INOXPA BALL Manual

BALL VALVE
A640
Original Instructions
10.110.30.03EN
(0) 2020/09
INSTALLATION, SERVICE AND MAINTENANCE INSTRUCTIONS
10.010.32.0024

E C D e c l a r a t i o n o f C o n f o r m i t y
Model:
INOXPA S.A.U.
Telers, 60
17820 - Banyoles (Spain)
hereby declare under our sole responsibility that the
Type
Serial number:
BALL
A640 (DN 25 - DN 100 / OD 1’’ - OD 4’’)
IXXXXXX o XXXXXXXXXIIN
fullls all the relevant provisions of the following directive:
The technical le has been prepared by the signer of this document.
Technical O󰀩ce Manager
25th September 2020
10.110.30.02ES
(0) 2020/09
Document:
Revisión:
Machine: VALVE
and with the following harmonized standards and/or regulations:
David Reyero Brunet
Machinery Directive 2006/42/EC1
Pressure Equipment Directive 2014/68/EU
Regulation (EC) nº 1935/2004
ATEX Directive 2014/34/EU2
EN ISO 12100:2010, EN 1127-1:2019, EN ISO 13732-1:2008, EN 1672-2:2005+A1:2009,
EN 1127-1:2019, EN 13237:2012, EN 15198:2007, EN ISO 80079-36:2016, EN ISO
80079-37:2016, EN IEC 60079-0:2018, EN 19:2016, EN 12266-1:2012
II 2G Ex h IIB T4 Gb
II 2D Ex h IIIB T125ºC Db
A copy of the technical le is in the possession of the notied body L.C.I.E. with reference
number 0081
1) A480/A490 with pneumatic actuator A940 series
2) A480/A490 with the following drives: two positions handle, actuator A940 series

1. Table of Contents
1. Table of Contents
2. Generalities
2.1. Instructions manual.................................................................................................................................4
2.2. Compliance with the instructions ............................................................................................................4
2.3. Warranty..................................................................................................................................................4
3. Safety
3.1. Warning symbols.....................................................................................................................................5
3.2. General safety instructions .....................................................................................................................5
4. General Information
4.1. Description ..............................................................................................................................................7
4.2.Application...............................................................................................................................................7
4.3. Scope of the ATEX certication...............................................................................................................7
5. Installation
5.1. Reception of the valve ............................................................................................................................8
5.2.Transport and storage.............................................................................................................................8
5.3. Identication of the valve ........................................................................................................................8
5.4. Location ................................................................................................................................................10
5.5. General installation ...............................................................................................................................10
5.6. Checking and review............................................................................................................................. 10
5.7. Welding ................................................................................................................................................. 11
5.8. Connecting the air to actuator............................................................................................................... 12
6. Start-up
6.1. Operating with two position handle .......................................................................................................14
7. Operating problems
8. Maintenance
8.1. General considerations .........................................................................................................................16
8.2. Maintenance .........................................................................................................................................16
8.3. Cleaning................................................................................................................................................17
8.4. Disassembly and assembly the valve ...................................................................................................18
8.5. Disassembly and assembly of the ball.................................................................................................. 19
8.6. Disassembly and assembly of the manual drive................................................................................... 20
8.7. Disassembly and assembly of the pneumatic drive .............................................................................. 21
8.8. Fitting the seat seal............................................................................................................................... 22
8.9. Actuator tting options...........................................................................................................................22
8.10. Valve position......................................................................................................................................22
9. Technical Specications
9.1. Valve ..................................................................................................................................................... 23
9.2.Actuator.................................................................................................................................................23
9.3. Materials ...............................................................................................................................................24
9.4. Sizes available ......................................................................................................................................24
9.5. Weight of the ball valve A640................................................................................................................24
9.6.Tightening torque .................................................................................................................................. 24
9.7. Dimensions of the ball valve A640 with two positions handle ............................................................... 25
9.8. Dimensions of the ball valve A640 with actuator...................................................................................25
9.9. Dimensions of the ball valve A640 with actuator and C-TOP S ............................................................ 26
9.10. Exploded drawing and parts list of the ball valve A640....................................................................... 27
INOXPA S.A.U. 10.110.30.03EN · (0) 2020/09 3

