructions for future reference.
WARNING: To reduce the risk of fire or electric shock, do not use this fan with any solid state
speed control device. This fan must be grounded, when using a plug cable, must be a three prong
plug. The fan’s motor is a dual voltage motor, take care to select the correct wiring configuration
based on your voltage level. This fan must be connected with a GFCI Protected Branch Circuit.
This fan is suitable for wet location. Suitable for Use In Wet Locations When Installed In A GFCI
Protected Branch Circuit.
General Safety Information
NOTE: Air circulator is not to be used in unattended areas.
1. Ensure that the power source conforms to the electrical requirements of the fan.
2. Installed in accordance with the United States National Electrical Code (NEC) and all applicable
local codes and ordinances. This work must be done by a qualified electrician, using copper wire
only.
3. The power cord must use Type SJTW, at least No. 18 AWG, rated minimum 300V, 105 C. The
minimum length of the power cord for USL is 5 feet, for CNL is 6 feet. The maximum length of the
power cord for USL is 25 feet, for CNL is 10 feet.
4. Do not kink the cord or allow it to contact oil, grease, chemicals, hot surfaces, or sharp or
abrasive objects.
5. This fan is to be operated ONLY with its OSHA compliant guards in place to prevent persons
and/or objects from contacting the revolving propeller. Any other use voids warranty and may
create unsafe conditions.
6. Fan is intended for general air circulation ONLY. It must NOT be used in potentially dangerous
locations such as flammable, explosive or chemical-laden atmospheres. Do not attach ductwork to
the fan.
7. Fan motor is equipped with an automatically resetting control circuit that will disconnect power
if the motor overheats. Always unplug fan before removing guard, as motor may restart
unexpectedly.
8. Do not operate any fan with a damaged cord or plug. Discard fan or return to an authorized
service facility for examination and/or repair.
9. Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar
coverings. Do not route cord under furniture or appliances. Arrange cord away from traffic area
and where it will not be tripped over.
10. Disconnect the fan when moving it from one location to another.

4
11. Make sure the fan is on a stable, flat surface while it is in operation.
12. Disconnect the fan when removing the guards for cleaning.
WARNING: The fan must be grounded and installed in A GFCI Protected Branch Circuit. Improper
connection may create the risk of electrocution. Use of such adapters is prohibited in Canada.
WARNING: Do not depend on any switch as the sole means of disconnecting power when
installing or servicing the fan. Failure to do so may result in fatal electrical shock.
WARNING: Do not insert fingers or foreign objects into the fan. Do not block or tamper with the
fan in any manner while it is in operation.
WARNING: Do not touch motor. May be hot enough to cause injury.
WARNING: Unplug prior to servicing unit.
IMPORTANT: Surges in electrical power or excessive heat could cause the fan to automatically shut
off. Should this occur, wait approximately 15 minutes for the fan to resume operation.
SAVE THESE INSTRUCTIONS
Product Specifications
Model
ILG8WD24-2P
ILG8WD30-2P
ILG8WD24-1W
ILG8WD30-1W
Size(inch)
24
30
24
30
Voltage(V)
115/230
115/230
115/230
115/230
Frequency(Hz)
60
60
60
60
Wattage(W)
310/305
310/305
310/305
310/305
AMPS(A)
2.85/1.55
2.85/1.55
2.85/1.55
2.85/1.55
RPM
1050/1060
1050/1060
1050/1060
1050/1060
Airflow(CFM)
7200
9600
7200
9600
N.W.(LBS)
55.7
60.8
45.8
51.3
Certification
UL
UL
UL
UL

5
PARTS OF THE FAN
For the Washdown Rated Stainless Steel Pedestal Fan
Model: ILG8WD24-2P & ILG8WD30-2P
CONTAINS
REF
QTY
DESCRIPTION
PART NUMBER
1
1
Front Fan Guard
SP-D242P-1 & SP-D302P-1
2
1
Blade
SP-D242P-2 & SP-D302P-2
3
1
Rear Fan Guard
SP-D242P-3 & SP-D302P-3
4
1
Motor Assembly
SP-D242P-4 & SP-D302P-4
5
1
Upper Column
SP-D242P-5 & SP-D302P-5
6
1
Lower Column
SP-D242P-6 & SP-D302P-6
7
1
Base Assembly
SP-D242P-7 & SP-D302P-7

