Intex Quickfill Plus AP619D User manual

(19PO) AP619D ELECTRIC PUMP ENGLISH 4.875” X 7.25” 04/30/2020
19PO
READ AND SAVE THESE INSTRUCTIONS
Page 1 019-*PO-R0-2004
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS BEFORE USING THIS PRODUCT
INTEX®OWNER'S MANUAL
Quickfill®Plus Internal Pump
Model AP619D 110 – 120 V~ 60 Hz 0.65 A
To reduce the risk of burns, fire, electric shock, or injury to persons:
•Infants have suffocated on inflatable mattresses. Never place infant aged birth to 15 months to sleep on this
inflatable air mattress / air bed. Infants can suffocate on an underinflated or deflated mattress, on bedding,
by co-sleeping with another person, and by entrapment between the mattress and bed frame or between the
mattress and a vertical surface.
•Children can be entrapped between the inflatable mattress and an adjacent vertical surface. Provide at least a
shoulder width space between the inflatable mattress/airbed and adjacent vertical surfaces such as walls,
dressers or other objects.
•Always keep the inflatable mattress fully inflated when in use.
• Never introduce any flammable substance into the inflatable airbed, SUCH AS AEROSOL TIRE REPAIR
PRODUCTS, as it may ignite or explode.
•For indoor household use only.
• Unplug from outlet before putting on or taking off parts.
• Close supervision is necessary when this furnishing is used by, or near children, invalids, or disable persons.
• Use this furnishing only for its intended use as described in these instructions. Do not use attachments not
recommended by the manufacturer.
• Do not operate where aerosol (spray) products are being used or where oxygen is being administered.
•This is not a toy. Children must not be left unattended when using the airbed.
•Keep the storage bag away from babies and children. The storage bag is not a toy. When not in use, fold the
bag and put it away out of the reach of children.
•Do not walk, stand on or jump on or use the airbed as a trampoline.
•Do not use on or near water. This is not a raft.
•Do not set up bed near stairs, doors, sharp edges or breakable objects. Provide adequate space between bed
and objects to avoid entrapment.
•Make sure the area is flat, smooth, free of sharp objects that could puncture the bed and keep away from
ledges.
•Keep pets away from the airbed. Pets may puncture the surface of the bed.
•Avoid sleeping on the edge of the airbed. Edges produce less support than the middle of the bed.
•Do not operate air pump for more than 5 minutes at a time. Let pump cool at least 15 minutes between use.
•Unplug electrical power cord when not in use. To disconnect, turn all controls to the off position, then remove
plug from outlet.
• Never operate the furnishing with the air openings blocked. Keep the air openings free of lint, hair, and the like.
Never drop or insert object into any opening.
• Never operate this furnishing if it has a damaged cord or plug, if it is not working properly, if it has been
dropped or damaged, or dropped into water. Return the furnishing to a service center for examination and/or
repair.
•If the AC supply cord is damaged, it must be replaced by the manufacturer or its service agent in order to
avoid a hazard.
•Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings. Do not route
cord under furniture or appliances. Arrange cord away from traffic area and where it will not be tripped over.
Keep the cord away from heated surfaces.
FOLLOW THESE RULES AND ALL INSTRUCTIONS TO AVOID SUFFOCATION, PROPERTY DAMAGE,
ELECTRIC SHOCK, BURNS OR OTHER INJURY.
WARNING
•To reduce the risk of electric shock or injury, use indoors only, do not expose to rain. Store indoors.
CAUTION
•
To reduce the risk of electric shock: Always unplug this furnishing from the electrical outlet before cleaning.
DANGER

(19PO) AP619D ELECTRIC PUMP ENGLISH 4.875” X 7.25” 04/30/2020
19PO
READ AND SAVE THESE INSTRUCTIONS
Page 2
PARTS REFERENCE
Part Descriptions:
1. Pump holder frame
2. Pump removal tab
3. Cord compartment
4. AC line cord
5. Manual inflation port cap
6. Manual inflation port
7. Cord compartment cover
8. Air passage
9. Power switch
10. Valve control dial
11. Airbed
NOTE: Drawings for illustration purpose only. May not reflect actual product. Not to scale.
Due to a policy of continuous product improvement, Intex reserves the right to change
specifications and appearance, which may result in updates to the instruction manual,
without notice.
OPERATING INSTRUCTIONS
General
•This appliance has a polarized plug (one blade is wider than the other). This plug will fit
in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not
change the plug in any way.
•Airbeds are designed for temporary use and are NOT designed to be a replacement for a
traditional mattress.
•Make sure the area is flat, level, clean and free from sharp objects, and within reach of
an electrical outlet.
•To prevent puncture or damage to the airbed, never drag the airbed across the floor. Lift
the inflated airbed when moving or changing location.
Maintenance instructions:
• No air pump maintenance is required. Pump is removable.
• For cleaning use only clean cloth with mild soapy solution. Do not use any chemicals.
• In case of repairs, use only common PVC repair glue and patches. For flocked surfaces:
rub away the flocking material with an eraser first before applying the glue and/or patch.
SERVICING OF A DOUBLE-INSULATED PRODUCT:
In a double-insulated product, two systems of insulation are provided instead of grounding.
No grounding means is provided on a double-insulated product, nor should a means for
grounding be added to the product. Servicing of a double-insulated product requires extreme
care and knowledge of the system, and should be done only by qualified service personnel.
Replacement parts for a double-insulated product must be identical to those parts in the
product. A double-insulated product is marked with the words “DOUBLE INSULATION” or
“DOUBLE INSULATED” and with the symbol .
11
9
10
1
2
3
4
5
6
7
8

