INIM PREVIDIA COMPACT User manual

Installation manual
1

INSTALLATION MANUAL
EN 54-2
EN 54-4
EN 54-21
EN 12094-1
ANALOG-ADDRESSABLE FIRE ALARM CONTROL PANEL,
EXTINGUISHANT SYSTEM CONTROL PANEL,
ALARM TRANSMISSION AND FAULT WARNING ROUTING EQUIPMENT
0051
0051-CPR-1498
0051-CPR-1499

2Warranty
Fire detection and extinguishant system
Warranty
INIM Electronics s.r.l. (Seller, Our, Us) warrants the original purchaser that this product shall be free from defects in
materials and workmanship under normal use for a period of 24 months. As INIM Electronics s.r.l. does not install this
product directly, and due to the possibility that it may be used with other equipment not approved by Us; INIM
Electronics s.r.l. does not warrant against loss of quality, degradation of performance of this product or actual damage
that results from the use of products, parts or other replaceable items (such as consumables) that are neither made nor
recommended by INIM Electronics. Seller obligation and liability under this warranty is expressly limited to repairing or
replacing, at Seller's option, any product not meeting the specifications. In no event shall INIM Electronics s.r.l. be liable
to the purchaser or any other person for any loss or damage whether direct of indirect or consequential or incidental,
including without limitation, any damages for lost profits, stolen goods, or claims by any other party caused by defective
products or otherwise arising from the incorrect or otherwise improper installation or use of this product.
This warranty applies only to defects in parts and workmanship relating to normal use. It does not cover:
• damage arising from improper maintenance or negligence
• damage caused by fire, flood, wind or lightning
• vandalism
• fair wear and tear
IINIM Electronics s.r.l. shall, at its option, repair or replace any defective products. Improper use, that is, use for purposes
other than those mentioned in this manual will void the warranty. Contact Our authorized dealer, or visit our website for
further information regarding this warranty.
Limited warranty
INIM Electronics s.r.l. shall not be liable to the purchaser or any other person for damage arising from improper storage,
handling or use of this product.
Installation of this Product must be carried out by qualified persons appointed by INIM Electronics. Installation of this
Product must be carried out in accordance with Our instructions in the product manual.
Copyright
The information contained in this document is the sole property of INIM Electronics s.r.l.
No part may be copied without written authorization from INIM Electronics s.r.l.
All rights reserved.

Installation manual
Table of contents 3
Table of contents
Warranty.......................................................................................................................... 2
Limited warranty........................................................................................................... 2
Copyright........................................................................................................................ 2
Table of contents .........................................................................................................3
Chapter 1 General information ....................................................................................................5
1.1 Manufacturer's details .....................................................................................................................5
1.2 Supplied Documentation...............................................................................................................5
1.3 About this manual............................................................................................................................5
1.4 Operator classification - Access Levels ......................................................................................6
1.5 CE Mark...............................................................................................................................................6
Chapter 2 General description .....................................................................................................8
2.1 Previdia Compact Models..............................................................................................................8
2.2 Control panel descriptions ............................................................................................................8
2.3 Fire Extinction..................................................................................................................................12
2.4 Previdia-C-DIAL, telephone line Communicator module ...................................................15
2.5 Previdia Compact REP Repeater................................................................................................16
2.6 Control panels in a Hornet+ network ...................................................................................... 17
2.7 Control Panels in an IP network................................................................................................. 17
Chapter 3 Installation ....................................................................................................................18
3.1 Mounting the control panel to the wall ...................................................................................18
3.2 Mounting the PREVIDIA-C-DIAL communicator module ...................................................19
3.3 Control panel wiring......................................................................................................................19
3.4 Connecting the “I/O” terminals ..................................................................................................21
3.5 Relay output wiring....................................................................................................................... 23
3.6 Loop connections......................................................................................................................... 24
3.7 Connecting the Hornet+ network............................................................................................ 25
3.8 Connecting the land-line (PSTN) ..............................................................................................25
3.9 Wiring the external communicators ........................................................................................ 26
System test...................................................................................................................27
Replacement and disposal of used devices........................................................27
WEEE .............................................................................................................................27

