inbody BWA2.0 User manual

BWA2.0 User's Manual for Measurement Guide and Setup
Thank you for purchasing the BWA2.0. This User's Manual describes all the features of the BWA2.0.
Please read before use and keep it in a safe place. By following properly these instructions, you will be able to use the BWA2.0
more safely and eectively.
User’s Manual
BWA_manual_USA_B_210916.indd 1BWA_manual_USA_B_210916.indd 1 2021-11-24 오전 9:58:172021-11-24 오전 9:58:17

ⓒ
2021 InBody Co., Ltd. All rights reserved. IM-USA-I3-C-211119
BWA2.0 is mainly used for healthy and acute or chronically ill populations in hospitals, medical practices and inpatient care
facilities in accordance with national regulations. It can be used to assist in the assessment of nutritional status, obesity and
muscle balance. Body composition analysis is important in changing the daily life style habits of a subject since it provides
the basis of appropriate physical activity and dietary habits for improving personal daily routine. It can be also usefully
applied to follow-up studies of patients who have been treated for various diseases.
Intended Use and Medical Indication
• Medical checkups: Body composition analysis enables health checkups by identifying the risk of diseases closely related
to body composition imbalances such as obesity, malnutrition, body water imbalance, and osteoporosis.
• Obesity: Percent body fat is considered to be more appropriate parameter rather than BMI to ensure proper weight loss
and improvements in long-term health, tracking changes for adjusting/developing customized treatments.
• Pediatric obesity: Body composition analysis is an essential part of health assessments for children and adolescents.
Percent body fat could be a useful parameter than just weight to verify health condition in children and adolescents.
• Sarcopenia: InBody Test is a quick and easy way to provide the Skeletal Muscle mass Index (SMI), which is the sum of
the skeletal muscle mass of the limbs divided by the height square. This parameter is useful for identifying muscle loss
or low muscle that increase risks of falls, disability, poor quality of life, and premature death.
• Diabetes & Endocrinology: Diabetes is often associated with excess fat, however having insufficient muscle mass
is just as detrimental and increases diabetes risk. Visceral fat also plays a key role in the development of metabolic and
cardiovascular disease.
• Edema: The ECW Ratio (ECW/TBW) is associated with residual renal failure, inflammation, malnutrition, and
hypertension, which are common in dialysis patients. Monitoring the ECW Ratio (ECW/TBW) allows the assessment of
body water accumulation in the extracellular water due to impaired cardiovascular function. Even in cirrhosis, patients
with high ECW Ratio can be used to recognize the risk of ascites, and have a high prognosis in critically ill or surgical
patients.
• Segmental ECW Ratio: InBody directly & separately measures each segment of the body and provides each segmental
ECW Ratio and it can be used to detect body water imbalances resulting from the development or progression of
lymphedema.
• Nutrition: ABCD method in nutrition is a mnemonic of four primary components of nutritional assessment. “A” stands
for anthropometric measurements including stature, body weight, BMI, and body composition. Body composition
analysis can reveal changes in body composition (body water, protein, minerals, and body fat) that cannot be known by
changes in body weight.
• Fitness: Strength training stimulates muscle growth, exercise burn the calories strengthens cardiorespiratory capacity,
which reduce the risk of diabetes, heart disease, and other health concerns and result in the various changes in body
composition. Body composition analysis shows skeletal muscle mass and segmental muscle mass, and it helps to focus
on building more muscle with symmetrical or lateral balance.
* The BWA2.0 is not a diagnostic device. To make an accurate diagnosis, a physician must go through a thorough
examinations and take their results into account in addition to the results of the InBodyXXX.
* The BWA2.0 is not used in home healthcare environment.
Intended Purpose
The device should be used as an adjunct for clinical decision making and is not intended to diagnose or treat any diseases.
BWA_manual_USA_B_210916.indd 2BWA_manual_USA_B_210916.indd 2 2021-11-24 오전 9:58:172021-11-24 오전 9:58:17

