Inter-m PE-603 User manual
Operation Manual
Chime & Siren
PE-603
CHIME & SIREN
Welcome
Welcome
A personal welcome to you from the management and employees of Inter-M
All of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value,
and we are delighted you have purchased one of our products.
We sincerely trust this product will provide years of satisfactory service, but if anything is not to your complete
satisfaction, we will endeavor to make things right.
Welcome to Inter-M, and thank you for becoming part of our worldwide extended family!
* It can be heated up if you use this product in closed box or ill-ventilated place.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING
To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
*Do not install this equipment in a confined space such as a book case or similar unit.
*The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such vases, shall be placed on the apparatus.
*WARNING FOR YOUR PROTECTION PLEASE READ THE FOLLOWING-WATER AND MOISTURE: Unit should not be used near water(e.g.
near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, etc). Care should be taken so than objects do
not fall and liquids are not spilled into the enclosure through openings.
*CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any
servicing other than that contained in the operating instructions unless you are qualified to do so.
NOTE : This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at his own expense.
This symbol is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
This symbol is intended to alert the user to the
presence of important operation and maintenance
(servicing) instructions in the literature accompanying
the appliance.
CAUTION:To prevent electric shock do not use this (polarized) plug with
an extension cord, receptacle or other outlet unless the
blades can be fully inserted to prevent blade exposure.
Attentions: Pour prévenir les chocs électriques ne pas utiliser cette
fiche polarisée avec un prolongateur, une prise de courant
on une autre sortie de courant, sauf si les lames peuvent
étre insérées à fond sans en laisser aucune partie à
découvert.
CHIME & SIREN
1
PE-603
Contents
Contents
Unpacking .......................................................................................................................................2
Installation
Environment....................................................................................................................................2
Important Safety Instructions.............................................................................................................2
Features............................................................................................................................................3
Front Panel ......................................................................................................................................4
Rear Panel .......................................................................................................................................5
Applications ....................................................................................................................................6
Block Diagram ................................................................................................................................7
Specifications ..................................................................................................................................8
Service
Procedures......................................................................................................................................9
Schematic.......................................................................................................................................9
Parts List .........................................................................................................................................9
Warranty .........................................................................................................................................9
Unpacking
CHIME & SIREN
2PE-603
Unpacking
Although your PE-603 is neither complicated nor difficult to operate, we recommend you take a few minutes to
read this brief manual and familiarize yourself with the important information regarding product features, setup
and operation.
As with most electronic devices, we strongly recommend you retain the original packaging. In the unlikely event
the product must be returned for servicing, the original packaging (or reasonable equivalent) is required.
Installation
Installation
Environment
Never place this product in an environment which could alter its performance or reduce its service life. Such
environments usually include high levels of heat, dust, moisture, and vibration.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
S3125A
S3125A
CHIME & SIREN
3
PE-603
FeaturesFeatures
Features
- MULTIPLE TONES
A variety of soft tones are available for your announcements, including two-tone, chime up and chime down.
- SIREN
Both steady and variable levels of siren tones are available for emergency announcements.
- REMOTE CONTROL CAPABILITY
Rear-panel terminals are provided for connecting a wired remote control to increase functionality.
CHIME & SIREN
4PE-603
Front Panel
Front Panel
1. CHIME SWITCHES
These four switches activate the different chime tones :
(a) Two tone (doorbell type)
(b) Four tone ascending
(c) Four tone descending
2. SIREN SWITCH
These three switches activate the emergency siren tones:
~ : Oscillating siren tone.
OFF : Turns off the siren tone.
- : Steady siren tone.
3. SIREN LED
RED : Oscillating siren tone.
GREEN : Steady siren tone.
2
3
1
PE
603
CHIME/SIREN
SIREN
CHIME & SIREN
5
PE-603
Rear Panel
Rear Panel
1. DC INPUT TERMINALS
These terminals are provided for the connection of the battery power supply. Connect a +24V DC battery
source to these terminals. Make certain the red terminal is connected to the battery’s positive (+) side, and the
black terminal to the battery’s negative (-) side.
2. OUTPUT JACK
This jack is provided for connecting to the input of a preamplifier, such as the Inter-M PP-613.
3. REMOTE CONTROL TERMINAL
These terminals are provided for connection of a wired remote.
CHIME & SIREN
6PE-603
Applications
Applications
@
PD-659
PP-613
PE-603
REMOTE CONTROL
The shape of outlets can be different according to country requirements.
CHIME & SIREN
7
PE-603
Block Diagram
Block Diagram
CHIME & SIREN
8PE-603
PE-603
Siren Frequency 630 Hz
Chime and Siren Output Level/Impedance 1V/10kΩUnbalanced
Operation Temperature -10°C ~ +40°C
Power Source 24V DC
Power Consumption 60mA
Weight (SET) 4.4kg/9.7lb
Dimensions (SET) 482(W)x88(H)x380(D)mm / 19(W)x3.5(H)x15(D)in
* Specifications and design are subject to change without notice.
Specifications
Specifications
8x8 AUDIO MATRIX
9
PE-603
CHIME & SIREN
Service
Service
Procedures
Take steps to insure the problem is not related to operator error or other products within the system. Information
provided in the troubleshooting portion of this manual may help with this process. Once it is certain that the
problem is related to the product contact your warranty provider as described in the warranty section of this
manual.
Schematic
A Schematic is available by contacting your warranty provider.
Parts List
A Parts List is available by contacting your warranty provider.
Warranty
Warranty
Warranty terms and conditions vary by country and may not be the same for all products. Terms and conditions
of warranty for a given product may be determined first by locating the appropriate country which the product
was purchased in, then by locating the product type.
To obtain specific warranty information and available service locations contact Inter-M directly or the
authorized Inter-M Distributor for your specific country or region.