4Table of contents
Fire detection and extinguishant system

Installation manual
General information 5
Chapter 1
General information
1.1 Manufacturer's details
Manufacturer: INIM ELECTRONICS s.r.l
Production plant: Centobuchi, via Dei Lavoratori 10
Comune: 63076, Monteprandone (AP), Italy
Tel.: [phone]
Fax: [phone]
E-mail: [e-mail]
Web: www.inim.biz
The persons authorized by the manufacturer to repair or replace the parts of this system, hold authorization to work on
INIM Electronics brand devices only.
1.2 Supplied Documentation
Previdia Compact User's Manual: contains the identification of the parts on the front plate and the end-user operating
instructions for use.
Previdia Compact Installation Manual: contains the technical specifications of the system components, the
description of the system applications and use, instructions for the installation of the system components with wiring
instructions complete with wiring diagrams for the various modules. contains the instructions for system commissioning.
Manual for system configuration, commissioning and maintenance: contains the instructions for system
commissioning and the operations to be carried out during commissioning, maintenance and troubleshooting sessions.
Guide to Networking: contains instructions for the connection of Previdia control panels in a Hornet network or via IP,
with the description of the system limits and responsibilities relating to network use.
BMS Manual: provides the installer with the guidelines relating to the integration of Previdia control panels with external
supervision systems.
The manuals which are not supplied with the apparatus can be ordered using their respective codes, or downloaded
from www.inim.biz.
1.3 About this manual
Manual code: DCMIINE0PREVIDIAC
Version: 1.10
1.3.1 Graphic conventions
Following are the graphic conventions used in this manual.
Conventions Example Description
Text in italics
Refer to paragraph
1.3.1 Graphic
conventions
Indicates the title of a chapter, section,
paragraph, table or figure in this manual or
other published reference.
[Uppercase letter] or
[number] [A] or [1] Reference relating to a part of the system or video object.

6General information
Fire detection and extinguishant system
Note: The notes contain important information relating to the text.
Attention: The “Attention” prompts indicate that total or partial disregard of the procedure could damage the
device or its peripherals.
EN54: Such indications indicate that the information and instructions refer to European standards.
Cables: Such indications state the types and specifications of the
cables which must be used for the wiring in accordance
with the manufacturer's advice or the standard concerned.
1.4 Operator classification - Access Levels
The control panel has 4 distinct access levels:
Level 1: Public level - this is the normal access level of the control panel and is the access level for building inhabitants
who are neither authorized to use the system nor instructed in its use.
This level allows building inhabitants to view information on the screen and signalling LEDs, interact with the system (in
accordance with Level 1) and scroll through the information by means of the buttons and touchscreen. Level 1 allows the
following operations only:
• mute buzzer
• test signalling LEDs
• activate alarm signalling when an early-warning process is running
Level 2: Authorized users - this access level is for the system supervisors and is for authorized personnel who are
adequately instructed in the use of the system and its functions.
Access requires the use of a key or entry of a valid access code with sufficient access rights. In addition to the operations
described for level 1 it is also possible to carry out the following operations:
• mute alarm signalling devices
• rearm the control panel
• activate alarm signalling devices manually
• disable control panel elements
• place in test status one or more of the system elements
Level 3: Programming - this access level is for specialized technical operators who carry out system configuration,
commissioning and maintenance.
Access requires entry of a valid access code with sufficient access rights after inserting a jumper which enables
programming. Refer to the manual for system configuration, commissioning and maintenance.
ONLY authorized technicians, appointed by the Manufacturer can, by means of special tools, carry out repair work on
the motherboard.
Level 4: ONLY authorized technicians, appointed by the Manufacturer can, by means of special tools, carry out repair
work on the motherboard.
1.5 CE Mark
1.5.1 Regulation (EU) No. 305/2011
This product complies with requirements stated by standards listed here below in compliance with Regulation (EU) No.
305/2011.

Installation manual
General information 7
1.5.2 Directive 2014/53/EU
Hereby, INIM Electronics S.r.l. declares that these Previdia Compact are in compliance with the essential requirements
and other relevant provisions of Directive 2014/53/EU.
Following paragraph explains how to download the complete Declaration of Conformity.
This product may be used in all EU Countries.
1.5.3 Documents for the users
Declarations of Performance, Declarations of Conformity and Certificates concerning to INIM Electronics S.r.l. products
may be downloaded free of charge from the web address www.inim.biz, getting access to Extended Access and then
selecting "Certifications" or requested to the e-mail address [email protected]z or requested by ordinary mail to the address
shown in paragrafo 1.5.1.
Manuals may be downloaded free of charge from the web address www.inim.biz, getting access to Extended Access and
then selecting "Manuals".