2. Generalities
2.1. INSTRUCTIONS MANUAL
This manual contains information about the reception, installation, operation, assembly and mainte-
nance of the ball valve A640.
Carefully read the instruction prior to starting the valve, familiarize yourself with the installation, ope-
ration and correct use of the valve and strictly follow the instructions. These instructions should be
kept in a safe location near the installation area.
The information published in the instruction manual is based on updated data.
INOXPA reserves the right to modify this instruction manual without prior notice.
2.2. COMPLIANCE WITH THE INSTRUCTIONS
Not following the instructions may impose a risk for the operators, the environment and the machine,
and may cause the loss of the right to claim damages.
This non-compliance may cause the following risks:
- failure of important machine/plant functions,
- failure of specic maintenance and repair procedures,
- possible electrical, mechanical and chemical hazards,
- risk to the environment due to the type of substances released.
2.3. WARRANTY
The conditions of the warranty are specied in the General Sales Condition that have been delivered
at time of placing your order.
The machine may not undergo any modication without prior approval form the manu-
facturer.
For your safety, only use original spare parts and accessories. The usage of other parts
will relieve the manufacturer of any liability.
Changing the service conditions can only be carried out with prior written authorization
from INOXPA.
Please do not hesitate to contact us in case of doubts or if further explanations are required regar-
ding specic data (adjustments, assembly, disassembly, etc.).
Generalities
INOXPA S.A.U. 10.110.30.03EN · (0) 2020/09
4

3.1. WARNING SYMBOLS
3. Safety
Safety hazard for people in general and/or for equipment
Electric hazard
ATTENTION Important instruction to prevent damage to the equipment and/or its function
3.2. GENERAL SAFETY INSTRUCTIONS
Read the instruction manual carefully before installing and starting the valve. Contact
INOXPA in case of doubt.
3.2.1. During installation
Always take into account the Technical Specications of chapter 9.
The installation and use of the valve should always be in accordance with applicable
regulations in regard to health and safety.
Before starting up the valve, check that it is assembled correctly and its shaft is perfectly
aligned. Incorrect alignment and/or excessive stress during coupling can cause serious
mechanical problems in the valve.
Important indications for explosion protection
Do an earth connection of the valve in order to ensure an electrical continuity between
pipes and valves to reduce a risk caused by the static electricity.
3.2.2. During operation
Always take into account the Technical Specications of chapter 9.
NEVER exceed the specied limit values.
NEVER touch the valve and/or piping that is in contact with the uid during operation. If
the process involves hot products there is a risk of burns.
The valve contains parts that move in a linear fashion. Do not place hands or ngers in
the valve closing area. This can cause serious injury.
Safety
5
INOXPA S.A.U. 10.110.30.03EN · (0) 2020/09

3.2.3. During maintenance
Always take into account the Technical Specications of chapter 9.
NEVER disassemble or remove the valve until the pipes have been emptied. Bear in
mind that the uid in the pipe may be hazardous or extremely hot. Consult the regula-
tions in e󰀨ect in each country for these cases.
Inside the actuator there is a spring with an applied load. The steps specied in this ma-
nual must be followed when performing maintenance operations to avoid injury.
Do not leave loose parts on the oor.
All electrical work must be carried out by authorised personnel.
NEVER exceed limit values of the working conditions in explosive atmospheres.
The valve and/or the actuator have been selected according to the working conditions
specied by the customer. INOXPA is not responsible for damages caused by using the
valve in di󰀨erent working conditions than those expressed by the customer.
All assembly/disassembly works of the valve and/or actuator that be carried out in explo-
sive atmospheres or in places where can be generated must be carried out by authorised
personnel to work in explosive atmospheres.
Safety
INOXPA S.A.U. 10.110.30.03EN · (0) 2020/09
6

