Inova Aeroski User manual

ASSEMBLY
MANUAL

1. Main Frame
2. Spring (x3).
A. Knob (x3). (Pre-assembled)
B. Plastic washer (x2).
C. O-ring (x1).
D. Pulley knob (x1). (Pre-assembled)
3. Fitness monitor.
4. Cart.
5. Right swiveling foot pedal.
6. Left swiveling foot pedal.
7. Front end caps (x2).
8. Rear end caps (x2).
9. Upper handle bar.
10. Lower pole right.
11. Lower pole left.
12. Upper pole right.
13. Upper pole left.
14. Screws M5X15 (x4).
15. Screws M6X20 (x2).
16. Knobs (x2).
17. Allen Key / Hex screwdriver.
18. Safety hook (attached to the main frame).
INCLUDED PARTS:
2Materials: Carbon Steel. Molded polyethylene housings.
Additional spring sold separately.
1
3
8
4
2 A B C D
9
14
12 13
10 11
5
7
15 16 17 18
6
(Pre-assembled)

A. Insert the front end caps (7), and rear end caps (8) into
the main frame (1) on each side.
B. Secure the caps with the screws M5x15 (14). Screw one
by one through the back of each of the covers with the
hexagonal screwdriver of the Allen key (17). (Figure 1)
3
STEP 2
A. Insert tness monitor (3) into the front part of the cart (4).
(Figure 2)
B. Manually unscrew the knobs (A) from the central rods at the cart.
C. Set the springs (2) -according the arrows direction- into the
rods at the center of each side of the cart (4). Screw knobs (A)
again into the rods to secure springs. (Figure 3)
STEP 1
NOTE: AeroSki comes with 3 springs. Additional springs can be bought at tryaeroski.com.
We recommend trying 2-3 springs initially and adjust according to weight and preference.
You can use up to 4 springs (2 on each side).
STEP 1
STEP 2
tryaeroski.com
A
A
SEE ARROW
DIRECTION LABEL
A
2
2
2
A

4
STEP 4
A. Place the right pedal (5) and left pedal (6) on the cart (4).
Take the slots in the sliding base as a guide to insert the pedals.
To identify the left and right pedal, keep in mind that the “AeroSki”
logo should be under your heels.
B. Insert lower pole (10) and (11) in the xed guide on the front
side of the main frame (1).
C. With the hex screwdriver (17) screw-in and tighten one screw
M5x20 (15) on each side, at the front slot of each of the xed
guides. (Figure 5)
D. Manually screw-in and tighten knobs (16) on each side,
in the holes below the slots. (Figure 5)
STEP 3
A. Manually unscrew knobs (A) and pulley knob (D) from the
main frame (1) center rods.
B. Insert a plastic washer (B) on each side at the main frame
center rods, then set the cart (4) onto the main frame (1) making
sure rollers slide over rails (Figure 4). Insert the springs into the
the center rods on each side of the main frame (1).
C. If your are using an extra spring, insert an O-ring (C) between
springs, then manually screw knob (A) at one side and then
manuallyscrewpulleyknob(D)ontheotherside(safetyhookside).
D. Manually screw knob (A) and pulley knob (D) into the main
frame (1) center rods. Inmovilize the cart with the safety hook.
STEP 4
STEP 3
BACK VIEW
CART SECURED WITH HOOK
2
2
A
C
B
B
D
2
1

