InFocus mondopad User manual

Communicate and Collaborate Better than Ever
The giant touch PC to present, annotate, and collaborate
with people in the room and around the world

Giant Touch Tablet for Your Conference Room
or Classroom
Present, annotate and collaborate on a giant tablet with meeting
participants in the room and around the world.
An InFocus®Mondopad™puts everything you need to visually
present, capture and share ideas at your fingertips – all beautifully
integrated into a single, cost-effective device.
Mondopad streamlines meetings and allows people to
communicate clearly. You'll bridge communication gaps, save
time and money on travel, and never look back.
Key Features
Multi-touch high definition display in 55” and 70” sizes
Flexible and expandable with built-in Windows PC
Digital interactive whiteboard and document annotation
Business-class video conferencing
Share, view and control from your tablet or smartphone
Full copy of Microsoft®Office ensures file compatibility
Removable PC is interchangeable between 55" and 70"
models
Designed for Multi-touch
Mondopad’s natural, touch interface changes the way people interact
with information, collaborate and connect. Meetings are more engaging,
content is more immersive, and audiences are more involved.
The Mondopad features edge-to-edge 5-point multi-touch capabilities
that provide smooth, quick and accurate performance for all of its
presentation, annotation and collaboration applications.
Video Connect to the World
Add Mondopad as a SIP endpoint on your video conference server or
service, or install your video conferencing desktop client onto
Mondopad, just like you would a PC.
If you don't have a video conferencing system, we have an affordable
video conferencing solution from Vidtel.
Industry standard collaboration
tools like GoToMeeting®, WebEx™,
Microsoft Lync™and Adobe®
Connect™run seamlessly on a
Mondopad. It's as easy as
downloading an app.
55”
CCFL LCD
5-point touch
inf5520a
70”
LED edge-lit LCD
5-point touch
inf7021

Upgrade Your Conference Room
The Mondopad combines a powerful and flexible PC with a giant touch
display to create an elegant and cost effective collaboration solution.
Expandable to meet your
requirements
Built around industry
standards and leading
technologies from Intel and
Microsoft
Easy to upgrade to the latest
software and tools
Securely monitor and
manage from anywhere
Whiteboard Wizard
The Mondopad's whiteboard and collaboration apps make it easy to
brainstorm and capture and share the ideas.
A complete set of writing and
drawing tools, pens, highlighters,
shapes and lines are at your
command
Whiteboard drawings can be
collected, saved and emailed to
meeting participants right from
the Mondopad
Paste your backgrounds and images
onto a whiteboard session, such as a
grid, flowchart, or other template
Familiar Applications Optimized for Touch
Sharing documents and visuals during a meeting from any device is
amazingly easy with the Mondopad's intuitive folder structure and 3rd
party app multitasking.
Add, remove and launch documents from the Mondopad's View/Share
folder, which anyone in the meeting can access
Quickly switch between multiple Windows apps and the Mondopad app
Use all of the office documents (PowerPoint, Word, Excel, PDF, JPGs and
more) that you use every day -- all optimized for touch
Connect, Share, View & Control Content from Any Device
You and your colleagues can securely connect, share and collaborate with
anyone, anywhere – making your meetings more collaborative, productive
and sustainable.
Securely connect Mondopad to your network via its built-in WiFi so
any authorized user of your network can share, view and control their
visuals from their PC, tablet or smartphone
Mondopad's WiFi also creates a wireless access point so guests in the
room can easily deliver documents to Mondopad or access the
Internet without connecting to the organization’s private network
Remote participants see what's on the Mondopad via a web page
served by the Mondopad
Never Lose An Idea
Use the whiteboard's writing and drawing tools to take notes on what is
being presented on screen. This highly-visual medium allows your teams
to communicate more effectively, collaborate in real time, and never lose
an idea.
Circle or highlight key information
on PPT slides, spreadsheets,
design comps, web pages, and
even on shared content in a video
meeting
Identify information on-screen
to help remote participants
follow along
Capture and share the notes with
everyone in the meeting right from
the Mondopad
CNET Crave
The Mondopad's aim is to drain
the boring out of business meetings.