,1,0(OHFWURQLFVVUO
9LD'HL/DYRUDWRUL)UD]&HQWREXFKL
0RQWHSUDQGRQH$3,WDO\

&35
(1$
(1$
(1
(1
35(9,',$&/*35(9,',$&/535(9,',$&/=*
35(9,',$&/=535(9,',$&/=(*35(9,',$&/=(5
Control and indicating equipment with power supply equipment, alarm
transmission and fault warning routing equipment and electrical automatic
control and delay device integrated for fire detection and fire alarm systems
installed in buildings and for gas extinguishing systems installed in
buildings and part of a complete system.

,1,0(OHFWURQLFVVUO
9LD'HL/DYRUDWRUL)UD]&HQWREXFKL
0RQWHSUDQGRQH$3,WDO\

&35
(1$
(1$
(1
(1
35(9,',$&6*35(9,',$&6535(9,',$&6=*
35(9,',$&6=535(9,',$&6=(*35(9,',$&6=(5
35(9,',$&6*35(9,',$&6535(9,',$&6=*
35(9,',$&6=535(9,',$&6=(*35(9,',$&6=(5
35(9,',$&6*35(9,',$&6535(9,',$&6=*
35(9,',$&6=535(9,',$&6=(*35(9,',$&6=(5
Control and indicating equipment with power supply equipment, alarm
transmission and fault warning routing equipment and electrical automatic
control and delay device integrated for fire detection and fire alarm systems
installed in buildings and for gas extinguishing systems installed in
buildings and part of a complete system.
(VVHQWLDOIHDWXUHV 3HUIRUPDQFH
3HUIRUPDQFHLQWKHHYHQWRIILUH 3$66
3RZHUVXSSO\SHUIRUPDQFH 3$66
5HVSRQVHGHOD\UHVSRQVHWLPHLQWKHHYHQWRIILUH 3$66
3HUIRUPDQFHRIWKHWUDQVPLVVLRQ 3$66
2SHUDWLQJUHOLDELOLW\ 3$66
'XUDELOLW\RI
UHOLDELOLW\
7KHUPDOUHVLVWDQFH 3$66
9LEUDWLRQUHVLVWDQFH 3$66
+XPLGLW\UHVLVWDQFH 3$66
(OHFWULFDOVWDELOLW\ 3$66
2SWLRQVSURYLGHGLQDFFRUGDQFHZLWK(1 3HUIRUPDQFH
2XWSXWWRILUHDODUPGHYLFHV 3$66
2XWSXWWRILUHDODUPURXWLQJHTXLSPHQW 3$66
2XWSXWWRILUHSURWHFWLRQHTXLSPHQW 3$66
'HOD\RQRXWSXWV 3$66
&RLQFLGHQFHGHWHFWLRQ7\SH$%DQG& 3$66
$ODUPFRXQWHU 3$66
3RLQWIDXOWVLJQDO 3$66
2XWSXWWRUHPRWHIDXOWRUZDUQLQJVLJQDOOLQJGHYLFHV 3$66
$GGUHVVDEOHSRLQWVRXWRIVHUYLFH 3$66
7HVWFRQGLWLRQ 3$66
2SWLRQVSURYLGHGLQDFFRUGDQFHZLWK(1 3HUIRUPDQFH
'HOD\RIH[WLQJXLVKLQJVLJQDO 3$66
6LJQDOUHSUHVHQWLQJWKHIORZRIH[WLQJXLVKLQJDJHQW 3$66
0RQLWRULQJRIWKHVWDWXVRIFRPSRQHQWV 3$66
(PHUJHQF\KROGGHYLFH 3$66
&RQWURORIIORRGLQJWLPH 3$66
0DQXDORQO\PRGH 3$66
7ULJJHULQJVLJQDOVWRHTXLSPHQWZLWKLQWKHV\VWHP 3$66
7ULJJHULQJRIHTXLSPHQWRXWVLGHWKHV\VWHP 3$66
(PHUJHQF\DERUWGHYLFH 3$66
$FWLYDWLRQRIDODUPGHYLFHVZLWKGLYHUVHVLJQDOV 3$66
RQHRQO\EHWZHHQDQG
$GGLWLRQDOLQIRUPDWLRQDFFRUGLQJWR(1
$ERXWLQIRUPDWLRQUHTXLUHGDWSRLQWVHHGDWDFRQWDLQHGLQWKLVPDQXDO
$GGLWLRQDOLQIRUPDWLRQDFFRUGLQJWR(1
$ERXWLQIRUPDWLRQUHTXLUHGDWSRLQWVHHGDWDFRQWDLQHGLQWKLVPDQXDO
$GGLWLRQDOLQIRUPDWLRQDFFRUGLQJWR(1
$ERXWLQIRUPDWLRQUHTXLUHGDWSRLQWVHHGDWDFRQWDLQHGLQWKLVPDQXDO
$GGLWLRQDOLQIRUPDWLRQDFFRUGLQJWR(1
(QYLURQPHQWDOFODVV$
'HJUHHRISURWHFWLRQ,3
)ORRGLQJ]RQHV
=RQHVIRU&2LQHUWJDVRUKDORJHQDWHGK\GURFDUERQV
5HVSRQVHGHOD\DFWLYDWLRQFRQGLWLRQPD[V
5HVSRQVHGHOD\WULJJHULQJRIRXWSXWVPD[V

