Interacoustics Orion User manual

Installation Instructions
Orion Rotary
Chair
(Auto-
Traverse/Comprehensive)
Micromedical by Interacoustics
Science made smarter
8525145 D-01272335-A – Valid 2020 10

Copyright © Interacoustics⅍: All rights reserved. Information in this document is proprietary to
Interacoustics⅍. The information in this document is subject to change without notice. No part of this
document may be reproduced or transmitted in any form or by any means without a prior written permission of
Interacoustics⅍.
FireWire® is a registered trademark of Apple Inc., registered in the United States and other countries.
Windows® is a registered trademark of the Microsoft Corporation, registered in the United States and other
countries.

Table of Contents
1INTRODUCTION........................................................................................................................... 1
1.1 About this manual ................................................................................................................1
1.2 Environmental Conditions....................................................................................................1
1.3 Marking ................................................................................................................................1
1.4 Required tools......................................................................................................................3
1.5 Determine location for booth and chair installation .............................................................6
2UNPACKING AND INSPECTION................................................................................................. 7
2.1 Inspection of shipment.........................................................................................................7
2.2 Unpacking the booth............................................................................................................7
2.3 Unpacking chair from the crate............................................................................................8
3BOOTH INSTALLATION .............................................................................................................. 9
3.1 Floor Assembly: ...................................................................................................................9
3.2 Booth Wall Assembly:........................................................................................................10
3.3 Booth Ceiling Assembly.....................................................................................................12
3.4 Booth Door Location:.........................................................................................................17
3.5 Install Door Threshold: ......................................................................................................17
3.6 Leveling the Booth: ............................................................................................................18
3.7 OKN Drum Installation.......................................................................................................18
4CHAIR INSTALLATION.............................................................................................................. 20
4.1 Prepare the booth for chair installation..............................................................................20
4.2 Moving Chair inside the Booth...........................................................................................22
4.3 Leveling the Chair..............................................................................................................24
4.4 Securing the Chair .............................................................................................................25
4.5 Laser Projector ..................................................................................................................26
4.6 Head Support.....................................................................................................................27
4.7 Camera and EOG Connectors ..........................................................................................28
4.8 Connecting Cables in Chair Base......................................................................................29
5COMPUTER CONFIGURATION ................................................................................................ 31
5.1 Isolation Transformer:........................................................................................................31
5.2 Intercom Speaker ..............................................................................................................31
5.3 Installation of Booth Observation Camera and monitor.....................................................31
5.4 Cart configuration ..............................................................................................................33
5.5 Pediatric Patient Observation pole mounted camera and Monitor (optional)....................33
5.6 SVV remote .......................................................................................................................33
5.7 Connections between accessories: ...................................................................................34
6SYSTEM CHECK ON WORKING CONDITION ......................................................................... 35
6.1 Program Check..................................................................................................................35
6.2 Validation ...........................................................................................................................35
6.3 Laser Check.......................................................................................................................37
6.4 OKN Check........................................................................................................................37
6.5 Safety checks ....................................................................................................................39

D-0172335-A – 2020/10
Orion Rotary Chair Installation Instructions Page 1
1Introduction
1.1 About this manual
This manual detail the installation procedure for the Orion Chair (Auto-transverse / Comprehensive), used
with the VisualEyes™ 515 and VisualEyes™ 525 Software version 3.0 and later. Both Auto-transverse and
Comprehensive will be hereafter denoted by ‘Orion Chair’ if it is not specified.
Interacoustics A/S
Audiometer Allé 1
5500 Middelfart
Denmark
Tel.: [phone]
Fax: [phone]
E-mail: [e-mail]
Web: www.interacoustics.com
1.2 Environmental Conditions
•Recommended for indoor use only
•Relative Humidity (transport): 30 to 80% (non-condensing), keep dry
•Temperature Storage: 32°to 122°F (0°to 50°C)
•Operating Temperature: 59°to 95°F (15°to 35°C)
•Power Supply: 115VAC, 230VAC step down to 115VAC through isolation
transformer
Note: Please refer user manual of VisualEyes™ 515 and VisualEyes™ 525 Software version 3.0 and later
for EMC related information.
1.3 Marking
The following marking can be found on the instrument:
Symbol
Explanation
An applied part that includes a patient connection that is intended to deliver
electrical energy or an electrophysiological signal to or from the patient shall
be a Type BF part. An EOG amplifier is considered a Type BF part.
An applied part that includes a patient connection which can be
disconnected from the patient immediately is a Type B part. The Aqua
Stim™ caloric irrigator is a Type B part.
Follow instructions for use
WEEE (EU-directive).
This symbol indicates that when the end-user wishes to discard this product,
it must be sent to separate collection facilities for recovery and recycling.
Failing to do so may endanger the environment.
0123
The CE-mark indicates that the manufacturer meets the requirements of
Annex II of the Medical Device Directive 93/42/EEC for the quality system.

