Interlogix TruVision PTZ 36X User manual

P/N1072593•REVD•ISS10OCT12
TruVision PTZ 36X Camera
User Manual

Copyright © 2012 UTC Fire & Security. All rights reserved.
Trademarks and
patents
Interlogix and Truvision names and logos are trademarks of
UTC Fire & Security.
Other trade names used in this document may be trademarks or registered
trademarks of the manufacturers or vendors of the respective products.
Manufacture
r
UTC Fire & Security Americas Corporation, Inc.
2955 Red Hill Avenue, Costa Mesa, CA 92626-5923, USA
Authorized EU manufacturing representative:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Certification N4131
FCC compliance Class A: This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own
expense.
ACMA compliance Notice! This is a Class A product. In a domestic environment this product
may cause radio interference in which case the user may be required to take
adequate measures.
Canada This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme á la norme NMB-003du
Canada.
European Union
directives
2004/108/EC (EMC directive): Hereby, UTC Fire & Security declares that
this device is in compliance with the essential requirements and other
relevant provisions of Directive 2004/108/EC
2002/96/EC (WEEE directive): Products marked with this symbol cannot be
disposed of as unsorted municipal waste in the European Union. For proper
recycling, return this product to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at designated collection points.
For more information see: www.recyclethis.info.
2006/66/EC (battery directive): This product contains a battery that cannot
be disposed of as unsorted municipal waste in the European Union. See the
product documentation for specific battery information. The battery is marked
with this symbol, which may include lettering to indicate cadmium (Cd), lead
(Pb), or mercury (Hg). For proper recycling, return the battery to your supplie
r
or to a designated collection point. For more information see:
www.recyclethis.info.
Contact information www.interlogix.com
Customer support www.interlogix.com/customer-support

TruVision PTZ 36X Camera User Manual i
Content
Chapter 1 Product introduction 1
Product overview 1
Features 1
System requirements 3
Chapter 2 Installation 5
Installation environment 5
Unpacking the dome camera 6
Removing the protective shipping materials 7
Setting up the dome camera 9
DIP switches and connectors 10
Setting the dome camera communication protocol 11
Setting the RS-485 communication 13
Setting the dome camera site ID 14
AC 24V power connector description 16
Alarm I/O 16
RS-485 connector 17
Wiring the dome camera 19
Mounting the dome camera on a ceiling 19
Mounting the dome camera on a wall 21
Pendant mounting the dome camera 21
Mounting an indoor dome camera in a ceiling (Flush mounting) 23
Chapter 3 Menu overview 29
On-screen information 29
Main menu overview 31
Using a keypad to program menus 33
Chapter 4 Basic setup 35
Language selection 35
Camera site ID displayed on a monitor 35
Title display 36
Title settings 36
Preset points settings 37
Sequence settings 38
Autopan settings 39
Cruise settings 40
Home settings 41
Chapter 5 Advanced setup 43
Default 43

ii TruVision PTZ 36X Camera User Manual
Backlight compensation 43
Focus adjustment 44
Exposure control settings 44
White balance 46
Camera setup menu 1 47
Camera setup menu 2 49
IR function (Day/night models only) 51
Alarm settings 52
Alarm detection 53
Wide dynamic range (WDR) 54
Privacy mask settings 55
Time setting 56
Schedule settings 57
Appendix A Specifications 59
Appendix B Camera settings checklist 61
Appendix C Contact information 67
Contacting support 67
Index 69

Chapter 1: Product introduction
TruVision PTZ 36X Camera User Manual 1
Chapter 1
Product introduction
Product overview
The TruVision PTZ 36X Camera is an innovative camera designed for middle and
small surveillance applications. It possesses true PTZ camera features and has a
graphical programming interface for easier customization of camera settings.
The TruVision PTZ 36X Camera can be integrated with digital surveillance products
such as DVRs, control keypads and various accessories for a total surveillance
solution. The dome camera incorporates several protocols to enhance control and
connectivity.
The dome camera is ideal for all surveillance requirements in a wide variety of
buildings such as hotels, department stores, intelligent buildings, amusement parks,
parking lots, factories, hospitals, schools, and stations.
Features
This section describes the TruVision PTZ 36X Camera features.
Precise and accurate dome camera performance
• High resolution: 650 TV lines
• Preset speed up to 400°/sec
• 360° endless pan
• Proportional pan and tilt speed
• Preset positions / Autopan / Sequence / Cruise
• Auto-calibration
• -10° to +190° tilt with digital image flip

