INSTEON SwitchLinc 2476DH User manual

SwitchLinc Dimmer
- 1000W
INSTEON-Enabled Dimmer Switch
For models:
#2476DH SwitchLinc Dimmer 1000W
™

SwitchLinc Dimmer 1000W User’s Guide
TABLE OF CONTENTS
ABOUT SWITCHLINC DIMMER .................................................................................................................. 4
What is INSTEON?.................................................................................................................................... 4
Key SwitchLinc Dimmer Features ............................................................................................................. 4
HOW TO INSTALL SWITCHLINC DIMMER................................................................................................5
Tools You Will Need .................................................................................................................................. 5
Preparing to Install SwitchLinc Dimmer..................................................................................................... 6
Installing SwitchLinc Dimmer .................................................................................................................... 7
Installing SwitchLinc Dimmer in a Multi-Way Circuit ................................................................................. 8
HOW TO SET UP SWITCHLINC DIMMER TO REMOTELY CONTROL AN INSTEON DEVICE ............ 14
Linking SwitchLinc Dimmer to a Controlled INSTEON Device................................................................ 14
Unlinking a Controlled INSTEON Device from SwitchLinc Dimmer........................................................15
Creating an INSTEON Scene..................................................................................................................15
HOW TO SET UP SWITCHLINC DIMMER TO BE REMOTELY CONTROLLED BY AN INSTEON
CONTROLLER ........................................................................................................................................... 16
Linking an INSTEON Controller to SwitchLinc Dimmer .......................................................................... 16
Unlinking SwitchLinc Dimmer from an INSTEON Controller................................................................... 17
HOW TO SET UP ON-LEVELS AND RAMP RATES ................................................................................ 18
Setting the On-Level and Ramp Rates (Optional)...................................................................................18
Setting the On-Level................................................................................................................................18
Setting the Ramp Rate ............................................................................................................................19
Locking In a Remote-Controlled On-Level and Ramp Rate.................................................................... 19
Locking In a Local On-Level and Ramp Rate..........................................................................................19
HOW TO CROSS-LINK MORE THAN ONE SWITCHLINC DIMMER....................................................... 20
Cross-Linking in a 3-Way Circuit .............................................................................................................20
ADVANCED FEATURES OF SWITCHLINC DIMMER.............................................................................. 21
Restoring Power to SwitchLinc Dimmer .................................................................................................. 21
Resetting SwitchLinc Dimmer to Its Factory Default Settings................................................................. 21
X10 PROGRAMMING OPTIONS ............................................................................................................... 22
Setting the X10 Primary Address ............................................................................................................22
Removing the X10 Primary Address .......................................................................................................22
Setting the X10 On-Level and X10 Ramp Rate for the X10 Primary Address ........................................23
Enabling and Disabling X10 Resume Dim ..............................................................................................23
ADVANCED X10 PROGRAMMING OPTIONS.......................................................................................... 24
Remotely Setting the On-Level for the X10 Primary Address................................................................. 24
Remotely Setting the Ramp Rate for the X10 Primary Address .............................................................24
About X10 Scene Address Programming................................................................................................25
Remotely Setting an X10 Scene Address and On-Level ........................................................................25
Remotely Removing an X10 Scene Address ..........................................................................................25
Remotely Setting the Ramp Rate for an X10 Scene Address.................................................................26
HOW TO USE SWITCHLINC DIMMER...................................................................................................... 27
Using the Paddle .....................................................................................................................................27
Using the Air Gap ....................................................................................................................................27
COLOR OPTIONS FOR SWITCHLINC DIMMER ...................................................................................... 28

Paddle and LED Colors are Changeable ................................................................................................28
How to Change Paddle and LED Colors.................................................................................................28
ABOUT INSTEON ...................................................................................................................................... 30
Understanding Why an INSTEON Network Is Reliable........................................................................... 30
Further Enhancing Reliability ..................................................................................................................30
Using Smarthome’s Access Point to Upgrade Your INSTEON Network ................................................ 30
About INSTEON and X10........................................................................................................................ 31
TROUBLESHOOTING................................................................................................................................ 32
SPECIFICATIONS ...................................................................................................................................... 34
SwitchLinc Dimmer Specifications ..........................................................................................................34
Certification..............................................................................................................................................36
Limited Warranty ..................................................................................................................................... 36

