AC1 4-Slot Battery Charger
AC1 4-Slot Battery Charger Instructions
*073530-008*
P/N 073530-008
You may need additional information when working with the AC1 and CK30 or CK31 in a data
collection system. Please visit our web site at www.intermec.com to download our current
manuals in PDF format.
Patent Information
Product is covered by one or more of the following
patents: 5,052,943; 5,195,183; 5,317,691; 5,331,580;
5,544,010; 5,644,471. There may be other U.S. and
foreign patents pending.
Electrical rating: x12V, 4A
Requires Intermec AC power supply
v100 to 240 VAC, 50 to 60 Hz
Worldwide Headquarters
6001 36th Avenue West
Everett, Washington 98203
U.S.A.
tel [phone]
fax [phone]
www.intermec.com
© 2010 Intermec Technologies
Corporation. Alle Rechte vorbehalten.
1
2
Place the battery charger on a at, stable, and clean surface that is within 1.5 m (5 ft) of
an AC power outlet.
Connect the AC power supply to the power connector on the battery charger and to
an AC power outlet. The Status light in each button turns on, showing that the battery
charger is ready to use.
To prevent re or electric shock, do not expose the AC1 to rain or moisture.
Status light
(4 places)
Power
connector
Button
(4 places)

What Is the AC1? Charging Batteries Understanding the Status Lights
The AC1 4-Slot Battery Charger is an accessory for the CK30 and CK31 Handheld Computers. You
can use the battery charger to charge up to four batteries at the same time.
This guide explains how to install and use the battery charger.
What You Need
To use the charger, you need:
•an AC power supply.
•an AC power cord.
You need to purchase the appropriate power cord for your location. For more information,
contact your Intermec sales representative.
You can charge up to four batteries at one time in the charger. The charger fully charges the
batteries in about 5 hours.
This table explains what the dierent colors of the Status lights mean.
2
1
To charge batteries
With the battery contacts facing the charger,
slide the battery into one of the slots.
Push the battery into the slot to engage the
latch. The Status light for that slot changes
from yellow to green or red to indicate the
battery charge status. See “Understanding
the Lights”to learn what the Status light
colors mean.
To remove batteries
•Press the button for that slot and
slide the battery up and out.
You must use the appropriate Intermec power supply with this device or
equipment damage may occur.
AC1 4-Slot Battery Charger Instructions
Color Description
No Color The battery charger is not receiving power. Make sure the power supply is
connected properly to a powered AC outlet.
Steady Yellow The battery charger is connected to AC power and is ready to charge.
Flashing Green The battery is charging.
Steady Green The battery is fully charged.
Flashing Red The battery is not charging. Try these solutions:
•Make sure the battery is rmly installed in the charger.
•Make sure the power supply is connected properly to a powered
AC outlet.
•Make sure the charging pins on the AC1 and the battery contacts
on the battery are clean.