Chapter 1: Product introduction
2 TruVision PTZ 36X Camera User Manual
Dynamic Dome applications
• Schedule function
• Multiple built-in protocols
• Lightweight design for easy installation
• Flexible indoor / outdoor mountings
• 20 privacy masks
• 4 alarms and 2 relays
• Weatherproof, IP66 (Outdoor models)
Superior dome camera image quality
• 36X optical zoom
• 12X digital zoom
• Wide Dynamic Range
• Electronic Image Stabilization
• Digital auto slow shutter
• Backlight compensation
• Auto focus
• Auto white balance
• Auto gain control
• Auto iris control
• Removable IR cut filter
• Minimum illumination: 0.1 Lux (Color), 0.01 Lux (B/W)
• 2D / 3D video noise reduction

Chapter 1: Product introduction
TruVision PTZ 36X Camera User Manual 3
System requirements
For proper operation, adhere to the following operational, cable, and power
requirements for TruVision PTZ 36X Cameras.
Figure 1: Example of a system
1. Monitor A
2. Monitor B
3. Control keypad
4. DVR /Multiplexer/ Quad/ Switcher
5. Dome camera
6. Repeater
Cable requirements
Table 1 below lists the requirements for the cables that connect to the dome
camera.
Table 1: Recommended cable requirements
Operation Cable requirement Max. length
feet meters
Data (RS-
485)
STP (shielded twisted-pair) cable
Cat-5 cable recommended. If the total cable length
exceeds 1219 m (4000 feet), using a repeater to
maintain the signal is recommended.
4000 1219
Video 75 ohm RS-59 coaxial cable with BNC ends
Alarm Cat-5 cable recommended. 1250 381
Power 24 VAC cable. To determine the size of cable needed for individual
applications, see “Power cable size and length requirements” on page 4.

Chapter 1: Product introduction
4 TruVision PTZ 36X Camera User Manual
Power cable size and length requirements
Using the proper gauge of power cable will ensure proper operation and
avoid voltage drops. See Table 2 below for the recommended cable gauge
for varying maximum cable lengths and power draws.
Table 2: Recommended power cable gauges based on maximum lengths for an
operating voltage of 24 VAC (±10%)
Wire gauge Indoor dome cameras
(14 W)
Outdoor dome cameras
(54 W)
AWG mm
(diameter) feet meters feet meters
10 2.59 2061 628 534 163
12 2.05 1294 394 335 102
14 1.63 813 247 211 64
16 1.29 512 156 133 41
18 1.02 322 98 83 25
20 0.81 203 62 53 16
22 0.64 127 39 33 10

Chapter 2: Installation
TruVision PTZ 36X Camera User Manual 5
Chapter 2
Installation
This chapter provides information on how to install the dome camera.
Use a control keypad or device, such as the Interlogix KTD-405/KTD-405-2D
keypad, to control the dome camera.
Installation environment
When installing your product, consider these factors:
• Handling: Handle the camera carefully. Avoid striking, shaking, etc. Improper
handing or storage could damage the camera.
• Electrical: Install electrical wiring carefully. It should be done by qualified
service personnel. The input electricity to the unit has a tolerance of 24 VAC
± 10%. Do not overload the power cord or adapter.
• Ventilation: Ensure that the location planned for the installation of the
camera is well ventilated.
• Temperature: Do not operate the camera beyond the specified temperature,
humidity or power source ratings. The operating temperature of the indoor
camera is 0°C to 40°C (32°F to 104°F) and that of the outdoor camera is -
40°C to 50°C (-40°F to 122°F). Maximum operating humidity is 90%.
• Moisture: Do not expose the indoor camera to rain or moisture, or try to
operate it in wet areas. The indoor camera is designed for indoor use or
locations only where it is protected from rain and moisture. Turn the power off
immediately if the camera is wet and ask a qualified service person for
servicing. Moisture can damage the camera and also create the danger of
electric shock.
• Cleaning: Clean only with a dry cloth. If the dirt is difficult to remove, use a
mild liquid non-abrasive detergent and wipe gently.