Please note the important information below before reading this User Manual.
Failure to comply with safety warnings and regulations can cause serious injury or death.
Warning
Failure to comply with safety cautions and regulations can cause injury or property damage.
Caution
Le non-respect des consignes de sécurité et des règlements peut causer des blessures graves ou la mort.
Avertissement
Le non-respect des consignes de sécurité et des règlements peut causer des blessures ou des dommages matériels.
Attention
For problems with the BWA2.0 or any clinical questions, contact:
InBody USA [USA]
13850 Cerritos Corporate Dr. Unit C Cerritos, CA 90703 USA
TEL: [phone]
FAX: [phone]
Website: inbody.com
E-mail: [e-mail]
InBody Europe B.V.
Gyroscoopweg 122, 1042 AZ, Amsterdam, The Netherlands
TEL: [phone] FAX : [phone] Website: nl.inbody.com E-mail: [e-mail]
InBody Co., Ltd. [MANUFACTURER]
15, Heugam-gil, Ipjang-myeon, Seobuk-gu, Cheonan-si, Chungcheongnam-do 31025 KOREA
TEL: [phone] FAX: [phone] Website: inbody.com E-mail: [e-mail]
Reproduction, adaptation, or translation of this manual is prohibited without prior written consent from InBody Co., Ltd.
under the copyright laws. This manual may be printed incorrectly and subject to change without notice. InBody Co., Ltd.
shall not be liable for any errors, incidental, or consequential damages that occurred by not complying with the content
of the User᾽s Manual.
Visit our website (inbody.com) to view and download additional information about the BWA2.0. InBody Co., Ltd. reserves
the right to modify the appearance, specifications, etc. of this product to improve its quality, without prior notice.
BWA_manual_USA_B_210916.indd 3BWA_manual_USA_B_210916.indd 3 2021-11-24 오전 9:58:172021-11-24 오전 9:58:17

I. Installing the BWA2.0
A. Product Components
B. Accessories
C. Installation Environment
D. Installation
E. Initial Setup
F. Connecting External Devices
G. Precautions for Maintenance
II. BWA2.0 Test
A. Precautions for Measurement
B. Test Instructions
C. Electrode Connection Method
D. Test Posture
III. Transportation and Storage
A. Caution during Transportation
B. Repacking Instructions
C. Transportation and Storage Environment
IV. FAQ
A. Regarding the Equipment
B. Regarding the Test
V. Others
A. Exterior and Functions
B. Using and Charging the Battery
C. Safety Information
D. Product Classication
E. Specication
F. Feature Specication
G. Other Specications
4
5
6
6
21
25
33
34
36
39
42
47
47
51
52
54
55
57
60
61
61
64
65
Table of Contents
BWA_manual_USA_B_210916.indd 5BWA_manual_USA_B_210916.indd 5 2021-11-24 오전 9:58:182021-11-24 오전 9:58:18

4
5
I. Installing the BWA2.0
A. Product Components
The BWA2.0 consists of the following components. Make sure all of the following components are present.
*Please check each component of the system for damage prior to installation.
❶BWA2.0 main unit
❷Four clamp electrodes (Contact type) or forceps electrodes (Adhesion type)
❸Power adapter
❹Power cable
❺User’s Manual
❻Two batteries (IB Battery 220)
❼
USB memory stick
❽
Cable cover
• For BWA2.0 electrodes, you can purchase and use either a clamp or forceps type.
• The optional disposable electrode (BWA-ES100) is available when purchasing the forceps electrode.
• The battery (IB Battery 220) is designed to connect to the BWA2.0.
• Do not use the battery for purposes other than connecting it to the BWA2.0.
• The BWA2.0 is supplied with two batteries.
• One battery can be used with the main unit while the other battery is charged or stored separately.
• The battery should be stored under the following conditions:
a. Please store in a pack or box in a cool state where is not exposed to direct sunlight.
b. Long-term storage may accelerate the battery self-discharge and degrade battery performance.
c. For long-term storage, store in a dry place where is low in humidity and temperature range of -20℃ to +30°C.
d. If charging for the first time after long-term storage, the capacity may be reduced.
e. Fully charge and discharge the battery several times to restore the original performance.
f. When the battery is stored for more than six months, it must be charged at least every six months to prevent
performance degradation due to solution leakage or self-discharge.
Caution
❶
❷
BWA2.0
사용자매뉴얼
❸
BWA2.0
사용자매뉴얼
❹
BWA2.0
사용자매뉴얼
❺
❼❽❻
BWA_manual_USA_B_210916.indd 4BWA_manual_USA_B_210916.indd 4 2021-11-24 오전 9:58:182021-11-24 오전 9:58:18

