Intel 41210 User manual

Intel®41210 Serial to Parallel PCI
Bridge Evaluation Board
User’s Guide
October 2004
Order Number: 278947-002

ii User’s Guide
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY
ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN
INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS,INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS
ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES
RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER
INTELLECTUAL PROPERTY RIGHT. Intel products are not intended for use in medical, life saving, life sustaining applications.
Intel may make changes to specifications and product descriptions at any time, without notice.
The Intel ®41210 Serial to Parallel PCI Bridge may contain design defects or errors known as errata which may cause the product to deviate from
published specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.
Copies of documents which have an ordering number and are referenced in this document, or other Intel literature may be obtained by calling
1-800-548-4725 or by visiting Intel's website at http://www.intel.com.
Intel is a trademark or registered trademark of Intel Corporation or its subsidiaries in the United States and other countries.
*Other names and brands may be claimed as the property of others.
Copyright © 2004, Intel Corporation

User’s Guide iii
Contents
Contents
1.0 Introduction ...............................................................................................................................5
2.0 Overview .....................................................................................................................................5
3.0 Features.......................................................................................................................................5
4.0 Major Components..................................................................................................................6
5.0 DIP Switches..............................................................................................................................7
Figures
1 Major Components Overview .......................................................................................................6
2 Switches, Jumpers, and Connectors Location..............................................................................7
Tables
1 DIP Switch Operation, PCI-X and PCI Clock Frequency..............................................................8
2 DIP Switch Operation, SMBUS ADRESS.....................................................................................8
3 Jumper Connections, JTAG Port..................................................................................................9
4 Jumper Connections, Microcontroller I2C interface......................................................................9
5 Jumper Connections, GNT “A” and “B” Header............................................................................9
6 Jumper Connections, REQ “A” and “B” Header..........................................................................10
7 Jumper Connections, J13, J14 and J17 .....................................................................................10
8 Jumper Connections, QSWITCH EN Header.............................................................................10

iv User’s Guide
Contents
Revision History
Date Revision Description
October 2004 002
-Updated naming terminology in Sections 2.0 and 3.0.
-Corrected PCI Bus name Header Connectors J5 and J6 in
Section 4.0.
-Corrected Switch S3 and S4 PCI-X 66 MHZ Pos 3 settings in
Table 1.
December 2003 001 This is the first release of this document.

Introduction
Evaluation Board User’s Guide 5
1.0 Introduction
This document describes the Intel® 41210 Serial to Parallel PCI Bridge (also called 41210 Bridge)
Evaluation Board.
2.0 Overview
The Intel® 41210 Serial to Parallel PCI Bridge evaluation board is a PCI-Express enabling tool
with PCI-X expansion slots that are used to evaluate the operation of the 41210 Bridge. The 41210
Bridge evaluation board can be used to perform the following functions:
•Develop initialization code to configure the 41210 Bridge and associated logic and devices on
the local PCI-X bus as a intelligent controller.
•Evaluate the operation of the 41210 Bridge with a variety of PCI/PCI-X devices configured in
an intelligent subsystem.
•Build and evaluate a system.
•Testing of the 41210 Bridge feature set.
3.0 Features
The 41210 Bridge evaluation board has the following features:
•Complies fully with:
— Protocol and electrical standards of the PCI Local Bus Specification, Revision 2.3
—PCI-X Bridge Architecture, Rev 1.0 B
—PCI-Express Base Specification, Rev 1.0A
— PCI-Express Card Electrical Mechanical Specification
— PCI-Express Bridge Specification.
•Includes a 41210 "transparent" PCI-X Enhanced PCI-to-PCI Bridge that provides bridging
between two processor domains.
•Includes a host PCI-Express interface that plugs into any x8 PCI-Express option card slot.
•Provides dual peer PCI-X 133 MHz slots on separate bus segments in addition to each having
a segregated PCI-X100/66 MHz slot
•Three MICTOR LA connectors for logic analyzer interfacing of each bus segment
•Support, Products, and Documentation

Major Components
6Evaluation Board User’s Guide
4.0 Major Components
The major components for the 41210 Bridge include:
•For the A Secondary:
— J11 is the PCI-X 100/66 MHz card slot.
— J7 is the PCI-X 133 MHz card slot.
•For the B Secondary:
— J12 is the PCI-X 100/66 MHz card slot.
— J8 is the PCI-X 133 MHz card slot.
•MICTOR connectors U14-17 and U19-20 provide test points for the 64-bit S_AD signals.
•Header Connectors J3 and J4 provides test points for the PCI Bus A REQ/GNT signals.
•Header Connectors J5 and J6 provides test points for the PCI Bus B REQ/GNT signals.
•J1 is the JTAG connector.
•J15 provides access to the Microcontroller
•S1, S3, S4, are option switches.
Figure 1. Major Components Overview