SwitchLinc Dimmer 1000W User’s Guide
Page 4 of 36
ABOUT SWITCHLINC DIMMER
Congratulations on purchasing the INSTEON®SwitchLinc™Dimmer 1000W. With its elegant look,
smooth touch, and stylish LED Bar, you can not only control the lights that you wire it to, but you can add
remote control to all kinds of other INSTEON and X10 devices in your home to match your lifestyle.
Besides controlling other devices, SwitchLinc Dimmer can itself be remotely operated from other
INSTEON or X10 Controllers, including other SwitchLinc Dimmers.
What is INSTEON?
INSTEON is a simple, reliable, and affordable breakthrough in home control. Simple, because Plug-n-
Tap™setup is a breeze, and there are no wires to add – INSTEON uses existing powerline wiring as well
as radio-frequency for communication. Reliable, because every INSTEON device is a two-way repeater.
And affordable, not just because of low cost, but because INSTEON also works with legacy X10 devices.
An INSTEON home grows in value with every INSTEON device you add, making life more convenient,
safe and fun.
Key SwitchLinc Dimmer Features
•After installation, setup is easy – links to controlled devices and other controllers in minutes
•Controls all standard incandescent lamps, up to 1000 watts
•Paddle has true rocker action – top is ON or BRIGHT, bottom is OFF or DIM
•9-level LED Bar shows brightness of lights
•Dims lights to 32 brightness levels
•Changes brightness at 32 ramp rates
•Paddle and Trim Frame colors are changeable to ivory, almond, black, brown, or gray with optional kit
(comes in white)
•White LED Bar color is changeable to green, blue, amber, or red with optional kit
•Responds to commands from X10 controllers and sends X10 commands to X10 devices
•Wires in like a standard wall switch (but also requires a NEUTRAL connection)
•Supports “virtual” 3-, 4-, or more-way circuits with multiple SwitchLinc Dimmers
•Warranted for two years
SET Button (push)
Air Gap (pull)
LED Bar
Brightness
Indicator
Faceplate
Paddle Top
ON/BRIGHT
Paddle Bottom
OFF/DIM
Trim Frame

SwitchLinc Dimmer 1000W User’s Guide
Page 5 of 36
HOW TO INSTALL SWITCHLINC DIMMER
Tools You Will Need
•A flat screwdriver to remove the faceplate from the switch junction box.
•A Phillips screwdriver for the screws that hold SwitchLinc Dimmer in the junction box.
•A wire cutter and stripper if the switch you are replacing requires you to cut the wires to remove them.
•A small Phillips screwdriver if you will be changing the color of the trim frame and paddle.
Caution
Read and understand these instructions before installing, and retain them for future reference.
SwitchLinc Dimmer is intended for installation in accordance with the National Electric Code and local regulations in the
United States, or the Canadian Electrical Code and local regulations in Canada. Use indoors only. SwitchLinc Dimmer
is not designed nor approved for use on power lines other than 120V 60Hz, single phase. Attempting to use SwitchLinc
Dimmer on non-approved powerlines may have hazardous consequences.
Do not install SwitchLinc Dimmer to control a receptacle or fluorescent lighting fixture. Connect only copper or copper-
clad wire to SwitchLinc Dimmer. Before installing, disconnect power at the circuit breaker or remove the circuit’s fuse to
avoid shock or possible damage to SwitchLinc Dimmer. It is recommended that a qualified electrician perform this
installation.
To reduce the risk of overheating and possible damage to other equipment, use SwitchLinc Dimmer to control 110V
incandescent lamps only. Dimming an inductive load, such as a fan or transformer, could cause damage to the dimmer,
the load device, or both. If the manufacturer of the load device does not recommend dimming, use a non-dimming
INSTEON switch such as SwitchLinc Relay. USER ASSUMES ALL RISKS ASSOCIATED WITH DIMMING AN
INDUCTIVE LOAD.
A Helpful Tool – Voltmeter or Voltage Tester
During the installation of SwitchLinc Dimmer, it may be necessary to identify the wires inside the junction box. Knowing
for sure which wire is the LINE (sometimes called HOT) can reduce the guesswork when installing a single switch, and it
is absolutely necessary when working with multi-way lighting circuits. A voltmeter is ideal for this application. Many of
the digital models can also read current so you can measure how much power is being drawn by the switch’s load.
A simpler measurement tool, available at most home improvement centers, is a voltage sensor. This device, often
costing less than $20, can sense voltage when placed near a wire. The tip of the voltage sensor can tell if voltage is on
the wire without touching the bare copper conductor or breaking the insulation.
When using these tools, be certain to read and understand the safety instructions. Often when these tools are used, the
power to the circuit will need to be turned on. When working around live electrical wires, take your time and concentrate
on the task.

