Insportline Cortela 23641 User manual

USER MANUAL –EN
IN 23641 Massage chair inSPORTline Cortela

2
CONTENTS
SAFETY INSTRUCTIONS....................................................................................................................... 3
WARNING ............................................................................................................................................... 5
PRODUCT DESCRIPTION..................................................................................................................... 6
FUNCTION.............................................................................................................................................. 7
CONTROLLER........................................................................................................................................ 8
DISPLAY.............................................................................................................................................. 8
BUTTONS............................................................................................................................................ 9
USE ....................................................................................................................................................... 10
CONNECTION................................................................................................................................... 10
TURN ON........................................................................................................................................... 10
PAUSE............................................................................................................................................... 12
MENU................................................................................................................................................. 12
AUTOMATIC MASSAGE................................................................................................................... 13
SPECIAL AUTOMATIC MASSAGE................................................................................................... 14
MANUAL MASSAGE ......................................................................................................................... 15
SPEED, WIDTH AND INTENSITY ADJUSTMENT........................................................................... 21
SETTINGS............................................................................................................................................. 23
BUTTONS.............................................................................................................................................. 27
ADJUSTMENTS ................................................................................................................................ 27
QUICK SELECTION BUTTON .......................................................................................................... 28
SWITCH OFF THE CHAIR.................................................................................................................... 28
ASSEMBLY ........................................................................................................................................... 29
PILLOWS........................................................................................................................................... 31
FLOOR PROTECTION.......................................................................................................................... 31
SPECIFICATIONS................................................................................................................................. 32
ENVIRONMENT PROTECTION ........................................................................................................... 33
TERMS AND CONDITIONS OF WARRANTY, WARRANTY CLAIMS................................................. 33

3
SAFETY INSTRUCTIONS
IMPORTANT SAFETY WARNINGS
•Place the product on flat and solid surface and keep at least 0.6 m free space around the
product.
•Kids can move around this product only under adult supervision.
•Use only well-grounded socket and proper power cord.
•Pull out the plug after every use or during maintenance to avoid injury or damaging the
product.
•Please use this product according to the manual.
•Do not use unauthorized modifications or accessories.
•Only for indoor use.
•Before first use, please read the manual carefully.
•Use this product as is described in the manual.
•Recommended maximum use time is 20 minutes.
•Do not use the device if it is damaged. (frame, leather etc.)
•Do not use the chair if the ventilation is blocked.
•No not put on chair heavy items or objects with sharp edge.
•Do not fall asleep during massage for safety reasons.
•Do not use the chair after you consumed alcohol or other drugs or if you are sick or dizzy.
•Do not use within one hour after meal.
•Please be caution and do not use too strong massage.
•Maximum load: 150 kg
POSITION OF MASSAGE CHAIR
•Do not use the chair in high temperatures or moist environments (e.g. bathroom).
•Do not use the chair immediately after temperature change.
•Do not use in dust or impropriety rooms.
•In is important to secure enough space and ventilation.
PEOPLE THAT SOULD NOT USE THE PRODUCT
•People suffering from osteoporosis.
•People who has hearth problems or are using electronic medical equipment (e.g.
peacemaker).
•People suffering fever.
•Pregnant women.
•People suffering skin diseases.
•Kids younger 14 years old or people suffering mental illness can use this product only under
adult supervision.
•People that are recommended rest from the doctor or people suffering from sickness.
•Do not use this chair if you have wet body.
•Do not use the heat function if you are heat sensitive.
SAFETY

4
•Maintenance should me done only by qualify person. Use should not disassemble the chair or
do the maintenance by themselves.
•After every use unplug the cord.
•Do not use the product if the power cord, plug or socked are damaged.
•If you are not using the chair for long period of time, store it at a clean and dry place and
secure the power cord.
•Do not expose the chair to high temperatures, direct sunlight and do not place the chair near
heat source.
•If the power cord, plug or socked are damaged, ask professional or qualified person for help.
•For cleaning use wet sponge only. Do not use thinner, gasoline or alcohol for cleaning.
•Mechanical parts are assembled and made to require minimum maintenance.
•Pay extra attention to not damage the chair with sharp objects.
•Do not push the chair on uneven ground, always pick the chair up and then move.
•Do not let the chair to work for long periods of time.
COMMON PROBLEMS AND SOLUTIONS
•It is common that the motor is making sounds.
•If the chair is not working please check the power cord, plug and socket and that the switch is
ON.
•After the massage time is over the massage chair will turn OFF. The product will automatically
shutdown if it is overheated –wait at least half an hour before next massage.

