Inateck AL2011 User manual

w w w . i n a t e c k . com
AL2011
2-PortRapidCarCharger
With3ft(0.9m)LightningCable
InstructionManual

AL20112-PortRapidCarCharger
Productintroduction
This handy car charger is a device which plugs the
cigarette lighter to power smartphones and tablets
electronics fast and safely. An integrated Apple MFI
certified Lightning cable can charge iPhone, iPad
quicklyplustheresttwooutput2.1AUSBportscould
feed three devices like phones, tablets or GPS
simultaneously. With premium ABS+PC fireproof
materials, this car charger is functioned with short
circuit, over-watt, over-current and overheat
protections,thisensuressafeandhigh-efficiencyuse.
ItiscertifiedbyCE,FCC&RoHS.
Components
This car chargerʼs integrating body was made from
plastic shell and its spring positive plate was
constructedwithcopper,whilezincalloymadeofthe
negativeplate.

ProductSpecifications
Input:
Output:
Surfacecrafts:
Material:
LEDindicatorlight:
Size:
Storagetemperature:
Color:
DC12-18V
DC5.0V6.6A33W(LightningCable2.4AUSB
2.1A)
UV
ABS+PC
Blue
30.34x30.34x83.8(mm)/0.91x0.91x3.29(inch)
1month(-20℃~60℃);3months(-20℃~50℃)
Unibodydesignwithblackandwhitecolors
LEDindicator
USBport
Model: Inateck AL2011 Input: DC 12-18V Output: DC 5.0V 6.6A
Made in China
2.1A
2.1A

Instructions
Plugthecarchargerincigarettelighter;LEDlightturns
bluemeansthechargerisreadytogo.Itcanpower
threemobiledevicesatthesametime.IftheLEDlight
goes out in the process of charging, then it may
causedbytheoutputover-currentprotection.Allyou
havetodoistopulloutthechargerandre-plugit.
Circuitperformancequota
DCinputvoltagerange:
USBoutputvoltagerangewithoutload:
USBfull-loadoutputrippleof5V/6.6A:
USBfull-loadoutputaverageefficiencyof5V/6.6A:
TheUSBoutputovervoltageprotection:
USBoutputover-currentprotection:
10-18V
5.05V-5.25V
≤250mV
≥90%
6.25±0.25V
≥10A
PackageContents
2-Portrapidcarcharger*1
MicroUSBchargingcable*1
Nylonstickerribbons*2
Instructionmanual*1

Notes
1.12/18VDCinputvoltagemaynotworkwithsome
24 volt output cigarette lighter sockets. Please use
original charging cordor the one with athird party
certification.
2. Please plug the charger after starting the car
engine;
3.Pleasepulloutthechargeraftershutdownthecar
engine;
4. Charging stops automatically in the event of
overcharging, lower/over voltage, overheating,
overcurrent,andshortcircuit.(Chargerwillbacktolife
afterpullingoutthedevices)
5.Itʼsnormalforthechargertobedissipatedwithin60
degreesunderthecommonroomtemperaturewhen
inuse.

Tel:+49342-7673081
(Servicetime:Mon.-Fri.9:00-17:00CET)
Email:[e-mail]
Website:Http://www.inateck.com
