INIM Electronics OTT100H Assembly instructions

1
Installation and programming manual
OTT100H
Triple technology detector for outdoor use
Installation and programming manual

2
OTT100H
Table of
contents
1 General information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1-1 About this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
1-2 Manufacturer's details. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
1-3 Description of the product. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
1-4 Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2 Functioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2-1 Detection range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2-2 Operating principles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2-3 “Antimasking” function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2-4 LEDs enabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
3 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3-1 Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
3-2 Mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4 Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5 Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6 Maintenance and periodic checks . . . . . . . . . . . . . . . . . . . 10
7 Disposal and scrapping . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Simplified EU Declaration of Conformity. . . . . . . . . . . . . . . 11
Copyright The information contained in this document is the sole property of INIM
Electronics s.r.l. No part may be copied without written authorization from INIM
Electronics s.r.l.
All rights reserved.
WEEE Informative notice regarding the disposal of electrical and electronic
equipment (applicable in countries with differentiated waste collection
systems)
The crossed-out bin symbol on the equipment or on its packaging indicates that
the product must be disposed of correctly at the end of its working life and should
never be disposed of together with general household waste.
The user, therefore, must take the equipment that has reached the end of its
working life to the appropriate civic amenities site designated to the differentiated
collection of electrical and electronic waste.
As an alternative to the autonomous-management of electrical and electronic
waste, you can hand over the equipment you wish to dispose of to a dealer when
purchasing new equipment of the same type. You are also entitled to convey for
disposal small electronic-waste products with dimensions of less than 25cm to the
premises of electronic retail outlets with sales areas of at least 400m2, free of
charge and without any obligation to buy.
Appropriate differentiated waste collection for the subsequent recycling of the
discarded equipment, its treatment and its environmentally compatible disposal
helps to avoid possible negative effects on the environment and on health and
favours the re-use and/or recycling of the materials it is made of.

General information 3
Installation and programming manual
1 GENERAL INFORMATION
1-1
About this manual
DESCRIPTION T riple technology detector for outdoor use ( I N01) installation manual
MANUAL CODE DCMIINIEOTT100H
VERSION 1.30
1-2 Manufacturer's details
Manufacturer: INIM ELECTRONICS S.R.L.
Production plant: Centobuchi, via Dei Lavoratori 10
63076, Monteprandone (AP), Italy
Tel.: [phone]
Fax: [phone]
e-mail: [email protected]
Web: www.inim.biz
The persons authorized by the manufacturer to repair or replace the parts of this
system, hold authorization to work on INIM Electronics brand devices only.
1-3 Description of the product
• Triple technology detector for outdoor use
• Two PIR and one microwave (MW) programmable sensors
• MW frequency 24GHz
• Low consumption infrared sensors double element with UV filter
• Programmable infrared sensitivity
• Low PIR beam precision adjustment (patented system)
• AND/OR selectable function
• Mechanism for horizontal coverage adjustment
• UV rays resistant Fresnel lens
• UV resistant polycarbonate case
• Stainless steel wall fixing bracket
• Stainless steel pole fixing brackets (available on request)
• 4 signalling LEDs
• Active infrared anti-masking (two pairs protection for each lens portion)
• Anti solar blinding through mechanical with high efficiency filters
• “Test” function to signalling each alarm by LED blinking; auto power off after 4
minutes
• Anti-tamper and anti-dislodgement system

4General information
OTT100H
I
Table 1: OTT100H technical features
Power-supply from 9 to 15 V
Maximum current 20mA
Microwave frequency K band
Maximum RF output power <17 mW e.i.r.p. (12.31 dBm)
Detection range from 3 to 18m
Horizontal coverage angle 85°
Horizontal coverage adjustment +/- 45°
Alarm, masking contacts
MOS FET relay 100 mA 35 V,
2 Ohm max.
Alarm time 1 s
Antimasking 2 levels active IR
IP protection degree IP44
Security grade 3
Environmental class IV
Working temperature from -25° to 55°C
Dimensions 189x81x70 mm
Weight (with wall fixing bracket) 370g
Table 2: Mechanical parts description
A “U” shaped bracket
B
Stainless steel wall
fixing bracket
C Electronic holder
D
Cover with Fresnel
lens
E
Lower PIR range
adjustment knob
F
Anti tamper
microswitch
G
Electronics and sen-
sors
H
Wall fixing bracket
enclosure screw
I
Cover enclosure
screw
J
External screw for
“U” brackets fixing
K
Inner screw for “U”
brackets fixing
A
B
C
D
A
G
I
E
F
H
J
K
J
K

