IMMI CADDIE User manual

INSTRUCTION MANUAL
Visit buyimmi.com for additional
products from
CHILD POSITIONER

GENERAL INFORMATION
CHILD FIT REQUIREMENTS
WARNINGS
FEATURES
INSTALLATION
SECURING CHILD
CARE & MAINTENANCE
1
1
2
3
4
5
7
CHILD POSITIONER

• Online: www.buyimmi.com/product-support
• Call: 1-877-447-2305
GENERAL INFORMATION
The IMMI team truly cares about child passenger safety and is committed to providing
innovative products that offer the utmost in safety and ease of use. While injury cannot be
prevented in every situation, proper installation and use can significantly reduce a child’s
risk of serious injury or death. It is critical to read and understand these instructions and the
vehicle manufacturer’s instruction BEFORE using this positioner. Failure to properly use this
positioner may result in serious injury or death of the child. If you have any questions after
reviewing the instructions, please contact us at:
Customer Service:
• Online:
• Call:
CHILD FIT REQUIREMENTS
For resources including: installation
videos, warnings, and instructions.
www.buyimmi.com/product-support
SCAN
LIL’ CADDIE POSITIONER IS FOR CHILDREN:
• 22 - 85 pounds (10.1 - 38.5 kg)
• 36 - 50.4 inches (91.4 - 128 cm)
• At least 2 years old
© 2022 IMMI All rights reserved. 8017P
Visit www.buyimmi.com for more information
on Lil’ Caddie and other IMMI products. 1

WARNINGS
When not properly buckled, or when the device is not
properly secured, children can escape and fall suddenly.
To avoid serious injury or death from falls or other
hazards:
• ALWAYS abide by applicable golf cart and low speed
vehicle regulations.
• ALWAYS follow warnings/instructions in the
vehicle’s owner’s manual.
• ALWAYS read and follow this device’s instruction
manual before use.*
• ALWAYS properly secure to the seat, and then
properly secure the child before use.
• ALWAYS adjust straps snugly around child and
confirm buckles are secure before use.
• USE ONLY on the seat of a low speed vehicle.
• USE ONLY with adult supervision and in a seat next
to an adult.
• NEVER leave child unattended in or around this
device.
• NEVER use in or near water to avoid drowning.
• ALWAYS inspect for damage before and after use.
* If damaged, do not use.
*Read instruction manual for detailed information,
instructions, and warnings.
This product is not a seatbelt. It is a positioner
device.
Use only with children
• who weigh between 22 and 85 pounds
(10.1 and 38.5 kg)
• whose height is between 36 and 50.4 inches
(91.4 and 128 cm)
• who are at least 2 years old.
Use only with golf carts that are Low Speed
Vehicles (LSV), (as defined by FMVSS 500 LSV
regulation).
• DO NOT USE in vehicles that can reach or exceed
20mph (32 km).
• DO NOT USE in cars, trucks, aircraft, boats, or any
vehicle other than an LSV.
Strangulation hazard: Children can strangle in loose
straps. NEVER leave child in this device when straps
are loose or undone. NEVER allow a child to sleep in
this device.
WARNING! DEATH or SERIOUS
INJURY can occur:
Failure to follow all warnings and
instructions can result in serious injury or
death of your child.
2© 2022 IMMI All rights reserved. 8017P
Visit www.buyimmi.com for more information
on Lil’ Caddie and other IMMI products.

Seat Wrap Straps (Grey)
Seat Wrap Bracket
Seat Wrap Snap Hook
Back pad
Base pad
Seat Wrap Strap Width Guide
Seat Wrap Strap Adjuster
Hook and Loop Strap Keepers
5-Point Straps (Black)
5-Point Tongue
5-Point Buckle
5-Point Adjusters
Chest Clip
5-Point Buckle Strap
5-Point Buckle Adjuster
Shoulder Pads
FEATURES
A
B
C
D
E
F
G
H
A
D
E
F
H
I
J
K
L
M
P
I
J
K
L
M
N
O
P
B
C
G
N
O
3© 2022 IMMI All rights reserved. 8017P
Visit www.buyimmi.com for more information
on Lil’ Caddie and other IMMI products.

1 Place the Lil’ Caddie Positioner on the
seat. Unbuckle seat wrap straps and
insert the gray seat wrap strap (buckle
end) through the opening at the rear of
the seat cushion. Route the seat wrap
straps around the back of the vehicle
seat and place buckles on top of the
vehicle seat back.
2 Connect the left seat wrap strap
bracket to the left seat wrap strap
snap hook. Connect the right seat wrap
strap bracket to the right seat wrap strap
snap hook. Place the snap hook/bracket
assemblies on the back of the seat.
3 Ensure snap hook/bracket assemblies
will not make contact with the child’s
head while child is in the seated
position. The seat wrap strap width
guide should be located at the top of
the seat back. After ensuring there are
no twists in the seat wrap straps, pull
seat wrap strap adjusters to tighten
both seat wrap straps.
4 Verify the security of the positioner by
moving the seat wrap straps sideways.
Positioner seat wrap straps should move
less than one inch.
5 Once all seat wrap straps are tight and
secure, use the hook and loop strap
keepers on each strap to secure the
free ends of the left and right seat wrap
straps.
6 Straps must appear as shown in figure 6
after installation is complete.
INSTALLATION
WARNING! DEATH or SERIOUS
INJURY can occur:
Failure to follow all warnings and
instructions can result in serious injury or
death of your child.
1
3
5
2
4
6
4© 2022 IMMI All rights reserved. 8017P
Visit www.buyimmi.com for more information
on Lil’ Caddie and other IMMI products.