SwitchLinc Dimmer 1000W User’s Guide
Page 6 of 36
Preparing to Install SwitchLinc Dimmer
Before installing SwitchLinc Dimmer, please familiarize yourself with the following and take the necessary
precautions listed here:
•Be sure that you have turned off the circuit breaker or removed the fuse for the circuit you are
installing SwitchLinc Dimmer in. Installing SwitchLinc Dimmer with the power on will expose you to
dangerous voltages.
•SwitchLinc Dimmer requires a small amount of power to operate, which it receives from a connection
to the NEUTRAL electrical wire (usually white). If you are replacing a standard mechanical switch
with SwitchLinc Dimmer, the switch you are replacing will normally not have a connection to the
neutral wire. However, most junction boxes will contain a NEUTRAL wire that you can connect
SwitchLinc Dimmer to. If your junction box does not contain a neutral wire, please call SmartLabs
Tech Support at 800-762-7846, or consult an electrician.
•Don’t use SwitchLinc Dimmer to control low-voltage lighting with electronic transformers, fluorescent
lights, or motors. These are inductive loads, which SwitchLinc Dimmer is not designed to control.
Use a SmartLabs SwitchLinc Relay instead.
•Don’t use SwitchLinc Dimmer to control an electrical outlet, because non-dimmable or inductive loads
may be plugged into it.
•SwitchLinc Dimmer may feel warm during operation. This includes the exaggerated mounting fins,
which are designed to aid in heat dissipation. The amount of heat generated is within approved limits
and poses no hazards. To minimize heat buildup, ensure that the area surrounding the rear of
SwitchLinc Dimmer has adequate ventilation by clearing away excess insulation.
•If the dissipation fins prevent SwitchLinc Dimmer from fitting in the desired installation location, the
fins can be removed by grasping the edge of each fin with pliers, and bending the fin back and forth
along the score line until the fin breaks off. The removal of each individual fin reduces SwitchLinc
Dimmer’s rated capacity by 100W, since removing the fins reduce the heat dissipation capacity.
Removing a single fin reduces SwitchLinc Dimmer’s rating to 900W, removing two fins reduces
capacity to 800W, and removing all four fins reduces capacity to 600W. Please note: dissipation fins
cannot be reattached once removed.
IMPORTANT!
If you are not knowledgeable about and comfortable with electrical circuitry, you should have a
qualified electrician install SwitchLinc Dimmer for you. Additionally, SwitchLinc Dimmer requires the
presence of a neutral wire in the installation location. Your will not be able to use SwitchLinc Dimmer
without a neutral wire. If there is no neutral wire available, or if you are unsure if you have a neutral
wire, please contact SmartLabs Tech Support for information and assistance.
SmartLabs Tech Support
800-762-7846
Heat dissipating mounting fins

SwitchLinc Dimmer 1000W User’s Guide
Page 7 of 36
Installing SwitchLinc Dimmer
1. For best INSTEON Network performance, be sure you have properly installed at least two Access
Point Signal Enhancers.
2. At the circuit breaker or fuse panel, disconnect the power for all of the circuits in the switch junction
box. Verify that power is off by trying to turn on the lights controlled by the switches.
3. Remove the faceplate from the switch junction box, then unscrew the switch you are replacing and
pull it out from the junction box.
4. Disconnect the wires from the switch you are replacing. If the wires cannot be detached by
unscrewing them, cut the wires where they enter the switch, then strip ½” of insulation off the ends.
5. If you are installing SwitchLinc Dimmer into a standard two-way circuit (where only one switch
controls the load), follow the diagram below to identify and connect the LINE, LOAD, NEUTRAL, and
GROUND wires. If the colors of the wires do not match the diagram, be sure you have identified the
wires correctly before connecting them.
6. If you are installing SwitchLinc Dimmer into a multi-way circuit (where more than one switch controls
the same load), follow the instructions in the section Installing SwitchLinc Dimmer in a Multi-Way
Circuit, below, to identify and connect the LINE, TRAVELER, NEUTRAL, and GROUND wires.
7. After you have connected all of the wires, ensure that all of the wire connectors are firmly attached
and that there is no exposed copper except for the GROUND wire.
8. Orient SwitchLinc Dimmer with the LED Bar at the left, gently place it into the junction box, then screw
it into place.
9. Turn the circuit breaker back on or re-install the fuse.
10. After the bottom LED in the LED Bar comes on, test that SwitchLinc Dimmer is working properly by
turning the light on and off.
11. Reinstall the faceplate.
NOTE
The NEUTRAL wire will not
normally be connected to the
switch you are replacing. If there is
no NEUTRAL wire in the junction
box (SwitchLinc Dimmer will not
function without a neutral), please
consult an electrician or call
SmartLabs Tech Support
800-762-7846
Main Panel
120 VAC
LINE
Usually Black
LOAD
Usually Red or Blue
NEUTRAL
Usually White
GROUND
Bare Coppe
r
LINE
Black
NEUTRAL
White
GROUND
Bare Copper
LOAD
Red
Light
Fixture(s)

SwitchLinc Dimmer 1000W User’s Guide
Page 8 of 36
Installing SwitchLinc Dimmer in a Multi-Way Circuit
Understanding Multi-Way Circuits
If more than one switch controls a single set of lights (called a LOAD), the switches are part of a multi-way
circuit. A 3-way circuit uses two switches to control a LOAD, a 4-way circuit uses three switches, and so
forth. Most homes have one or more 3-way circuits, with two switches located in hallways, stairwells, or
two different entrances to a room. Less commonly found are circuits that are 4-way or above.
You can use SwitchLinc Dimmers to replace switches in multi-way circuits that are already wired in, or
you can use them to create virtual multi-way circuits where there is no existing wiring.
Here is how a wired-in three-way circuit (with two switches) works:
A wired-in four- or more-way circuit (with three or more switches) has additional switches added in the
middle of the circuit. In the diagram below, the additional switch is shown in one position in the upper box
and in the other position below.
To learn more about multi-way circuits, go to Google.com or another search engine on the Internet and
enter the search terms “three-way switch” or “four-way switch.”