6
For the Washdown Rated Stainless Steel Wall Mounted Fan
Model: IILG8WD24-1W & ILG8WD30-1W
CONTAINS
REF
QTY
DESCRIPTION
PART NUMBER
1
1
Front Fan Guard
SP-D241W-1 & SP-D301W-1
2
1
Blade
SP-D241W-2 & SP-D301W-2
3
1
Rear Fan Guard
SP-D241W-3 & SP-D301W-3
4
1
Motor Assembly
SP-D241W-4 & SP-D301W-4
5
1
Wall Mounting Bracket
Assembly
SP-D241W-5 & SP-D301W-5

7
INSTALLATION INSTRUCTION
PRE-INSTALLATION:
All necessary screws are installed in the associate part for ease of tracking for
customer. Please use the following pictures as guide to locate installation parts.
For the Washdown Rated Stainless Steel
Pedestal Fan
(Model: ILG8WD24-2P & ILG8WD30-2P)
Base Assembly INSTRUCTIONS:
1. Loosen the screw from the base assembly, insert the
lower column to the base assembly. Align the hole of
the lower column and base assembly , then tighten it.
2. Loosen the screws from the upper pose, insert the
upper column to the lower column. Align the hole of
the upper column and lower column , then tighten it.
COLUMN/MOTOR ASSEMBLY INSTRUCTIONS:
1. Align the motor flange and column.
2. Insert the pivot screw through the motor flange, column
and washer. Attach using the position nut and tighten it.
3. Insert the smaller position screw through the bottom
radius. Attach it with the position nut.
GRILLE/MOTOR ASSEMBLY INSTRUCTIONS:
1. Unscrew the nuts and washers from the motor .
2. Arrange the rear guard in its proper position.
3. Attach the rear guard by inserting and
tightening the nuts to the motor (through the
eyelets on the guard).

8
4. Insert the blade into the motor
shaft until it reaches a stopping
point and the set screw is in line
with the flat groove on the
motor shaft.
NOTE: Make sure the blade’s set
screw is facing the motor. You may
need to loosen the set screw at the
rear of the blade to slide it onto the
shaft.
5. Firmly tighten the blade’s set
screw with the spanner (not
supplied).
CAUTION: Do not alter the angle of
the blades.
6. Hang front grill on top rib of rear grill by utilizing the “U” shaped fixed clip at top
of front grill rim.
For the Washdown Rated Stainless Steel Wall Mounted Fan
(Model: IILG8WD24-1W & ILG8WD30-1W)
MOUNTING BASE ON A WOOD FRAMED WALL
1. Located a wall stud secure and solid enough to hold the weight of the base
assembly. Carefully located and mark the center of wall stud. If you do not have a
solid structural framing member at that location then you must provide an
adequate alternative for mounting the fan.
2. Place mounting bracket against the wall centered with the centerline of the wall
stud and 4 holes.
3. Drill 4 holes on the wall and secure bracket to wall using 4 lag screws （not
provided）.

9
If mounting on a concrete wall, be sure to locate a structurally solid and secure
location to hold the weight of the fan assembly and use suitable concrete anchors
(not provided ) to mount the base to the wall.
WALL MOUNT BRACKET/ MOTOR ASSEMBLY
1. Remove the 2 bolts, washers and nuts from the
mounting bracket.
2. Align the holes on the mounting bracket with the
holes in the motor flange on the motor assembly.
3. Insert the bolts and replace the washers and nuts
removed in step 1.
4. Tighten the position bolt and nut.
CAUTION: BE SURE TO SECURE THE KNOB.
MOTOR / REAR GRILLE & BALDE
ASSEMBLY
1. Removed the 4 nuts, spring washers
and flat washers from the bolts
around the motor shaft.
2. Carefully slide the rear grille over the
bolts.
3. Secure with the flat washers, spring
washers and nuts removed in Step 1.
4. Carefully slide the blade assembly
over the shaft and align the inner hex
head driver provided with the slot on
the shaft of the motor.
5. Tighten the blade assembly
with the hex head screw using the
hex head driver provided with the
fan.
NOTE: Keep the hex driver for
future use.
CAUTION: DO NOT ALTER THE
ANGLE OF THE BLADES.
6. Hang front grille on top rib of rear
grille by utilizing the hook.
7. Snap the front grille into the rear
grille to secure.