4
5
• The BWA2.0 can be installed in the portable cart or portable bag, both are available for purchase.
Caution
B. Accessories
❶Portable cart basket
❷Portable bag stand
❸Portable cart lower body part
❹Portable bag
❺ Disposable electrode (BWA-ES100)
❻ Thermal printer (TP100)
❼ Serial distributor (SD400) ❶
❷
❸
A�ach the adhesive electrodes so
that the dashed line is aligned with
the ulnar head of the wrist when
a�aching it on your hands, and in
the ankle bones when a�aching it
on your legs.
Clamp the black clip on the wrist
and ankle, and clamp the red clip on
the top side of the hand and foot.
❺
❹
❻❼
• Pour les électrodes du BWA2.0, vous pouvez choisir et acheter celles de type pince ou forceps.
• Achetez l'électrode de type forceps avec l'électrode jetable (BWA-ES100) en option.
• La batterie (Batterie IB 220) est conçue pour connecter le BWA2.0 du InBody.
• N'utilisez pas la batterie à aucune autre fin.
• Le BWA2.0 vient avec deux batteries.
• Insérez une des batteries dans l'unité principale. Mettez l'autre à charger ou rangez-la séparément.
• La batterie doit être rangée en respectant les conditions ci-dessous :
a. Veuillez la ranger dans une boîte ou un emballage dans un endroit frais sans lumière directe du soleil.
b. Un entreposage long terme peut augmenter le taux d'autodécharge de la batterie.
c. Pour un entreposage long terme, placez la batterie dans un endroit sec ayant un faible taux d'humidité et une
température entre -20℃ et +30°C.
d. Un entreposage long-terme peut nuire à la capacité de recharge de la batterie.
e. Dans ce cas, rechargez et déchargez la batterie au complet à plusieurs reprises pour retrouver sa performance d'origine.
f. Toute batterie entreposée doit être rechargée tous les six mois pour prévenir une dégradation de performance due aux
fuites de solution ou à l'autodécharge.
Attention
• Le BWA 2.0 peut être installé dans le chariot portable ou la valise. Vous pouvez acheter l'un ou l'autre.
Attention
BWA_manual_USA_B_210916.indd 5BWA_manual_USA_B_210916.indd 5 2021-11-24 오전 9:58:192021-11-24 오전 9:58:19

6
7
C. Installation Environment
Check the environment before installing the BWA2.0. This equipment is suitable for indoor use. If installing the
equipment outdoors, the following requirements must be fullled.
Temperatures range 1
0 ~ 40°C (50 ~ 104°F)
Relative humidity 30 ~ 75% RH
Atmospheric pressure range 70 ~ 106kPa
D. Installation
1. Installation for cart user
1) Open the cart packing box and remove the inner material. In this order, take out the lower body part, stand,
and basket from the box.
Protective vinyl for
package
• Pour réemballer ultérieurement le BWA2.0, conservez les emballages d'origine.
Débarrassez-vous de tout autre déchet selon les lois et règlements en vigueur.
• Évitez de vous coincer les mains ou les pieds dans la boîte d'emballage.
• Évitez que les enfants jouent dans la boîte.
• Évitez tout contact des vinyles de l'emballage avec le visage.
Attention
• For repackaging the BWA2.0 at a later time, the supplied packing materials should be kept.
Other wastes should be disposed of according to relevant local laws and regulations.
• Be careful not to get your hands or feet caught by the packaging box.
• Be careful for children not to enter the packaging box.
• Do not put vinyls for the packing box on your face.
Caution
BWA_manual_USA_B_210916.indd 6BWA_manual_USA_B_210916.indd 6 2021-11-24 오전 9:58:192021-11-24 오전 9:58:19