8General description
Fire detection and extinguishant system
Chapter 2
General description
2.1 Previdia Compact Models
Previdia Compact is a series of control panels for the management of fire detection and extinguishing systems.
This series provides different models of control panels distinguished by certain technical characteristics such as the
number of loops and devices that can be managed, the type of cabinet in which the modules are housed, the presence
of signalling LEDs on the frontplate and the possibility of managing an extinction channel.
The name of each model specifies its characteristics, in accordance with the following table:
2.2 Control panel descriptions
Each control panel model comes in a metal cabinet that is
packed in a cardboard box. The cabinets used for the
Previdia Compact series differ in size and colour:
•small cabinet, dimensions 325x325x80mm, capacity to
house 2 batteries of 1,5A – 7Ah, in light grey or red
•large cabinet, dimensions 497x380x87mm, capacity to
house 2 batteries of 4A – 7Ah, in light grey or red
Installed inside:
- CPU unit with 4.3’’ touchscreen, buttons and LEDs for
the user interface
- I/O unit for loop management, Hornet+ network and
input/output terminals
-powersupplymodule
- batteries, not included
In Some versions there is also a signalling module with 30
individually programmable indicator LEDs (three colours).
The PREVIDIA-C-DIAL Module (communication module over PSTN or GSM telephone line and for the management of
GPRS connections) can be installed in all the power stations of the range.
A plastic bag is supplied with the control panel, containing:
• battery connection wires
• ring terminal for the earth connection
• Key to select access level 2
• resistors and EOL diodes for the supervised circuits
• installation manual
Series prefix Number of loops Mounting cabinet
size Zone LEDs Extinction channel Cabinet colour
PREVIDIA-C
200
2 loops of 240 points
S
small cabinet
Z
Available LED
indicators
E
Discharge zone
G
grey
100
1 loops of 240 points
L
large cabinet
-
LED indicators
not available
-
Extinction not
available
R
red
050
1 loops of 64 points

Installation manual
General description 9
Note: The control panels described in this manual have been designed and developed to the highest standards
of quality, reliability and performance.
The components selected for this product will operate properly within their specifications when the
environmental conditions outside the product enclosure comply with Class 3k5 (EN 60721-3-3).
EN54: The gas detection function is not provided for in the aforesaid standard and therefore cannot be
considered EN54-2 compliant.
When you remove the four screws and metal-frontplate, you will find:
Specification
Previdia Compact Models
PREVIDIA-CxxxS
(in small cabinet)
PREVIDIA-CxxxL
(in large cabinet)
Supply voltage 230V~ (-15% / +10%) 50/60Hz
Maximum current draw 230V 0.5 A 1.1 A
AC Mains input terminals
Nominal output voltage 27.6 V
Maximum output current 1.5 A 4 A
I
max. a
1.5 A 4 A
I
max. b
1.5 A 4 A
Main board current draw
stand-by 150mA
without supply voltage 130mA
test LEDs 170mA
LED indicators board current draw
(if present)
stand-by 5mA
test LEDs 115mA
Maximum battery-charge current 0.6 A 1.2 A
Battery specifications 2 x 12 V, 7 Ah 2 x 12 V, 17 Ah
with UL94-V2 flame class cabinet or higher
Maximum internal resistance of the batteries (R
i max
)2.7 Ohm 1 Ohm
Output voltage from 19 to 27.6V
Battery shutdown tension 19V
Internal fuse of switching power supply module T 3.15A 250V
Maximum output current ripple 420 mV 260 mV
Operating temperature from -5°C to 40°C
Isolation class I
Enclosure protection class (EN 60529) IP30
Dimensions 322 x 324 x 86 mm 497 x 380 x 97 mm
Weight (without batteries) 3.3 Kg 6.1 Kg
N
L
230V ~ 50/60 Hz
AC I
nput
NL
230V ~ 50/60 Hz
AC I
nput