1 Prepare 5-point straps:
• Push left 5-point adjuster button and
pull up on left shoulder strap to loosen
straps. Repeat with right shoulder
strap.
•Open chest clip and unbuckle 5-point
straps.
2 Prepare 5-point buckle strap:
• Lay 5-point buckle forward, toward
front of positioner.
• Push 5-point buckle adjuster button
and pull on buckle strap to lengthen
buckle strap to it’s longest position.
3 Place child in positioner:
• Place child in positioner with child’s
back flat against the positioner back
pad.
• Remove any twists from straps.
• Position shoulder straps over child’s
shoulders. Back pad should be
positioned so that shoulder straps exit
at or just above child’s shoulder.
4 Buckle 5-point straps:
• Make sure straps are not twisted.
•Insert 5-point buckle tongues into
5-point buckle. Listen for an audible
click when each buckle tongue is
fastened.
• Check buckle connection is secure by
pulling on shoulder straps.
5 Evaluate buckle placement:
• When properly secured, the 5-point
buckle should be positioned on child
as shown in figure 5.
SECURING YOUR CHILD
WARNING! DEATH or SERIOUS
INJURY can occur:
Failure to follow all warnings and
instructions can result in serious injury or
death of your child.
1
3
5
2
4
5© 2022 IMMI All rights reserved. 8017P
Visit www.buyimmi.com for more information
on Lil’ Caddie and other IMMI products.

6
6 Adjust buckle placement:
• If buckle is not positioned on child as
shown in figure E, remove child. Pull
on 5-point buckle adjuster strap
to adjust the buckle strap and retest
length until the buckle strap properly
fits the child.
7 Tighten 5-Point Straps:
• Pull free end of 5-point strap, located
on the outside of child’s leg, until
5-point strapis snug around the child.
• Repeat with second 5-point strap.
• A snug strap should not allow any
slack. It lies in a relatively straight
line without sagging. It does not press
on the child’s flesh or push the child’s
body into an unnatural position.
• Be sure the 5-point strap is snug and
tight on both the thighs and chest
before each use.
• Once the 5-point strap is snug, use the
Hook and loop strap keepers on each
strap to secure the free ends of the
left and right 5-point straps.
8Fasten chest clip:
• Fasten chest clip by pushing both sides
together. Position chest clip at middle
of child’s chest, at armpit level.
9 Evaluate 5-point straps:
•5-point straps must appear as
shown in figure 9 after installation is
complete.
To remove child from the positioner:
• Open chest clip by squeezing middle
tabs and pulling apart.
• Loosen 5-point straps: Pull shoulder
strap while pushing button on 5-point
adjuster located on outside of child’s
leg. Repeat with second 5-point strap.
• Pull buckle away from child. Unbuckle
5-point buckle by pressing down on
red release button.
• Remove child and rebuckle 5-point
buckle to prevent twisting.
SECURING THE CHILD (CONTINUED)
WARNING! DEATH or SERIOUS
INJURY can occur:
Failure to follow all warnings and
instructions can result in serious injury or
death of your child.
7
8 9
6© 2022 IMMI All rights reserved. 8017P
Visit www.buyimmi.com for more information
on Lil’ Caddie and other IMMI products.

The straps, back pad, base pad, and
shoulder pads can be cleaned with a damp
cloth using mild soap solution and lukewarm
water.
The seat pad is connected to the base with
the use of hook and loop fasteners. To remove,
pull up on the pad to remove from the base
and disconnect the hook and loop fasteners on
the back of the pad in two places.
Lil’ Caddie Positioner Replacement
The Lil’ Caddie Positioner system is considered
to have a finite life and must be frequently
inspected and replaced as needed. The default
service life of a Lil’ Caddie Positioner is 6
years from the date of manufacture. Use of
the Lil’ Caddie must be discontinued six years
after the date of manufacture. The date of
manufacture can be found on 5-point buckle
adjuster strap.
The Lil’ Caddie and its components must
be inspected frequently (per instructions
to the right). If you have any doubts about
the condition or function of the positioner,
REPLACE IT, even if it is less than 6 years from
the date of service expiration.
If any component or part of the Lil’ Caddie
Positioner requires replacement, the entire
system must be replaced.
Lil’ Caddie In a LSV Crash
If the low speed vehicle (LSV) is involved in
a moderate or severe crash, the entire Lil’
Caddie Positioner must be replaced regardless
if the Lil’ Caddie was occupied for use at the
time of the crash.
Lil’ Caddie Positioner Inspection
1. Inspect webbing on entire system for cuts,
fraying, or extreme or unusual wear. Most
common areas of belt wear include the
buckle/latch area and any place where the
positioner makes contact with the vehicle
or seat.
Corrective action – Replace entire
Lil’ Caddie.
2. Inspect latch and buckle for proper
operation by inserting the latch into the
buckle. Latch must insert smoothly, and you
must hear an audible click. Verify proper
latching by tugging on the belt. Latch must
not be worn, deformed or corroded. Buckle
must not be damaged, cracked or broken.
Corrective action – Replace entire
Lil’ Caddie.
3. Inspect the seat belt height adjuster for
damage. Move adjuster up and down.
It must move freely and should not be
damaged, cracked or broken.
Corrective action – Replace entire
Lil’ Caddie.
4. Inspect dual seat wrap system for cuts,
fraying, or extreme or unusual wear.
Corrective action – Replace entire
Lil’ Caddie.
5. Inspect chest clips for damage and
operation. Chest clip halves should not be
damaged, cracked or broken. Clips should
engage and disengage smoothly with each
other. Move clip halves up and down. They
must move freely.
Corrective action – Replace entire
Lil’ Caddie.
CARE AND MAINTENANCE
© 2022 IMMI All rights reserved. 8017P
Visit www.buyimmi.com for more information
on Lil’ Caddie and other IMMI products. 7
