INOXPA INNOVA G Manual

1
INSTALLATION, SERVICE AND
MAINTENANCE INSTRUCTIONS
ANNEX FOR CE MARKED EQUIPMENT ACCORDING TO THE
ATEX DIRECTIVE 2014/34/EU:
INNOVA G Ex CONTROL VALVE
The content of this Annex supplements the information in the instruction
manual. The instructions in this Annex must be taken into account in
conjunction with the equipment marked according to Directive
2014/34/EU.
Original Manual
10.247.30.07EN
(0) 2022/11
This Annex is complemented, if applicable, by the manuals of the
ATEX-certified components comprising the assembly.

(1) the serial number may be preceded by a slash and by one or two alphanumeric characters
(2) pneumatic actuator D/E make connection between the shaft and the actuator support, to ensure electrical
continuity. Likewise, the turret must be in stainless steel
EU Declaration of Conformity ATEX 2014/34/EU
We,
INOXPA, S.A.U.
Telers, 60
17820 –Banyoles (Girona)
Hereby declare under our sole responsibility that the machine
CONTROL VALVE
Model
INNOVA G
From serial number IXXXXXXXXX to IXXXXXXXXX (1)
Fulfills (2) all the relevant provisions of Safety and Health from ATEX 2014/34/EU Directive
and are adapted to the harmonized norms:
EN ISO 80079-36:2016
EN ISO 80079-37:2016
EN 1127-1:2019
EN 13237:2012
EN 15198:2007
This Declaration of Conformity covers equipment with the following ATEX marking:
The technical documentation referenced 034044/18 is on file with the notified body INSTITUT
NATIONAL DE L’ENVIRONNEMENT INDUSTRIEL ET DES RISQUES (INERIS), Parc
Technologique Alata BP 2, 60550 Verneuil-en-Halatte, France. Reference num. 0080.
Signed by and on behalf of:
INOXPA, S.A.U.
David Reyero Brunet
Technical Office Manager
Banyoles, 2022
II 2G Ex h IIB T6…T3 Gb
II 2D Ex h IIIB T85 ºC…T200 ºC Db
10.247.30.08EN
(0) 2022/11

_______________________________________________________________________________________________
ED. 2022/11 1. CONTROL VALVE SAFETY
2
1. Safety
1.3. SAFETY
1.3.1. Warning symbols
Danger! Important instructions for protection from explosions
1.4. GENERAL SAFETY INSTRUCTIONS
1.4.1. During installation
The reduce the danger from static electricity, the assembly should be earthed to
ensure electrical continuity between pipes and valves
1.4.2. During operation
The limit values for the operating conditions in explosive atmospheres must not be
exceeded
The valve was selected according to the working conditions specified by the user,
therefore INOXPA is not responsible for any damage that may occur due to the use
of valve under conditions other than those stated in the order
1.4.3. During maintenance
Danger! Important instructions for protection from explosions.
An explosive atmosphere may be generated or be present when removing the valve
therefore safe work permits should be set and these tasks should only be carried out
by qualified or trained personnel
1.4.4. Compliance with the instructions
Failure to comply with the instructions may prove hazardous for operators, the environment, the machine
and the installations, leading to a loss of rights for claiming damages.
This non-compliance may result in the following hazards (in addition to those already listed in the manual):
- Generation of explosive atmospheres and risk of explosion.

_______________________________________________________________________________________________
ED. 2022/11 1. CONTROL VALVE SAFETY
3
1.4.5. Warranty
Any warranty will immediately be declared void, as of right, and we will be entitled to indemnity for any
civil liability claim put forward by third parties (in addition to the conditions referred to in the manual):
- The material has been badly used or has not been used according to the conditions for working in the
classified zone, in a different classified zone, in temperature or pressure conditions and/or different
substance.

_______________________________________________________________________________________________
ED. 2022/11 2. CONTROL VALVE INDEX
4
2. Table of Contents
The instructions provided in these sections of this Annex should be taken
into account jointly with the valve manual.
1. Safety
1.1. Instruction Manual --
1.2. Implementation instructions --
1.3. Safety 3
1.4. General safety instructions 3
2. Table of Contents
3. General information
3.1. Description --
3.2. Application --
4. Installation
4.1. Delivery of the valve 6
4.2. Transport and storage --
4.3. Identification 6
4.4. Positioning --
4.5. Flow direction --
4.6. General Installation 6
4.7. Checking and revision --
4.8. Welding 6
4.9. Valve configuration with actuator --
4.10. Actuator air connection --
5. Start-up
5.1. Uses of the valve --
5.2. Start-up 7
5.3. Operation 7
7. Maintenance
7.1. General information 8
7.2. Maintenance 8
7.3. Cleaning 8
7.4. Assembly and disassembly 8
7.5. Removal / Installation of the INNOVA G valve 8
7.6. Replacing the seat seal --
7.7. Actuator assembly / disassembly --
8. Technical specifications
8.1. Technical specifications 11
8.2. Exploded view and parts list --