Chapter 2: Installation
6 TruVision PTZ 36X Camera User Manual
• Protect from bright light: Never face the camera towards the sun. Do not
aim the camera at bright objects. Whether the camera is in use or not, never
aim it at the sun or other extremely bright objects. Otherwise, the camera
may be damaged.
• Servicing: Do not attempt to service this camera yourself. Any attempt to
dismantle or remove the covers from this product will invalidate the warranty
and may also result in serious injury. Refer all servicing to qualified service
personnel.
Unpacking the dome camera
When you receive the product, check the package and contents for damage, and
verify that all items are included. If any of the items are damaged or missing,
please contact your local supplier.
Items shipped with the indoor (Figure 2 below) and outdoor (Figure 3 on page 7)
dome cameras include:
Figure 2: Indoor dome camera contents
Dome camera and 6” bubble Hard ceiling mount User manual
M4 screws (X4) and plastic
anchors (X4)

Chapter 2: Installation
TruVision PTZ 36X Camera User Manual 7
Figure 3: Outdoor dome camera contents
Dome camera, housing top cap, and
6” bubble
User manual
Security screws (X4):
M3 standard screw (x1)
M3 security screw (x1)
M5 standard screw (x1)
M5 security screw (x1)
Waterproof top cap boot
Security TORX wrench
Container of gasket lubricant (not
shown)
3-pin 24 VAC power connector
(not shown)
5-pin RS-485 connector
(not shown)
Removing the protective shipping materials
The outdoor dome camera is shipped with a protective tape and PE sheet on the
dome camera for protection. These must be removed before installation.
To remove the shipping materials:
1. Unpack the dome camera.
2. Remove the bubble assembly from the dome
housing by placing your hands on the plastic
ring and pushing up (away from the dome
housing) on the bubble assembly. The bubble
assembly is only held in place by compression,
due to the gasket.

Chapter 2: Installation
8 TruVision PTZ 36X Camera User Manual
3. Remove the protective sheet.
4. Remove the protective tape on top of the
camera block and lens cover.
5. Apply a small amount of lubricant on the
surface of the waterproof rubber gasket.
6. Re-attach the bubble assembly to the dome
camera body by first aligning the center point
(dimple) on the bubble assembly with one of
the four holes in the dome camera housing, as
shown.
7. Place both hands on the bubble assembly ring
and gently press down the bubble assembly.
Make sure that the holes on the bubble
assembly align with the holes in the dome
camera housing.

Chapter 2: Installation
TruVision PTZ 36X Camera User Manual 9
Caution: Do not press on the top of the bubble as
shown in the figure as it might damage the unit.
8. Secure the bubble assembly to the dome
camera housing with the supplied security
screw. Use the supplied security TORX wrench
to tighten the security screw.
9. Further secure the bubble assembly in place by
loosening (unscrewing) the two slotted screws
that are located on the bubble assembly so that
they are flush with the outside edge of the
dome camera housing.
10. Remove the plastic protective sheet from the
bubble.
11.Set the DIP switches.
Setting up the dome camera
To quickly put the TruVision PTZ 36X Camera into operation:
1. Configure the dome camera’s DIP switches, which are located on the top of
the dome camera.
2. Set the dome camera communication protocol.
3. Set the RS-485 communication DIP switch.
4. Verify and set the communication termination, if required.
5. Set the dome camera ID.
6. Mount the dome camera.
7. Wire the dome camera.
8. Connect the dome camera to a monitor.
9. Program the dome camera.

Chapter 2: Installation
10 TruVision PTZ 36X Camera User Manual
DIP switches and connectors
Configure the dome camera’s ID and communication protocol before connecting
the analog dome camera to other devices. The DIP switches used for
configuring these settings are located on the top of the dome camera housing.
See Figure 4 below for the location of the DIP switches on both the indoor and
outdoor dome cameras.
Figure 4: Dome camera DIP switch location
Indoor dome camera Outdoor dome camera
A. Alarm I/O
B. Dome camera site ID DIP switches
C. BNC Video Output
D. Communication switch setting
E. Camera protocol setting
F. RS-485 connector
G. 24VAC power connector
See the following sections on how to setup the ID and control protocol of the
dome camera.