10 General description
Fire detection and extinguishant system
[A]
Touchscreen display
[B]
Status LED
[C]
LED and function button
[D]
LED and multiple-alarm
button
[E]
Access-key slot
[F]
Buzzer
[G]
MicroSD card holder
[H]
Reset button
[I]
Button to reset default
settings (factory settings)
[J]
Programming jumper
connector
[K]
Ethernet port
[L]
Mini USB port
[M]
Connector for PREVIDIA-
C-DIAL board
[N]
Support for the
motherboard
[O]
Support anchor screw
[P]
Terminal board
[Q]
Power-supply terminals
[R]
Earthing point
[S]
Frontplate earth wire
[T]
Battery wires
[U]
Thermal probe for
batteries
[V]
Cable entry
[W]
Locations for the
mounting screws of the
optional plate
[X]
Mounting screw
locations
[Y]
Locations for the
frontplate screws
[Z]
Battery housing
AB
E
S
D
G
H
C
F
L
V
K
V V
T
U
Z
Previdia Compact in large cabinet
N
Q
P
O
O
O
O
R
V
W
W
XX
XX
Z
Y Y
Y Y
I
J

Installation manual
General description 11
Output connection terminals
number name maximum current function
1, 5
+24
500mA
Hornet+ network
terminal
Positive
2, 3
A+, A-
/Port A (positive and
negative)
6, 7
B+, B-
/Port B (positive and
negative)
4, 8
-
/Negative
AB
E
S
D
G
C
F
VVV
T
U
Previdia Compact in small cabinet
N
O
O
O
O
Q
P
R
W
W
XX
XX
Z
YY
Y Y
H
LK
I
J
M
L
K
O
Back of the motherboard
N
O
O
O

12 General description
Fire detection and extinguishant system
2.3 Fire Extinction
Some models of Previdia Compact control panel allow the management of a gas-extinguishing channel.
Complies with EN12094-1 and provides the inputs, outputs and control logic required by these systems.
The following figure shows a flowchart of the operations carried out by the control panel in the pre-extinction phase,
that is, from the occurrence of the events that trigger the extinction phase to the start of the release condition, and
during the release of fire extinguishing gas:
9, 10
+ L1.O -
500mA Terminals of loop 1
Output
12, 13
+ L1.I -
Input
14, 15
+ L2.O -
500mA Terminals of loop 2
Output
17, 18
+ L2.I -
Input
11, 16 / Earth terminal
19, 20
+ I/O1 -
1A @ 27.6V
Input/Output connection terminals
21, 22
+ I/O2 -
1A @ 27.6V
23, 24
+ I/O3 -
1A @ 27.6V
25, 26
+ I/O4 -
1A @ 27.6V
27, 28, 29
NO, C, NC
5A @ 30V Free voltage relay
LED Colour On solid Flashing
Extinguishment
channel activation LED Red Discharge activated Pre-extinguishment condition
running
Automatic activation
indicator LED Red Automatic discharge
command activated
Automatic discharge
command partially activated
Bypass automatic
activation LED Yellow The automatic discharge command has been bypassed /
Bypass extinction
channel LED Yellow Channel bypassed /
Manual stop extinction
LED Yellow Extinguishment locked Fault on stop-extinction circuit
Stop extinction LED
from non-electrical-
devices
Yellow Extinguishment locked Fault on stop-extinction circuit
Output connection terminals
number name maximum current function

Installation manual
General description 13
Blinking
ON
ON
YES
NO
OFF
YES
NO
ON
OFF
ON
ON
ON ON
Pre-extinguishment
time started
Pre-extinction time
terminated
Condition
sufficient?
Stop
extinction
?
PRE-
AUTOMATIC
“EXTERNAL”
“EXTERNAL”
Deactivation
STOP “ABORT”
mode
“HOLD”
Activation
“ADD”
Activation
“ABORT”
MANUAL
“HOLD”
Deactivation
“ADD”
Deactivation
Stand-by
from flow sensor
ACTIVATION
Manual Automatic
Flow switch Manual
extinction
Pre-
Extinguishing
Stop
extinction
Stop extinction
active
Stop extinction
active
Stop
extinction
active Stop
extinction
active
Electro
valve
Release
Blinking
Release
Flash
ON
ON
YES
NO
OFF
YES
NO
OFF
Pre-discharge time
started and
terminated
Interval expired
between two
discharge procedures
Pressure
switch
activated?
Verify?
Gas discharged
Discharge time started
and terminated
DISCHARGE GAS
Electro
valve
Electro
valve
YES
NO
Number of
attempts ≥
value set?
“Failed
confirmation”
fault
Confirm from
pressure switch
ON
YES
NO
Pulse
Electroval
ve?