6
7
2) Turn the two knobs on the bottom of the stand counterclockwise to remove them.
3) After aligning the two bolt positions of the stand and the lower body part, turn the knob clockwise to fix
them. When aligning the stand on the lower body part, pay attention to the direction of the stand so the stand properly
ts into the shape of the lower part.
4) Turn the knob counterclockwise on the back of the stand to remove it.
• When removing the knob, keep it well, so as not to lose it.
Note
• Lorsque vous retirez la poignée, assurez-vous de la garder dans un endroit sécuritaire afin de ne pas la perdre.
Remarque
• When turning the knob bolt, be careful not to get your hands or other body parts caught.
• One person of a team of two people should hold the upper side of the stand while the other person removes the
knobs at the lower side.
Caution
• Lorsque vous tournez le bouton de fixation, assurez-vous de ne pas coincer les mains ou autres parties du corps.
• Soyez à deux, une personne pour tenir le bord supérieur du support et l'autre pour attacher les boutons au bord
inférieur.
Attention
BWA_manual_USA_B_210916.indd 7BWA_manual_USA_B_210916.indd 7 2021-11-24 오전 9:58:202021-11-24 오전 9:58:20

8
9
5) Tilt the basket to insert it into the top of the stand as shown below. Hang it by aligning the four grooves with
the four knob positions on the back of the stand.
6) Align the knob removed in Step 4 with the position, then turn it clockwise to x it.
7) Refer to the gure below after completing the assembly of the portable cart.
• When hanging the basket on the top of the stand, be careful not to get your hands or other body parts caught.
Caution
• Lorsque vous suspendez le panier sur le haut du support, assurez-vous de ne pas coincer les mains ou une autre
partie du corps.
Attention
BWA_manual_USA_B_210916.indd 8BWA_manual_USA_B_210916.indd 8 2021-11-24 오전 9:58:202021-11-24 오전 9:58:20

8 9
8) Open the main unit packing box and remove the packing pad. Take out the BWA2.0 main body, clamp electrodes
(or forceps electrodes) and batteries from the box. Then remove the protective packaging material from the main
unit and the electrodes.
BWA_manual_USA_B_210916.indd 9BWA_manual_USA_B_210916.indd 9 2021-11-24 오전 9:58:222021-11-24 오전 9:58:22

10
11
9) Press the cover located on the back of the main unit and pull it down to remove the cover.
(Store the cover separately.)
10) Align the main unit into the mounting part of the cart, and then lower the main body downward to insert it.
11) Connect the electrode cables to the main unit. Connect the electrode cables labelled Right Arm (black),
Left Arm (red), Right Leg (yellow), and Left Leg (blue) to each position of the main unit according to the color.
• When inserting the main unit to the mounting part of the cart, be careful not to get your hands or other body parts caught.
Caution
• En montant l'unité principale sur le support prévu à cette fin sur le chariot, assurez-vous de ne pas coincer les mains ou
une autre partie du corps.
Attention
BWA_manual_USA_B_210916.indd 10BWA_manual_USA_B_210916.indd 10 2021-11-24 오전 9:58:242021-11-24 오전 9:58:24

