INTEX® OWNER'S MANUAL E
Fast-FillTM Electric Air Pump
Model AP619C 110 — 120 V~ 60 Hz 0.9 A
IMPORTANT SAFETY INSTRUCTIONS .
READ AND FOLLOW ALL INSTRUCTIONS BEFORE USING THIS PRODUCT
A DANGER
To reduce the risk ofelectréc shock: Always unplug 1his furnishing from the electrical outlet before cleaning.
A WARNING
To reduce the risk of burns, fire, electric shock, or injury to persons:
- Infants have suffocated on inflatable mattresses. Never place infant aged birth to 15 months to sleep on this
inflatable air mattress / air bed. Infants can suffocate on an underinflated or deflated mattress, on bedding,
by co-sleeping with another person, and by entrapment between the mattress and bed frame or between the
mattress and a vertical surface.
- Children can be entrapped between the inflatable mattress and an ad'acent vertical surface. Provide at least a
shoulder width space etween the inflatable mattress / airbed and adjacent vertical surfaces such as walls,
dressers or other objects.
- Always keep the inflatable mattress fully inflated when in use.
0 Never introduce any flammable substance into the inflatable airbed, SUCH AS AEROSOL TIRE REPAIR
PRODUCTS, as it may ignite or explode.
o For indoor household use onlty.
- Unplug from outlet before pu ing on or taking off parts.
0 Close su ervislon is necessary when this furnishing ls used by, or near children, invalids, or disable persons.
- Use this urnlshin onl for its intended use as described in these instructions. Do not use attachments
not recommende byt e manufacturer.
- Do not operate where aerosol (spray) products are bein used or where oxygen is being administered.
0 This is not a toy. Children must not e left unattended w en using the airbe .
- Keep the storage bag away from babies and children. The storage bag Is not a toy. When not In use,
fold the bag and put rt away out of the reach of children.
- Do not wal , stand on or jump on or use the airbed as a trampoline.
- Do not use on or near water. This is not a raft.
' Do not set up bed near stairs, doors, sharp edges or breakable objects. Provide adequate space between bed
and objects to avoid entrapment. .
- p/lakel sgre the area Is flat, smooth, free of sharp objects that could puncture the bed and keep away
rom e ges.
- Keep pets away from the airbed. Pets may puncture the surface of the bed.
- Avord sleeping on the ed e of the airbed. Edges produce less support than the middle of the bed.
- Do not operate air pump or more than5 minutes at a time. Let pump cool at least 15 minutes between use.
' Ulnplpg electaical power cord when not in use. To disconnect, turn al controls to the off position, then remove
ug rom ou et.
' ever operate the furnishing with the air openings blocked. Keep the air openings free of lint, hair, and
the like. Never drop or insert object into any opening.
- Never operate this furnishing if It has a damaged cord or plug, if it is not working properly, If it has been
dropped or damaged, or dropped into water. eturn the furnishing to a service center for examination and / or
reparr.
- If the AC supply cord is damaged, it must be replaced by the manufacturer or its service agent in order to
avoid a hazard.
- Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings. Do not route
cord under furniture or appliances. Arrange cord away from traffic area and where it will not be tripped over.
Keep the cord away from heated surfaces.
FOLLOW THESE RULES AND ALL INSTRUCTIONS TO AVOID SUFFOCATION, PROPERTY DAMAGE,
ELECTRIC SHOCK, BURNS OR OTHER INJURY.
A CAUTION
- To reduce the risk of electric shock or injury, use indoors only, do not expose to rain. Store indoors.
READ AND SAVE THESE INSTRUCTIONS
Page 1 150—‘PO-R1-1806
INTEX ET AL V. TWW IPR2018—00870
TWW EXHIBIT 2706
Page 1
f
Find authenticated court documents without watermarks at docketalarm.com.

TWW EXHIBIT 2706
Page 2 .
SERVICING OF A DOUBLE-INSULATED PRODUCT:
In a double-insulated product, two systems of insulation are provided instead of grounding. No
grounding means is provided on a double-insulated product, nor should a means for grounding
be added to the product. Servicing of a double-insulated product requires extreme care and knowledge
of the system, and should be done only by qualified service personnel. Replacement parts for a
double-insulated product must be identical to those parts in the product. A double-insulated product
is marked with the words “DOUBLE INSULATION" or “DOUBLE INSULATED" and with the symbol IEI.
OPERATING INSTRUCTIONS
General
- This appliance has a polarized plug (one blade is wider than the other). This plug will fit in a polarized
outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician to install the proper outlet. Do not change the plug in any way.
- For inflatable products with a total air volume up to 2 cubic meter (70 cubic feet), which correspond
to an expected inflation time of about 5 min and 30 sec.
Maintenance instructions:
- No air pump maintenance is required. Air pump has no user serviceable parts.
- For cleaning use only mild soapy solution. Do not use any chemicals.
- In case of repairs, use only common PVC repair glue and patches.
PARTS REFERENCE
Part Descriptions:
AC line cord
Switch
Inflation mark( E )
Off mark ( )
Deflation mark ( V )
Air passage
Cord compartment
Airbed
9°.“.°7.°‘P9’!\’.‘
ih‘IfII \
\ 7 8
NOTE: Drawings for illustration purpose only. May not reflect actual product. Not to scale. Due to a
policy of continuous product improvement, lntex reserves the right to change specifications and
appearance, which may result in updates to the instruction manual, without notice.
