INSTALLATION, USE AND MAINTENANCE MANUAL
..2.0 Rinnova Ceiling

Page2
INDEX
1GENERALITY ..................................................................................................................................................................4
1.1.1 INTRODUCTION.................................................................................................................................................4
1.1.2 BASIC SAFETY RULES .....................................................................................................................................4
1.1.3 SYMBOLOGY .....................................................................................................................................................5
1.1.4 WARNINGS ........................................................................................................................................................5
1.1.5 COMPLIANCE ....................................................................................................................................................6
1.1.6 RANGE ...............................................................................................................................................................6
1.1.7 IDENTIFICATION................................................................................................................................................6
1.1.8 CONSTRUCTION FEATURES...........................................................................................................................7
1.1.9 MAIN COMPONENTS OF THE UNIT.................................................................................................................8
1.1.10 PACKING AND TRANSPORT ........................................................................................................................8
1.1.11 RECEPTION, CONTROL AND HANDLING ...................................................................................................8
1.1.12 DISASSEMBLY AND DISPOSAL ...................................................................................................................8
2INSTALLATION ...............................................................................................................................................................9
2.1.1 INSTALLATION CONDITIONS...........................................................................................................................9
2.1.2 UNIT PLACEMENT.............................................................................................................................................9
2.1.3 CONDENSATE DRAIN CONNECTION............................................................................................................10
3AREA CONNECTIONS .................................................................................................................................................11
3.1.1 AREAUAL ORIENTATIONS .............................................................................................................................11
3.1.2 INSTALLATION OF EXTERNAL GRILLES ......................................................................................................12
4ELECTRICAL CONNECTIONS.....................................................................................................................................13
4.1.1 GENERALITY ...................................................................................................................................................13
4.1.2 CONNECTION PLACEMENT AND PROCEDURES........................................................................................13
4.1.3 INSERTING THE REMOTE CONTROL BATTERIES.......................................................................................14
4.1.4 WIRING DIAGRAM ...........................................................................................................................................15
4.1.5 CONNECTIONS................................................................................................................................................15
5COMMISSIONING AND METHOD OF USE .................................................................................................................16
5.1.1 OPERATION OF THE CONTROL PANEL ON THE MACHINEWIFI AND REMOTE CONTROL ...................16

Page3
6MAINTENANCE.............................................................................................................................................................19
6.1.1 CLEANING OR REPLACING EPM1 FILTERS.................................................................................................19
6.1.2 REPLACING THE PREFILTER ........................................................................................................................19
6.1.3 LAMP MAINTENANCE .....................................................................................................................................20
7ALARMS ........................................................................................................................................................................21
7.1.1 GENERALITY ...................................................................................................................................................21
7.1.2 PROBLEMS WITHOUT ERROR INDICATION ON THE DISPLAY .................................................................21
7.1.3 TABLE OF ALARMS INDICATED BY THE DISPLAY ......................................................................................22
8NOTES AND MAINTENANCE INFORMATION ............................................................................................................23
NOTE .............................................................................................................................................................................23