4. General Information
The ball valve A640 is an hygienic valve which incorporates a perforated ball inside the body. The
perforated ball allows the ow of a uid. It can be manual or automatic drive. With both drives
The valve can be manual or automatic drive. A two position handle is used for the manual drive and
an actuator is used for the automatic drive. The two position handle blocks the valve in the open or
close position and the actuator transforms the axial movement of the piston into a 90º rotary move-
ment which it transmits to the ball.
The design of the valve allows an easy inspection and a simple maintenance.
4.1. DESCRIPTION
4.2. APPLICATION
The ball valves can be used with viscous uids o uids with solids in suspension in the food-proces-
sing, beverage, wine, oil, cosmetic and chemical industries.
4.3. SCOPE OF THE ATEX CERTIFICATION
Only are compliant to the essential health and safety requirements of Directive 2014/34/EU the val-
ves tted with two position handle or air operated actuator A940 series, all of them INOXPA brand.
The manufacturer of an assembly consisting of di󰀨erent compliant pieces of equipment or compo-
nents as dened by Directive 2014/34/EU, must perform his own risk assessment of the assembly
and full with all the obligations of manufacturers that are required in the Directive 2014/34/EU.
General Information
7
INOXPA S.A.U. 10.110.30.03EN · (0) 2020/09

INOXPA is not liable for any deterioration of the material caused by its transport or unpac-
king
When receipt the valve, check to see whether all the parts listed on the delivery slip are present:
- complete valve
- its components if any are supplied,
- instruction manual.
INOXPA inspects all its equipment before packaging. However, it cannot guarantee that the mer-
chandise arrives to the user intact.
When unpacking the valve:
- remove any possible traces of packaging from the valve or its parts,
- inspect the valve or the parts that comprise it for possible damage incurred during shipping,
- take all possible precautions against damage to the valve and its components.
5.1. RECEPTION OF THE VALVE
5. Installation
5.2. TRANSPORT AND STORAGE
The buyer or user shall be liable for assembly, installation, start-up and operation of the
valve
Take all possible precautions when transport and storage the valve to avoid damage it and its com-
ponents..
5.3. IDENTIFICATION OF THE VALVE
Check that the valve and/or actuator adjust at the requests working conditions and at the
classied explosive atmosphere.
Each valve and each actuator is inscribed a fabrication number for its identication and the specic
marked for the explosion protection. Indicate the fabrication number on all documents to refer to the
valve.
The specic marked for the explosion protection for the valve and/or actuator is:
II 2G Ex h IIB T4 Gb
II 2D Ex h IIIB T125ºC Db
Installation
INOXPA S.A.U. 10.110.30.03EN · (0) 2020/09
8

VA 64 0 - 00 06 52 050
Size
025 DN 25, OD 1’’
040 DN 40
045 OD 1½’’
050 DN 50, OD 2’’
063 OD 2½’’
065 DN 65
076 OD 3’’
080 DN 80
100 DN 100, OD 4’’
Material of seat seals
40 HNBR
52 EPDM
78 FPM
Material
04 1.4307 (AISI 304L)
06 1.4404 (AISI 316L)
Connexions
00 weld/weld
10 male/weld
11 male/male
77 clamp/clamp
Standard pipe
0 DIN
1 OD
Type
64 ball valve A640
Product family
VA valve
Installation
9
INOXPA S.A.U. 10.110.30.03EN · (0) 2020/09