(19PO) AP619D ELECTRIC PUMP ENGLISH 4.875” X 7.25” 04/30/2020
19PO
READ AND SAVE THESE INSTRUCTIONS
Page 3
3. Switch ON the pump by pressing “I” on the switch located on top of pump. See Fig (3).
4. Turn valve control dial fully clockwise until it stops. The airbed is now inflating. See Fig (4).
5. When the airbed is fully inflated,turn the valve control dial back (counterclockwise) to the
center position closing the inflation valve. Then turn off the pump by pressing “O” on the
switch. See Fig (5).
NOTE: Turning the valve control dial from the center/closed position will open the valve
inside the pump and allow air to escape, even if pump is not running. Operate the valve
control dial when inflating or deflating the airbed, or for firmness adjustment (see step #6).
Never disconnect the power line cord from the electrical outlet while the pump is operating.
Switch off the pump first before disconnecting the power line cord.
INFLATION
1. Open line cord compartment cover and remove line cord. Do not yank on the cord.
See Fig (1).
2. Plug in the AC line cord into an AC electrical outlet. See Fig (2).
6. If the airbed feels too firm, release some air by simply turning the valve control dial
gradually in either direction to allow air to escape until desired firmness is achieved, then
turn the valve control dial back to the center/closed position. If the bed feels too soft,
repeat steps #3 to #6 as necessary.
FIG (3) FIG (4)
Inflate
Position
FIG (5)
Rotate Back to Close Valve
FIG (2) √
110 – 120 V
220 – 240 V
FIG (1)

(19PO) AP619D ELECTRIC PUMP ENGLISH 4.875” X 7.25” 04/30/2020
19PO
READ AND SAVE THESE INSTRUCTIONS
Page 4
Proper inflation of the airbed.
The ambient temperatures of air have an effect on the airbed internal pressure. At low
ambient temperature the air will contract within the airbed and the airbed will feel softer:
add air as necessary. At high ambient temperature the air within the airbed will expand
significantly and the airbed will become hard and may burst: release air to avoid damage
to the airbed or to soften the feel. Do not expose the airbed to extreme temperatures (hot
or cold).
Stretching is a natural characteristic of new vinyl. During initial use, the airbed may become
soft and require additional inflation to maintain desired firmness. This is normal for the first
few days of use.
Dimensions shown are approximate and will vary due to the vinyl temperature and the air
temperature.
In no event shall Intex, their authorized agents or employees be liable for damages
(such as pin holes) to the airbed caused by negligence, ordinary wear and tear,
abuse and carelessness, or external forces.
IMPORTANT NOTE
4. When all the air is removed from the airbed, turn the valve control dial back (clockwise)
to the center position closing the valve. Then turn off the pump by pressing “O” on the
switch. See Fig (5).
5. With the airbed fully deflated begin rolling the airbed from the end opposite of the pump
towards the end where the pump is located. See Fig (7).
6. Disconnect the AC line cord from the electrical outlet, coil the line cord and place it
inside the cord compartment, then close the cover. Make sure the line cord is free
of twists, kinks or knots.
FIG (7)
DEFLATION
1. Plug in the AC line cord into an AC electrical outlet. See Fig (2).
2. Switch ON the pump by pressing “I” on the switch located on top of pump. See Fig (3).
3. Turn valve control dial fully counterclockwise until it stops. The airbed is now deflating.
See Fig (6).
MANUAL INFLATION OPTION
If electrical power is not available, a conventional foot, manual, or battery-operated air
pump can be used by connecting it to the manual inflation port located inside the line cord
compartment. See Fig (8). Follow these steps:
FIG (6)
Deflate
Position