General information 5
Installation and programming manual
1-4 Package contents
Inside the package you will find:
• OTT100H detector
• Stainless steel wall fixing bracket
• Installing manual (this)
• Plastic bag containing:
•• 2 stainless steel metric screw M3 x 8
•• 2 anchor screws and plugs for wall mounting
“U” shaped brackets are not included in the package (accessory items to be
purchased separately).
Table 3: Electronic part description
L Terminal board for wire connection
M Red LED 1 for general alarm
N Yellow LED 2 for MW
O
Green LED 3 for higher PIR detec-
tion
P
Green LED 4 for lower PIR detec-
tion
Q
Microwave sensitivity adjustment
trimmer
R Higher infrared sensor (PIR 1)
S Lower infrared sensor (PIR 2)
T DIP switches
U Anti-masking LED
V PIR 2 marked positions
Table 4: Terminal board
POWER
+Power supply 12 V
(from 10 to 15 V)
-
MASK NC Anti-mask output Normally closed contact in
standby
TAMPER NC 24 h anti tamper output
ALARM NC Alarm output
L
R
S
M
O
P N
T
Q
E
V
U
U

6Functioning
OTT100H
2 FUNCTIONING
2-1 Detection range
ADJUSTMENT Use the trimmer “MW” (table 3, Q) to adjust the microwave sensitivity (the
sensitivity is increased turning it clockwise).
Adjust the microwave sensibility in relationship to the needed detection range.
By using the knob (table 2, E) it is possible to move the PIR2 (lower) in order to
obtain different ranges from 3m to 18m.
The knob moves vertically the RIP along the marked positions on the holder (table
3, V). Each position corresponds to a distance:
These distances are reached when the detector is installed at about 120cm
(height).
If the object in motion is very large (for example a car) there is possibility that the
detector can detect its presence even if it's farther than 18 m.
2-2 Operating principles
The detector works on the combined action of two PIRs and a microwave sensors.
The figures below shows some of most relevant working examples.
Table 5: Top view
A
Zones that can not be
covered
B
Zones that can be
covered by electronic
holder rotation
170°
85°
B
A
B
A
Table 6: Side view
PIR2
position Distance
A
3 m
B 5 m
C 8 m
D 16 m
E 18 m
1.2m
3m 5m 8m 16m 18m
EA

Functioning 7
Installation and programming manual
2-3 “Antimasking” function
The detector is equipped with an active IR anti-masking function to protect the
PIR. It emits a tampering signal within 3 minutes. The output of this function is
the MASK terminal block.
In a standard configuration, this terminal block can be connected to a 24h active
line or to a control unit input appropriately programmed to send fault messages.
When the detector identifies a masking attempt, the four LEDs flash
simultaneously until the masking condition is resolved.
To enable the correct operation of the masking detection system (Anti-masking),
allow the detector to study and analyse the environmental conditions of the area
to be protected. This procedure is mandatory to guarantee the correct operation
of the anti-masking channel.
Anti-masking sensitivity can be adjusted trough the DIP switch 5 (table 3, T):
• “OFF”, low sensitivity
• “ON”, high sensitivity
Follow the procedure below:
1. Make the connections to the detector terminal box, leaving the DIP switch 5
set to OFF.
2. Once powered, close the cover and run all the detection tests required.
3. Open the cover and set the anti-masking sensitivity via the DIP switch 5.
4. Close the cover immediately (maximum within 10 seconds).
5. Stay at least 1 meter from the front part of the detector for at least 4 min-
utes.
Table 7: Working examples
A Detector
B Protected area limit
C The pet is detected only by two of the three sensors (lower PIR and MW). No alarm
D The person is detected by all three sensors (upper PIR, lower PIR, MW). Alarm
E The person is detected by two sensors (upper PIR and MW). No alarm
F
If the detector is installed on a tilted wall, or pole, the detection range will be
reduced.
Both, upward as downward.
Uncorrected installation
No alarm
D EC B
A
E B
F