5.4. LOCATION
Place the valve leaving enough space around it in order to realize easily the dismantling, the inspec-
tion and the review the valve as well as in order to access to the actuator air connection’s device for
valves with automatic actuation even when the valve is operating. Consult in chapter 5.7. Welding
the required minimum distances. The installation should allow that the removable parts are could
remove easily.
5.5. GENERAL INSTALLATION
After the location of the valve is dened, the valve can be joined to the pipe by welding the valve
housing or using ttings.
5.6. CHECKING AND REVIEW
Perform the following checks before using the valve:
- open and close the valve several times in order to ensure that it works properly and check that
the buttery smoothly connects up to the coupling.
- if the valve is tted with a pneumatic drive, apply the compressed air several times checking to
make sure that the valve carry out the opening and closing action without di󰀩culty.
10.110.32.0015
10.110.32.0022
válvula abierta
válvula cerrada
I case of joining the valve to the pipe by ttings do not forget the seals and tighten the unions pro-
perly.
During installation the valve avoid using excessive force and pay special attention to:
- vibrations that may be produced on the facility,
- thermal dilation that the pipe may undergo when hot uids are circulating,
- the weight that the pipe can support,
- excessive welding current.
Ground the assembly to ensure electrical continuity between pipes and valve to reduce
the danger from static electricity.
Installation
INOXPA S.A.U. 10.110.30.03EN · (0) 2020/09
10

5.7. WELDING
Welding work should only be done by qualied persons who are trained and equipped
with the necessary equipment to perform this kind of work.
To perform the welding works:
- disassemble the valve as indicated in chapter 8.5. Disassembly and assembly of the ball,
- weld the two valve bodies to the pipes maintaining the distance indicated in the following table,
dimension A. This will allow an axial movement of the internal part of the valve necessary in
order to disassemble the internal pieces (disc and seat seal).
- Mount the valve follolwing the instructions indicated in chapter 8.5. Disassembly and assembly
of the ball.
5.7.1. Ball valve A640 welding/welding
10.110.32.0004
- Mount the valve following the instructions indicated in chapter 8.5. Disassembly and assembly
of the ball.
DN A
25 - 1’’ 36
40 - 1½’’ 47
50 - 2’’ 59
65 - 2½’’ 76
80 - 3’’ 92
100 - 4’’ 112
If possible, do the welding work in areas not classied as potentially explosive atmos-
pheres. If it is not possible, the welding work in areas classied as potentially explosive
atmospheres must be carried out by authorised personnel to work in explosive atmos-
pheres.
5.7.2. Ball Valve A640 with pneumatic drive
To perform the welding works on valves with pneumatic drive should be maintain, in addition to the
dimension mentioned in chapter above, a distance which allow disassembly the pneumatic drive
and the control head. The minimum distances that must be kept are indicated in the following table,
dimension B for valves with pneumatic drive or dimension C for valves with pneumatic drive and
control head.
If the actuator is not supplied by INOXPA, it must comply with the specications of Direc-
tive ATEX 2014/34/EU and you will have to full the supplier’s specications.
Installation
11
INOXPA S.A.U. 10.110.30.03EN · (0) 2020/09

5.8. CONNECTING THE AIR TO ACTUATOR
10.110.32.0023
To perform the air connection to the actuator:
- Connect and check the air connections (G 1/8’’ thread for tubing Ø6 mm) with thread in accor-
dance with double-e󰀨ect or simple e󰀨ect needs.
- Correctly orient the actuator and disc depending whether an NO/NC is required. By turning the
buttery 90º achieves one or the other solution.
- Mind the quality of the compressed air according to the specications described in chapter 9.
Technical Specications.
10.110.32.0005
DN
B C
Actuator Actuator +
C-TOP S
25 - 1’’ 331 371
40 - 1½’’ 373 413
50 - 2’’ 391 431
65 - 2½’’ 417 457
80 - 3’’ 496 536
100 - 4’’ 524 564
Installation
INOXPA S.A.U. 10.110.30.03EN · (0) 2020/09
12