SwitchLinc Dimmer 1000W User’s Guide
Page 9 of 36
Using SwitchLinc Dimmers in Virtual Multi-Way Circuits
In a virtual multi-way circuit, only one SwitchLinc Dimmer, called the SwitchLinc Primary, actually controls
the LOAD in the multi-way circuit. Any additional SwitchLinc Dimmers, called SwitchLinc Secondaries,
are not connected to the LOAD, but only to the powerline (by being wired to the LINE and NEUTRAL). All
of the SwitchLinc Dimmers can communicate with one another using INSTEON networking on the
powerline. After wiring in the SwitchLinc Dimmers, you create the virtual multi-way circuit by setting up all
of the SwitchLinc Dimmers to control each other (see HOW TO SET UP SWITCHLINC DIMMER TO
REMOTELY CONTROL AN INSTEON DEVICE, below).
The diagram below shows how you convert a wired-in three-way circuit into a virtual three-way circuit
using two SwitchLinc Dimmers. Step-by-step instructions for wiring in the SwitchLinc Dimmers are in the
next section.
Notice that one of the TRAVELER wires (number 1, the red one) is not used, so you will cap it off at both
ends with a wire nut.
The other TRAVELER (number 2, the black one) you will convert to a LINE wire. In the junction box
where the SwitchLinc Secondary is, connect TRAVELER 2 to the existing LINE and also to the
SwitchLinc Secondary’s LINE wire. In the other junction box at the other end, you will connect
TRAVELER 2 to the SwitchLinc Primary’s LINE wire.
The SwitchLinc Primary’s LOAD wire gets connected to the actual lights that are being controlled.
The LOAD wire for any SwitchLinc Secondaries that you will be installing will not be connected to
anything, so cap those LOAD wires off with a wire nut.
All SwitchLinc Dimmers, whether they are Primaries or Secondaries, must be connected to NEUTRAL
and to GROUND. Note that the switches you are replacing will not normally have a connection to
NEUTRAL. If there is no NEUTRAL wire in the junction box (SwitchLinc Dimmer will not function without
a neutral), please consult an electrician or call SmartLabs Tech Support, 800-762-7846.
NOTE
Wire colors
marked with a *
are the usual
colors and may
differ in some
homes.
LINE
Black*
NEUTRAL
White*
GROUND
Bare Coppe
r
LINE
Black
NEUTRAL
White
LOAD
Red
LOAD
Red* or Blue*
GROUND
Bare Coppe
r
LINE
Black
NEUTRAL
White
GROUND
Bare Copper
LOAD
Red
TRAVELER 1
Red* or Blue*
TRAVELER 2
Black*
SwitchLinc
Secondary
SwitchLinc
Primary
Light
Fixture(s)
Main Panel
120 VAC

SwitchLinc Dimmer 1000W User’s Guide
Page 10 of 36
Step-by-Step Instructions for Installing Multi-Way SwitchLinc Dimmers
When replacing a three-way mechanical switch, each switch will have three wires connected to it from the
wall box. Four-way or greater circuits will have four wires connected to the switches in the center of the
circuit. For this tutorial, we will follow the most commonly used wire colors for homes in North America.
1. Find the LINE wire. Your first task is to find out which
switch junction box is the one where the electricity comes
into the circuit. This box will contain the LINE wire
(sometimes called HOT).
a. Turn off the electricity at the circuit breaker panel.
b. Pull all the switches in the multi-way circuit out of their
junction boxes. Each switch should have three wires
connected to it. If the circuit is a four-way or greater,
some of the switches will have four wires.
c. Disconnect the wires from the old switches. If the wires cannot be detached by unscrewing them,
cut the wires where they enter the switch, then strip ½ inch of insulation off the ends.
d. Making sure that none of the wires are touching anything and that no one is around the wall
boxes, turn the electricity back on.
e. Using a voltmeter or voltage sensor, individually test each wire for voltage. When you measure
120 Volts AC, that wire is the LINE wire. LINE wires are usually black.
f. The other two wires, usually black and red, are the TRAVELERS and go to the next junction box.
TRAVELER wires are usually in the same cable sheath.
g. Turn off the electricity to resume installing the new SwitchLinc Dimmers.
2. Connect the SwitchLinc Secondary’s LINE Wire. The SwitchLinc Dimmer that will be the
Secondary goes in the junction box where you found the LINE wire. Connect the black LINE wire that
you found, the black TRAVELER, and the Black LINE wire on SwitchLinc Dimmer all together with a
single wire nut.