D-0172335-A – 2020/10
Orion Rotary Chair Installation Instructions Page 2
Medical Device
Manufacturer.
Year of Manufacture.
Do not re-use.
Parts like foam cushions and irrigator tips are for single use only.
Reference number used to denote the model of the equipment.
Do not push symbol used with components that could easily tip over, such
as the Digital Light Bar
Chinese RoHS compliance standard where the product contains less than
the maximum concentration value of lead, mercury, cadmium, hexavalent
chromium, polybrominated biphenyls, and polybrominated diphenyl ethers.
This product contains a component (Orion
Comprehensive/Auto Traverse chair) of ‘Class
2 Laser beam’. Hence, do not look directly
into the laser beam
Keep dry
Transport and storage temperature range
Transport and storage humidity limitations

D-0120794-C – 2019/11
Orion Rotary Chair Installation Instructions Page 3
1.4 Required tools
The following tools are required to assemble the Orion Chair which will be provided by the dealer.
NOTICE It is important to note that two people are required for this installation process. The installation
process approximately will take 5 to 6 hours to complete.
Step ladder, six foot minimum (supplied with the product)
2 wheel steel hand truck (supplied with product)
Zip ties (supplied with the product)
Plastic shims (supplied with the product)
Double sided tape (supplied with the product)
3’’/7.62 cm black tape and ½”/1.27 cm white tape (supplied
with the product)
3 booth mount sleeves (supplied with the product)
3/8”/0.95 cm -16 Zinc coated nuts and washers (supplied with
the product)
3/8” /0.95 cm -16 threaded female concrete drop-in anchors
(supplied with the product)
3/8” /0.95 cm -16 Nylock nuts
Installation tool for 3/8” /0.95 cm -16 female threaded anchors
(supplied with the product)

D-0120794-C – 2019/11
Orion Rotary Chair Installation Instructions Page 4
Yellow drill guide (supplied with the product)
½”/1.27 cm thick black washers (supplied with the product)
High strength black oxide steel threaded rod 3/8” -16 thread
size, 5” / 12.7 cm long (supplied with the product)
Allan Key (supplied with the product)
Masonry drill for concrete (supplied with the product)
Booth observation camera mount parts (supplied with the
product)
Battery powered drill with Phillips bit
Hammer drill with SDS Plus chuck (A SDS Plus ½” / 1.27 cm
inch masonry drill bit is supplied)
Small battery powered screwdrivers (flat blade)
Small head Phillips screwdriver (supplied with the product)
16 oz hammer
Small Shop-Vac (Vacuum cleaner with hose adapter)

D-0120794-C – 2019/11
Orion Rotary Chair Installation Instructions Page 5
Adjustable wrench or socket wrench set
Ratchet with ½” /1.27 cm and 9/16” / 1.43 cm deep socket
connectors
Rubber head mallet
Paper towels and water for concrete dust cleanup
Bubble level, 1’-3’
Bubble level or smartphone level
Pencil with eraser, Knife and Scissors
Stud finder
Compressed air

D-0120794-C – 2019/11
Orion Rotary Chair Installation Instructions Page 6
1.5 Determine location for booth and chair installation
Ensure that you have a very clear floor plan to install the booth with the chair and other accessories.
Ensure that the room has at least an 8 ft high ceiling and space in front of the booth to lift the round roof into
place.