ATTENTION
6. Start-up
Read carefully the instructions in chapter 5. Installation before start-up the valve..
Before putting the valve or the actuator into service the following must be taken into consideration:
- check that the piping and valve are completely free of possible traces of welding slag or other
foreign particles. Clean the system if is necessary,
- Check to make sure the valve moves smoothly. If is necessary, lubricate it with special grease
or soapy water,
- Check for possible leaks, and make sure the pipes and their connections are sealed and do not
have any leaks,
- If the valve has been supplied with an actuator, make sure that the alignment of the valve shaft
and the actuator shaft enables smooth movement,
- check that the compressed air pressure at the inlet of the actuator matches what is indicated in
chapter 9. Technical Specications,
- consider the quality of the compressed air, according to the specications described in chapter
9. Technical Specications,
- Activate the valve.
Prior to start-up, the persons in charge must be duly informed about how the valve works
and the safety instructions to follow. This instruction manual will be available to person-
nel at all times.
Do not modify the operating parameters for which the valve has been designed without
prior written authorisation from INOXPA.
Do not touch the movin parts of the coupling between the actuator and the valve when
the actuator is connected to the compressed air supply.
¡Burn hazard! Do not touch the valve or the pipes when hot uids are circulating or when
cleaning and/or sterilization are being carried out.
Check that the valve and/or actuator are in accordance with the working conditions spe-
cied by the customer and with the potentially explosive atmosphere classied.
Do an earth connection of the valve in order to ensure an electrical continuity between
pipes and valves to reduce a risk caused by the static electricity.
NEVER remove the handle of the valve because it would remain electrically isolated.
Do not modify the operating parameters for which the valve has been designed without
prior written authorisation from INOXPA.
The valve and/or the actuator have been selected according to the working conditions
specied by the customer. INOXPA is not responsible for damages caused if the infor-
mation provided by the customer as nature of liquid, viscosity, the classication of the
potentially explosive atmosphere, etc. is incomplete or incorrect.
Start-up
13
INOXPA S.A.U. 10.110.30.03EN · (0) 2020/09

6.1. OPERATING WITH TWO POSITION HANDLE
The two position handle allows operating the valve manually in the on/o󰀨 position. To manoeuvre the
handle follow the following instructions.
- pull the handle outwards,
- while pulling the handle turn it 90º.
10.010.32.0007
Turn
Pull
Start-up
INOXPA S.A.U. 10.110.30.03EN · (0) 2020/09
14

7. Operating problems
External leak. The product is leaking at the shaft
Internal product leak (closed valve)
The valve is jerking
The valve does not open/close
Water hammer
PROBABLE CAUSES SOLUTIONS
• The seal has completely worn or is deteriorated
- Replace the seal
- Change the seals for others made of a di󰀨erent
material more suitable to the product
• Normal wear and tear of the seat seals - Replace the seals
•
Premature
wearing of
seals
Seal worn or a󰀨ected by the
product
- Change the seals for others made of a di󰀨erent
material more suitable to the product
- Tighten loose parts
- Clean frequently
- Decrease valve opening / closing frequency
Excessive pressure on line
Work temperature too high (nuts
and screws)
Loss of impenetrability (vibrations)
High manoeuvre periodicity (num.
operations / tour)
•The seals are jamming up - Lubricate with soapy water or lubricant suitable
with the gasket material and the product
•The actuator does not operate the valve e󰀩cient-
ly
- Check the supply pressure of the compressed
air
- Replace with a larger sized actuator
• Excessive pressure on line - Check the installation pressure and adjust whe-
never necessary
• Deformation of the seal - Replace the seals with others of di󰀨erent quali-
ty, if prematurely deteriorated
• Incorrect operation of the actuator - Replace from NC to NO
• Worn actuator components - Check the actuator
• Dirt in actuator - Check the compressed air pressure
• The valve closes too fast - Adjust the closing speed of the actuator with a
ow regulator
Operating problems
15
INOXPA S.A.U. 10.110.30.03EN · (0) 2020/09