SwitchLinc Dimmer 1000W User’s Guide
Page 11 of 36
3. Cap the other TRAVELER wire. The other TRAVELER
wire, usually red, will not be used, so put a wire nut on the
end of it.
4. Cap the red LOAD wire from the SwitchLinc Secondary. Put a wire nut on the end of the
SwitchLinc Secondary’s LOAD wire to ensure that it won’t connect to anything.
5. Connect the SwitchLinc Secondary’s NEUTRAL Wire.
Locate the group of NEUTRAL wires, usually white, in the
rear of the box. The old switch should not have been
connected to the NEUTRAL wires, but SwitchLinc Dimmer
requires this connection in order to draw a small amount of
power for itself (SwitchLinc Dimmer will not function without a
neutral). Connect SwitchLinc Secondary’s white NEUTRAL
wire to the other NEUTRAL wires with a wire nut.

SwitchLinc Dimmer 1000W User’s Guide
Page 12 of 36
6. Connect the SwitchLinc Secondary’s GROUND Wire.
Connect the bare copper GROUND wire to the other
GROUND wires in the junction box.
7. Install Additional SwitchLinc Secondaries. If you have a four-way or greater switching circuit, see
Special Treatment for Four- or More-Way Circuits at the end of this section.
8. Identify the Wires for the SwitchLinc Primary. The SwitchLinc Primary is the SwitchLinc Dimmer
that will actually control the LOAD. In the remaining junction box where you will install the SwitchLinc
Primary, find the wire that carries power from the switch to the lights. This wire, called the LOAD
wire, is commonly red.
In the same junction box, there will also be the two TRAVELER wires from the first box, often both in
the same cable sheath. Identify the one TRAVELER wire (black) that you connected the LINE wire to
in the first junction box.
If you’re not sure which is the TRAVELER wire connected to the LINE wire, you can use the same
method described earlier to find it. Turn on the power (taking the same precautions), and use a
voltmeter to find the wire with 120 Volts AC on it. This wire is the TRAVELER wire that you
connected to the LINE wire in the first junction box.
Make sure the power is turned off again before proceeding.
9. Connect the SwitchLinc Primary’s LINE Wire. Use a wire
nut to connect the TRAVELER wire, usually black, that you
identified as connected to the LINE wire to the SwitchLinc
Primary’s black LINE wire.

SwitchLinc Dimmer 1000W User’s Guide
Page 13 of 36
10. Cap the other TRAVELER wire. The other TRAVELER
wire, usually red, will not be used, so put a wire nut on the
end of it.
11. Connect the SwitchLinc Primary’s LOAD Wire. Use a wire nut to connect the LOAD wire, usually
red, to the SwitchLinc Primary’s red LOAD wire.
12. Connect the SwitchLinc Primary’s NEUTRAL and GROUND Wires. Follow the same instructions
as before in Steps 5 and 6 for the SwitchLinc Secondary.
13. Return to the installation instructions on page 7 and continue on with step 7.
Special Treatment for Four- or More-Way Circuits
If your lighting circuit includes more than two switches controlling a single set of lights, those extra
switches will have four wires connected to them. Two of the wires are TRAVELERS from the preceding
switch and the other two are TRAVELERS to the next switch in the chain. You will be converting the
black TRAVELER wires to LINE wires and replacing the old four-wire switches with SwitchLinc
Secondaries.
1. Connect the SwitchLinc Secondary’s LINE Wire. Use a wire nut to connect both black
TRAVELER wires to the SwitchLinc Primary’s black LINE wire.
2. Cap the Two Unused TRAVELERS. The other two TRAVELER wires, usually red, will not be used,
so put wire nuts on the ends of them.
3. Cap the red LOAD wire from the SwitchLinc Secondary. Put a wire nut on the end of the
SwitchLinc Secondary’s LOAD wire to ensure that it won’t connect to anything.
4. Connect the SwitchLinc Secondary’s NEUTRAL and GROUND Wires. Use the same instructions
given previously in Steps 5 and 6.