5
STEP 6
(POLES SET UP)
A. Manually unscrew the knobs (16) and place them in orice, for safe
keeping. (Figure 10)
B. Remove upper handle (9) from lower poles (10/11) by pressing the
safety push buttons. (FIgure 11) First remove one side, pressing the
safety button and pulling the joint slightly towards your body, then pull it
up; afterwards remove the other end normally.
C. Insert upper poles (12/13) into the lower poles (10/11) by pressing the
push buttons so they pop out from corresponding orice in the lower
pole. (Figures 8 and 9)
STEP 5
A. Insert upper handle (9) into lower poles (10/11) by
pressing the safety push buttons so that they pop out from the
corresponding orice in the lower pole. (Figures 6 and 7)
* The safety buttons should point towards the rear end caps.
Make sure all pieces are securely tightened before using the equipment.
Wipe down your equipment regularly, specially the main frame track, with
a soft cloth and a mild cleanser. Keeping your AeroSki clean will ensure a
longer lasting, smoother running machine.
STEP 6
STEP 5
It is highly recommended to place a mat under your Aeroski to avoid any stains
from lubricants the machine might release, especially with surrounding carpet.
tryaeroski.com

6
STEPPING ON THE AEROSKI USING THE HOOK
(REGULAR SET UP)
CAUTION: You should always use the safety hook every time you start working out.
A. Lift the safety hook (18) by pressing the pedal with your foot, in order to attach it to the pin that holds the resistance springs.
B. Stand on the back of the machine and grab the upper handle (9) with both hands.
C. Lift your right leg and set your right foot on the right swiveling foot pedal (5).
D. Step on, using your right leg, lift your left leg and set your left foot on the left swiveling foot pedal (6). Make sure both feet are rmly positioned on each
foot pedal and that you are balanced.
E. Switch your weight to your left leg and swing to your left. The safety hook will immediately disengage so you can start exercising.
9
56
View of the Safety Hook (18) View of the Safety Hook (18)
In order to lift the safety hook, just
press the pedal with your foot.
After you swing, the hook
will disengage.

7
CAUTION:
You must step off the Aeroski while
standing still and gripping the upper
handles at all times.
To step on and off the
AeroSki and to use the poles
setting, reapeat the same steps
described for the regular setting.
STEPPING OFF THE AEROSKI
(REGULAR SET UP)
A. Stop all movement and stand still while gripping both hands on the upper handle
bars (9).
B. If you are right footed, lift your left leg and set your left foot on the floor. If you are
left footed, do the opposite.
C. Once your left foot is on the floor, lift your right leg and set your right foot on the
floor. If you are left footed, do the opposite.
CAUTION: You should
always use the safety
hook every time you
start working out.
WARNINGS
Place your AeroSki on a stable surface, leaving at least 2 meters of distance around the device.
It is recommended to place an exercise mat under the AeroSki to protect the floor / carpet from
any damage. * Keep the equipment indoors, to avoid dust and moisture. * Always keep children
under 12 and pets away from the appliance. * Minor children should not remain alone, without
adult supervision, in the same room as the appliance. * People with disabilities should not use
the equipment without the supervision of a professional. * Consult your doctor before starting any
exercise, especially if you are concerned about your physical condition and ability to use AeroSki. *
The equipment must not be used by more than one person at a time. * DO NOT use the appliance if
you are tired or under the influence of drugs or alcohol. * Do not wear loose, loose clothing, jewelry
or accessories that may get stuck in the appliance mechanism. * If you feel dizzy, nausea, chest
pain or any other abnormal symptom, stop exercising and consult your doctor immediately. * Do
not use solvents or abrasives to clean the equipment. * To avoid damaging the screen, do not bring
it near liquids or expose it to sunlight.
VERY IMPORTANT:
When exercising, always keep your weight at both legs.
Use the top rail (9) just to maintain your balance, do not
lean on it. The maximum user weight is 100 kg (220 lb).
Frontal view
of the
Safety Hook
(18)
tryaeroski.com