5
WARNING
If the footrest rises, do not apply pressure to the
footrest. You may damage the product or injure
yourself.
Before sitting down, make sure that the massage
heads do not protrude from the seat. You may
damage the heads or be injured.
Never unplug the power cord during use or when
the chair is in standby mode. After use, we
recommend switching off the chair and unplugging
the power cord.
Before using the angle adjustment function,
make sure that you have enough free space and
that there are no other people or pets behind the
chair.

6
PRODUCT DESCRIPTION
1.
Canopy
2.
LED blue light
3.
Lights
4.
Pillows
5.
3D speakers and aromatherapy
6.
Upper arm airbags
7.
Arm airbags
8.
Quick use buttons
9.
USB charging port
10.
Buttock airbags
11.
Seat
12.
Leg rest
13.
Footrest
14.
LED lighting
15.
Backrest
16.
Controller
17.
Armrests
18.
Side cover
19.
Back cover
20.
Aperture for aromatic oils
21.
Side decorative cover
22.
Drive cover
23.
Wheels
24.
Power cord and plug
25.
Controller connection
26.
Switch
27.
Fuses
28.
Power socket

7
FUNCTION
•The chair contains 3D massage heads that move up and down, forwards and backwards in
quiet operation.
•It automatically detects the position of the shoulders and adjusts the position of the massage
heads. It automatically detects the shape of the human body and adjusts the movement of the
massage heads forwards and backwards.
•6 types of massages: Shiatsu, buttocks, deep massage, neck and shoulders, back stretching,
relaxation massage.
•3 special massage functions: blue light therapy, healing, spa.
•3 positions for storing your own massages.
•5 positions of upper body massage: total massage, partial, fixed, upper and lower back,
shoulders.
•6 massage techniques: shoulder massage, kneading, tapping, Shiatsu, kneading and tapping,
3D massage; for all techniques it is possible to set 5 speeds, in Shiatsu and double tap modes
you can set 5 positions of the width of the massage heads.
•Air cushion massage: upper arm (8 airbags), lower arm (4 airbags), back massage (4 airbags),
foot massage (22 airbags), foot massage (12 airbags), buttocks massage (4 airbags). 3
intensity options.
•Heated back and legs, carbon fiber is used as a source of infrared light.
•The backrest frame uses track technology, so the backrest does not take up excess space
when angled.
•Waist massage with air cushions.
•Quick control buttons on the right.
•Massage rollers for foot massage. The footrest automatically detects the distance and then
adjusts the most comfortable angle.
•Ergonomic backrest.
•8 magnets in the foot area.
•Adjustable LED lights on the right and left side.
•USB charging port on the right.
•Movable canopy for a relaxing massage using blue light.
•Aromatherapy.
•Driver with color TFT display.
•Possibility to connect a phone or tablet with a smart device via Bluetooth.
•3D speakers.
•Double layer cushion for improved comfort.

8
CONTROLLER
DISPLAY
1.
LCD display
12.
Adjustment
2.
Type of massage
13.
Adjusting the position of the arms
3.
Canopy
14.
Bluetooth
4.
Aromatherapy
15.
Type of massage
5.
Timer
16.
Massage location
6.
Zero gravity
17.
Heating settings
7.
Display of the type of back massage
18.
Width adjustment
8.
Arm massage using airbags
19.
Massage intensity
9.
Leg massage using airbags
20.
Arm intensity adjustment
10.
Massage rollers
21.
Leg intensity adjustment
11.
Speed setting
22.
Information

9
BUTTONS
1.
Pause: pause the current massage
11.
Return
2.
Power supply
12.
Manual massage interface
3.
Navigation key up
13.
Heating
4.
Confirm button
14.
Lifting the leg rest
5.
Navigation key left
15.
Lowering leg rest
6.
Right navigation button
16.
Zero gravity setting I
7.
Navigation key down
17.
Zero gravity setting II
8.
Menu
18.
Connected adjustment of the backrests
and legs rest
9.
Automatic massage interface
19.
Connected adjustment of the backrests
and legs rest
10.
Adjusting

10
USE
CONNECTION
Plug in.
Connect the controller and plug
in the power cord.
Turn on power switch
TURN ON
Once turned on, the chair is in standby mode.
Press the power button on the remote control, the backrest stays in its original position, the footrest
raises slightly and waits for the automatic massage to be selected. If the massage is not selected
within 5 minutes, the chair will automatically switch off.
Once you select any automatic mode, the backrests and legs are adjusted to the preset position.
After adjusting the rests, the chair will automatically detect the shoulders and body shape. Press the
confirmation button to skip detection.