8Installation
OTT100H
2-4 LEDs enabling
LED signalling activations can be enabled via the DIP switch 6 (table 3, T):
• OFF set - LEDs enabled
• ON set - LED disabled
3 INSTALLATION
WARNING • The wall does not have any pronounced depressions or protrusions.
• Install the detector on rigid surfaces, free of vibrations.
• Avoid to fix the detectors near to heat sources or at direct sunlight.
• Avoid electromagnetic energy reflection on wide surfaces such as mirrors, metal
walls, etc.
• Avoid to fix the detector in front of fluorescent lamps or in proximity of them.
• Connections shielded cable is suggested and one cable per detector is preferred.
• Separate the alarm system cables from the mains cables.
The detector can be installed outdoors (according to the Class IV EN 50131-1).
• Avoid to direct the detector towards moving objects or, if impossible, please take
care in adjusting the detector in order to avoid false alarms.
• Be sure to install the cover with Fresnel lens before the detector testing. Without
cover, the detector doesn't work.
3-1 Placement
Environmental conditions are important elements to be evaluated during the
installation. Bump, bottomland or slops can modify the performances of the
detector.
If into the detection area any medium size animal can walk, it is suggested to
choose carefully the installation height in order to avoid false alarms.
Installation height must be between 1 m and 1.30 m (not tilted ground).
Note The maximum coverage range, 18m, is reached when the detector is installed at
about 120cm (height).
Do not obscure partially or completely the detector’s field of view.
COVERAGE TESTS Once the detector has been powered, wait 3-4 minutes before running the
coverage test (the IR sensors need to be stabilised).
In order to obtain a real simulation, free the protected area, preventing more
people from moving inside the same area.
After 30-40 seconds of quiet, try to access the detection area by moving
perpendicularly to the beams, thus avoiding a frontal approach.
Check the operation of the two PIRs with the two green LEDs and the operation of
the microwave with the yellow LED.
Run the operation test, making sure to break the IR beams (table 5 "Top view" e
table 6 "Side view") by moving perpendicularly to them.
Once detection has been achieved, wait for at least 7-8 seconds before trying to
be detected again.
3-2 Mounting
1. Unscrew the screw for the cover enclosure (table 2, I).
2. Remove the cover with lens (table 2, D).
3. Set up for the steel bracket fixing (table 2, B) on the wall, or on a pole (be
sure the pole is stable and ripple free).
POLE FIXING 4. Position the two “U” (table 2, A) shaped bracket around the pole.

Programming 9
Installation and programming manual
5. Block them with the inner screws (table 2, K) and the external screws (table
2, J).
WALL FIXING 4. Perforate the wall in correspondence of the holes on the casing.
5. Insert the wall plugs into the holes.
6. Pull the wires through the wire entry on the steel bracket.
7. Fix the steel bracket on the wall or on the pole.
Note Fix the metallic support on the wall perpendicularly to the ground.
8. Pull the wires trough the entry on the electronic holder (table 2, C). Perfo-
rate the cable passage knockout using a sharp point tool, as a screwdriver
or similar.
9. Screw up the detector on the support using the 2 provided screws (table 2,
H).
10. Connect the wires to the terminals (table 3, L).
11. Run the range settings (PIR 2 position adjustment, MW sensitivity, PIRs
sensitivity). See paragraph 2-1 Detection range.
12. Close the detector with the front cover with Fresnel lens as shown opposite.
13. Screw up the metric screw (table 2, I).
4 PROGRAMMING
In order to make the detector suitable for outdoor applications, a single sensor
adjustment system has been implemented.
In the tables below are shown the DIP switch configurations (table 3, T):
If the detector is set in triple AND (DIP 3 and DIP 4 in OFF position) configuration,
the maximum distance of detection is the one setted through the Adjustment of
the PIR2.
Table 8: Infrared sensitivity adjustment
DIP 1
OFF ON
DIP 2 OFF
High sensitivity Medium-high sensitivity
ON Medium-low sensitivity Low sensitivity
Table 9: Sensor programming
DIP 3
OFF ON
DIP 4
OFF
PIR 1 AND PIR 2 AND MW PIR 1 AND PIR 2
Alarm output active only when all three
technologies detect the presence.
It can be used in most outdoor installations.
Alarm output active when both PIRs detect a
presence.
The MW is not managed. The detection of
the MW does not affect the performance of
the detector.
ON
(PIR 1 OR PIR 2) AND MW PIR 1 AND MW (PIR 2 bypassed)
Output alarm active when the MW and one
of the two PIR detect a presence.
Not recommended in particularly hostile
environments.
Alarm output active when PIR 1 and the MW
detect a presence.
Not recommended in particularly hostile
environments.
Table 10: Antimasking and LEDs
OFF ON
DIP 5 Low anti-masking sensitivity High anti-masking sensitivity
DIP 6 LEDs enabled LEDs disabled