14 General description
Fire detection and extinguishant system
The following table contains a description of the functions associated with the extinction that can be programmed for
the control panel inputs and outputs (on-board or on loops, through supervised outputs, such as those of the EM312SR
modules).
Terminal function Activation
Pressure
switch
Input for the supervision of the pressure
of the cylinders containing the gas.
The input is activated in the case of pressure drop in the cylinders.
During stand-by status, its activation generates a fault warning.
Confirm
release from
pressure
switch
Input, for the connection of a pressure
switch, confirming the release of the gas
from the cylinders.
After releasing the electrovalve, its activation is used to confirm the
release of the gas.
Flow switch
Input, for the connection of a flow
sensor that will signal the release of the
gas from the cylinders.
The input will be activated by a sensor that detects the flow of
extinguishing gas.
The flow may have been activated directly without following the
procedure of extinction and pre-extinction.
Stop
extinction
The inputs stop the extinction procedure
in accordance with the activation mode
described opposite.
Abort
If this input is activated during the pre-extinguishment
phase, the extinguishment procedure will be aborted
even if the input resets.
The procedure can be restarted only after control panel
reset.
If this input is activated during stand-by, it will generate a
fault warning.
Add
If this input activated during pre-extinguishment status,
the extinguishment procedure will remain locked until
the input resets. On input reset the pre-extinguishment
countdown will refresh and restart.
If this input is activated during stand-by, it will generate a
fault warning.
Hold
If activated during a pre-extinction condition, the
extinction procedure is stopped but the pre-extinction
time count continues. When the input is restored, if the
pre-extinction time count has terminated, the gas will be
released.
If this input is activated during stand-by, it will generate a
fault warning.
External
This function is identical to the “Hold” function but refers
to mechanical or electrical intervention (for example, a
door contact that inhibits gas discharge, etc.).
This activation will be signalled separately.
If activated during stand-by, it will not generate a fault
warning.
Manual
extinction
This input is for the connection of one or
more manual call points for the
activation of extinguishing-agent
discharge.
Electrovalve
Output for the connection of the
electrovalve which discharges the
extinguishing agent.
It will activate only when the pre-extinguishment time expires
Stop
extinction
active
Output for the connection of stop-
extinction signalling devices.
It will activate when the extinction channel is stopped by one or
more inputs connected to the “Stop extinction” input.
Pre-
Extinguishing
Output for the connection of a signal
relating to imminent discharge of the
extinguishing agent.
It will activate during the pre-extinguishment time which runs before
the discharge of the extinguishing agent.
Release
Output for the connection of signalling
devices which warn building inhabitants
of the actual discharge of the
extinguishing agent.
It will activate on activation of the electrovalve.

Installation manual
General description 15
EN12094-1: To guarantee compliance of the product to EN 12094-1, the control panel must be configured to make
available the following functions (the others are optional):
Manual extinction, Electrovalve, Pre-extinction, Release.
The "Electrovalve" function must only be associated with the "I/O4" terminal on board the control panel.
The "Pre-Extinction" function at default is associated with the terminal "I/O3" on board the control panel.
Refer to the Configuration Manual for the programming details of the other functions.
EN12094-1: In compliance with the requirements of standard EN 12094-1, if the “Stop extinction-Abort” function is
used in a Previdia Compact control panel, the “Stop Extinction-Hold” and “Stop Extinction-Add” functions
cannot be activated, and vice versa.
Please remember that no more than 32 devices can be connected to each of the selected input or
output terminals.
2.4 Previdia-C-DIAL, telephone line Communicator module
The optional Previdia-C-DIAL board allows you to connect Previdia Compact control panels to the landline (PSTN) and to
the GSM 2G and 3G networks.
It manages reporting protocols used by alarm receiving centres. This module allows the control panel to make voice
calls and send SMS text messages.
The board comes with:
• Mounting plate
•7mountingscrews
• cable for the connection to the motherboard
• remote antenna
• Instructions manual
SIM card not included
[A]
Motherboard connector
[B]
Ground terminal
L.E.
Telephone line
connection terminals
L.I.
Internal telephone line
terminals
[C]
Mini USB port
[D]
Reset button
[E]
Button to reset default settings
(factory settings)
[F]
SIM card holder
[G]
GSM antenna connector
[I]
Mounting plate
[H]
Screws for fixing the board to the
plate
[J]
Hole for the mounting plate
screw
A
C
B
F
G
D
H
H
J
H
J
H
H
IE