10
11
12) Mount the electrodes to the cart basket electrode mounting groove as shown below.
13) Inserting battery
❶ Place your ngers on both sides of the OPEN mark on the rear of the main unit. Press the buttons in the direction
of the arrows and then pull the cover down to open.
❷ With the battery button visible, push the battery into the main unit until it clicks.
When mounting clamp electrodes When mounting forceps electrodes
• When connecting or disconnecting the cable, grasp the connector part and not the cable. Otherwise, the cable may break.
Caution
• Pour éviter d'endommager le câble, saisissez le connecteur et non le câble en branchant et en débranchant celui-ci.
Sinon, le câble peut briser.
Attention
BWA_manual_USA_B_210916.indd 11BWA_manual_USA_B_210916.indd 11 2021-11-24 오전 9:58:272021-11-24 오전 9:58:27

12
13
❸ Lift the cover up and press the cover inward until it clicks. If the cover does not close, make sure that the battery
is inserted properly.
• Lisez attentivement la liste ci-dessous pour prévenir le risque de fuite, d'explosion ou de combustion de la batterie.
a. NE PAS laisser tomber ni jeter les batteries à l'eau.
b. NE PAS utiliser ou ranger une batterie près d'une source de chaleur(par ex. foyer ou chauffage - 60°C+).
c. En rechargeant la batterie, veuillez utiliser l'adaptateur fourni par InBody.
d. NE PAS brancher la batterie directement dans une prise murale ou une prise de véhicule.
e. NE PAS brûler ni chauffer les batteries.
Advertissement
Warning
• Read carefully the following items. Improper usage of the components may lead to battery leakage, explosion,
or combustion.
a. Do not drop or throw batteries into water.
b. Do not use or store the battery nearby a heat source(e.g. fire or heater, above 60°C).
c. When charging, please use the adapter provided by InBody.
d. Do not connect the battery directly to a wall outlet or socket in a vehicle.
e. Do not burn or heat up the batteries.
f. Do not short-circuit the terminals of the battery with conductors or other metallic objects, and do not carry
or store the batteries along with other metallic objects such as necklaces.
g. Do not apply shock or mechanical vibration to the battery.
h. Do not crush or hammer the battery.
i. Do not touch fingernails or other sharp objects to batteries, and avoid tapping or hitting it with a hammer.
j. Do not weld the battery terminals directly.
k. Do not attempt to disassemble the battery in any way.
l. Do not charge the battery in a fire or extremely high temperatures.
m. Do not place batteries in microwave ovens.
n. Do not use the batteries when they smell, heat up, deform, discolor or have other abnormalities.
Take batteries out of the device or charger to stop using them if they are in use or charging.
o. Keep the batteries away from children.
p. Remove the battery from the machine immediately if there is a leakage or foreign smell.
q. A fire or explosion may occur from a leaked electrolyte.
r. Do not rub your eyes if the leaked electrolyte gets into your eyes. Immediately wash them with running water.
Then consult a physician immediately. The eyes may be further damaged if not properly treated.
BWA_manual_USA_B_210916.indd 12BWA_manual_USA_B_210916.indd 12 2021-11-24 오전 9:58:302021-11-24 오전 9:58:30