11
An audible signal sounds when the shoulders are detected. If the position of the massage heads is
different from the position of the shoulders, you can adjust the position of the heads using the up and
down buttons. You can set up to 11 positions. If the position of the arms is not adjusted within 10
seconds, the massage will start, or press the confirmation button to start immediately. If the chair
cannot detect the position of the shoulders, the massage will start with a preset value.
Button
Description
Massage head up
Massage head up
In the interface below you can select "adjust" or "shoulder", after selecting the function press the "ok"
button.

12
PAUSE
If you press the "pause" button during the massage, the chair will temporarily stop all functions. Press
the function again to start again. If the pause is longer than 20 minutes, the chair switches off.
MENU
Press "menu" to enter the menu interface. You can choose automatic massage, special massage,
manual mode, adjustment, custom massage, settings, display of chair information and others.
Navigate in the menu using the up and down buttons, use the "ok" button to enter. Press "back" to
return to the previous interface.

13
AUTOMATIC MASSAGE
You can choose an automatic massage via the menu or by pressing "auto" on the remote controller.
There are 6 massages to choose from: activating collaterals, hip shaping, sleep aid massage, neck &
shoulder massage, back waist stretch, breath conditioning.
Massage
Description
Activating collaterals
Massage of the neck, shoulders, back, waist, buttocks, etc. Massage with the
fingers, squeezing and tapping, in combination with foot massage rollers and
foot airbags. Full body massage.
Hip shaping
Massage the buttocks and hips with airbags.
Sleep aid massage
Gentle and deep body massage.
Neck & shoulder
massage
Neck and shoulder massage, kneading and tapping the shoulders.
Back waist stretch
Back and waist massage using Shiatsu and other techniques.
Breath conditioning
Full body massage using all techniques. The neck, shoulders, back and waist
are massaged mainly by kneading and tapping. The waist is also massaged
with the fingers.

14
SPECIAL AUTOMATIC MASSAGE
In the menu interface, select featured massage and choose one of the offered massages: Blue bath
therapy, health, music spa.
Navigate in the menu using the up and down buttons, confirm the selection by pressing "Ok".
Massage
Function
Blue bath therapy
The chair is placed in zero gravity mode and launches the sky with blue light.
The kneading massage starts.
Health
The chair is laid down, and the aromatherapy massage is started. The airbag
massage is started.
Music SPA
The chair is laid down and combines aromatherapy with full body massage and
airbag massage.

15
MANUAL MASSAGE
Select "manual mode" in the menu. You can choose the massage technique, which part you want to
massage, airbag pressure and other functions.
You can switch between the menus using the right and left buttons. You can navigate in the menu
using the up and down buttons. Press the "back" button to return to the previous interface.
SELECTING OF MASSAGE TECHNIQUE
There are 6 massage techniques to choose from: 3D massage, kneading, kneading and tapping,
shoulder massage, tapping, Shiatsu.
Navigate in the menu using the up and down buttons, confirm the selection by pressing "ok".

16
Function
Settings
Display
3D massage
4 types of 3D massages, different speed and
intensity.
kneading
Speed and strength.
kneading & tapping
Speed and strength.
shoulder lifting
Speed and strength.
tapping
2 modes with different speed, width, and intensity.
Shiatsu
Two types with different speed, width, and intensity.
Press stop to pause all functions.
MASSAGE LOCATION
Sport, partial, full back, upper back, lower back, others.
Navigate in the menu using the up and down buttons, confirm the selection by pressing "ok".

17
Location
Description
spot
Massage in a fixed place
You can change the location
using the up and down buttons
partial
Massage on a small area
full back
Massage of the back
upper back
Upper back massage
lower back
Lower back massage
AIRBAGS
You can adjust the airbags of the arms, buttocks, legs and / or a total body massage.
Navigate in the menu using the up and down buttons, confirm the selection by pressing "ok".

18
Airbags
Description
Arm
Activate or deactivate the arm airbags
Buttocks
Activate or deactivate the buttock airbags
Legs
Activate or deactivate the foot airbags
Whole body
Activate or deactivate full body airbags

19
OTHERS
In the "others" interface you can set the functions of heating, foot massage rollers, aromatherapy,
canopy, etc.
Navigate in the menu using the up and down buttons, confirm the selection by pressing "ok".
HEATING
Press "ok" to start or stop the heating, the warm-up time is approximately 3 minutes.
You can also start the function using the quick selection buttons on the chair.
Navigate in the menu using the up and down buttons, press "back" to return.
FEET ROLLERS
Press "ok" to start or stop foot massage.
Navigate in the menu using the up and down buttons, press "back" to return.

20
AROMATHERAPY
Press "ok" to start or stop aromatherapy.
Navigate in the menu using the up and down buttons, press "back" to return.
CANOPY
Press "ok" to start or turn off the canopy.
Navigate in the menu using the up and down buttons, press "back" to return.