TO TURN ON THE MONITOR, PRESS THE MIDDLE BUTTON FIRST AND
PRESS ONE AT A TIME, TO SCROLL THROUGH THE 7 DIFFERENT MODES.
SCAN
TIME
SPEED
DISTANCE
In miles.
CYCLES
REPETITIONS
(Cycles/Minutes)
CALORIES
FITNESS MONITOR
8
A. Remove the tness monitor (3) from the cart (4).
B.Take out the batteries.
C.Replace the new batteries. Make sure the batteries are inserted with
the polarities in the correct directions.
D. Put the tness monitor back in the car cart (4).
1. Use 2 batteries AAA (1.5 V)
2. Install only new batteries of the same type.
3. Failure to insert batteries in the correct polarity, as indicated in the ba-
ttery compartment, will result in malfunction and/or cause batteries
to leak.
4. Do not mix old and new batteries.
5. Do not mix Alkaline, Standard (carbon-zinc) or Rechargeable (nickel
cadmium) or Nickel Metal Hydride batteries.
6. Do not expose batteries to re.
7. Batteries should be recycled or disposed of as per state and local
guidelines.
BATTERY REPLACEMENT (Battery included)
BATTERY CAUTION & DISPOSAL
• If the monitor doesn´t display clearly or
only partial segments appear, remove
the battery and wait fteen seconds
before reinstalling.
• Estimated battery life is approximately
3 months under normal use.
• When the battery is removed, all function
values return to zero.

9
WARNINGS WARRANTY
Place the machine on a at and stable surface, leaving at least 2
meters of space around it. It is recommended to place a tness
mat under the equipment to protect the oor and / or carpet from
any possible damage • Keep the equipment indoors and away from
moisture or dust • Keep children under 12 and pets away from the
equipment at all times. Children should not be left alone in the room
with equipment. • People with disability should not use the equip-
ment without supervision of qualied personnel • Consult your phy-
sician before beginning any exercise, especially if you have concer-
ns about your level of physical tness and to determine if you are
qualied to exercise using AeroSki. • Never allow more than one
person at a time to use the equipment • Do not use the equipment if
you feel tired or are under the inuence of drugs or alcohol • When
using the equipment, wear appropriate exercise clothing- do not
wear loose clothing or jewelry or accessories that may get stuck in
the mechanical parts. • If you experience dizziness, nausea, chest
pain or any other abnormal symptoms, stop exercising and consult
your doctor immediately. Never use abrasives or solvents to clean
the equipment. To prevent possible damage to the computer, keep
liquids away and avoid contact with the sunlight.
VERY IMPORTANT: While working out, always maintain your weight
on both legs. Use the Upper Handle (9) only for keeping your balance.
Do not lean forward and shift weight to your arms. Maximum user
weight should not exceed 220 lb (100 kg).
BEFORE RETURNING THIS PRODUCT TO THE STORE
We will be happy to assist you with any problem you may have and
we are glad to answer any questions regarding the purchase of this
product. Please contact us at our Toll-Free Customer Service Line
[phone].
You may also e-mail us at [email protected] or visit our web
site at tryaeroski.com
Thank you!
AEROSKI LIMITED WARRANTY ONE (1) YEAR (VALID ONLY FOR PURCHASES IN USA AND ITS TERRITORIES)
Warranty: Inova US (“Inova”) warrants to the original AeroSki purchaser (“Customer”), and only to the Customer, that the AeroSki
(“Product”) for which the Customer received this warranty was designed, developed, manufactured and/or assembled using all due
reasonable commercial care and good manufacturing practices. Inova US Product shall be, when properly assembled and used,
free from defects in material and workmanship and t for the ordinary porpose for which such Product is used for one (1) year from
original date of purchase. Inova’s sole obligation under this warranty is to repair or replace the Product, at Inova’s option. Inova’s
obligations to the buyer hereunder shall be conditioned upon the buyer’s notifying Inova of the claimed defect within thirty (30)
days of the discovery thereof and upon the Product: (I) being returned, freight prepaid, to Inova at the address below; (II) being found
defective; (III) being found to have been properly assembled and used (if assembled and/or used); and (IV) being returned within one
(1) year from the date of sale to the buyer.
Warranty and Liability Disclaimer: INOVA MAKES NO OTHER WARRANTIES OR REPRESENTATIONS OF ANY KIND WHATSOEVER,
EXPRESS OR IMPLIED, EXCEPT THAT OF TITLE, AND ALL IMPLIED WARRANTIES INCLUDING ANY WARRANTY OF MERCHANTA-
BILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY DISCLAIMED. Notwithstanding the foregoing, the duration of any
implied warranty or condition of merchantability, tness for a particular purpose, or otherwise, on the Product that may be found to
be made shall be limited to the duration of the express warranty set forth above. In no event shall Inova be liable for any loss, incon-
venience, damage, or personal injury, whether direct, incidental, consequential or otherwise, resulting from breach of any express or
implied warranty or condition of merchantability, tness for a particular purpose or otherwise with respect to the Product, or from use
of the Product, except as set forth herein. Some states or countries do not allow limitation on how long an implied warranty lasts and
some do not allow exclusions or limitations of incidental or consequential damages, so the above limitations or exclusions may not
apply to you. This warranty ives you specic legal rights, and you may have other rights which may vary from location to location. This
warranty will be interpreted pursuant to the laws of the United States and the State of Florida. The original English version (meaning)
of this warranty controls over all translations; Inova is not responsible for any errors in translation of this warranty and/or any Product
instructions. This warranty is not intended to confer any additional legal, jurisdictional or warranty rights to you other than those set
forth herein or required by law. If any portion of this warranty is held to be invalid or unenforceable for any reason, such nding will
not invalidate any other provision.
Warranty Service Options: For service under this warranty you must notify Inova in writing within 30 days to obtain a Returned Mer-
chandise Authorization (RMA). When requesting your RMA, you must specify the Product in question by providing the order number.
TO OBTAIN ASSISTANCE in USA and its Territories Contact AeroSki Customer Care Center:
Phone: [phone] Email: [email protected] Website: www.tryaeroski.com
Any insurance and/or shipping costs incurred in returning your Product under the approved Returned Material warranty option are
your responsibility. Inova will not be responsible for any products lost or damaged in shipment.
Warranty Exclusions: Representatives and brokers of Inova products and services are not authorized to modify this warranty in any
way. It is the Customer’s responsibility to examine the Product regularly to determine the need for normal service or replacement.
This warranty does not cover the following:
• Products that have been modied, neglected or poorly mantained, misused, abused, or involved in accidents or natural disasters;
• Damage occurring during shipment of the Product (such claims must be presented directly to the freight forwarder or shipping company);
• Damage to the Product resulting from improper maintenance or repair, the use or installation of parts and/or accessories that are
not compatible with the original intended use of the Product, or the failure to follow the Product warnings and usage instructions or
by anyone weighting more than 220 lb (100 kg);
• Any products for which the Customer does not follow the warranty procedures outlined above.
Warranty for other Countries/Territories see attached sheet.
tryaeroski.com