Full HD 1080p (1920 x 1080)
70”
55”

Optional Accessories
RealCam Pan/Tilt/Zoom Camera (INF-SPTZ)
Polycom Speakerphone Adapter and Cable
(INF-POLYCBLE)
Mondopad Virtual Training (INF-VT2, INF-VT4)
Wall Mount (INF-WALLMNT2)
Floor Stand (INF-FLRSTND)
Mobile Cart (INF-MOBCART)
Accessories Shelf for INF-MOBCART or
INF-FLRSTND (INF-ACCYSHELF)
Webcam Shelf for INF-MOBCART or
INF-FLRSTND (INF-VIDSHELF)
Pro Mobile Cart in Silver
(INF-MOBCARTPRO-S)
Pro Mobile Cart in Black (INF-MOBCARTPRO-B)
Accessories Shelf for Pro Mobile Cart in
Silver (INF-ACCYSHELFPRO-S)
Accessories Shelf for Pro Mobile Cart in
Black (INF-ACCYSHELFPRO-B)
USB to HDMI Adapter (HW-USB2HDMI)
Extended warranties
Specifications*
www.infocus.com
InFocus Corporate Headquarters
13190 SW 68th Parkway
Portland, Oregon 97223-8368, USA
Phone: [phone]
Toll Free: (1) 877-388-8385
Fax: [phone]
* Product specifications, terms, and offerings are subject to change at any time without notice.
** Keyboard, mouse and/or speaker bar may not be shipped to all countries.
©2013 InFocus Corporation. All rights reserved. Specifications are subject to change without further notice.
InFocus, The New Way to Collaborate and Mondopad are either trademarks or registered trademarks of InFocus
Corporation in the United States and other countries. All trademarks are used with permission or are for identification
purposes only and are the property of their respective companies.
InFocus_Mondopad_INF5520a_INF7021_Datasheet_EN_08OCT13.
inf5520a
inf5520a
inf7021
Size
Resolution
Refresh Rate
Viewing Angle
Technology
Display Colors
Pixel Pitch
Picture-in-Picture
Video Input Compatibility
Data Input Compatibility
Inputs
Outputs
Touch Screen
Speakers (Integrated)
Power
Mount
Display
55”
60 Hz
±89°
CCFL LCD
SBS/4 quadrant PiP
HDMI × 2, VGA (HD15 VESA), Component, S-Video,
Composite, RS232, RCA stereo audio × 2, 3.5 mm stereo
mini-jack, USB Type-B to touch screen controller board
RCA stereo audio output for sound bar or other external
A/V system
VESA MIS-F, 400 × 400 mm, M6 screws
70”
120 Hz
±176°
LED edge-lit LCD
N/A
HDMI x 2, VGA (HD15 VESA), 3.5mm stereo mini-jack,
RCA stereo audio in, 3.5mm stereo audio in,
USB Type-B to touch screen controller board
RCA audio stereo (L/R) output, 3.5mm stereo mini jack out
for sound bar
VESA standard 400 x 400mm, M6 screws
Full HD 1920 × 1080
1.07G (10-bit)
0.63 mm
Full NTSC (INF5520 only), 480i, 480p, 720p, 1080i, 1080p/24, 1080p/30, 1080p/60
VGA (640×480), SVGA (800×600), XGA (1024×768), SXGA (1280×1024), SXGA+ (1400×1050), UXGA (1600×1200),
WXGA+ (1440×900), WSXGA+ (1680×1050), WXGA (1280×800), WUXGA (1920×1200)
Edge-to-edge quad camera multi-touch system with support for 5 point gestures and Windows 8
Stereo 7W × 2
AC 100 to 240V, 50/60Hz
inf7021
Processor
Memory
Hard Drive
LAN (2×)
Wi-Fi
Input Connections
Output Connections
Operating System
Included Software
PC
USB Type-A × 6 (4 on side of display,
