Invacare®Aerosol Prod cts
• Stratos™Aerosol Compressors
• Neb lizers
• Asthma Management

Invacare®Aerosol Prod cts
Invacare is proud to offer an
updated aerosol product line
that includes the Stratos™
Compact, Portable Plus and
Invacare®select aerosol
compressors. The feature the
performance, reliabilit , and
value that providers and
patients have come to expect
from Invacare.
Table of Contents
Stratos™Compact Aerosol Compressor 2
Stratos™Portable Plus Aerosol Compressor 3
Invacare®select aerosol compressor 4
Aerosol Compressors/Aspirators 5
Nebulizers 6
Asthma Management 7
For Oxygen Products – form 05-054
For Sleep Products – form nos. 03-061
and 07-065
Invacare®Aerosol Products
1

2
Invacare®Stratos™Compact Aerosol Compressor
Invacare®Stratos™Compact Aerosol Compressor
Features
•Packaged with a reusable nebulizer
•Economical – premium product that is priced to
fit the needs of the managed-care market
•Stylish – updated design and color
•Durable – five year limited warranty
•Nebulizer parking post
Specifications
•Dimensions: 5.9" l x 5.7" w x 3.7" h
•Weight: 3.2 lb.
•Maximum compressor pressure: 33 PSI
•Typical operating pressure: 11 - 16 PSI
•Typical operating flow rate: 4 - 8 PM
Reusable Jet Nebulizer
Model no. MS2600
The new Reusable Jet Nebulizer is an
extremely cost effective, durable nebulizer.
The special geometry and smooth surface
finish of the nebulizer result in minimal
residual volume.
IRC1710 Stratos Compact Aerosol Compressor.
Invacare®Stratos™Compact Aerosol Compressor
Model no. IRC1710
The updated Invacare Stratos Compact is a sleek, new piston compressor that offers
stylish design, quality and economy in one compact package. Now it is even smaller, yet
still powerful enough to deliver the fast, effective aerosol treatments users expect.
Model Selection Guide
Model no. Units/Case imited warranty Description
IRC1710 1 5 years Stratos Compact Aerosol Compressor
MS2600 10 n/a Reusable Jet Nebulizer
IRC1711 1 n/a Stratos Compact carrying case

Invacare®Aerosol Compressors
Invacare®Stratos™Portable Plus Aerosol Compressor
3
Invacare®Stratos™Portable Pl s Aerosol Compressor
Invacare®Stratos™Portable Plus Aerosol Compressor
Model no. IRC1730
The Invacare Stratos Portable Plus is a sleek, new portable compressor
that offers speed, ease-of-use and stylish design in one compact pack-
age. Small enough to fit in the palm of your hand, it is ideal for those
who desire mobility, expediency and efficiency in an aerosol delivery
device.
IRC1731 Battery Pack (sold separately). Reusable nebul zer w th tub ng, DC car adapter, AC power cord
and carry ng case all come standard w th Stratos Portable
Plus un t.
Model Selection Guide
Model no. Units/Case imited warranty Description
IRC1730 1 3 years Stratos Portable Plus aerosol compressor
reusable nebulizer, AC power cord,
DC car adapter and carrying case
IRC1731 1 6 months Battery pack for Stratos Portable Plus
MS2700 10 n/a Reusable Jet Plus Nebulizer
IRC1722 1 n/a Stratos Portable Plus carrying case
Features
•Powerful enough to drive a
standard nebulizer
•Mobile – small size, quiet oper-
ation and battery pack (sold sep-
arately) allows the unit to be
used almost anywhere
•Economical – premium product
that is priced to fit the needs of
the managed-care market
•Flexible – can be powered using
the AC power cord in a wall out-
let, the DC adapter in a car, or
the optional battery pack
•Three year limited warranty
•U isted
Specifications
•Dimensions: 5.1" l x 3.6" w x 1.6" h
•Weight: 1 lb. (450 g) – without battery pack
1.4 lb. (650 g) – with battery pack
•Maximum compressor pressure – 29 PSI
•Operating flow rate – 3.5 PM
•Maximum flow rate – 10 PM
•Noise level – 52 dB
Stratos Portable Plus
Nebulizer Features
•Nebulization Rate - 0.4 ml/minute
•Particle size - < 5 microns