16 General description
Fire detection and extinguishant system
2.5 Previdia Compact REP Repeater
For installations requiring a system control point other than the point where the Previdia Compact control panel is
installed, there are two repeater panel models, that is, devices that allow you to remotely view the information available
on the user interface of the control panel.
The models are:
• PREVIDIA-C-REP, standard repeater
• PREVIDIA-C-REPE, standard repeater with extinction channel LEDs
Technical specifications
Supply voltage 19-30 V
Consumption @
27.6V
stand-by 40mA
maximum 140mA
Band frequency 2G: 850/900, 1800/1900 MHz
3G: 800/850/900, 1900/2100 MHz
Maximum RF output power 2W, 1W
Operating temperature from -5°C to +40°C
Antenna
remote GSM-UMTS cable 2m, SMA-Male
connector (50Ohm impedance) and magnetic
base
[A]
Touchscreen
display
[H]
Ethernet port
[B]
Status LED
[I]
Mini USB port
[C]
LED and function
button
[J]
Terminal board
[D]
LED and multiple-
alarm button
[K]
Backlocking grips
[E]
Access-key slot
[L]
Cable entry
[F]
Buzzer
[M]
Mounting screw
locations
[G]
MicroSD card
holder
[H]
Ethernet port
H
I
J
KK
G
LL
M
M
M
MM
M
A
B
E
D
C
F
K
K

Installation manual
General description 17
The repeaters can be connected to the system via the Hornet+ network (paragraph 3.7 Connecting the Hornet+
network) or via a TCP-IP connection and can also be associated with Previdia Max control panels.
If necessary, it is possible to power the repeater using an external power supply module.
EN54: The power-supply unit employed must be EN54-4 standard compliant.
2.6 Control panels in a Hornet+ network
In order to enlarge the installation, it is possible to connect several Previdia Max
and Previdia Compact control panels (with a maximum of 48 points including
control panels and repeaters) thus creating an expanded system (Hornet+
network).
Each model of the Previdia Compact control panel provides two RS485 ports for
the ring connection (for details on the wiring refer to paragraph 3.7 Connecting
the Hornet+ network).
For further information regarding the method used for connecting control
panels in a network refer to the Previdia Networking Guide available at
www.inim.biz
2.7 Control Panels in an IP network
Several Previdia-Max and Previdia Compact control
panels or more Hornet+ control panel networks can be
connected to each other via a TCP-IP connection.
Each node in a connection of this type is identified as a
“cluster”. Each cluster can consist of a single control
panel, a Hornet+ network of control panels or a
repeater.
For further information regarding the method used for
connecting control panels in a network refer to the
Networking Guide available at www.inim.biz
Technical specifications
Supply voltage 19-30 V
Consumption @
27.6V
stand-by 110mA
during mains failure 80mA
maximum 130mA
Operating temperature from -5°C to +40°C
Dimensions 210 x 132 x 32mm
Weight 330g
21 3
A+
-
A-
4
+24
65 7
B+
-
B-
8
+24
21 3
A+
-
A-
4
+24
65 7
B+
-
B-
8
+24
-
+
Previdia Compact Repeater
Previdia Compact REP 24V
LAN
Router
Internet

18 Installation
Fire detection and extinguishant system
Chapter 3
Installation
Note: The installation of these control panels must be carried out in full compliance with the local fire
regulations, the laws and regulations in force, and in accordance with the instructions and relevant
guidelines.
This Fire control panel should be located in a place that is:
•Dry
• Far from electromagnetic interference (electrical equipment, heating units, air-conditioning units, radio transmitters,
etc.)
The mounting location must satisfy all the requirements of the respective Fire Code, laws and bylaws in force.
The system must be installed in accordance with the following procedure:
1. Lay the cables
2. Connect all the devices to the BUS and to the loops.
3. Mount the Previdia-C-DIAL module inside the control panel (optional).
4. Mount the control panel to the wall
5. Complete the connections inside the control panel.
6. Power up the system.
7. Test the system
EN54: In order to guarantee the IMQ-safety systems certification and compliance to standard EN54-2:
• all the manual alarm buttons and fire detectors employed in the system must be associated with fire
detection and alarm functions.
• not more 512 detectors and/or manual call points can be connected.
• the wiring must be such that, in the event of any failure, the number of devices that remain insulated
can never exceed 32.
3.1 Mounting the control panel to the wall
1. Remove the securing screws and door (paragraph 2.2 - [Y]).
2. Remove the screws of the plastic housing containing the motherboard (paragraph 2.2 - [N]) paying attention to the
power-supply connection cables.
3. Open the holes at the side that you intend to use for the cable passage.
Note: In order to guarantee the IP30 protection grade, do not open any other holes..
4. Pull the cables through the open cable entries.
5. By means of the holes on the back of the cabinet, mount it to the wall (paragraph 2.2 - [X]).
Use anchor screws (stop screws) with 8mm diameter minimum.
6. Complete the connections with the control panel terminals.
7. Replace the frontplate.