INFLATION
1. Plug in the AC line cord into an AC electrical outlet. See Fig (1).
110-120V
FIG (1) FIG (2)
2. Slide the switch up to the inflation mark ( A ). See Fig (2).
READ AND SAVE TH SE INSTRUCTIONS
Page 2
3. When the airbed is fully inflated to the desired firmness, slide the switch down to
the Off mark ( ). The line on the switch must be aligned with the dot to
ensure the internal air passage is closed. See Fig (3).
FIG (3) FIG (4) FIG (5)
Lie down on the airbed to test the firmness.
If the sleeping surface is too hard, adjust the firmness by slowly sliding the switch down
to the deflation mark ( V ). See Fig (4). Slide the switch up to the Off mark ( )
when the desired firmness is achieved. The line on the switch must be aligned
with the dot to ensure the internal air passage is closed. See Fig (5). If the airbed
becomes too soft repeat step #2 thru #5 as necessary.
6. Disconnect the AC line cord from the wall socket, place it inside the cord compartment.
IMPORTANT NOTE
Proper inflation of the airbed.
The ambient temperatures of air have an effect on the airbed internal pressure. At low
ambient temperature the air will contract within the airbed and the airbed will feel softer:
add air as necessary. At high ambient temperature the air within the airbed will expand
significantly and the airbed will become hard and may burst: release air to avoid damage
to the airbed or to soften the feel. Do not expose the airbed to extreme temperatures
(hot or cold).
Stretching is a natural characteristic of new vinyl. During initial use, the airbed may become
soft and require additional inflation to maintain desired firmness. This is normal for the first
few days of use.
Dimensions shown are approximate and will vary due to the vinyl temperature and the air
temperature.
In no event shall lntex, their authorized agents or employees be liable for damages
(such as pin holes) to the airbed caused by negligence, ordinary wear and tear,
abuse and carelessness, or external forces.
DEFLATION
1. Plug in the AC line cord into an AC electrical outlet. See Fig (1).
2. Slide the switch down to the deflation mark ( V ). See Fig (6).
Q
I."
9"?
FIG (6) FIG (7)
READ AND SAVE THESE INSTRUCTIONS
Page 3
TWW EXHIBIT 2706
Page 2
f
Find authenticated court documents without watermarks at docketalarm.com.

TWW EXHIBIT 2706
Page 3 .
3. When the airbed is completely deflated, begin rolling the airbed from the foot of
the airbed towards the head of the airbed where the pump is located. See Fig (7).
4. When all air is removed from the airbed, slide the switch up to the Off mark
( ). See Fig (3).
5. Disconnect the AC line cord from the wall socket, place it inside the cord compartment.
IMPORTANT
Never disconnect the power line cord from the pump or from the electrical outlet while the pump
is operating. Switch OFF ( 7 ) the pump first before disconnecting the power line cord.
INFLATION OPTION
1. If electrical power is not available then a conventional foot
or manually operated air pump can be connected to the (m [€41
air passage (6) for inflation. See Fig (8). .m ""
2. Slide the switch up to the inflation mark ( A ). - m I
3. Insert air pump nozzle to the air passage to inflate the
airbed. '
4. When the airbed is fully inflated to the desired firmness, 3"
slide the switch down to the Off mark ( ). The FIG (8)
line on the switch must be aligned with the dot to
ensure the internal air passage is closed.
Note: Inflate only with a low pressure inflator. Donot over
inflate. Fill with cold air only.
STORAGE INSTRUCTIONS
1. Deflate the airbed following the "DEFLATlON".instructions.
2. Make sure the airbed is clean and dry.
3. Lay bed flat with sleeping surface facing upwards and follow the folding steps on Figs
(9 - 13). Fold the airbed loosely and avoid sharp bends, corners and creases which can
damage the airbed.
Z
FIG (9) FIG (10) FIG (11)
FIG (12) FIG (13)
4. Place the airbed inside the storage bag and store in a dry, cool storage location.
@2018 lntex Marketing Ltd. - lntex Development Co. Ltd. - lntex Recreation Corp. All rights reserved/1’ ous droits réservésl'l'odos los derechos
reservadoslAlle Rechte vorbehalten. Printed in chinallmprimé en Chine/lmpresu en China/Gedruckt in China.
®m Trademarks used in some countries of the world under license from/@Wl Marques utilisées dans oertains pays sous licence tie/Mamas registradas
utilizadas en algunos paises del mundn baja Iicencia delWarenzeiehen verwendet in einigen Landern der Welt in Lizenz von/lntex Marketing Ltd. tolalal
an Intex Development Co. Ltd., G.P.O Box 28829, Hang Kong a. lntex Recreation carp, P.O. Box 1440, Long Beach, CA 90801 - Distributed in the
European Union by/Distribué dans I'Union Europe'enne par/Distribuidu en la unidn Eumpea porNertI-ieb in der Européischen Union durchllntex Trading
i INTEX® B.V., Venneveld 9, 4705 RR Roosendaal — The Netherlands Consumer Service 1-800-234-6839
www.intexcarp.com
READ AND SAVE THESE INSTRUCTIONS.