12
13
• NE PAS installer les batteries avec les mains mouillées.
• NE PAS les utiliser à des fins autres que le fonctionnement du BWA2.0.
• Sortez les batteries de leur compartiment lorsqu'elles ne serviront pas pendant une longue période de temps.
• En cas de fuite, ne la touchez pas. Si le liquide se retrouve sur la peau ou les vêtements, lavez ceux-ci à l'eau courante.
• NE PAS permettre aux bornes de batteries de toucher à des fils de métal, des colliers, des chaînes, etc.
• Pour éviter des dommages ou un mauvais fonctionnement, NE PAS laisser tomber la batterie de haut.
Attention
f. NE PAS permettre aux conducteurs ou autres objets métalliques de court-circuiter les bornes de la batterie.
NE PAS transporter ou ranger la batterie avec d'autres objets métalliques, comme un collier.
g. NE PAS faire subir un choc ou une vibration mécanique à la batterie.
h. NE PAS écraser ni clouer la batterie.
i. NE PAS toucher la batterie avec les ongles ou autres objets coupants et évitez de la taper ou la frapper avec un marteau.
j. NE PAS souder directement les bornes des batteries.
k. NE PAS démonter la batterie d'aucune façon.
l. NE PAS charger la batterie en présence de flammes ou à des températures très élevées.
m. NE PAS placer des batteries au four à micro-ondes.
n. NE PAS utiliser les batteries si elles dégagent une odeur, chauffent, se déforment, changent de couleur ou présentent
d'autres anormalités. Retirez les batteries de l'appareil pour mettre fin à son utilisation ou son chargement.
o. Gardez les batteries hors la portée des enfants. Consultez un médecin immédiatement si un enfant avale une batterie.
p. Enlevez la batterie de l'appareil immédiatement en cas de fuite ou d'odeur de corps étranger.
q. Une fuite d'électrolyte peut causer un incendie ou une explosion.
r. Si la batterie fuit et que vous recevez de l'électrolyte dans les yeux, ne les frottez pas. Rincez les yeux à l'eau
courante puis consultez immédiatement un médecin. Un traitement inapproprié des yeux peut s'avérer dommageable.
• Do not install batteries with wet hands.
• Do not use the batteries for other purposes except the BWA2.0 operation.
• Remove the batteries from the battery compartment when not in use for a long period.
• Do not touch any leakage. If it gets on your skin or clothes, wash it off with running water.
• Do not connect the battery terminals to metal wires, necklaces, chains, etc.
• To avoid damage or malfunction, do not drop the battery.
• Do not disassemble the battery.
• If the terminals of the battery get dirty, clean the battery before using it.
• Otherwise, power loss or charging failure may occur by a loose battery contact.
• Do not use the battery if there are any abnormalities such as smell, deformation, discoloration, etc.
• If the battery goes underwater, it may malfunction. Do not use that battery.
• Do not use high temperature (over 60℃) packaging materials.
• Dispose of the batteries according to local regulations and guidelines.
• Improper using of batteries may cause the performance degradation of the BWA2.0 or a fire which may damage
the BWA2.0.
Caution
BWA_manual_USA_B_210916.indd 13BWA_manual_USA_B_210916.indd 13 2021-11-24 오전 9:58:302021-11-24 오전 9:58:30

14
15
14) The cart has wheels for easy transport. The wheels can be locked/unlocked as shown below.
15) Connect the power adapter to the power inlet on the right-side port of the BWA2.0. Connect the power cable to the
power adaptor.
* The BWA2.0 can be connected to optional test equipment and PC programs such as stadiometer, blood pressure monitor and
LookinBody120. For steps to connect, please refer to "Connecting External device" in this User's Manual.
Wheel unlocked Wheel locked
Terminal
Power inlet
• NE PAS démonter la batterie.
• Si les bornes de la batterie s'encrassent, nettoyez-la avant de vous en servir. Sinon, un mauvais contact peut
causer un manque de puissance ou un échec de chargement.
• NE PAS utiliser la batterie si elle présente une mauvaise odeur, une déformation, une décoloration ou autres
anormalités.
• Si la batterie se retrouve sous l'eau, elle pourrait mal fonctionner. NE PAS utiliser cette batterie.
• NE PAS utiliser des matériaux d'emballage dont la température dépasse 60℃).
• Débarrassez-vous des batteries conformément aux règlements et lignes directrices de votre localité.
• Une utilisation inappropriée des batteries peut nuire à la performance du BWA2.0. Un BWA2.0 endommagé
peut s'enflammer.
Grounded outlet
BWA_manual_USA_B_210916.indd 14BWA_manual_USA_B_210916.indd 14 2021-11-24 오전 9:58:312021-11-24 오전 9:58:31

