Can control and distribute Various functions :
Audio, Video, Internet, IP phone etc…
Connectivity and installation via CAT6 network structure,
keeps wiring simple and installation costs to a minimum.
IPC-III_Brochure_E-1 2009.4.14 5:46 PM 페이지 1

Network based Full-duplex
Distribution System!
Multimedia IP Broadcasting System!
IPC-III SYSTEM
SD video streaming
�8CH SD video transmission
Emergency Interface
�Automatic broadcasting activated by fire alarm sen-
sors(64 contacts)and manual paging microphone
�Interface of intruder alarm and activation of emer-
gency bell/tone using sensor inputs
User Control Panel
�15″LCD touch screen with simple graphic icon
menu interface
Time signal and Preset broadcasts
�Built-in time signal sound sources (various options)
�100 activations/day, 700 activations/week available
Time
Simplified installation
�Using the CAT6 network the transmission of multiple
data; audio, video, telecommunication, internet, IP
phone, telephone is easily achieved
BGM Options
�BGM can be broadcast using CD/deck/tuner/built-in
CD-ROM/built-in MP3
Multi bus broadcasting
�Audio 6bus + Video 8bus broadcasting
Remote Control
�Using a simple remote control program the system
can be accessed via Ethernet/Network connection
Text broadcasting
�Text(as page unit) broadcasting
ABC...
High quality Video/Audio broadcasting
�General broadcasting/Announcement/Emergency
broadcasting/Video-using lesson/Language learning
class etc
Full duplex broadcasting
�Upward broadcasting and monitoring up to 4CH of
each local broadcasting
Switching to Analog on emergency
� Signals are normally broadcast via the CAT6 however
in the event of an emergency(loss of network/network
error) the system can revert to analog broadcasts
IPC-III_Brochure_E-1 2009.4.14 5:46 PM 페이지 3

CPU Core 2DUO 2.4GHz FSB 1066MHz
RAM DDR2 2GB
A/V INPUT SD Full D1 X 8CH with Stereo Audio
AUDIO INPUT 6CH Balanced Audio from SA-300
SD VIDEO ENCODING MPEG4 ASP@L2
SD AUDIO ENCODING G.723 16kHz
6CH AUDIO CODEC HD Audio Codec
POWER SOURCE 100~120VAC or 220~240VAC ; 50/60Hz
(Supplied AC Mains Transformer Depends on Country Requirements)
WEIGHT 9.1kg / 20lb
DIMENSIONS (W X H X D) 482 X 176 X 441mm / 19 X 6.9 X 17.3in
MIC Input(BAL) 1~8 -50dB ±3dB
INPUT SENSITIVITY AUX Input(UNBAL) 1~8 -10dB ±3dB
Remote MIC Station 1~8 0dB ±3dB
T.H.D Under 1%
SNR Over 65dB
AUDIO OUPUT Line Out(BAL) 0dB ±3dB
44.1kHz / 24Bit Balanced Adat, 6CH Audio Output for A/V Server Input
AUDIO INPUT AUX 1~8, Remote MIC Station 1~4
Built-in Memory for Emergency / Evacuation / General Audio Broadcasting
CONTROL INPUT/OUTPUT 64CH CONTROL Inputs for Fire Information
RJ 45 Port 4ea for Remote MIC Station Control, RJ 45 Port 4EA for TCP/IP Link
COMMUNICATIONS Digilink Port 2ea and Serial Port 1ea, USB Port 2ea for Audio Source Input for
Emergency / Evacuation / General Audio Broadcasting
RS232C Port 1ea for A/V Server Interface
POWER SOURCE 100~120VAC or 220~240VAC ; 50/60Hz
(Supplied AC Mains Transformer Depends on Country Requirements)
WEIGHT 11kg / 24.2lb
DIMENSIONS (W X H X D) 482 X 176 X 380mm / 19 X 6.9 X 15in
FEATURES
�Embedded XP based A/V server system
�
8CH SD video real-time streaming by UDP transmission method
�6CH audio real-time streaming by UDP transmission method
�
Output: encoded A/V and Audio data transmission through network
�Transmission status indicating LED
FEATURES
�Embedded XP based stand-alone system
�Video 8bus and audio 6bus broadcasting
�Linkable 4CH remote microphone station (SR-100)
�Fire sensor(64 control inputs) and serial 1 port for emergency
broadcasting
�Built-in CD-ROM and MP3 for BGM play
�Preset broadcasting : 100ea/day, 700ea/week
�Text transmission
�Upward broadcasting up to 4CH
�Digi-link control 2 port and AMX/CRESTRON 1 port
�Built-in remote control program using TCP/IP
�Combo jack for 8CH(Line/Mic.) input
�Upward transmission of video which has provided from
SB-300, by UDP transmission method
�Controlled by SA-300 through RS-232 communication
�Built-in 1 Gigabit LAN
�7” LCD monitor display
SPECIFICATIONS SPECIFICATIONS
IPC-III_Brochure_E-1 2009.4.14 5:46 PM 페이지 5