10 Trouble shooting
OTT100H
5 TROUBLE SHOOTING
6 MAINTENANCE AND
PERIODIC CHECKS
Keep the lens clean to guarantee proper operation of the detector.
A lens which is not perfectly clean may cause detection problems and/or problems
to the anti-mask function.
The cleaning must be done when necessary or when clearly dirty.
CLEANING
PROCEDURE
Clean the lid and the lens with a cloth dampened with water.
Wipe with a dry cloth.
ATTENTION! Do not use chlorine-based or abrasive products or alcohol to remove particularly
noticeable dirt.
7 DISPOSAL AND
SCRAPPING
DISMANTLING 1. Unscrew the screws that fasten the front lid and remove it.
2. Disconnect the detector; disconnect all the terminals on the terminal block.
3. Divide the parts by type and dispose of them in accordance with applicable
laws.
ATTENTION! Do not dispose of the components or any other product material in the
environment.
Seek the assistance of companies authorised to dispose of and recycle waste
materials.
Table 11: Possible solutions
Trouble Solution
LEDs fail to switch on Check wiring connection. Check the presence of current and if the voltage is between 9.5 and 16 V.
Make sure that DIP switch 6 is set to OFF.
False alarms
The detector is not perpendicular to the ground.
Check if the lower detection area is wider than your planning.
Check if there are objects in movement in the detection area.
MW adjustment is set at maximum level.
No detection, sometimes The lower PIR is not properly adjusted.
MW adjustment is set at minimum level.
Continuous alarms of
MASK output
Medium-sized obstacles close to the detector.
Open the cover, disconnect the detector (wait about 5 seconds), re-power and close
the cover immediately (within 10 seconds), go out of range for 4 minutes.
Red LED blinking Verify that the detector’s power supply.