Page4
1 GENERALITY
INTRODUCTION
This manual was conceived with the aim of making installation and management of your system as simple as possible.
By reading and applying the suggestions in this manual, you will be able to obtain the best performance from the purchased product.
We would like to thank you for the choice you made by purchasing our product.
Read this booklet carefully before carrying out any operation on the unit.
The unit must not be installed or performed on it in any way unless this manual has been carefully read and understood in all its parts. In particular, all
the precautions listed in the manual must be taken.
The documentation supplied with the unit must be handed over to the system manager so that he can keep it carefully (at least 10 years) for any future
assistance, maintenance and repairs.
The installation of the unit must take into account both the purely technical requirements for correct operation and any local legislation
in force and specific provisions.
Make sure that when the unit is delivered, there are no obvious signs of transport damage. In this case, indicate it on the delivery note.
This manual reflects the state of the art at the time the machine was marketed and cannot be considered inadequate because it is subsequently
updated on the basis of new experiences. The Manufacturer reserves the right to update the production and the manuals, without the obligation to
update the previous ones, except in exceptional cases.
Contact the Manufacturer's Sales Department to receive further information or updates to the technical documentation and for any improvement
proposal to this manual. All reports received will be rigorously screened.
BASIC SAFETY RULES
We remind you that the use of products that use electricity and water implies the observance of some fundamental safety rules:
•Use of the appliance by disabled and unassisted persons is prohibited
•It is forbidden to touch the appliance with bare feet and with wet or damp parts of the body
•Any cleaning operation is prohibited before having disconnected the appliance from the mains power supply by setting the main system switch
to off
•It is forbidden to modify the safety or adjustment devices without the authorization and indications of the appliance manufacturer
•It is forbidden to pull, disconnect or twist the electric cables coming out of the appliance, even if this is disconnected from the mains power
supply.
•It is forbidden to introduce objects and substances through the air intake and delivery grilles.
•It is forbidden to open the access doors to the internal parts of the appliance without having first turned the main switch of the system to off.
•It is forbidden to disperse and leave the packaging material within the reach of children as it can be a potential source of danger.
•Respect the safety distances between the machine and other equipment or structures to guarantee sufficient access space to the unit for
maintenance and assistance operations as indicated in this booklet.
•The power supply of the unit must take place with electric cables having a section suitable for the power of the unit. The voltage and
frequency values must correspond to those indicated for the respective machines; all machines must be earthed as per current legislation in
the various countries.
•Do not release R410A into the atmosphere: R410A is a fluorinated greenhouse gas, referred to in the Kyoto protocol, with a global warming
potential (GWP)=1975.

Page5
SYMBOLOGY
The symbols shown in the following file allow you to quickly provide the information necessary for correct use of the unit.
Safety related symbols
ATTENTION
Authorized personnel only Warns that the operations indicated are important for the safe operation of the machines
DANGER
Risk of electric shock Warns that failure to observe the instructions involves a risk of electric shock.
DANGER Warns that failure to observe the instructions involves a risk of harm to exposed persons.
WARNING It warns that failure to observe the instructions involves a risk of damage to the unit or the system.
DANGER Warns that there is the presence of moving parts and involves a risk of harm to exposed people
WARNINGS
The installation of the unit must be carried out by qualified and authorized personnel according to the regulations in force in the various
countries.
If the installation is not performed it could become a dangerous situation
Avoid installing the unit in very humid rooms or with the presence of large heat sources.
On the electrical side, to prevent any risk of electrocution, it is essential to disconnect the main switch before carrying out any operations
electrical connections and any maintenance operation.
In the event of water leaks inside the unit, position the main switch of the system to "Off", close the taps of the
water and contact the technical service
It is recommended to use a dedicated power circuit; Never use a power supply in common with other appliances.
It is recommended to install an earth leakage breaker; failure to install this device may result in shock
electric.
For the connection, use a cable long enough to cover the entire distance, without any connection; do not use
extension cords and do not apply other loads on the power supply but use a dedicated power circuit.

Page6
After connecting the electric cables, make sure that the cables are arranged so as not to exert excessive forces on the covers or on the
electrical panels; any incomplete connection of the covers may cause overheating of the terminals.
Make sure that the earth connection is made; do not earth the appliance on distribution pipes.
High intensity surge currents could damage the unit
Installations carried out outside the warnings of this manual or use outside the operating limits will invalidate
the guarantee instantly.
Make sure that the first start-up is carried out by personnel authorized by the company (see first start-up request form)
COMPLIANCE
The CE marking (present on each machine) certifies compliance with the following EU standards:
•Low Voltage Directive 2014/35/EC
•Electromagnetic Compatibility Directive 2014/30/EC
•RoHS2 2011/65/EU
•WEEE 2012/19/EC
RANGE
-1- -2- -3- -4-
..2.0 Rinnova Ceiling
40 H M Y
1) Defines the Total flow rate and the fresh air flow rate
40 - up to 460 m³/h
2) Configuration
H - horizontal
3) Type of installation
M: Sight
4) Electronic typology
Y: Electronics version Y remote control
W: Electronic version W command on board + remote control
IDENTIFICATION
- The unit can be identified by the plate placed on the lower front panel of the same.
- On the packaging there will be an additional identification plate with the unit model and shipping references.
- The label on the packaging has no value for the traceability of the product in the years following the sale.
The removal, deterioration and illegibility of the plate placed on the unit, involves major problems in identifying the machine, in finding spare parts and
therefore in any future maintenance.