8. Maintenance
This valve, just like any other machine, requires maintenance. The instructions in this chapter cover
the maintenance of the valve, the identication and replacement of the spare parts and the disas-
sembly and assembly of the valve. The instructions are aimed at maintenance personnel and those
responsible for the supply of spare parts.
Read carefully the chapter 9. Technical Specications.
Maintenance work should only be done by qualied persons who are trained and equi-
pped with the necessary equipment to perform this kind of work.
All replaced material should be duly disposed or recycled according to the directives in
e󰀨ect in each area.
Make sure that the pipes are not under pressure before starting maintenance work.
8.1. GENERAL CONSIDERATIONS
8.2. MAINTENANCE
To perform maintenance properly is recommended:
- periodic inspection of the valve and its components,
- keeping an operational record of each valve writing down any problems,
- always having spare replacement seals in stock.
Pay special attention to the hazard warnings indicated in this manual during the performance the
maintenance work.
Do not touch the moving parts when the actuator is connected to the compressed air.
The valve and the pipes must never be under pressure during maintenance.
¡Burn hazard! Do not touch the valve or the pipes when hot uids are circulating or when
cleaning and/or sterilization are being carried out.
Keep in mind that the springs are not protected during the disassembly of the actuator
for its maintenance or its repair.
8.2.1. Maintenance of the seals
REPLACING SEAL
Preventive maintenance Replace after 12 months
Maintenance after a leak Replace at the end of the process
Planned maintenance
Regularly check the absence of leaks and the smooth ope-
ration of the valve.
Keep a record of the valve’s maintenance.
Use statistics for planning inspections.
Lubrication During assembly, apply lubricants that are suitable with the
material of which the seat seal is made
The assembly and disassembly of the valve and/or actuator must be carried out by au-
thorised personnel to work in explosive atmospheres.
When the valve is supplied without manual drive, actuator or head control and the custo-
mer want to install one of them, they will have to full with the regulations of the Directive
2014/34/UE.
Maintenance
INOXPA S.A.U. 10.110.30.03EN · (0) 2020/09
16

The time interval between each preventive maintenance may vary in accordance with the work con-
ditions to which the valve is subject: temperature, pressure, number of operations per day, type of
cleaning solutions used, etc.
COMPONENTE JUNTA LUBRICANTE CLASE NLGI DIN
51818
NBR / FPM klübersynth UH 1 64-2403 3
EPDM / NBR / FPM PARALIQ GTE 703 3
8.2.2. Storage
The valves should be stored in a closed area under the following conditions:
- temperature between 15ºC y 30ºC,
- air humitidy < 60%
Storage of the equipment in the open air is NOT allowed.
8.2.3. Spare parts
To request spare parts is necessary to indicate the type of valve, the fabrication number, the position
and the description of the part which can be found in chapter 9. Technical Specications.
8.3. CLEANING
The use of aggressive cleaning products such as caustic soda and nitric acid may burn
the skin.
Wear rubber gloves during all cleaning procedures.
Always wear protective goggles.
8.3.1. CIP (clean-in-place) cleaning
If the valve is installed in a system with a CIP process its disassembly will not be required. EPDM is
the standard seal material that will be used for CIP cleaning, both in alkaline mediums and in acid
mediums. The materials of the seal NBR and FPM are not recommended.
Two types of solutions can be used for CIP processes:
a. alkaline solution: 1% by weight of caustic soda (NaOH) a 70ºC (150ºF). To make this solution:
1 kg NaOH + 100 l H2O1= cleaning solution
2,2 l NaOH al 33% + 100 l H2O = cleaning solution
b. acid solution: 0,5% by weight of nitric acid (HNO3) a 70ºC (150ºF). To make this solution:
0,7 l HNO3al 53% + 100 l H2O = cleaning solution
1) only use chlorine-free water to mix with the cleaning agents
When ordering spare parts for valves and/or actuators which operating in potentially
explosive atmospheres you should indicate that to be for valves and/or actuators which
operate in ATEX areas and the features of this area. If there is no indicate this informa-
tion INOXPA is not responsible that the valves and/or actuator operated with parts no
suitables for the classied area where is installation.
Before start the assembly and disassembly works of the valve and/or actuator take ac-
count of the presence or possible formation of potentially explosive atmospheres.
Clean the external part of the valve and/or actuator in order to avoid an excessive accu-
mulation of dust, combustible or explosive on the external surface of the machine. Don’t
be allow accumulations of a thickness greater than 2 mm.
Maintenance
17
INOXPA S.A.U. 10.110.30.03EN · (0) 2020/09