Simplified EU Declaration of Conformity 11
Installation and programming manual
SIMPLIFIED EU DECLARATION
OF CONFORMITY
Hereby, INIM ELECTRONICS S.R.L. declares that the radio equipment type
OTT100H is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following
internet address: www.inim.biz.
BG : ǹȕȈșȚȖȧȡȖȚȖ INIM ELECTRONICS S.R.L. ȌȍȒȓȈȘȐȘȈ, ȟȍ ȚȖȏȐ ȚȐȗ ȘȈȌȐȖșȢȖȘȢȎȍȕȐȍ OTT100H ȍȊșȢȖȚȊȍȚșȚȊȐȍ șǬȐȘȍȒȚȐȊȈ
2014/53/ǭǹ.
ǾȧȓȖșȚȕȐȧȚ ȚȍȒșȚ ȕȈ ǭǹ ȌȍȒȓȈȘȈȞȐȧȚȈ ȏȈ șȢȖȚȊȍȚșȚȊȐȍ ȔȖȎȍ ȌȈ șȍ ȕȈȔȍȘȐ ȕȈ șȓȍȌȕȐȧ ȐȕȚȍȘȕȍȚ ȈȌȘȍș: www.inim.biz
CS : Tímto INIM ELECTRONICS S.R.L. prohlašuje, že typ rádiového zaĜízení OTT100H je v souladu se smČrnicí 2014/53/EU.
Úplné znČní EU prohlášení o shodČje k dispozici na této internetové adrese: www.inim.biz
DA : Hermed erklærer INIM ELECTRONICS S.R.L., at radioudstyrstypen OTT100H er i overensstemmelse med direktiv 2014/53/EU.
EU-overensstemmelseserklæringens fulde tekst kan findes på følgende internetadresse: www.inim.biz
DE : Hiermit erklärt INIM ELECTRONICS S.R.L., dass der Funkanlagentyp OTT100H der Richtlinie 2014/53/EU entspricht.
Der vollständige Text der EU-Konformitätserklärung ist unter der folgenden Internetadresse verfügbar: www.inim.biz
ET : Käesolevaga deklareerib INIM ELECTRONICS S.R.L., et käesolev raadioseadme tüüp OTT100H vastab direktiivi 2014/53/EL
nõuetele.
ELi vastavusdeklaratsiooni täielik tekst on kättesaadav järgmisel internetiaadressil: www.inim.biz
EL : ưİ IJdžnj ȺĮǏǎǘıĮ ǎ/džINIM ELECTRONICS S.R.L., įdžNJǙnjİLj ǗIJLj ǎǏĮįLjǎİǍǎȺNJLjıNjǗǐ OTT100H ȺNJdžǏǎǁ IJdžnj ǎįdžDŽǁĮ 2014/53/ƪƪ.
Ʒǎ ȺNJǀǏİǐ ljİǁNjİnjǎ IJdžǐ įǀNJǔıdžǐ ıǑNjNjǗǏijǔıdžǐ ƪƪ įLjĮIJǁLJİIJĮLj ıIJdžnj ĮljǗNJǎǑLJdž LjıIJǎıİNJǁįĮ ıIJǎ įLjĮįǁljIJǑǎ: www.inim.biz
ES : Por la presente, INIM ELECTRONICS S.R.L. declara que el tipo de equipo radioeléctrico OTT100H es conforme con la Directiva
2014/53/UE.
El texto completo de la declaración UE de conformidad está disponible en la dirección Internet siguiente: www.inim.biz
FI : INIM ELECTRONICS S.R.L. vakuuttaa, että radiolaitetyyppi OTT100H on direktiivin 2014/53/EU mukainen.
EU-vaatimustenmukaisuusvakuutuksen täysimittainen teksti on saatavilla seuraavassa internetosoitteessa: www.inim.biz
FR : Le soussigné, INIM ELECTRONICS S.R.L., déclare que l'équipement radioélectrique du type OTT100H est conforme à la directive
2014/53/UE.
Le texte complet de la déclaration UE de conformité est disponible à l'adresse internet suivante: www.inim.biz
HR : INIM ELECTRONICS S.R.L. ovime izjavljuje da je radijska oprema tipa OTT100H u skladu s Direktivom 2014/53/EU.
Cjeloviti tekst EU izjave o sukladnosti dostupan je na sljedeüoj internetskoj adresi: www.inim.biz
HU : INIM ELECTRONICS S.R.L. igazolja, hogy a OTT100H típusú rádióberendezés megfelel a 2014/53/EU irányelvnek.
Az EU-megfelelĘségi nyilatkozat teljes szövege elérhetĘa következĘinternetes címen: www.inim.biz
LT : Aš, INIM ELECTRONICS S.R.L., patvirtinu, kad radijo šrenginižtipas OTT100H atitinka Direktyvą2014/53/ES.
Visas ES atitikties deklaracijos tekstas prieinamas šiuo interneto adresu: www.inim.biz
LV : Ar šo INIM ELECTRONICS S.R.L. deklarŋ, ka radioiekŅrta OTT100H atbilst Direktŝvai 2014/53/ES.
Pilns ES atbilstŝbas deklarŅcijas teksts ir pieejams šŅdŅinterneta vietnŋ: www.inim.biz
MT : B'dan, INIM ELECTRONICS S.R.L., niddikjara li dan it-tip ta' tagřmir tar-radju OTT100H huwa konformi mad-Direttiva 2014/53/
UE.
It-test kollu tad-dikjarazzjoni ta' konformità tal-UE huwa disponibbli f'dan l-indirizz tal-Internet li œej: www.inim.biz
NL : Hierbij verklaar ik, INIM ELECTRONICS S.R.L., dat het type radioapparatuur OTT100H conform is met Richtlijn 2014/53/EU.
De volledige tekst van de EU-conformiteitsverklaring kan worden geraadpleegd op het volgende internetadres: www.inim.biz
PL : INIM ELECTRONICS S.R.L. niniejszym oĞwiadcza, Īe typ urządzenia radiowego OTT100H jest zgodny z dyrektywą2014/53/UE.
Peány tekst deklaracji zgodnoĞci UE jest dostĊpny pod nastĊpującym adresem internetowym: www.inim.biz
PT : O(a) abaixo assinado(a) INIM ELECTRONICS S.R.L. declara que o presente tipo de equipamento de rádio OTT100H está em
conformidade com a Diretiva 2014/53/UE.
O texto integral da declaração de conformidade está disponível no seguinte endereço de Internet: www.inim.biz
RO : Prin prezenta, INIM ELECTRONICS S.R.L. declarăcătipul de echipamente radio OTT100H este în conformitate cu Directiva
2014/53/UE.
Textul integral al declaraΌiei UE de conformitate este disponibil la următoarea adresăinternet: www.inim.biz
SK : INIM ELECTRONICS S.R.L. týmto vyhlasuje, že rádiové zariadenie typu OTT100H je v súlade so smernicou 2014/53/EÚ.
Úplné EÚ vyhlásenie o zhode je k dispozícii na tejto internetovej adrese: www.inim.biz
SL : INIM ELECTRONICS S.R.L. potrjuje, da je tip radijske opreme OTT100H skladen z Direktivo 2014/53/EU.
Celotno besedilo izjave EU o skladnosti je na voljo na naslednjem spletnem naslovu: www.inim.biz
SV : Härmed försäkrar INIM ELECTRONICS S.R.L. att denna typ av radioutrustning OTT100H överensstämmer med direktiv 2014/53/
EU. Den fullständiga texten till EU-försäkran om överensstämmelse finns på följande webbadress: www.inim.biz

12 Simplified EU Declaration of Conformity
OTT100H
Centobuchi, via Dei Lavoratori 10
63076 Monteprandone (AP) Italy
Tel. [phone] _ Fax [phone]
[email protected] _ www.inim.biz