SwitchLinc Dimmer 1000W User’s Guide
Page 14 of 36
HOW TO SET UP SWITCHLINC DIMMER TO REMOTELY CONTROL AN
INSTEON DEVICE
Linking SwitchLinc Dimmer to a Controlled INSTEON Device
To use SwitchLinc Dimmer as an INSTEON Controller, follow these steps to link SwitchLinc Dimmer and
a controlled INSTEON Device together. Refer to your INSTEON Device’s User’s Guide for detailed
instructions on how to properly install it and link it to SwitchLinc Dimmer. The following will work for the
most common INSTEON Devices.
1. Set SwitchLinc Dimmer to Linking Mode by pressing and holding the
Paddle Top for 10 seconds until the top LED in the LED Bar begins
blinking slowly and the controlled light flashes. Don’t let up too soon – 10
seconds is a pretty long time!
2. Select your INSTEON Device from the list below and follow the linking method for that Device. You
have about 4 minutes to perform this step before SwitchLinc Dimmer’s Linking Mode times out
automatically.
A. A Second SwitchLinc Dimmer – Press and hold the Second SwitchLinc
Dimmer’s Paddle Top for 10 seconds, then release. To confirm linking, the
Second SwitchLinc Dimmer will blink the top LED in its LED Bar and flash the
light that it is wired to.
B. LampLinc™Dimmer – Press and hold the SET Button on the side of LampLinc
Dimmer for 3 seconds, then release. To confirm linking, LampLinc Dimmer will
blink its Status LED and flash the lamp that it is controlling.
C. ApplianceLinc™– Press and hold the SET Button on the side of ApplianceLinc
for 3 seconds, then release. To confirm linking, ApplianceLinc will blink its Status
LED.
D. KeypadLinc™– Press and hold the ON Button at the top of KeypadLinc for 10
seconds, then release. To confirm linking, KeypadLinc will blink the ON Button
and flash the light that it is wired to.
E. Other INSTEON Devices – See the INSTEON Device’s User’s Guide.
3. Go back to the SwitchLinc Dimmer that you placed in Linking Mode. If linking was successful, the top
LED in its LED Bar will not be blinking but will remain steadily on.
4. Test that your INSTEON Device is working as expected by pressing the Paddle Top and Paddle
Bottom.
BE CAREFUL
Any paddle press will exit Linking Mode early.

SwitchLinc Dimmer 1000W User’s Guide
Page 15 of 36
Unlinking a Controlled INSTEON Device from SwitchLinc Dimmer
If you are no longer going to use an INSTEON Device that has previously been linked to SwitchLinc
Dimmer, it is very important that you unlink it, because otherwise SwitchLinc Dimmer will retry any
commands intended for the unused INSTEON Device, thus slowing down your system.
1. Set SwitchLinc Dimmer to Linking Mode by pressing and holding the Paddle Top for 10 seconds
until the top LED in the LED Bar begins blinking slowly and the controlled light flashes.
2. Set SwitchLinc Dimmer to Unlinking Mode by pressing and holding the Paddle Top again for 10
seconds until the controlled light flashes again.
3. Follow the same method given above that you used to link your INSTEON Device to unlink it. On
most INSTEON Devices, you just push an ON Button for 10 seconds or a SET Button for 3 seconds.
4. Go back to the SwitchLinc Dimmer that you placed in Unlinking Mode. If linking was successful, the
top LED in its LED Bar will not be blinking but will remain steadily on.
Creating an INSTEON Scene
INSTEON Scenes let you activate dramatic lighting moods with the press of just one button. INSTEON
Scenes are very easy to set up – just link more than one INSTEON Device to SwitchLinc Dimmer. Then,
when you press either the Paddle Top or Paddle Bottom on SwitchLinc Dimmer, all of the INSTEON
Devices linked in the scene will respond as a group. You can link multiple INSTEON Devices to multiple
of INSTEON Controllers.
To add an additional INSTEON Device to a scene controlled by SwitchLinc Dimmer, simply follow the
same procedure as above in Linking SwitchLinc Dimmer to a Controlled INSTEON Device. To remove an
INSTEON Device from a scene, see Unlinking a Controlled INSTEON Device from SwitchLinc Dimmer.
TIP
You can avoid having to hold SwitchLinc Dimmer’s Paddle Top down for 10 seconds for each
INSTEON Device in a scene by placing SwitchLinc Dimmer in Scene Setup Mode, also called
Multilink Mode.
1. Set SwitchLinc Dimmer to Scene Setup Mode by
pressing and holding the Paddle Top for 10
seconds, then pressing the SET Button at the
bottom of the paddle. SwitchLinc Dimmer’s top
LED in the LED Bar will blink slowly.
2. Follow the linking method given above for the INSTEON Device you want to include in the scene.
On most INSTEON Devices, you just push an ON Button for 10 seconds or a SET Button for 3
seconds. SwitchLinc Dimmer will flash its controlled light to confirm linking, and the top LED in its
LED Bar will continue to blink slowly.
3. On some INSTEON Devices, you may be able to set up additional features, such as On-Levels or
Ramp Rates at this time.
4. Continue Steps 2 and 3 for any additional INSTEON Devices you want to link to the scene.
5. When you are finished linking INSTEON Devices to SwitchLinc Dimmer, complete Scene Setup by
pressing the Paddle Top (actually, any button press will terminate Scene Setup). The top LED in
SwitchLinc Dimmer’s LED Bar will stop blinking and remain steadily on. You have about 4
minutes of inactivity before SwitchLinc Dimmer’s Scene Setup Mode times out automatically.