NETWORK INTERFACE Control Format UDP
1 Giga Bit Hub 8Port 10/100/1000Mbps
VIDEO Video Output CVBS, Component(Y Pb Pr), S-Video
Video Input CVBS 1ch
MIC Input(XLR @1kHz, 666ΪLoad Output) Left: 15W, Right: 15W
AUDIO INPUT/OUTPUT Input Level -70dB±3dB
S/N(20kHz LPF) More than 60dB
Frequency Response(±3dB) 400Hz ~ 8kHz
POWER SOURCE DC 14V~15V, 4.5A (Adapter : 100~120VAC or 220~240VAC ; 50/60Hz)
WEIGHT 4.8kg / 11lb
DIMENSIONS (W X H X D) 406 X 443 X 51mm / 16 X 17.4 X 2in
FEATURES
�15 LCD monitor panel and Touch Screen for convenience of
users
�Emergency MIC front volume for emergency broadcasting
FEATURES
�Embedded Linux based stand-alone system
�Built-in video server function for upward broadcasting service
�Decoding of A/V data and audio data transmitted from server
�Built-in 30W amplifier (left:15W, right:15W)
�Can be equipped with emergency battery for broadcasting during
the electricity failure
�Video input channel 1 port
�Analog video input and H/W based MPEG4 encoding
�A/V stream transmission to main server by UDP method
�Video and sound source play using USB memory
�1CH microphone input for self-local-broadcasting
�LAN port for Ethernet
�Interface for IP phone/Telephone
�Accessory : Remote controller (channel, volume control)
�Built-in Gigabit switching hub
�Speaker volume for monitoring input source and output zone
�Arrange the button for moving the screen by the front UI
function
SPECIFICATIONS SPECIFICATIONS
SCREEN SIZE 15" Diagonal
DISPLAY AREA 304.1x228.1mm
RESOLUTION 1024(H)X768(V)
SCREEN REFRESH RATE 60Hz(MAX: 75Hz)
BRIGHTNESS 250cd/
㎡
CONTRAST RATIO 450 : 1
POWER SOURCE DC 12V, 3.5A
WEIGHT 6.5kg/14.3Ib
DIMENSIONS (W X H X D) 482 X 310.5 X 60mm / 19 X 12.2 X 2.4in
IPC-III_Brochure_E-1 2009.4.14 5:46 PM 페이지 7