_______________________________________________________________________________________________
ED. 2022/11 4. CONTROL VALVE INSTALLATION
5
4.Installation
4.1. DELIVERY OF THE VALVE
It should be checked that the valve received is adjusted to the working conditions
in the classified zone as well as the order conditions
4.3. IDENTIFICATION
ATEX valves should be identified in a complementary manner:
The temperature class and the maximum surface temperature depend on the temperature of the product to
be stirred and the ambient temperature.
Temperature class for explosive gas atmospheres
Temperature
class
Product temperature (in process
or cleaning)
Room temperature
T6
≤ 60 °C
-20 °C to +40 °C
T5
≤ 75 °C
T4
≤ 110 °C
T3
≤ 140 °C
Maximum surface temperature for explosive dust atmospheres
Maximum
surface
temperature
Product temperature (in process
or cleaning)
Room temperature
T85 °C
≤ 85 °C
-20 °C to +40 °C
T100 ºC
≤ 100 °C
T125 ºC
≤ 125 °C
T 200 °C
≤ 200 °C
4.6. GENERAL INSTALLATION
The reduce the danger from static electricity, the assembly should be earthed to
ensure electrical continuity between pipes and valves
4.8. WELDING
Safe work permits must be set for any welding work in potentially explosive
atmospheres; it is recommended to this kind of work in non-classified atmospheres
(there is no explosive atmosphere in the valve’s location during handling)
II 2G Ex h IIB T6…T3 Gb
II 2D Ex h IIIB T85ºC…T200 oC Db

_______________________________________________________________________________________________
ED. 2022/11 5. CONTROL VALVE START-UP
6
5.Start-up
5.2. START-UP
It should be checked that the valve received is adjusted to the working conditions
in the classified zone as well as the order conditions
Ensure electrical continuity between the valve and the installation, as well as
connecting the installation to earth
The stem and the body are connected to ensure electrical continuity (in case of DE double effect
actuator)
5.3. OPERATION
Do not modify the operating parameters for which the valve has been designed
without prior written authorisation from INOXPA
The valve was selected for certain working conditions in potentially explosive
atmospheres at the time of placing the order. INOXPA is not liable for any damage
that may arise if the information provided by the buyer is incomplete or incorrect
(liquid type, viscosity, classification of the potentially explosive area, gas generated
by the potentially explosive atmosphere, etc.)

_______________________________________________________________________________________________
ED. 2022/11 7. CONTROL VALVE MAINTENANCE
7
7.Maintenance
7.1. GENERAL INFORMATION
The assembly and disassembly of the valves must only be carried out by qualified
personnel, taking into account the need to adopt safe working conditions in
potentially explosive atmospheres
If the positioning head is not supplied with the valve, and the client wants them
installed, the specifications of Directive 2014/34/EU ATEX must be met
7.2. MAINTENANCE
7.2.3. Spare parts
On requesting spare parts for a valve intended to work in a classified zone, it is necessary to
explicitly indicate in the order that they are for valve operating in an ATEX zone, as well as
the characteristics of said zone.
If the spare parts are not requested in this way, INOXPA shall not be responsible for the case
that the valve may not operate with parts which are not suitable for the classified zone where is
installed.
7.3. CLEANING
Before beginning the disassembly and assembly work it should be taken into account
the presence or possible formation of potentially explosive atmospheres
7.4. ASSEMBLY AND DISASSEMBLY
The assembly and disassembly of the valves must only be carried out by qualified
personnel, taking into account the need to adopt safe working conditions in
potentially explosive atmospheres.
7.5. REMOVAL / INSTALLATION OF THE INNOVA G VALVE
The stem and actuator support are connected to ensure electrical continuity,
only for double effect actuator (DE)
7.5.1. Disassembly:
1. Apply compressed air to the actuator so that the plug stem (08) is in the open position (only for
NC valves).
2. Loosen and separate the clamps (34).
3. Separate the actuator (10) from the body assembly.
4. Remove the seal (20B) from the lower opening (02).
5. Release the compressed air in the actuator (only NC valves).
6. Unscrew the Allen bolts (23) from the lantern (21).
7. Unscrew the plug stem (08) from the actuator shaft two 17 mm crescent spanners.

_______________________________________________________________________________________________
ED. 2022/11 7. CONTROL VALVE MAINTENANCE
8
8. Finish unscrewing the plug stem by hand.
9. Once the plug stem is out, remove the body cap (12) and the seals inside it (20B and 05)
10. Extract the guide bushing (17) and the scraper (60), and take out the washer with the electrical
continuity connection cable.
11. Extract the seat seal (05C), and the washer with the electrical continuity connection cable.
7.5.2. Assembly:
1. Loosen the scraper (60), the electrical continuity connection cable and the guide bushing (17) on
the lantern (21).
2. Insert the lantern (21) underneath the actuator.
3. Lubricate the seals with soapy water if necessary.
4. Install the seals (20B and 05) in the body cap (12) and put this assembly in the lantern.
5. Install the seat assemblies (05C, 05E).
6. Once the seat assembly (05C) is installed, house the washer with the electrical continuity
connection cable on the plug stem (08); thread the same with the actuator shaft (10).
7. Tighten the four Allen bolts (23) that secure the lantern (21) to the actuator.
8. Apply compressed air to the actuator so that the plug stem (08) is in the open position (only for
NC valves).
9. Install the seal (20B) on the lower opening (02).
10. Install the lower opening (02) and the intermediate body (01) and ensure the assembly is using a
clamp.
11. Install the actuator (10) - lantern (21) - plug shaft (08) - body cap (12) assembly to the valve
body (01) (can be turned 360º according to the user’s needs) and secure it using the clamp (34).
10. Release the compressed air in the actuator (only NC valves).

_______________________________________________________________________________________________
ED. 2022/11 8. CONTROL VALVE TECHNICAL SPECIFICATIONS
9
8.Technical Specifications
Temperature range. See section 4.3.
PNEUMATIC ACTUATOR GENERAL DATA
The pneumatic actuator cannot exceed, under any circumstances, the 12 cycles per minute to
ensure that there is no significant increase in temperature.
In any case, in ongoing work it is not recommended to exceed the 2/3 cycles per minute to
ensure a reasonable life of the seal.