10
DISPUTE RESOLUTION BY BINDING ARBITRATION: PLEASE READ THIS CAREFULLY. IT AFFECTS YOUR RIGHTS.
Summary:
Most customer concerns can be resolved quickly and to the customer’s satisfaction by calling our customer
service department at [phone]. In the unlikely event that AeroSki’s customer service department is unable
to resolve a complaint to your satisfaction (or if AeroSki has not been able to resolve a dispute between us after
attempting to do so informally or through mediation), we each agree to resolve those disputes through binding
arbitration or small claims court instead of in courts of general jurisdiction. Arbitration is more informal than a
lawsuit in court. Arbitration uses a NEUTRAL ARBITRATOR instead of a judge or jury. You thus GIVE UP YOUR
RIGHT TO GO TO COURT to assert or defend your rights under this contract (EXCEPT for matters that may be
taken to SMALL CLAIMS COURT). You are entitled to LEGAL REPRESENTATION and a FAIR HEARING, BUT
the arbitration procedures, including discovery, are SIMPLER, MORE LIMITED AND USUALLY FASTER THAN
PROCEEDINGS IN COURT. Arbitration decisions are as enforceable as any court order BUT ARE SUBJECT TO
VERY LIMITED REVIEW BY A COURT. Arbitrators can award the same damages and relief that a court can award.
Any arbitration under this Agreement will take place on an INDIVIDUAL BASIS; CLASS ARBITRATIONS AND
CLASS ACTIONS ARE NOT PERMITTED. For any non-frivolous claim that does not exceed $75,000, AeroSki will
pay all costs of the arbitration. Moreover, in arbitration you are entitled to recover attorneys’ fees from AeroSki to
at least the same extent as you would be in court. In addition, under certain circumstances (as explained below),
AeroSki will pay you more than the amount of the arbitrator’s award and will pay your attorney (if any) twice his
or her reasonable attorneys’ fees if the arbitrator awards you an amount that is greater than what AeroSki has
offered you to settle the dispute.
ARBITRATION AGREEMENT
(1) AeroSki and you agree to arbitrate all disputes and claims between us. This agreement to arbitrate is intended
to be broadly interpreted. It includes, but is not limited to:
• claims arising out of or relating to any aspect of the relationship between us, whether based in contract, tort,
statute, fraud, misrepresentation or any other legal theory;
• claims that arose before this or any prior Agreement (including, but not limited to, claims relating to advertising);
• claims that are currently the subject of purported class action litigation in which you are not a member of a
certied class; and
• claims that may arise after the termination of this Agreement.
References to AeroSki,” “you,” and “us” include our respective subsidiaries, afliates, agents, employees, prede-
cessors in interest, successors, and assigns, as well as all authorized or unauthorized users or beneciaries of
products and services under this or prior Agreements between us. Notwithstanding the foregoing, either party
may bring an individual action in small claims court. This arbitration agreement does not preclude you from
bringing issues to the attention of federal, state, or local agencies, including, for example, the Federal Trade Com-
mission or Consumer Product Safety Commission. Such agencies can, if the law allows, seek relief against us on
your behalf. You agree that, by entering into this Agreement, you and AeroSki are each WAIVING THE RIGHT TO A
TRIAL BY JURY OR TO PARTICIPATE IN A CLASS ACTION. This Agreement evidences a transaction in interstate
commerce, and thus the Federal Arbitration Act governs the interpretation and enforcement of this provision.
This arbitration provision shall survive termination of this Agreement.
(2) A party who intends to seek arbitration must rst send to the other, by certied mail, a written Notice of Dis-
pute (“Notice”). The Notice to AeroSki should be addressed to: Ofce for Dispute Resolution, AeroSki, 4095 State
Road 7 Ste L216, Wellington, FL 33449 (“Notice Address”). The Notice must (a) describe the nature and basis of
the claim or dispute; and (b) set forth the specic relief sought (“Demand”). If AeroSki and you do not