SwitchLinc Dimmer 1000W User’s Guide
Page 16 of 36
HOW TO SET UP SWITCHLINC DIMMER TO BE REMOTELY
CONTROLLED BY AN INSTEON CONTROLLER
Linking an INSTEON Controller to SwitchLinc Dimmer
To remotely control SwitchLinc Dimmer using another INSTEON Controller, follow these steps to link
SwitchLinc Dimmer and the INSTEON Controller together. Refer to your INSTEON Controller’s User’s
Guide for detailed instructions on how to properly install it and link it to SwitchLinc Dimmer. The following
will work for the most common INSTEON Controllers.
1. Select your INSTEON Controller from the list below and follow the method shown to put it into
Linking Mode.
A. A Second SwitchLinc Dimmer – Press and hold the Second SwitchLinc
Dimmer’s Paddle Top for 10 seconds, then release. To confirm that it is in Linking
Mode, the Second SwitchLinc Dimmer will flash the light that it is wired to once and
begin blinking the top LED in its LED Bar.
B. ControLinc™Tabletop Controller – Choose the ON/OFF Button Pair you want to
use for controlling SwitchLinc Dimmer. Press and hold the ON Button of the pair
for 10 seconds. To confirm that it is in Linking Mode, ControLinc’s Status LED will
begin blinking.
C. KeypadLinc™– Choose the ON Button you want to use for controlling SwitchLinc
Dimmer. Press and hold the ON Button for 10 seconds. To confirm that it is in
Linking Mode, KeypadLinc will flash the light that it is wired to once and begin
blinking the ON Button that you pushed.
D. Other INSTEON Controllers – See the INSTEON Controller’s User’s Guide.
2. Press and hold the Paddle Top for 10 seconds on the SwitchLinc Dimmer
that is being controlled. To confirm linking, the SwitchLinc Dimmer will blink
the top LED in its LED Bar and flash the light that it is wired to. Depending
on the INSTEON Controller, you have about 4 minutes to perform this step
before Linking Mode times out automatically.

SwitchLinc Dimmer 1000W User’s Guide
Page 17 of 36
Unlinking SwitchLinc Dimmer from an INSTEON Controller
If you are no longer going to control a SwitchLinc Dimmer with an INSTEON Controller, it is very
important that you unlink it, because otherwise the controller will retry any commands intended for the
unused SwitchLinc Dimmer, thus slowing down your system.
1. Select your INSTEON Controller from the list below and follow the method shown to put it into
Unlinking Mode.
A. A Second SwitchLinc Dimmer – Follow the instructions in the section Unlinking
a Controlled INSTEON Device from SwitchLinc Dimmer, above. (Briefly, press
and hold the Second SwitchLinc Dimmer’s Paddle Top for 10 seconds twice.)
B. ControLinc™Tabletop Controller – Press and hold the OFF Button of the
ON/OFF Button Pair you used for controlling SwitchLinc Dimmer for 10 seconds.
To confirm that it is in Unlinking Mode, ControLinc’s Status LED will begin
blinking.
C. KeypadLinc™– Press and hold for 10 seconds the ON Button you used for
controlling SwitchLinc Dimmer, then press and hold the same ON Button for 10
seconds again. To confirm that it is in Unlinking Mode, KeypadLinc will flash the
light that it is wired to once and begin blinking the ON Button that you pushed.
D. Other INSTEON Controllers – See the INSTEON Controller’s User’s Guide.
2. Press and hold the Paddle Top for 10 seconds on the SwitchLinc
Dimmer that is being controlled. To confirm unlinking, the SwitchLinc
Dimmer will blink the top LED in its LED Bar and also the light that it is wired to. Depending
on the INSTEON Controller, you have about 4 minutes to perform this step before Unlinking
Mode times out automatically.

SwitchLinc Dimmer 1000W User’s Guide
Page 18 of 36
HOW TO SET UP ON-LEVELS AND RAMP RATES
Setting the On-Level and Ramp Rates (Optional)
The On-Level is the brightness that the light you are controlling will go to when you turn it on. The On-
Level is adjustable from OFF to 100% brightness. The default is 100%.
The Ramp Rate sets the time it will take for the light you are controlling to go from OFF to the On-Level
brightness, or from the On-Level brightness to OFF. This time is adjustable from 0.1 to 9 seconds to
ramp between full-ON and full-OFF. The default is 0.1 second.
SwitchLinc Dimmer can store many On-Levels and Ramp Rates in its memory.
Local On-Level and Ramp Rate values apply when you tap the Paddle Top or Paddle Bottom on
SwitchLinc Dimmer itself.
Remote-Controlled On-Level and Ramp Rate values apply when another INSTEON Controller tells
SwitchLinc Dimmer to turn on or turn off. SwitchLinc Dimmer stores separate On-Levels and Ramp Rates
for each button on each Controller that it is linked to. These On-Levels and Ramp Rates can all be the
same, or they can be different.
You establish an On-Level and Ramp Rate by first setting them up and then locking them in. Setting an
On-Level and setting a Ramp Rate are always done the same way, but locking them in is different,
depending on what you want the On-Level and Ramp Rates to apply to.
You can set up an On-Level or Ramp Rate in any order. When you do the lock-in, the currently-set On-
Level and Ramp Rate are locked in together.
Setting the On-Level
1. Hold down SwitchLinc Dimmer’s Paddle Top or Paddle Bottom to adjust the brightness of the
controlled light to the desired On-Level.
2. Press the SET Button at the bottom of the paddle.
3. SwitchLinc Dimmer will flash the controlled light once to confirm the On-Level setting.
BE CAREFUL
If SwitchLinc Dimmer is flashing an LED in its LED Bar, you held the SET Button down too long.
Holding down the SET Button for 3 seconds is an alternate way to place SwitchLinc Dimmer into
Linking Mode. To exit Linking Mode, tap the Paddle Top.