Installation manual
Installation 19
3.2 Mounting the PREVIDIA-C-DIAL communicator
module
The optional Previdia-C-DIAL module must be mounted internally to the
back of the cabinet.
1. Open the control panel cabinet by removing the metal frontplate and the
plastic support for the motherboard ([A], paragraph 2.2 - [N]).
2. Attach the mounting plate to the back of the cabinet by fastening the
screws provided into the appropriate holes ([B], paragraph 2.2 - [W] and
paragraph 2.4 - [J]).
3. Attach the board to the mounting plate by fastening the screws provided
into the appropriate holes ([C], paragraph 2.4 - [H]).
4. Using the wire provided, connect the board to the motherboard via the
appropriate connectors (paragraph 2.2 - [M] and paragraph 2.4 - [A]).
5. Complete the telephone connections (paragraph 3.8 Connecting the
land-line (PSTN)).
6. Replace the plastic support and replace the lid+.
3.3 Control panel wiring
Attention: Take care to remove all sources of power, including the batteries before starting any wiring
operations.
Note: The ends of wires must not be soft soldered in points where they are subject to clamping.
3.3.1 Mains connection
EN54: The power-supply system of Previdia Compact control panels is EN54-4 compliant.
Attention: Do not power up the system with a non-compliant voltage.
1. Connect the mains power supply to the
terminals on the power-supply module
(paragraph 2.2 - [Q] and [A]).
For a safety standards compliant system, the
Line must be connected to terminal “
L ”, the
Neutral conductor to terminal “
N ”.
The power supply to the control unit must
come directly from a reserved line on the
Electrical Switchboard (Mains power supply).
The line must be protected by a sectioning
device which complies with local safety
regulations, fire codes, laws and bylaws in force.
Note: As a further safety measure, the
electrical system of the building
must be protected against overload
and short-circuit.
B
C
C
C
A
C
B
D
E
F
A
G
Previdia Compact in
large cabinet

20 Installation
Fire detection and extinguishant system
Note: The end of a stranded wire must not be
consolidated with soft soldering in points where
the wire is subjected to contact pressure.
2. Crimp the earth line wire to the eyelet terminal [B].
3. Attach the wire with the eyelet to the control panel using the
ground connection screw [C].
4. Ensure that the terminal “ ” of the power supply module
[D]], the motherboard [E] and the frontplate
[F]. of the cabinet are connected to earth system.
Attention: The protective earthing system must be compliant with the local safety regulations, fire codes, laws
and bylaws in force.
Note: A protective earth connection ensures that all exposed conductive surfaces are at the same electrical
potential as the earth surface, in order to avoid the risk of electrical shock if a person touches a device in
which an insulation fault has occurred. In the event of an insulation fault, a protective earth connection
will generate a high fault current which in turn will trigger an overcurrent protection device (fuse) and
disconnect the power supply.
5. Ensure that low-current safety or signal lines DO NOT come into contact with points with potentially dangerous
currents.
Using a plastic cable tie, bunch the wires together and secure them to one of the wire hooks on the back of the
cabinet
[G].
Note: The connection wires (to the mains supply and also any other wires inside the cabinet) must be secured
to the cable hooks on the backplate by means of plastic cable ties. Use cable with double isolation for
the connection to the electrical mains.
3.3.2 Connecting the batteries
The metal cabinet of the control panel provides housing for two 12V, 7 Ah lead batteries for the small version and 17 Ah
for the large version. The two batteries must be connected in series, in such way as to supply 24V.
1. Place the batteries into the battery compartment inside the cabinet (paragraph 2.2 - [Z]).
2. Using the battery wire ([A]), connect the batteries together.
3. Connect the wire coming from the power supply ([B] paragraph 2.2 - [T]) to the battery terminals ([C]).
Attention: Ensure that the polarity is correct.
Red - positive
Black - negative
Connection of the batteries before the mains voltage is present will not activate the system. Once the mains voltage is
supplied, the power-supply module will connect the batteries automatically and initialize the circuits which manage
them.
4. Position the thermal probe (paragraph 2.2 - [U]).
The thermal probe must be positioned on the side of the battery and held in place by a strip of tape ([D]).
D
E
F
A
C
B
G
Previdia Compact in
small cabinet