Page7
CONSTRUCTION FEATURES
The ..2.0 Rinnova Ceiling units are designed for the renewal of air in rooms. The ease of installation through two 160 mm diam. holes and the high renewal air
flow rate allow application in situations such as residential buildings, schools, clinics, offices and all contexts where air renewal is required; The thermodynamic
recovery allows to have an integration with respect to the environmental climatic conditions, helping the air conditioning system to satisfy the internal comfort;
Furthermore, the air introduced is always at a temperature close to or better than the room temperature, thus guaranteeing superior perceived comfort;
The unit is made up of a monobloc including all components for correct operation: fans, cooling circuit with high efficiency compressors, air filtration sections and
high efficiency counter-current heat recovery unit.
ALL IN ONE: Complete unit capable of exchanging the air and integrating the thermal and refrigeration requests of
the rooms served. The unit is complete with every component for its operation and is ready for use.
UV LAMP AND VOC SENSOR: The unit is equipped with a UV lamp (accessory) which allows a germicidal action on the air
introduced from outside through the effect of the UVC; The lamp is activated automatically
according to the ambient air quality,
VENTILATION: Fans with directly coupled brushless motor; The fans operate in various modes mainly controlled by
the air quality sensor located inside the unit;
ACTIVE THERMODYNAMIC RECOVERY: The unit allows the active recovery of the energy of the expelled air. The thermodynamic recovery
allows, thanks to its cooling circuit, to supply energy to the environment in a higher quantity than that
subtracted from the ventilation for 90% of the unit's operation;
FILTRATION: There are 2 ePM1 filters on the extracted air and the introduced air; The inlet air filter is placed after
the coil to completely filter out any impurities in the inlet air. There is a Coarse pre-filter on the
outside air which protects the cleanliness of the unit;
STRUCTURE: Self-supporting sheet metal frame
Self-supporting sheet metal structure, externally painted (in the visible versions), with interposed
thermal and acoustic insulation in polyethylene and Epdm;
REFRIGERANT CIRCUIT: Made of brazed copper complete with: BLDC high efficiency compressor, drier filter, finned coils,
electronic expansion valve, reverse valve and safety devices.
ADJUSTMENT: Electrical panel on the unit with microprocessor and dedicated regulation. Fan management, display
and timed dirty filter management temperature setpoint.
Defrost algorithm management optimized for operation with low outside temperatures; Panel with
graphic interface and WI-FI on board the machine and remote control included in the visible
versions;
Remote panel to be purchased optionally with WI-FI or MODBUS RTU for connection up to 10 m
from the unit for built-in versions;

Page8
MAIN COMPONENTS OF THE UNIT
1 Compressor
2 Supply fan
3 Exhaust fan
4 Battery entry
5 Battery ejected
6 Electrical panel
7 Displays
8 External air pre-filter
9 Epm filters1
10 UV lamp
PACKING AND TRANSPORT
The units are supplied for transport fixed on a wooden pallet and inserted in cardboard boxes. To facilitate movement, the units are equipped with a
wooden pallet and hooks on the base which allow them to be lifted and positioned on the installation site. The unit can be stored in a place protected
from atmospheric agents with temperatures not lower than 0 °C, up to a maximum of 40 °C.
RECEPTION, CONTROL AND HANDLING
The unit is shipped completely pre-charged with refrigerant gas in the circuits and with non-freezing oil in the compressors. Under no circumstances can
water be present in the hydraulic circuits, since after testing the unit is carefully emptied. Upon arrival, the customer is required to inspect the unit also in
the internal areas to verify that it has not been damaged during transport; the unit left the factory in perfect condition. Otherwise, it is necessary to take
immediate recourse against the carrier, reporting the extent of the damage in detail on the document, producing photographic evidence of the apparent
damage and notifying any apparent damage to the shipper by registered mail. The manufacturer assumes no responsibility for damage due to transport,
even in if he did the shipping himself.
Great care must be taken in handling the units during unloading and positioning on site, in order to avoid damage to the casing and to the more delicate
internal components such as compressors, exchangers, etc. In any case, keep the unit horizontal without tilting it. All the indications regarding the
precautions necessary to ensure that no damage is done to the unit and the indication of the weight of the same are shown on the packaging. The
materials that make up the packaging can be of various kinds such as wood, cardboard or polyethylene (plastic). It is good practice to send them for
disposal or recycling through specialized companies to reduce their environmental impact.
DISASSEMBLY AND DISPOSAL
Do not disassemble or dispose of the product yourself. The disassembly, demolition, disposal of the product must be carried out by authorized
personnel in accordance with local regulations.

