GALLEYMASTER SERIES
ELECTRIC or STEAM HEAT
60, 85, 135, 185, 250
STANDARD FEATURES
OPTIONAL ACCESSORIES
• Power loader
• Power unloader
• Rack limit switch
• Patented CrossFire™Wash System
• Modular "take-apart" design fits through a 26" x 66"
watertight hatch and navigates interior passageway turns
• Heat: Electric– 5 x 7.5 KW low watt density electric
immersion heaters and 54 KW electric booster with low
temp cut-off. Steam- 2 stainless steel steam coils and
steam booster with low temp cut-off
• Tank heaters easily removable from inside tank
• Integral vent cowl system with dampers
• Hermetically sealed and tank mounted thermometers for
wash and rinse designed to minimize breakage
• Vacuum breaker on all incoming water lines
• Pressure reduction valve and line strainer
• Locking plungers and keys on spray pipes
• Color-coded curtains
• Low water protection
• Permanent legs on the rinse tank, at the split line
• Porthole level indicator on wash and rinse tanks
• Premium ball valves on all water and steam lines
• “Loss proof” wire lanyards on suction strainers, overflow
tubes, and spray pipe end plugs
• Easily cleaned crowned hood top
DESIGN
The GalleyMaster is engineered with an emphasis on dependability,
durability, and serviceability, safety in operation, ease of cleaning and
maintenance.
The modular "take-apart" design enables the dishwasher to go through a
26" x 66" watertight hatch and navigate interior passageway turns for
easy installation. In operation the seams are leak proof.
Live Tech Service is Available
24 hours/day 7 days/week
800-344-4802
6245 State Road
Philadelphia, PA 19135-2996
215-624-4800
215-624-6966 FAX
800-344-4802
www.insingermachine.com
• External conveyor drive system (HTD) with frictionless
overload release.
• Inspection doors with welded handles and splash guards
• 2 safety catches on each door
• Electrical interlock switch on each door
• Hermetically sealed in-line thermometer for final rinse
• Manifold clean-out brush
• S/S frame, legs, feet and front panels
• Manual tank fills
• Connection points for detergent and rinse aid dispensers
• Detergent probe hole in bottom of wash tank
• Bulk-head mounted NEMA 12 control panel
• NEMA 4 control switches
• Simplified scrap screen design
• Standard frame TE motors
• Complies with ASTM specification F859-04
• 2 tech manuals
• Authorized tech rep in each port
• Exact footprint replacement for 20M-NSU Series
• Data plate and instructions in easy to read locations
• Plastic 20" x 20" racks