(19PO) AP619D ELECTRIC PUMP ENGLISH 4.875” X 7.25” 04/30/2020
19PO
READ AND SAVE THESE INSTRUCTIONS
Page 5
1. Open line cord compartment cover and locate the
manual inflation port.
2. Make sure the valve control dial of the internal electric
pump is still in the center/closed position.
3. Remove the cap from the manual inflation port and
insert the nozzle of the pump into the port. Inflate the
airbed to desired firmness.
NOTE: Do not overinflate. The firmness should be
approximately the same as the level achieved with the
internal electric pump.
4. Remove nozzle from manual inflation port and close
the cap and the line cord cover.
FIG (9) FIG (10) FIG (11)
FIG (13)
FIG (12)
STORAGE INSTRUCTIONS
1. Deflate the airbed following the "DEFLATION" instructions.
2. Make sure the airbed is clean and dry.
3. Lay the airbed flat with the sleeping surface facing upwards and follow the folding steps
on Figs (9 - 13). Fold the airbed loosely and avoid sharp bends, corners and creases
which can damage the airbed.
REPLACING INTERNAL AIR PUMP OR THE AIRBED COMPONENT
If there is a need to replace either the internal air pump or the airbed portion, detach
the internal pump from the airbed as follows:
1. While holding both lock tabs pressed inward (see Figure 14), turn the round body of the
pump (the large outer rim, not the valve control dial) counterclockwise and pull the air
pump body out of the holder frame.
2. Depending on which part is being replaced, keep the remaining component (either the
airbed portion or the removed pump) in a safe place until the replacement part is
received. Reattach the components when the new part is received: simply place
the pump into the holder frame and turn clockwise untill the lock tabs click into place.
NOTE: Make sure the rubber seal on the pump housing as well as the inside wall of the
holder frame are clean and free from any lint, hair or dirt, to ensure aproper seal and avoid
air leaks.
NOTE: Do not remove internal air pump from the holder frame other than for servicing, as
this may introduce lint, hair or dirt into the seal area and cause air leaks. If air leak is
experienced, check that the seal is clean before replacing the pump or the airbed.
1
2
1
FIG (14)
FIG (8)

(19PO) AP619D ELECTRIC PUMP ENGLISH 4.875” X 7.25” 04/30/2020
19PO
READ AND SAVE THESE INSTRUCTIONS
Page 6
©2020 Intex Marketing Ltd. - Intex Development Co. Ltd. - Intex Recreation Corp. All rights reserved/Tous droits réservés/Todos los derechos
reservados/Alle Rechte vorbehalten. Printed in China/Imprimé en Chine/Impreso en China/Gedruckt in China.
®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous licence de/Marcas registradas
utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/
an Intex Development Co. Ltd., G.P.O Box 28829, Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the
European Union by/Distribué dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading
B.V., Venneveld 9, 4705 RR Roosendaal – The Netherlands Consumer Service 1-800-234-6839
www.intexcorp.com
PROBLEM CAUSE SOLUTION
Air leakage
between internal air
pump and the pump
holder frame
• Pump not securely
attached.
• Pump O-ring is
dirty.
• Internal airbed
beam threads are
caught between
the internal air
pump and the pump
holder frame.
• Pump O-ring is
twisted and/or
damaged.
• While holding the pump outer rim, push in and
turn the pump fully clockwise until the two side
tabs lock into place.
• Remove the pump from the airbed, remove the
O-ring from the pump and clean it with water.
Carefully replace the O-ring back to the pump
as to prevent dust, lint from sticking onto the
O-ring again. Also make sure the pump holder
frame inner wall is free from dust, hair or lint.
• Remove the internal air pump and carefully
replace the pump back making sure the
internal airbed beam threads are away from
the pump holder frame.
• Remove the pump from the airbed, make sure
the O-ring is not damaged and/or twisted.
Realign the O-ring or replace a new O-ring.
Contact Intex service center for replacement.
Air pump does not
work
• Not connected to
an electrical outlet
socket.
• Pump motor
thermo-protector
activated.
• Internal air pump
defective.
• Make sure the pump is plugged into the correct
power outlet, then switch on the pump and turn
the valve control dial fully clockwise to the
inflation position.
•
Switch off and disconnect the line cord from the
power outlet, let the pump rest for more than 30
minutes before resume the use of the pump.
• Remove the internal air pump from the airbed
and keep the airbed in a safe place. Contact
Intex service center for an internal air pump
replacement.
Pump motor is
running but airbed
is not inating or
deating
• The inflation or
deflation mode is
not set yet.
•
Press “I” to switch on the pump and make sure
there is air flowing. Then turn the valve control
dial fully clockwise until it stops to inflate the
airbed. Or turn the valve control dial fully
counterclockwise until it stops to deflate the airbed.
After ination air is
escaping through
the pump air
passage or through
the manual inflation
port
• The pump air
passage is not
completely closed.
• The manual
inflation port cap is
not securely closed.
• Make sure the air passage is closed by turning
the valve control dial to the center position.
• Push the cap firmly into the manual inflation
port.
TROUBLESHOOTING GUIDE