reach an agreement to resolve the claim within 30 days after the Notice is received, you or AeroSki may
commence an arbitration proceeding. During the arbitration, the amount of any settlement offer made
by AeroSki or you shall not be disclosed to the arbitrator until after the arbitrator determines the amount,
if any, to which you or AeroSki is entitled.
(3) After AeroSki receives notice at the Notice Address that you have commenced arbitration, it will
promptly reimburse you for your payment of the ling fee, unless your claim is for greater than $75,000.
(The ling fee currently is $125 for claims under $10,000 but is subject to change by the arbitration
provider. If you are unable to pay this fee, AeroSki will pay it directly upon receiving a written request
at the Notice Address.) The arbitration will be governed by the Commercial Arbitration Rules and the
Supplementary Procedures for Consumer Related Disputes (collectively, “AAA Rules”) of the American
Arbitration Association (“AAA”), as modied by this Agreement, and will be administered by the AAA.
The AAA Rules are available online at adr.org, by calling the AAA at 1-800-778-7879, or by writing to the
Notice Address. The arbitrator is bound by the terms of this Agreement. All issues are for the arbitrator
to decide, except that issues relating to the scope and enforceability of the arbitration provision are for
the court to decide. Unless AeroSki and you agree otherwise, or the arbitrator directs otherwise, any
arbitration hearings will take place in the county of your billing address. If your claim is for $10,000 or
less, we agree that you may choose whether the arbitration will be conducted solely on the basis of
documents submitted to the arbitrator, through a telephonic hearing, or by an in-person hearing as
established by the AAA Rules. If your claim exceeds $10,000, the right to a hearing will be determined by
the AAA Rules. Regardless of the manner in which the arbitration is conducted, the arbitrator shall issue
a reasoned written decision sufcient to explain the essential ndings and conclusions on which the
award is based. Except as otherwise provided for herein, AeroSki will pay all AAA ling, administration,
and arbitrator fees for any arbitration initiated in accordance with the notice requirements above. (Each
party shall pay the fees and costs of its own counsel, experts and witnesses.) If, however, the arbitrator
nds that either the substance of your claim or the relief sought in the Demand is frivolous or brought
for an improper purpose (as measured by the standards set forth in Federal Rule of Civil Procedure
11(b)), then the payment of all such fees will be governed by the AAA Rules. In such case, you agree to
reimburse AeroSki for all monies previously disbursed by it that are otherwise your obligation to pay
under the AAA Rules. In addition, if you initiate an arbitration in which you seek more than $75,000 in
damages, the payment of these fees will be governed by the AAA rules.
(4) If, after nding in your favor in any respect on the merits of your claim, the arbitrator issues you an
award that is greater than the value of AeroSki’s last written settlement offer made before an arbitrator
was selected, then AeroSki will:
° pay you the amount of the award or $5,000 (“the alternative payment”), whichever is greater; and
• pay your attorney, if any, twice the amount of attorneys’ fees, and reimburse any expenses (including
expert witness fees and costs) that your attorney reasonably accrues for investigating, preparing, and
pursuing your claim in arbitration (“the attorney premium”).
If AeroSki did not make a written offer to settle the dispute before an arbitrator was selected, you and
your attorney will be entitled to receive the alternative payment and the attorney premium, respectively,
if the arbitrator awards you any relief on the merits. The arbitrator may make rulings and resolve dispu-
tes as to the payment and reimbursement of fees, expenses, and the alternative payment and attorney
premium at any time during the proceeding and upon request from either party made within 14 days of
the arbitrator’s ruling on the merits.
ARBITRATION