Chapter 2: Installation
TruVision PTZ 36X Camera User Manual 11
Setting the dome camera communication
protocol
The TruVision PTZ 36X Camera can use several different protocols for
communication. To select a protocol, you must set the protocol DIP switches to
the correct sequence of 1s (on) and 0s (off).
To set a dome camera protocol using the DIP switches:
1. Locate the protocol DIP switch block (see E, Figure 4 on page 10).
2. Using Table 3 below, find the DIP switch sequence for the desired protocol
and set the switches accordingly.
Table 3: Protocols supported
Protocol Baud rate Switch position
INTERLOGIX Impac RS-485 9600 000000
INTERLOGIX Digiplex RS-422 4800 100000
Pelco D 2400 010000
Pelco D 4800 110000
Pelco D 9600 001000
Pelco P 2400 101000
Pelco P 4800 011000

Chapter 2: Installation
12 TruVision PTZ 36X Camera User Manual
Protocol Baud rate Switch position
Pelco P 9600 111000
Philips 9600 000100
AD422 4800 100100
JVC 9600 010100
Panasonic 19200 11010
VCL 9600 001100
DSCP 9600 101100
DMP 9600 011100
Chiper 9600 111100

Chapter 2: Installation
TruVision PTZ 36X Camera User Manual 13
Functions supported by third party protocols
Table 4: Functions supported
Function Key commands
Pelco AD 422 VCL Philips
Enter menus Preset 95 Preset 94
(alternate Preset
77)
Wipe or Preset
77
Preset 77
Exit menus Preset 95 Preset 95 Preset 97 Preset 77
Select/enter in
menus
Iris+ Iris+ Iris+ Iris+
Set auto pan limits Preset 92 and 93 Preset 62 and 63
Start auto pan Preset 99 Preset 79 Preset 79 On – 2 - Enter
Play Cruise 1 Pattern 1 Preset 65 1 + Autopan Preset 70 – 76 =
S Tours 1-7,
Preset 78 = S
Tours 8
Play Sequence 1 Preset 98 Preset 70 Preset 70 On – 8 - Enter
Turn 180 degrees
on pan
Preset 33 N/A N/A On – 1 - Enter
Show splash
screen
N/A N/A N/A On – 997 - Enter
Setting the RS-485 communication
RS-485 is the interface that connects the dome camera to the control device.
Consequently the RS-485 setup of the dome camera and the control device
must be identical.
Locate the communication DIP switch block (see D, Figure 4 on page 10). See
Figure 5 for a depiction of the communication DIP switches of the dome camera.
The RS-485 default setting is half-duplex (see Figure 5). This setting should only
be changed by a qualified CCTV specialist. DIP switches SW3 and SW4 are
used for termination and Line Lock adjustment respectively. The SW5 DIP
switch is used to restore the dome camera to the factory default status.

Chapter 2: Installation
14 TruVision PTZ 36X Camera User Manual
Figure 5: RS-485 setting
Half-duplex (Default)
(Switches 5 & 6 are unused)
Full-duplex
(Switches 5 & 6 are unused)
Setting the dome camera site ID
Before turning on the dome camera, you must set the dome camera site ID.
Each dome camera connected to the same network must have a unique ID. Use
the 10-bit DIP switch to set the dome camera’s site ID setting.
To set a dome camera site’s ID:
1. Locate the dome camera site ID DIP switch block (B, Figure 4 on page 10).
2. Using Table 5 below, determine which DIP switches need to be set to the on
position. The equivalent value of the switches will add up to create the site ID
number for that dome camera. See Figure 6 on page 16 for an example.
3. Place the switches that correspond to those values in the On position.
4. Carefully record the site ID of each dome camera installed.
Table 5: DIP switch positions and equivalent values
DIP switch position
number
1 2 3 4 5 6 7 8 9 10
Equivalent value 1 2 4 8 16 32 64 128 256 512

Chapter 2: Installation
TruVision PTZ 36X Camera User Manual 15
Table 6: Dome camera site ID DIP switch settings for dome cameras 1 to 30
Unit DIP switch Unit DIP switch Unit DIP switch
1 11 21
2 12 22
3 13 23
4 14 24
5 15 25
6 16 26
7 17 27
8 18 28
9 19 29
10 20 30

Chapter 2: Installation
16 TruVision PTZ 36X Camera User Manual
Figure 6: Example of setting DIP switches for the dome camera site ID 210 (2 + 16 + 64 +
128 = 210)
AC 24V power connector description
Before wiring, refer to Figure 7 for power connector definition.
Figure 7: Power connector
P1: AC1
P2: GND
P3: AC2
Alarm I/O
The camera supports four digital alarm inputs and two digital alarm outputs.
Please make sure that the alarm connections are properly wired before starting
to configure alarm related settings. Please refer to Figure 8 and Table 7 for alarm
system wiring.
Figure 8: Alarm I/O connector