10
ELECTRICAL WIRING
OPERA
Your licensed electrician is responsible for providing all electrical components and making
all necessary connections from the motor to the appropriate power source.
All Washdown Rated Stainless Steel Fans come with a wiring schematic, usually printed on
the nameplate of the motor. Fans must be wired exactly as shown. This is a dual voltage
motor, take care to select the correct wiring configuration based on your voltage level.
Warning: Improper wiring can damage motors, cause injury, and affect warranty coverage.
It is highly recommended that all fans have an independent disconnect switch located
within visual sight of the fan. This switch should be used in conjunction with all “lock out,
tag out” procedures during service and maintenance.
ELECTRICAL INSTALLATION (Power cord not included)
1. Remove the 4 screws from the Junction Box. Open the Junction Box Cover.
2. Unscrew the Thread-Lock Sealing Nut.
3. Thread the appropriate power cord through the Thread-Lock Sealing Nut and Cable
Gland body in turn. （Power cord not included）
4. Follow the wiring diagram (Figure 2: 115V/60Hz, Figure 3: 230V/60Hz and
table1:Plug and socket) for proper connections.
5. Tighten the Thread-Lock Sealing Nut.
Thread-Lock Sealing Nut tightening requirements: No movement of the power cord
under a maximum tension of 36 LBS.
6. Install the junction box cover: CAUTION:Make sure the sealing ring is in the
original position after installation.
Installation standard Requirements: Screws are tightened with a torque of 2.4NM.

11
Figure 2
Figure 3

12
Table 1 Plug and socket
Wiring 115V, according to the user socket, you can choose 5-15P, 5-20P, 5-30P,5-50P.
Wiring 230V, according to the user socket, you can choose 6-15P, 6-20P, 6-30P,-50P.
MAINTENCE AND CLEANING
WARNING: Parts replacement and troubleshooting to be performed only by qualified
personnel.
WARNING: Do not depend on any switch as the sole means of disconnecting power when
installing or servicing the fan. Failure to do so may result in fatal electrical shock.
WARNING: Unplug the fan from the wall outlet before servicing or cleaning.
CAUTION: There is no user maintenance part except regular cleaning as following
description. All other servicing or maintenance should be performed by qualified service
personnel.
To clean the fan, use a soft damp cloth. Wipe down with a dry cloth.
Do not use cleaners that are harmful to paints or plastics.
CAUTION: Do not use gasoline, benzene, thinner, harsh cleaners, etc., which are
dangerous and will damage the air circulator.
The propeller, guard, and motor should be cleaned periodically to prevent
overheating, and/or operating in an imbalanced condition.
CAUTION: If cleaning requires the removal of a guard, remove only the front guard and
re-install when finished in its originally installed position. Do not repair propeller if it
becomes damaged. The propeller is accurately balanced at the factory and should be
replaced if damaged.
Do not bend the blades.
Motor is permanently lubricated.

13
TROUBLE SHOOTING
If your fan fails to operate, please follow these Instructions:
1. Make sure the fan is plugged in and the electrical outlet is working properly.
2. Check for any obstruction. If you find an obstruction, turn the fan “OFF”. Unplug the fan
and carefully remove the obstruction.
Plug the fan in and turn it on again and see if it resumes normal.
NOTE: IF YOU EXPERIENCE A PROBLEM WITH YOUR FAN, PLEASE DO NOT
ATTEMP TO OPEN OR REPAIR THE FAN YOURSELF. DOING SO COULD CAUSE
DAMAGE OR PERSONAL INJURY. Always consult the authorized dealer or certified
electrician for further action.

14
Warranty Information
This product comes with a 1-YEAR LIMITED COMPONENT WARRANTY. If your unit
does not appear to be working properly, please contact our service center by calling
1-800-317-1688. Prior to your call, we encourage you to visit our service related
website www.ilivingusa.com for troubleshooting tips and service instructions if
needed.
Register your product at our website:
Or visit iLivingUSA.com/register-product
Feedback
Love it? Help us make the product more for you.
Let us know with a customer review.
Please visit: https://www.amazon.com/review/review-your-purchases#
At iLiving USA, we are committed to bringing top quality products to our customers.
iLIVING USA
860 Mahler Road,
Burlingame, CA 94010
Tel: [phone]
Email: [e-mail]