14
15
• Do not install the equipment where the power cable is difficult to disconnect.
• Do not plug or disconnect the power cable with wet hands. Otherwise, it may cause an electric shock.
• Always use an outlet supplied to the right power supply (AC 100-240 V). Otherwise, it may cause a fire or
malfunction.
• When using a power surge protector, make sure that the outlet or the extension cable has adequate power capacity.
• Do not disassemble the equipment. This may cause electric shock or injury, product malfunction, and inaccurate
results, and it will not be covered by the manufacturer’s warranty.
• Do not directly connect the BWA2.0 with any other electronic device when the BWA2.0 is on. This may cause an
electric shock.
Warning
• NE PAS installer l'appareil là où le câble d'alimentation est difficile d'accès (pour brancher et débrancher).
• NE PAS brancher ou débrancher le câble d'alimentation avec les mains mouillées, et ce, pour éviter un choc électrique.
• Utilisez en tout temps une prise qui correspond à la bonne alimentation électrique (AC 100-240 V), et ce, pour éviter
un feu ou un mauvais fonctionnement.
• Si vous utilisez une prise multiple, soyez sûr que sa capacité est suffisante ou utilisez une rallonge.
• NE PAS démonter l'équipement n'importe comment, et ce, pour éviter des chocs électriques, des blessures, un
mauvais fonctionnement du produit ou des résultats inexacts. Dans un tel cas, l'équipement ne sera plus couvert par la
garantie du manufacturier.
• Lorsque le BWA2.0 est branché, il ne doit toucher à d'autres dispositifs électroniques, et ce, pour éviter de causer des
chocs électriques.
Avertissement
• Using the BWA2.0 in a dry environment or on a carpet may result in static electricity and damage to the
equipment. Use an antistatic mat if you need to install in such an environment.
• Install the BWA2.0 on a floor that is flat and vibration-free. If the equipment is installed where the floor is not
flat, the test results may be inaccurate.
• Do not clean the electrodes with detergent. If a liquid cleaner touches the electrode, it may cause corrosion and
equipment failure. For cleaning, use an InBody tissue (wet tissue) with an antibacterial agent.
• The equipment may be damaged by electrical shock and malfunction if it is plugged into an ungrounded outlet.
The test results may also be inaccurate.
• If the BWA2.0 is subjected to electrical interference, the test results may be inaccurate. Do not install the
BWA2.0 in proximity with fluorescent lights, large AC motor equipment such as treadmills, vibrators,
refrigerators, air conditioners, compressors, high-frequency heat treatment devices, and heating devices that
cause electrical interference. Unplug and plug them into different power outlets when the BWA2.0 and a device
that causes electrical interference are connected to the same power outlet.
• If you are connecting the BWA2.0 to another electrical device, then turn on the other device first. When turning
off the power, turn off the power of the BWA2.0 first, and then turn off the power of the other device. This can
minimize the electric shock from the BWA2.0.
• Use the adapter provided by InBody. The BWA2.0 may malfunction if using other adapters.
• Do not use the BWA2.0 near heat sources such as heating appliances. It may cause deformation, breakdown, or a fire.
• Use the BWA2.0 in a location where it is not exposed to direct sunlight. It may cause discoloration or damage
to equipment.
Caution
BWA_manual_USA_B_210916.indd 15BWA_manual_USA_B_210916.indd 15 2021-11-24 오전 9:58:312021-11-24 오전 9:58:31

