Monopoly Roll -N- Go Marquee Two Cabinet Assembly Guide
Innovative Concepts in Entertainment
10123 Main Street
Clarence, NY 14031
[phone] Service Department

AC Splitter for Network Switch adaptor.
Long AC power Cable.
Short extension cable.
Keys and hardware.
What is included with your Marquee for A Two Cabinet Install
Another network cable for the upper sign.
You should have a total of three.
USB A to B cable.
DVI to Display port cable
Network switch, AC adaptor and 2 network cables.
Rev F

Step 1:
Position the two games leaving
1/2” between them at the front.
1/2”
Installing the Marquee on top of two games.
Step 2:
Unlock the back cover from the mount. This mount has the
electronics in it.
Facing the back of the game, the cabinet to the right will have
the mount that contains all the electronics. The cabinet to the
left will have the mount with no electronics.

Step 3:
Secure the cabinet mounts to the top of the
cabinets. Use four AA6220 bolts and
AA6070 washers.
Make sure the mount with the
electronics are on top of the
cabinet on the left looking at
the front of the game
(right if from the back!).
Step 4:
Slide the right upper assembly over and onto
the mount as shown.

Step 5:
Secure it to the mount using two AA6212
bolts and two AA6281 washers.
Step 6:
Slide the left upper assembly over and onto the mount as
shown. Then secure using two AA6281 bolts and two
AA6212 washers.

Step 7:
At each side of the center display are the
mounting inserts. They are shown within the
circles. They insert into slots in each of the top
signs. One of those slots are shown.
Insert the center display into the two slots.
Step 8:
Secure the display using two AA6281 bolts and AA6212 washers.
Location is shown with the yellow circles with arrows.

Step 9:
Connect one end of a network cable to the marquee electronic box. Then connect the other end to
the top connector (port B) center display.

Step 10:
Locate the left and right connectors coming out of the marquee electronics box. They are labeled as
if you were standing in front of the game. FROM THE BACK OF THE GAME, plug the left harness
directly into the RIGHT side panel (the same with the electronics).
Labeled as if you were in front of the game!
Step 11:
Then use the extension cable to connect the right harness to the left sign.

Step 13:
Slide the sign onto the poles.
Step 12:
Connect the 6 pin power harness to the
display board.

Step 15:
Carefully wire tie all wires and neatly tuck them inside this channel.
Secure the wire channel using two AA6177 screws and 2 AA6031 washers.
Step 14:
Connect the 3 pin power harness to the upper sign.

Step 16:
Plug the long AC cord in to the side of the cabinet.
Make sure switch is set to on (1).
Step 17:
Plug in the USB cable and DVI to
display port cable into the marquee
electronics box.

Step 18:
Route the USB and DVI cables inside the cabinet through the top. They will be con-
nected to the bottom of the cabinet at the PC.
Step 19:
Connect the display port connector (DVI to display port cable) to the video card’s dis-
play port connection (NOT MOTHERBOARD!). Then connect the USB cable in any
available USB connector.

Step 20:
Unplug one of the AC connections at the bottom of the game and next to the power
module. Then plug the AC Y-splitter into where you unplugged the AC connector.
You should now have a AC outlet to plug the network switch power adaptor into.
Step 21:
Plug the AC power adaptor for the network switch into the AC outlet you just added.
Then connector a network cable from the network switch to each computer’s network
connector.

Step 22:
Open the operator panel at the bottom of the cabinet. Press the program button to
enter the main menu. Navigate to the system settings of each game.
On the left game set mega marquee master to on and then set machine ID to 1.
On the right game set Mega marquee master to off and set machine ID to 2.

MY DISPLAY IS UPSIDE DOWN!!
Open the operator panel at the bottom of the cabinet. Press the program button to
enter the main menu. Navigate to the system settings of each game.
On the left machine navigate to the system settings and increase the value of
the mega marquee LED angle. Keep doing so until the display is correct.