8.3.2. Automatic SIP (sterilization-in-place)
Sterilization with steam is applied to all equipment including the pigging.
ATTENTION
Do NOT start the equipment during the sterilization with steam.
The parts and the materials will not be damaged if the indications specied in this manual
are observed.
No cold uid can enter the equipment until the temperature of the equipment is lower
than 60°C (140°F).
Maximum conditions during the SIP process with steam or superheated water:
a. maximum temperature: 140ºC / 284ºF
b. maximum time: 30 min
c. cooling: sterile air or inter gas
d. materials: EPDM (the materials NBR and FPM are not recommended)
8.4. DISASSEMBLY AND ASSEMBLY THE VALVE
Proceed with caution. Personal injury can occur.
Always disconnect the compressed air before starting to disassemble the valve.
Never disassemble the valve clamps directly without reading the instructions carefully,
since the actuator contains a spring inside it with an applied load.
Valve and actuator assembly and disassembly should only be done by qualied persons.
The following tools are needed in order to disassembly and assembly the valve and the drives:
- two crescent spanners 13 mm for the valve
- a 4 mm allen key for the manual drive
- a crescent spanners 10 mm and a allen key 4 mm for the pneumatic drive
To remove any traces of cleaning products, ALWAYS perform a nal rinse with clean water at the end
of the cleaning process.
Clean the entire interior and exterior of the valve before starting disassembly and assem-
bly tasks.
ATTENTION
Check the concentration of the cleaning solutions. An incorrect concentrations may lead
to the deterioration of the valve seals.
The assembly and disassembly of the valve and/or actuator must be carried out by au-
thorised personnel to work in explosive atmospheres.
Maintenance
INOXPA S.A.U. 10.110.30.03EN · (0) 2020/09
18

8.5. DISASSEMBLY AND ASSEMBLY OF THE BALL
1. Remove the screws (23) and the nuts (26) that join bots bodies (02).
2. Separate the bodies (02) and remove the guide bushing (17).
3. Remove the ball (03) and the seat seal (05) with the shaft (08).
4. Remove the ball guides (11) and the O-rings (20) from the bodies (02).
5. Remove the ball (03) and the seat seal (05) from the shaft (08).
8.5.1. Disassembly
8.5.2. Assembly
1. Mount the shaft of the ball (08) to the ball and t it on the seat seal (05) as indicated in chapter 8.8.
Fitting the seat seal.
2. Lubricate the O-rings (20) and the guide balls (11) with the grase indicated in chapter 8.2.1. Main-
tenance of the seals and place them in the bodies (02).
3. Mount the ball-shaft-seat seal assembly between two bodies (02) and place the guide bushing
(17).
4. Position the screws (23) and the nuts (26), screw them crosswise according to the tightening
torque value indicated in chapter 9.5. Tightening torque and check that the ball guides (11) are po-
sitioned correctly.
10.110.32.0001
Avoid disassembly the valve in an area dened as a potentially explosive atmosphere
because the valve is electrically isolated when it have not a drive.
Maintenance
19
INOXPA S.A.U. 10.110.30.03EN · (0) 2020/09

8.6. DISASSEMBLY AND ASSEMBLY OF THE MANUAL DRIVE
1. Remove the protective plug (07A) from the
upper part of the handle (04).
2. Loosen the screw (23A) and remove the hand-
le (04).
1. Place the handle (04) on the shaft of the ball
(08) positioning tha handle arm aligned with the
through hole of the ball and tighten the screw
(23A).
2. Place the protective plug (07A).
8.6.1. Disassembly
8.6.2. Assembly
10.110.32.0007
When the valve is supplied without manual drive, actuator or head control and the custo-
mer want to install one of them, they will have to full with the regulations of the Directive
2014/34/UE.
Avoid disassembly the valve in an area dened as a potentially explosive atmosphere
because the valve is electrically isolated when it have not a drive.
Maintenance
INOXPA S.A.U. 10.110.30.03EN · (0) 2020/09
20