16
17
16) Press the power button on the right-side of the BWA2.0 to turn it on.
• L'utilisation d'un BWA2.0 dans un environnement sec ou sur du tapis peut créer de l'électricité statique et
endommager l'équipement. Dans un environnement sujet à l'électricité statique, posez l'équipement sur un tapis
antistatique.
• Installez le BWA2.0 sur un plancher plat et sans vibrations. Si ce n'est pas le cas, les résultats de tests pourraient s'avérer
inexacts.
• Ne nettoyez pas les électrodes avec un détergent. Un produit nettoyant liquide qui coulent dans l'électrode peut
causer de la corrosion ou une défaillance de l'équipement. À des fins de nettoyage, utilisez d'une lingette
antibactérienne InBody (humide).
• Un équipement branché dans une prise sans terre peut causer un choc électrique ou une défaillance de
fonctionnement. Ainsi, les résultats risquent d'être inexacts.
• Si le BWA2.0 est soumis à des interférences électriques, les résultats des tests peuvent manquer de précision.
NE PAS installer le BWA2.0 près de lumières fluorescentes, de gros appareils dotés de moteurs à c.a. comme des
tapis roulant, des vibrateurs, des réfrigérateurs, des appareils de climatisation, des compresseurs, etc., des machines
de traitement thermique à haute fréquence ainsi que des systèmes de chauffage qui causent des interférences
électriques. Débranchez et rebranchez-les dans des prises différentes lorsque le BWA2.0 et un appareil qui cause de
l'interférence sont branchés dans la même prise.
• Si vous connectez le BWA2.0 à un autre appareil d'analyse, allumez l'autre appareil en premier. Dans le cas
contraire, fermez le courant du BWA2.0 en premier et ensuite celui de l'autre appareil, et ce, pour minimiser le choc
électrique que pourrait subir le BWA2.0.
• Utilisez l'adaptateur fourni par InBody. D'autres adaptateurs pourraient causer un mauvais fonctionnement du
BWA2.0.
• NE PAS utiliser le BWA2.0 proche de sources de chaleur comme les appareils de chauffage, et ce, pour prévenir
une déformation, une pannes ou un incendie.
• Faites fonctionner le BWA2.0 dans un endroit sans exposition directe aux rayons du soleil, et ce, pour éviter une
décoloration de l'équipement ou des dommages.
Attention
BWA_manual_USA_B_210916.indd 16BWA_manual_USA_B_210916.indd 16 2021-11-24 오전 9:58:312021-11-24 오전 9:58:31

16
17
* How to turn the Power On/o
Turning the power on: Press the Power button briey if the BWA2.0 has been turned o.
Turning the power o: Press and hold the Power button for about three seconds if the BWA2.0 has been turned on.
*Operation status according to the LED color of the Power button
LED color of the power button Operation status
Blue BWA2.0 is turning on.
Red The battery is plugged into the BWA2.0 with the power turned o, and the battery
is being charged with the adapter connected.
Green The battery is plugged into the BWA2.0 with the power turned o, and the battery is
completely charged with the adapter connected.
* Installing the Thermal Printer in the Cart
1. There is a part to connect the thermal printer on the rear of the BWA2.0.
2. Insert the thermal printer into the groove on the rear of the BWA2.0 and slide it down.
Hold the cart with one hand and push the thermal printer into the part to be xed.
• The thermal printer is sold separately.
Caution
• When you insert the thermal printer to the BWA2.0, do not place your hands or other body parts on the main unit and
the thermal printer fastening area. There is a risk of getting the hand or other body parts caught.
Caution
• L'imprimante thermique est vendue séparément.
Attention
• Lorsque vous insérez l'imprimante thermique dans le BWA2.0, ne placez ni les mains ni autres parties du corps sur
l'unité principale ou là où l'imprimante thermique s'attache, et ce, pour ne courir le risque de les coincer.
Attention
BWA_manual_USA_B_210916.indd 17BWA_manual_USA_B_210916.indd 17 2021-11-24 오전 9:58:312021-11-24 오전 9:58:31

18
19
3. Connect the BWA2.0 to the thermal printer with a thermal printer cable.
2. How to Install the Portable Bag
1) Open the box and take out the bag.
2) Put the BWA2.0, four clamps (or forceps) electrodes, two batteries, power cable, power adapter, thermal printer,
disposable electrode, and electrolyte tissue into the portable bag.
Power cable and
power adapter
Disposable electrode or
electrolytic tissue
Thermal printer
Clamp electrode(Left Arm)
Clamp electrode(Left Leg)
Forceps electrode
Clamp electrode(Righ tArm)
Clamp electrode(Right Leg)
Battery
BWA_manual_USA_B_210916.indd 18BWA_manual_USA_B_210916.indd 18 2021-11-24 오전 9:58:312021-11-24 오전 9:58:31