Page9
2 INSTALLATION
INSTALLATION CONDITIONS
The unit must be installed according to the national and local standards governing the use of electrical devices and according to the following
indications:
•install the unit inside residential buildings with an ambient temperature between 0°C and 45°C;
•avoid areas near sources of heat, steam, flammable and/or explosive gases and particularly dusty areas;
•install the unit in a place not subject to frost (the condensed water must be discharged not frozen, at a certain angle, using a siphon);
•do not install the unit in areas with a high relative humidity (such as the bathroom or toilet) to avoid condensation on the external surface;
•choose an installation site where there is sufficient space around the unit for the connections of the air ducts and to be able to carry out
maintenance operations;
•the consistency of the ceiling/wall/floor where the unit will be installed must be suitable for the weight of the unit and not cause vibrations.
In the environment chosen for installation there must be:
- air duct connections;
- 230 V single-phase electrical connection
- connection for the condensate drain
UNIT PLACEMENT
Ceiling mount
To mount the unit on the ceiling you will need:
•Remove the front grille by extracting it levering from the
bottom upwards and extracting it first towards the
bottom;
•remove the lower panel using the front screws and
extracting it from the rear seats;
•Remove the screws on the side panels by removing the
4 screws on the front;
•Push the side to make it come out of the rear seats and
remove it;
•Fix the unit to the ceiling, using the brackets, using
suitable anchoring systems (dowels, chains…) and
check its leveling using a spirit level.
•Keep the unit detached from the ceiling at least 10mm;
•Do not mount the unit with the sides in direct contact
with the walls to avoid possible contact noise, insert
rubber or neoprene strips in this case.
Ensure sufficient space for carrying out maintenance activities: the
opening of the cover of the unit (from below) must be guaranteed.
Ceiling mount

Page10
CONDENSATE DRAIN CONNECTION
Due to the thermodynamic heat recovery system of the
dehumidification coils, the humidity contained in the internal air
condenses inside the unit.
For the correct functioning of the heat recovery unit, it is
therefore necessary to connect the condensate drain to the
hydraulic system (drain); Furthermore, to allow the correct
outflow of the condensate water and avoid air suction, the
condensate drains must be equipped with a special siphon to
be supplied and installed by the installer;
The condensate drain comes out as standard at the rear of the
unit where there should be a hole in the wall as shown
alongside;
If it is impossible to bring the condensate drain outside, it is
possible to exit on the right side of the unit using the pre-cut
hole on the side;
For the installation of the condensate drain, comply with the
following standards:
•give the drain pipe a slope of at least 2%;
•provide for the possibility of disconnecting the drain
pipe for any maintenance (particularly in the case of
ceiling installation);
•make sure that the discharge end of the hose is at
least below the water level of the siphon;
•make sure that the siphon is always full of water.
•The H dimension as per the attached image must be
at least H=50 mm;
Condensate drain connection