2 on PC (1 used by camera)), Ethernet (RJ45 × 2)
USB Type-A x 7 (4 on side of display, 1 on top of display
(used by camera), 2 on PC), Ethernet (RJ45 × 2)
Intel®Core i5-2520m, QM67 chipset with support for AMT 7.1
4 GB of DDR3
SSD 120GB
802.3 10/100/1000 Base-T with Wake on LAN
Dual band 802.11 a/b/g/n MIMO PCIe half mini card, 2.4 GHz with Intel, AMT support
Optional USB 2.0 to HDMI adapter (for display out)
Windows 7 Pro 64bit, compatible with Windows 8
Microsoft Office Home & Business 32bit, Mondopad interface software
Camera
Resolution: 1280 × 720
Frame rate: 22 fps at HD with H.264+YUV (2-way)
Lens and Field ofView: F/2.0, 3P Lens; FOV(D) 56.8° in HD mode, FOV(D) 50° in
VGA mode 1.0× zoom, FOV(D) 30° in VGA mode 1.6× zoom
Audiosupport: 4 built-in Unidirectional microphones
Interface: USB 2.0 High Speed
Focus: Auto focus
Tilt: Manual up/down and left/right ±40°
Power via USB
Soundbar
Power: 100 – 240voltsAC, 50 – 60Hz
Speaker Drivers (L&RChannel):Two 3" and one 3/4" Aluminum Neodymium
Tweeter (per side)
Power Output (RMS): 25 watts/channel @ 1% THD, 1KHz, 2-channels drive, 70
watts total system PEAK
Frequency Response: 90 Hzto 20 KHz
System INF5520a INF7021
Product Weight 134.4 lbs / 61 kg 170 lbs / 77.1 kg
Shipping Weight
(monitor, PC & camera) 136 lbs / 61.7 kg 173 lbs / 78.5 kg
(sound bar) 14.3 lbs / 6.5 kg 17.4 lbs / 7.9 kg
(feet) 9.3 lbs / 4.2 kg Not included
Product Dimensions (W x D x H)
INF5520a: 53 x 5.5 x 38.3 in / 1346 x 140 x 973 mm
INF7021: 65.7 x 4 x 45 in / 1669 x 102 x 1143 mm
Shipping Dimensions: INF5520a
Monitor, PC& camera: 58.7 x 13.9 x 38.4 in / 1490 x 352 x 975 mm
Sound bar: 57.5 x 7.1 x 5.7 in / 1430 x 180 x 145 mm
Feet: 22.1 x 5.3 x 15.9 in / 560 x 135 x 405 mm
Shipping Dimensions: INF7021
Monitor, PC& camera: 73 x 10.5 x 49 in / 1854 x 267 x 1245 mm
Sound bar: 30.4 x 12.3 x 6.7 in / 772 x 313 x 169 mm
Accessories Included**: Wireless keyboard (where allowed), wireless mouse
(where allowed), stylus,VGA cable, USB cable, security screws, security screw
removal tool, power cord, remote, quick setup guide, sound bar assembly,
camera assembly, foot assembly (feet not inlcuded with INF7021)
Warranty: 1 year limited, extended warranties available
Operating Temperature: 41 to 95°F at 0 to 10K ft/ 5 to 35°C at 0 to 3,048 m
Noise: <40dBA @ 77°F / 25°C
EnergyStar: 5.1 for display and PC
Approvals for INF5520a: UnitedStates (FCC, UL), Europe (CE),Australia (RCM),
Brazil (ANATEL),Canada (IC, FCC, cUL), Chile (SUBTEL), China (CCC,CMIT),
Columbia,Costa Rica, India (WPC), Indonesia (PLG), Malaysia (SIRM), Mexico
(NOM, SCT, Energy Consumption label), New Zealand (C-tick), Panama, Peru
(MTC), Puerto Rico (FCC, UL),SaudiArabia (SASO,CITC), Singapore (PSB, IDA),
Taiwan (BMSI, NCC), United Arab Emirates (TRA)
Approvals for INF7021: United States (FCC)
Interface Languages: English, German, French, Italian,Spanish, Simplified
Chinese, TraditionalChinese, Korean, Vietnamese, Japanese, Malay, Bahasa