D-0120794-C – 2019/11
Orion Rotary Chair Installation Instructions Page 7
2Unpacking and inspection
2.1 Inspection of shipment
Check for damage
When the product is received, ensure that you have received all the components on the shipping checklist.
All the components should be checked visually for scratches and missing parts before use. All the contents
of the shipment have to be checked for their mechanical and electrical functioning. If the equipment is found
faulty, please contact your local distributor immediately. Keep the shipping materials for the carrier’s
inspection and insurance claim.
Keep carton for future shipment
The product comes with shipping cartons, which are specifically designed for the components. It is
recommended to keep the cartons for future shipments in case of any need for return or service.
Reporting and returning procedure
Any missing part or malfunction or any damaged components (due to shipment) should be reported
immediately to the supplier/local distributor along with the invoice, serial number and a detailed report of the
issue. For any on-site service-related information, please contact your local distributor. If the system /
components are to be returned for service, please fill all the details related to product issues in the ‘Return
Report’, which is attached to this manual. It is very important that you describe all the known facts about the
issue in the return report, as this will help the engineer to understand and solve the problem to your
satisfaction. Your local distributor holds the responsibility for coordinating any service/return procedure and
related formalities.
Disposition of packaging materials
Incase if you wish to dispose the Crates and pallets and materials used for shipment, those shall be
recycled according to the local requirements and possibilities.
2.2 Unpacking the booth
NOTICE Ensure that the designated room for booth installation has high ceiling (min. of 8 ft / 244 cm) and
space in front of the booth to lift the round roof into place. It is important Room fire suppression systems
(e.g. sprinkler heads) should not be directly over the booth.
Remove top and one end screws of the booth crate using battery powered drill with Phillips to open the
crate.
A booth crate contains
Six (6) curved panels,
Vinyl floor in a roll,
Floor section in 3 pieces,
Roof section in 3 pieces,
Door threshold and shims,
Black strips to cover wall seams.
Assembly materials (like anchors, electrical conduit, tools and etc)
Ensure that all the booth parts are taken out from Crate.
Remove Styrofoam packing and take out the wall panels from the crate.
Booth installation requires step ladder which will be a part of Chair Crate.
Caution: These booth panels are lightweight and can be damaged easily. Hence each wall
panel should be always handled with two people. Do not stand on the panels inside the crate as
this can break the panels. The Door Panel can come open and break, so carry the door in a way
it doesn’t open. If a cart is used for transporting panels, make sure the panels are protected by
pads.

D-0120794-C – 2019/11
Orion Rotary Chair Installation Instructions Page 8
The panels are numbered (1-6) with the temporary stickers. Stack the curved panels with the panel number
(1 - 6) up against a wall in the designated room or alternatively the door can be kept safely on the floor.
Then, set up the panels into the booth starting with the door (panel 1) followed by assembling the remaining
panels in order (refer section 3.2 detailed information).
2.3 Unpacking chair from the crate
Use a battery powered drill with Phillips to remove screws from top of the crate then all four sides.
Unwrap the chair by carefully cutting tape and removing the plastic sheeting on it. Note that ladder and ramp
which are required for the installation procedure are attached with inside chair crate.
Chair in crate Chair wrapped on pallet
Chair pallet with shipping cover removed Ramp secured to base
Chair is strapped to a 2-wheel steel hand truck inside crate. A wooden ramp, that is part of the equipment on
the pallet, should be fastened with screws to the chair pallet to form a ramp. Tilt the chair and roll it off the
pallet and down the ramp. See Section 4.2 for details.
Caution: Two people are needed to handle the chair as the chair assembly is heavy. First, the
chair has to be tilted back. While the chair weight is counterbalanced by the person handling the
hand truck, the second person can help to guide, move and lower the chair in position.
Ramp
Ladder

D-0120794-C – 2019/11
Orion Rotary Chair Installation Instructions Page 9
3 Booth Installation
Refer to section 1.5 for the booth installation prerequisites before starting the booth installation. Booth
installation is done in different steps which are described below.
3.1 Floor Assembly:
The booth floor is comprised of three sections (one base and two wings). Assemble the booth floor with the
bottom side up. The wings of the floor are attached using the rubber mallet and secured using manufacturer
supplied screws. One wing has a slot that will align with the hole in the main floor base to complete the
channel for routing cables through floor into the rotational chair.
Flip the assembled base over, placing the weight on the main section to prevent damage to the wings. Clean
off the booth floor with a damp rag. Set ½ of the vinyl flooring in position and draw a line indicating the center
of the floor. Apply a few strips of double face adhesive tape on the outer perimeter of the booth floor portion
where the door panel will be situated. Place a strip of carpet tape on either side the line that was drawn
leaving a small gap between the strips. Lay down the vinyl flooring over the carpet tape. With the vinyl
flooring in place, remove the film from the carpet tape to secure the flooring. Press down on the flooring by
walking on the flooring over the tape. Repeat the same steps to place another vinyl flooring to cover another
half of booth flooring.

D-0120794-C – 2019/11
Orion Rotary Chair Installation Instructions Page 10
Finally the booth floor looks like this.
3.2 Booth Wall Assembly:
Set step ladder in booth floor. Ensure that you have all the tools required for installation included booth wall
screws and Phillips screwdriver.
Caution: These booth panels are lightweight and can be damaged easily. Hence each wall
panel should be always handled with two people. Do not stand on the panels inside the crate as
this can break the panels. The Door Panel can come open and break, so carry the door in a way
it doesn’t open. If a cart is used for transporting panels, make sure the panels are protected by
pads
One person should stand on the ladder and hold the door (panel #1) in place.
Set panel #2 in place on the right side of panel #1, locking walls together. You may need to put a ½” /
1.27 cm high block shim under panel #1 wall to get panel #2 to lock in place (the two panels ends should be
level at the top). Insert one of the marked wall screws into existing screw hole in top at 45 degree angle and
the panel levels can be adjusted using shims (Figure 4 and Figure 5)