NETWORK INTERFACE
Control RS-422
Connectors RJ-45 Jack
Cable Type UTP CAT.5
Cable Length 100m Less than
Output Level 0dBV
AUDIO INPUT Input Sensitivity(at 0dBV Output) 0dBV
DIGITAL INPUT(RJ-45 INPUT) S/N (20kHz LPF,A-weight filter) 85dB Better than
T.H.D (at 0dBV output,20kHz LPF) 0.1% Less than
LOCAL INPUT(XLR INPUT)
Input Sensitivity(at 0dBV output) -60dBV
S/N (20kHz LPF,A-weight filter) 60dB Better than
T.H.D (at 0dBV output,20kHz LPF) 0.1% Less than
Frequency Respones 100Hz ~ 20kHz (±3dB)
LOCAL INPUT(PHONE INPUT)
Input Sensitivity(at 0dBV output) 0dBV
S/N (20kHz LPF,A-weight filter) 75dB Better than
T.H.D (at 0dBV output,20kHz LPF) 0.1% Less than
Frequency Response 100Hz ~ 20kHz (±3dB)
POWER SOURCE AC: 100-240V, 50/60Hz , DC 24V
WEIGHT 6.5kg / 14.33Ib
DIMENSIONS
(W X H X D) 440 X 88 X 388mm / 17.3 X 3.46 X 15.27in
NETWORK INTERFACE
Control format RS-422
Connector RJ45 Jack
Cable Type UTP CAT5
Cable Length ≤100m
AUDIO INPUT Rated Power (THD ≤1%, 20kHz LPF) 60W (100V:166.7Ω, 70V:81.7Ω)
- LINK INPUT Input Level 0dBV
(@1kHz, LOAD OUTPUT) Signal to Noise (S/N, 20kHz LPF, A-WTD) More than 80dB
Frequency Response (±3dB) 100Hz-15kHz
Rated Power (THD ≤1%, 20kHz LPF) 60W (100V:166.7Ω, 70V:81.7Ω)
PHONE INPUT Input Level -43dBV ~ 0dBV
(PHONE @1kHz, LOAD OUTPUT) Signal to Noise (S/N, 20kHz LPF, A-WTD) More than 70dB (Trim Max)
Frequency Response (±3dB) 100Hz-15kHz
Rated Power (THD ≤1%, 20kHz LPF) 60W (100V:166.7Ω, 70V:81.7Ω)
MIC INPUT Input Level -60dBV ~ -16dBV
(XLR @1kHz, LOAD OUTPUT) Signal to Noise (S/N, 20kHz LPF, A-WTD) More than 60dB
Frequency Response (±3dB) 100Hz-15kHz
POWER SOURCE 100–120VAC or 220–240VAC; 50/60Hz
WEIGHT 13kg/28.6lb
DIMENSIONS
(W X H X D) 482 X 88 X 380mm / 19 X 3.5 X 15in
FEATURES
�6CH full digital amplifier built-in
�6-way broadcasting with a CAT.5 wire
�Volume and 5 band EQ by channel
�Self-broadcasting function using local input
�Auto/Manual allocation of amplifier ID
�Interface function with other units using control output
contact
SPECIFICATIONS
FEATURES
�IPC system Interlocking
- It interlocks with SI-100 and is available to connect analog/dig-
ital amplifier in the output terminal according to a purpose
�6CH pre-amplifier
- It is possible to conduct six broadcastings with the single CAT.5 line
�Make available to be interfaced with other devices using an out-
put interface
�Remote control using work
- Available to automatically allocate an amplifier ID and
recognize
�Make available to control each of the output volumes for
6 channels
�Self broadcasting function using a local input
SPECIFICATIONS
IPC-III_Brochure_E-1 2009.4.14 5:46 PM 페이지 9

INPUT SENSITIVITY/IMPEDANCE
Mic -60dB, Balanced Input
Aux -10dB, Unbalanced Input
T.H.D(20kHz LPF) Mic 0.5%
Aux 0.5%
S/N(20kHz LPF) Mic 50dB
Aux 60dB
FREQUENCY RESPONSE Mic 300Hz~10kHz
Aux 300Hz~15kHz
COMMUNICATION METHOD RS-485
POWER SOURCE DC 12V
WEIGHT 11kg / 24.2lb
DIMENSIONS (W X H X D) 482 X 176 X 380mm / 19 X 6.9 X 15in
FEATURES
�MIC/AUX/Speaker volume adjustable
�Configuration of simple interface using a CAT5 wire
�One-touch broadcasting function using the [TALK] button
�Speaker volume for monitoring zone broadcasting
�Expansion and contraction function of zone using the
Expansion Keypad (SR-100KP)
�Location where the priority of broadcastings are executed
SPECIFICATIONS