SwitchLinc Dimmer 1000W User’s Guide
Page 19 of 36
Setting the Ramp Rate
The Ramp Rate sets the time it will take for the light you are controlling to go from OFF to the On-Level
brightness, or from the On-Level brightness to OFF. This time is adjustable from 0.1 to 9 seconds to
ramp between full-ON and full-OFF. The default is 0.1 second.
1. Hold down SwitchLinc Dimmer’s Paddle Top or Paddle Bottom to adjust the Ramp Rate of the
controlled light. Adjust the Ramp Rate to be faster by brightening the light, or adjust it to be slower by
dimming the light. The table below gives the approximate relationship between the brightness you
set and the Ramp Rate you get.
2. Double-press the SET Button at the bottom of the paddle.
3. SwitchLinc Dimmer will flash the controlled light once to confirm the Ramp Rate setting.
Locking In a Remote-Controlled On-Level and Ramp Rate
Whenever you link an INSTEON Controller to SwitchLinc Dimmer, the current On-Level and Ramp Rate
values are stored in SwitchLinc Dimmer’s memory. So, locking in a remote-controlled On-Level and
Ramp Rate is really just the same as linking. Just follow the instructions in the section Linking an
INSTEON Controller to SwitchLinc Dimmer, above.
Linking an INSTEON Controller to SwitchLinc Dimmer restores the previous values for the Local On-Level
and Local Ramp Rate. So, linking does not affect the Local On-Level and Ramp Rate.
Locking In a Local On-Level and Ramp Rate
To lock in the current On-Level and Ramp Rate as the Local On-Level and Ramp Rate, all you have to do
is not link SwitchLinc Dimmer to an INSTEON Controller for four minutes. After the four-minute timeout,
the current On-Level and current Ramp Rate will be permanently locked in as the Local On-Level and
Local Ramp Rate.
BE CAREFUL
If you got two flashes of the light, you didn’t double-press the SET Button fast enough, and
SwitchLinc Dimmer incorrectly thought you set up the On-Level twice. Re-set the correct On-
Level and try the Ramp Rate setting again.
NOTE
If the light is ramping to
less than full brightness,
then the time it will take
will be proportionately
less. For instance, if the
light is going to half
brightness, the time it will
take for a given Ramp
Rate will be halved.
Approximate
Brightness
Level
Ramp
Rate in
Seconds
90-100% 0.1
77-87% 0.2
65-74% 0.3
52-61% 0.5
39-48% 2.0
26-35% 4.5
13-23% 6.5
1-10% 8.5
1% 9.0

SwitchLinc Dimmer 1000W User’s Guide
Page 20 of 36
HOW TO CROSS-LINK MORE THAN ONE SWITCHLINC DIMMER
Cross-Linking in a 3-Way Circuit
The purpose of cross-linking switches allows you to track LED brightness levels as well as on/off levels on
both the primary and secondary switches. For this example we will use a Primary switch controlling the
load and one secondary switch in a virtual 3-way. They will be referred to as: Primary Switch (load
controlling) and Secondary Switch.
Note: If you intend on setting a ramp rate or ON level; this should be done on each switch prior to cross-linking them.
Please refer to the section above on How to set up SwitchLinc Dimmer to remotely control an INSTEON device for
instructions on linking switches
1. Link Primary Switch to Secondary Switch.
2. Cross-link Secondary Switch to Primary Switch.
Upon successful completion, each switch in the above scenario will now track both ON/OFF status and
brightness level on the LED bar of the other switches it has been cross-linked to.
Cross-Linking in a Multi-Way Circuit using Multi-Link Mode
For more than two switches, multi-link mode will allow you to save time. For this example we will use a
Primary switch controlling the load and two secondary switches in a virtual 4-way. They will be referred to
as: Primary Switch (load controlling), Secondary Switch 1, and Secondary Switch 2.
1. Primary Switch should be put into Multi-Link mode then link to Secondary Switch 1 and Secondary
Switch 2. Tap the Primary Switch to go out of Multi-Link mode.
2. Secondary Switch 1 should be put into Multi-Link mode then link to Primary Switch and Secondary
Switch 2. Tap the Secondary Switch 1 to go out of Multi-Link mode.
3. Secondary Switch 2 should be put into Multi-Link mode then link to Primary Switch and Secondary
Switch 1. Tap the Secondary Switch 2 to go out of Multi-Link mode.
Upon successful completion, each switch in the above scenario will now track both ON/OFF status and
brightness level on the LED bar of the other switches it has been cross-linked to.