D-0120794-C – 2019/11
Orion Rotary Chair Installation Instructions Page 11
Locking Brackets between Panels
Fixing two panels with the provided
screws and adjusting the panel levels
using shims.
Caution: Keep walls stabilized with hands when the next panel is positioned to prevent damage due
to fall.
Set panels #3, 4, and 5 in place and insert a screw into each panel as it is locked together. Make sure the
wall joints fit tightly together. Note: If a gap appears in the bottom or top of the wall joint, one or more of the
walls connection tabs did not lock. Lift the panel and reassemble. The rectangular hole in bottom of panel #3
is for the cables for motor, camera, and instrument. Line up the hole with the wire channel in the booth floor.
Set panel #6 in place. Before securing the last joint between panels #6
and #1, you should push the walls in at the base all around the perimeter
to bring #1 and #6 closer. When the panels are close together, open the
door and lift up on the door panel, then push the door frame and the
panels together (this joint is the hardest to latch). Pull down on panel #1
and lock into place. Carefully inspect the wall joint to make sure that it
has latched without a gap. Put the final screw in the top panel to join both
panels together. Place a curved threshold strip under the door, use
multiple threshold strip if necessary to keep the threshold in place with friction. This threshold strip protects
the narrow door frame from cracking when stepped on.
Threshold

D-0120794-C – 2019/11
Orion Rotary Chair Installation Instructions Page 12
3.3 Booth Ceiling Assembly
Assemble the booth ceiling either upright or on the floor. Note: One ceiling wing will line up with a hole in the
corner of the main ceiling base. When assembling the booth ceiling on the floor, set the assembly on top of
the cardboard boxes to prevent damage or scratches to the ceiling. Offset the wing 1-2 inches from the main
section and slide the wing in a downward position. Use the rubber mallet to align the pieces, taking care only
to strike along the outside edge of the wing to prevent breaking the pieces.
Caution: Attach the wings using a rubber mallet by striking only the flat edge of the wing or the
plastic edge may crack.
Using rubber mallet to attach the wings is shown in the
figure
Once the wing is aligned to the base section, secure the wing using the ceiling screws. Repeat the step for
the second wing.
Securing Wing to Ceiling
Using two people, walk the assembled booth ceiling above the booth and lower it into place. Do not lift the
ceiling by the wings to prevent damage to the ceiling. Caution must be taken not to damage the two wires
that located on top of the booth door.

D-0120794-C – 2019/11
Orion Rotary Chair Installation Instructions Page 13
Walking the Ceiling into the Booth
Line up the conduit holes in the top and panel #1 by lifting the ceiling and rotating (figure ). Feed the wires for
the fan and light through the hole down into panel #1 to the switch box. Push the small length conduit into the
ceiling. Connect the two phone plugs/jacks, one for the intercom magnetic switch above the door and
another for booth door safety switch.
Caution: Be careful not to crush the intercom connection wire and booth door safety switch wire
when setting the ceiling in place.
Conduit hole in the booth ceiling

D-0120794-C – 2019/11
Orion Rotary Chair Installation Instructions Page 14
Booth ceiling diagram with possible connection details
Connecting the Door and Fan wires

D-0120794-C – 2019/11
Orion Rotary Chair Installation Instructions Page 15
Attach the fan and light switches to the wires in the outlet box. Put the switches into the box and place the
cover plate over the switches. The light and fan are 24vdc. This power is supplied by the electronics in the
chair base, thus there will not be light or fans until the chair base is powered on.
Important: The booth fans are very quiet and you must listen carefully or observe them running from the roof.
Fixing the fan and light switches in the figure.
There are 6 black strips that cover the wall joints on
the outside of the booth. These strips block light from
entering the booth. Each strip has tape along its
length. Remove the protective covering on each tape
strip. It is important to wipe the wall (both inside and
outside) with foam cleaner to remove dirt at the wall
joint. Starting flush with the top of the booth, press the
black strip onto the wall and continue to the floor to
cover the crack. Continue this for all six joints. Remove
the panel # labels from the top of each panel.
From the top using a step ladder, place 2” / 5.08 cm wide black tape all around the
ceiling perimeter at the wall-ceiling gap. This black tape blocks light from entering
from above.
Inside the booth, at the bottom of the door wall, there will be gaps to the right and to the left of the door.
There will be a light leak that must be blocked. Use a 3” / 7.62 cm long section of black tape torn into a 1” /
2.54 cm wide strip. Place the tape at the bottom of the wall
Blocking the light leakage around the booth door using the black tape.