11
(5) The right to attorneys’ fees and expenses discussed in paragraph (4) supplements any right to
attorneys’ fees and expenses you may have under applicable law. Thus, if you would be entitled
to a larger amount under the applicable law, this provision does not preclude the arbitrator from
awarding you that amount. However, you may not recover duplicative awards of attorneys’ fees
or costs. Although under some laws AeroSki may have a right to an award of attorneys’ fees and
expenses if it prevails in an arbitration, AeroSki agrees that it will not seek such an award.
(6) The arbitrator may award declaratory or injunctive relief only in favor of the individual party
seeking relief and only to the extent necessary to provide relief warranted by that party’s individual
claim. YOU AND AEROSKI AGREE THAT EACH MAY BRING CLAIMS AGAINST THE OTHER ONLY
IN YOUR OR ITS INDIVIDUAL CAPACITY, AND NOT AS A PLAINTIFF OR CLASS MEMBER IN ANY
PURPORTED CLASS OR REPRESENTATIVE PROCEEDING. Further, unless both you and AeroSki
agree otherwise, the arbitrator may not consolidate more than one person’s claims, and may not
otherwise preside over any form of a representative or class proceeding. If this specic provision
is found to be unenforceable, then the entirety of this arbitration provision shall be null and void.
tryaeroski.com

Imported and Distributed by:
INOVA US
Wellington, FL 33449