Page11
3 AREA CONNECTIONS
AREAUAL ORIENTATIONS
The unit is equipped with 2 circular rear connections for connection to the external air;
For the correct connection of the air ducts, refer to the following diagram and the stickers placed on the unit.
Table of unit aeraulic connection diameters
Unit
..2.0 Rinnova Ceiling
External air Ø mm
Ø Ejection mm
160 mm
We recommend the installation of at least 500 mm of flexible piping to avoid the dragging of vibrations and annoying noises due to the installation.
Configurations Air flows
CONFIGURATION ..2.0 RENEW CEILING
VIEW FROM ABOVE

Page12
INSTALLATION OF EXTERNAL GRILLES
Once the holes have been made, inside them, they must be
introduced the supplied plastic sheets.
Roll up the sheet and introduce it
into the hole, paying attention
to the seam A which must always be positioned upwards.
Cut any excess part of the tube using a normal cutter.
To position the external grids, proceed as follows:
- attach the chains to the ends of the springs;
- fold the external shutters back on themselves;
- introduce the arm into the hole until it protrudes
completely the damper outside maintaining
the end of the chain stitches with the other hand to avoid
accidental falls;
- reopen the damper outside the hole;
- rotate the damper so as to bring the flap in
vertical position C checking that the mechanism
closing functions;
- pull the chains by tensioning the springs;
- cut the links of the chain stitches with a nipper
excess.
- fix the hook of the chain to the wall B.
Only use the grills provided,
or grids that maintain the same
characteristics.
The dampers must be positioned with the fin vertically.
Shutters are different. It is necessary to distinguish that
to be positioned on the intake from the one to be positioned on
the delivery, based on the opening direction of the flaps.
Once the installation of the grilles is completed, check their
opening (inwards the duct for the "IN" suction grille and
towards the outside of the duct for the "OUT" exhaust grille).
Note that the grilles open when the outside air flow is activated
to allow the cooling or heating function. For their testing it is
therefore essential to operate the air conditioner to cool or heat
Installation of external grilles

Page13
4 ELECTRICAL CONNECTIONS
GENERALITY
- Before starting any operation to make the electrical connections, make sure that the unit is not electrically powered
- Make the necessary electrical connections by consulting only the electrical diagram attached to this manual.
- Install a suitable cut-off and differential protection device for the exclusive service of the unit.
- It is essential that the unit is connected to an earth socket.
- Check that the electrical components chosen for installation (main switch, circuit breakers, cable section and terminals) are suitable for the electrical
power of the installed unit and that they take into account the compressor peak currents as well as the maximum load that can be reached. The relative
data are indicated on the attached wiring diagram and on the unit identification plate
- It is forbidden to enter the unit with electric cables unless specified in this booklet.
- Use cables and electrical conductors with adequate sections and compliant with the regulations in force in the various countries.
- Absolutely avoid running the electrical cables in direct contact with pipes or components inside the unit
- After the first moments of operation, check the tightness of the screws of the power supply terminals
Power line sizing table
Models
40
Diet
V/Ph/Hz
230/1/50
Max absorbed current
TO
6.1
CONNECTION PLACEMENT AND PROCEDURES
The unit is supplied with all electrical connections prearranged
and with a shucko plug for connection to the mains;
The electrical cable entry is positioned on the rear of the unit
where two DN 16 mm passages are provided;
If it is impossible to bring the wiring from the rear of the unit, it
is possible to exit on the right side of the unit using the pre-cut
hole on the side;
Furthermore, in the lower part, the electrical panel can be
reached via a dedicated door
Condensate drain connection

Page14
INSERTING THE REMOTE CONTROL BATTERIES
Only a 3 V CR2025 dry lithium battery
(included in delivery) may be used for the
remote control.
Exhausted batteries must be disposed of only
through the appropriate collection points set
up by the Local Authorities for waste of this
type.
To insert the battery, open the special release
door located in the lower part of the remote
control. The battery must be inserted
scrupulously respecting the polarity. Close the
flap after inserting the battery
Remote control batteries

Page15
WIRING DIAGRAM
CONNECTIONS
NL-PE – POWER SUPPLY
The unit is supplied with a power supply
socket connected to terminals N , L , PE ;
HT - EXTERNAL HEATER
It provides for the connection of the
integrative electrical resistance (Accessory) to
be inserted on the air delivery duct
CP- ON OFF REMOTE
Provides an external connection to enable the
unit as an presence or window contact;
Comes with a bridge included;
Connections