DIP Switches
Evaluation Board User’s Guide 7
5.0 DIP Switches
The 41210 Bridge uses a combination of switches and jumpers to control the various configuration
options. The following sections describe these controls.
Figure 2. Switches, Jumpers, and Connectors Location
5.0.1 Switch Settings
Table 1 and Table 2 describe the functions of the 41210 Bridge Evaluation Board switches. The
switches should be set before powering up the system. Figure 2 shows the Evaluation board
switches.
Note: When a switch is ON, it is Closed.
B2762-01
J18 F1
FAN
J13 J17
J15
J1
J5
J6
J10
J9
J7
J11
J12
S3 S4
J14
U18
U22
U23
+3.3 V
GND +12 V
GND
Intel
®
41210
Microcontroller
2003 IQ41210 REV B
41210 BRIDGE EVALUATION BOARD
MADE IN USA
©
REV
S/N
PROG INTERFACE
JTAG
"B" GNT
"B" REQ
PCI-X SEC A SLOT 1A
AUX "A" PCI-X SLOT 2A
AUX "B" PCI-X SLOT 2B
J3
S1
J4
"A" GNT
"A" REQ
"A" PCI
"A" PCIX 66
"A" PCIX 100
"A" PCI 33
"B" PCI
"B" PCIX 66
"B" PCIX 100
"B" PCI 33

DIP Switches
8Evaluation Board User’s Guide
Table 1. DIP Switch Operation, PCI-X and PCI Clock Frequency
Table 2. DIP Switch Operation, SMBUS ADRESS
Note: BOLD settings are Defaults.
5.1 Jumpers
In addition to the DIP switches, the 41210 Bridge provides stake-pin jumpers for selecting special
features. The jumpers can be used for debugging and for evaluating special features. Table 3
through Table 8 show the configuration jumpers and the jumper function. Figure 2 shows the
41210 Evaluation Board jumpers.
Switch Function Pos 1 Pos 2 Pos 3 Pos 4
S3 Selects Secondary A PCI-X 133 MHz Open Open Open NA
S3 Selects Secondary A PCI-X 100 MHz Open Open Closed NA
S3 Selects Secondary A PCI-X 66 MHz Open Open Closed NA
S3 Selects Secondary A PCI 66 MHz Closed NA NA Open
S3 Selects Secondary A PCI 33 MHz Closed NA NA Closed
S4 Selects Secondary B PCI-X 133 MHz Open Open Open NA
S4 Selects Secondary B PCI-X 100 MHz Open Open Closed NA
S4 Selects Secondary B PCI-X 66 MHz Open Open Closed NA
S4 Selects Secondary B PCI 66 MHz Closed NA NA Open
S4 Selects Secondary B PCI 33 MHz Closed NA NA Closed
Switch Function Pos 1-4
S1 All 1’s Open
S4 All 0’s CLOSED

DIP Switches
Evaluation Board User’s Guide 9
Table 3. Jumper Connections, JTAG Port
Table 4. Jumper Connections, Microcontroller I2C interface
Table 5. Jumper Connections, GNT “A” and “B” Header
Jumper Function Default
J1-2,1 TCK
Test Clock Not Installed
J1-4,3 TDO
Test Data Out Not Installed
J1-6,5 TDI
Test Data In Not Installed
J1-8,7 TMS
Test Mode Select Not Installed
J1-10,9 TRST#
Test Reset Not Installed
J1-1,3,5,7,9 GND
J1-11,12 NC
Jumper Function
J15-1 MPP/CLR
J15-2 VDD
J15-3 GND
J15-4 RB(7) (dat)
J15-5 RB(6)(Clk)
J15-6 nc
Jumper Function Position Default
J3 & 5-1,2 GNT4 1 Not Installed
J3 & 5-3,4 GNT3 2 Not Installed
J3 & 5-5,6 GNT2 3 Installed
J3 & 5-7,8 GNT1 4 Installed
J3 & 5-9,10 GNT0 5 Installed
J7-2,4,6,8,10 GND
J7-11,12 NC

DIP Switches
10 Evaluation Board User’s Guide
Table 6. Jumper Connections, REQ “A” and “B” Header
Table 7. Jumper Connections, J13, J14 and J17
Note: When selecting External Oscillator Source, source can be connected to the J8 BNC.
Note: BOLD settings are Defaults.
Table 8. Jumper Connections, QSWITCH EN Header
Note: J9 and J10 straps the QSWITCHEN# line.
Note: BOLD settings are Defaults.
Jumper Function Position Default
J4 & 6-1,2 REQ4 1 Not Installed
J4 & 6-3,4 REQ3 2 Not Installed
J4 & 6-5,6 REQ2 3 Installed
J4 & 6-7,8 REQ1 4 Installed
J4 & 6-9,10 REQ0 5 Installed
J7-2,4,6,8,10 GND
J7-11,12 NC
Function Normal Installed Test mode
SMDAT J13-1 to J13-2 J13-2 to J13-3
SMCLK J14-1 to J14-2 J14-2 to J14-3
CFGRETRY J17-1 to J17-2 J17-2 to J17-3
Function Installed Not Installed
For 133 MHz Operation J9 &10-1 to J9 &10-2 J9 &10-3
Enables 2nd PCI/PCI-X Connector &
MICTOR LA Connectors J9 &10-2 to J9 &10-3 J9 &10-1