Page16
5 COMMISSIONING AND METHOD OF USE
OPERATION OF THE CONTROL PANEL ON THE MACHINEWIFI AND REMOTE CONTROL
The unit is controlled both through the wi-fi panel on the
machine and through the infrared remote control supplied. It is
also possible to download the app and control the main
functions from IOS systems or ANDROID systems;
The display normally shows the operating status (see
paragraph Description of operation) and any alarms (see
paragraph Viewing alarms on the display). Furthermore, by
pressing the various symbols it is possible to select the various
functions. By pressing the keys it is possible to set the various
functions (see paragraph Description of operation). The remote
control supplied with the appliance has been designed to give it
maximum sturdiness and exceptional functionality, however it
must be handled with some caution.
To avoid:
- leave it exposed to rain, spill liquid on its keyboard, or drop it
in water
- make it subject to strong impacts or drop it on hard surfaces
- leave it exposed to sunlight
Wifi machine board panel Remote control
5.1.1.2 TURNING THE UNIT ON AND OFF
In order to manage the appliance using the remote control or the touch screen display, the main switch which has been
provided on the power supply line must be switched on (and on whose position the technician who installed the appliance
can be more precise), or insert the power plug of the appliance into the socket of the system. Once the operations
described have been carried out, by holding down (3 seconds) the symbols on the touch screen display, or with the remote
control, it is possible to manage the system.
To transmit the commands to the indoor unit, turn the front of the remote control towards the display of the indoor unit itself.
Receipt of the command is confirmed by the emission of a note from the buzzer and by the relative visualization on the
display. The maximum distance at which commands can be received is approximately 8 metres. Using the appropriate
button it is possible to turn the appliance off (stand-by) or on. The control system of the appliance is equipped with a
memory, so that all settings will not be lost either in the event of switching off or in the event of a power failure. The button
in question is used to activate and deactivate the appliance for short periods. In the event of a prolonged standstill of the
appliance,
Unit On / Off

Page17
5.1.1.3 MODIFY TEMPERATURE SET
- On the display there are the keys for selecting the desired temperature of the unit;
Every time the set temperature is modified, the display will also show the requested set point variation
Modify set temperature
5.1.1.4 CHANGE FAN SPEED
-By pressing this button sequentially, it is possible to set the power supplied by the appliance to 5 settings: Minimum,
Medium, Maximum, Dual Power and Automatic. The greater the power set, the greater the yield of the appliance, but
the less silent it is.
The Dual Power function (visible by the flashing of the 3 speed bars on the display and the scrolling of the 7 red or blue
bars of the digital thermometer), available in heating and cooling only, provides an Overboost for 30 minutes.
Subsequently, the controller inhibits the function and goes into automatic operation.
By setting the Automatic choice (visible by scrolling the 3 speed bars on the display) the on-board microprocessor
adjusts the power automatically, keeping it higher the greater the difference between the room temperature and the set
temperature. In dehumidification only and nocturnal comfort mode, power control is not possible as the appliance can
only operate at minimum.
Fan speed management
5.1.1.5 AUTOMATIC FUNCTION
By setting this function, the appliance prepares itself so as to obtain optimal comfort in the air-conditioned room.
Depending on the set temperature, the air conditioner automatically selects the operating mode (cooling or heating), and
the fan speed based on the temperature of the room and the quality of the air detected;
AUTO function
5.1.1.6 VENTILATION ONLY FUNCTION
-By activating this function, the compressor is never activated and the appliance does not perform any action either on
the
temperature or humidity in the room. It is possible to choose the fan speed
Ventilation only
5.1.1.7 NIGHT WELLNESS FUNCTION
With the appliance on and cooling or heating mode selected, pressing the button allows you to perform multiple functions
aimed at maximizing the silence of the appliance, saving electricity and regulating night-time well-being. In this mode,
fan operation is set to minimum speed. This feature should be activated immediately before falling asleep
• In cooling, the temperature set is increased by 1 °C after one hour and by a further °C after 2. After the second hour,
the temperature set is not altered further and after another 6 hours the appliance is placed on standby.
• In heating mode, the set temperature is decreased by 1 °C after one hour and by a further °C after 2 hours.
After the second hour, the temperature setting is not altered further and after another 6 hours the appliance is placed in
stand-by. This function is not available for dehumidification only, ventilation only and automatic economy mode and can
be excluded at any time (ideally when you wake up) by pressing the button again.
If the timer function is set at the same time, the appliance will switch off after the set time has elapsed.
Nocturnal well-being

Page18
5.1.1.8 DEHUMIDIFICATION FUNCTION
Using this mode, the appliance dehumidifies the room. Activating this function is therefore particularly useful in mid-
season, ie on those days (such as rainy days for example) in which the temperature is all in all pleasant, but excessive
humidity makes one feel a certain sense of unease. In this mode, both the room temperature setting and the fan speed
setting are ignored, which always correspond to the minimum. With this mode it is normal for the appliance to work
intermittently
Dehumidification
5.1.1.9 SEASON CHANGE
- Season change must be made from the keyboard;
Press and hold the season change button for at least 3 seconds to change the status of the season;
The operation must be carried out to activate the correct logics:
Symbol logic: SUN - WINTER SNOWFLAKE - SUMMER
Season change
5.1.1.10 TIMER FUNCTION
The logic of the appliance provides the User with the possibility of programming its activation or deactivation, as desired.
While the air conditioner is on, it is possible to program its shutdown by pressing the Timer button, followed by setting
the number of hours (from 1 to 24) after which the appliance will go into stand-by. • When the air conditioner is off, it is
possible to preset its switching on by pressing the Timer button, followed by setting the number of hours (from 1 to 24)
after which the appliance will start
Press the key again to confirm.
5.1.1.11 DESCRIPTION OF OPERATION AIR QUALITY SENSOR
-The unit foresees the functioning of the fans according to the pre-selected speed and the internal logics linked to the
value of air quality detected; For each speed, if the air quality is not optimal, the fans increase the flow rates to have a
greater air exchange and improve the quality of the internal air;
5.1.1.12 UVC LAMP OPERATION DESCRIPTION
-The unit foresees the operation of a germicidal UVC lamp placed in the new air intake section;
The lamp is activated permanently together with the activation of the fans;

Page19
6 MAINTENANCE
To always guarantee the correct and optimal functioning of the unit, it is necessary to carry out all the maintenance interventions periodically.
CLEANING OR REPLACING EPM1 FILTERS
To replace the filters, or clean them, proceed as follows:
•remove power to the unit;
•remove the front grille
•extract the 2 dirty filters by sliding downwards;
•gently insert the new filters;
•close the front grille;
If the conditions of the filters allow it, they can be cleaned using a vacuum cleaner or a
low pressure compressor.
Filter extraction view
REPLACING THE PREFILTER
To clean the external air pre-filter, proceed as follows:
•remove power to the unit;
•Remove the front grille
•remove the lower panel using the front screws and extracting it from the rear
seats;
•remove the inspection door using the dedicated screws;
•take out the filter;
If the conditions of the filters allow it, they can be cleaned using a vacuum cleaner or a
low pressure compressor.
•Close the filter cover making sure that you tighten all the screws;
•Reposition the lower panel in its seats and insert the screws in the front part;
•Reposition the grate in its seat;
Filter extraction view

Page20
LAMP MAINTENANCE
To carry out maintenance on the UVC lamp:
•Cut power to the unit;
•Remove the front grille
•Remove the intake air filter to access the UV lamp;
•The UV lamp will be clearly visible behind the filter;
•Remove the lamp from the support and from the connector, being careful to
extract it gently
•Replace and reseat the new lamp
•Reinsert the filter in its seat;
•Finally, position the front grille,
Attention
Never carry out these operations with the lamp and the unit powered;
UVC rays can cause damage to the skin and eyes;
View for lamp maintenance