4
Invacare®select aerosol compressor
Model no. IRC1705
The Invacare select aerosol compressor is a standard compres-
sor packaged with a disposable nebulizer. It is designed to meet
today’s performance and price requirements.
Conven ent carry ng handle for ease of transportat on.
Model Selection Guide
Model no. Units/Case imited warranty Description
IRC1705 1 3 years Invacare select aerosol compressor
Features
•Packaged with one disposable nebulizer
•Built-in handle
•Easy operation
•U listed
Specifications
•Dimensions: 6" l x 4.5" w x 3.5" h
•Weight: 3.2 lb.
•Maximum compressor pressure: 36 PSI
•Typical operating pressure: 11 - 16 PSI
•Typical operating flow rate: 4 - 8 PM
Invacare®select aerosol compressor
Invacare®select aerosol compressor

Invacare®D rable Compressors/Aspirators
Invacare®Durable Compressors/Aspirators
5
Specifications
Dimensions 8" l x 8" w x 10.5" h
Weight 11.3 lb.
Pressure range 0 - 50 PSI
Operating pressure 7 lpm at 23 PSI nominal with
a filtered nebulizer system
Electrical requirements 115 VAC/60 Hz, 1/8hp
shaded pole motor
Model Selection Guide
Model no. Units/Case imited warranty Description
IRC607 1 1 year 50 PSI compressor,
115 VAC/60 Hz
Specifications
Dimensions 14.8" l x 6.8" w x 9.8" h
Weight 12.1 lb.
Vacuum range 0 - 520 mm Hg
0 - 23" Hg
Air flow 0 - 40 PM
Electrical requirements 115 VAC
60 Hz, 1/10 hp
shaded pole motor
Invacare®Aspirator
Model no. IRC1135
The Invacare aspirator is a durable suction unit
designed for most home care suction requirements.
Features
Invacare®MOBILAIRE™50 PSI Compressor
Model no. IRC607
The durable Invacare MOBI AIRE 50 PSI compressor is
ideal for use with medications that require more flow
and pressure for proper nebulization.
Features
•ow-noise operation
•Easy-to-read pressure
gauge
•Non-marring rubber feet
•Suction-cup feet for sta-
ble operation
•Durable piston
•Adjustable pressure
•Optional J-tube (IRC5070)
available
•U and CSA listed
•High-performance
vacuum specifications
•Adjustable vacuums
from 0" to 23" Hg
•Durable piston vacu-
um pump
•Easy-to-read gauge
•Non-marring suction
cup feet
•Single-use collection
jars and connecting
tubing for quick and
easy replacement
(1 set included)
•U and CSA listed
Model Selection Guide
Model no. Units/Case imited warranty Description
IRC1135 1 1 year Aspirator
IRC1140 10 n/a Disposable collection jars,
800 cc capacity, 6 ft.
suction tubing
1148804 1 Tube and Filter kit

6
Invacare®Neb lizers
Invacare®Nebulizers
Features
•Rapid and efficient
•Nebulizes 2ccs in approximately three minutes
•ow residual volume of medication
•Constant nebulization in every position at an angle
of up to 80˚
Model no. MS0312
Pediatric Dragon Mask provides a
fun, yet calming option. Children
can be encouraged to take
frequent deep breaths and receive
the biofeedback of the dragon
exhaling “smoky dragon breath.”
Model no. MS0312
The Pedi-Neb pacifier calms an
infant or toddler during aerosol
treatment, as the medication is
inhaled through the nose, not
mouth.
Model Selection Guide
Model no. Units/Case Description
MS2600 10 Reusable Jet Nebulizer (6 ml capacity) with T-piece, mouth piece and 6.5 ft (200 cm) tubing
MS2700 10 Reusable Jet Plus Nebulizer (10 ml capacity) with T-piece, mouth piece and 6.5 ft (200 cm) tubing
MS2120 10 VixOne™Nebulizer (5 ml capacity) with pediatric mask and 7 ft. (213 cm) tubing
MS2110 50 VixOne™Nebulizer (5 ml capacity) with adult mask and 7 ft. (213 cm) tubing
MS2100 50 VixOne™Nebulizer (5 ml capacity) with T-piece, mouthpiece, 7 ft. (213 cm) tubing and 6 in. (15 cm) flextube
MS0312 50 VixOne™Nebulizer with pediatric Dragon mask and 7 ft. (213 cm) tubing
MS0382 12 VixOne™Nebulizer with Pedi-Neb pacifier and 7 ft. (213 cm) tubing
MS2300 50 Salter abs®Disposable Nebulizer (5ml capacity) with T-piece, 6” reservoir tube and 7’ supply tube
MS2500 10 Salter abs®Reusable Nebulizer (5ml capacity) with mouth-piece and 7’ tubing
MS0312
MS2120
MS2110
MS2100
Tubing
MS0382
The new Reusable Jet Nebulizer is an extremely cost effective, durable
nebulizer. The special geometry and smooth surface finish of the nebulizer
result in minimal residual volume.
Reusable Jet Nebulizers
Model no. MS2600, MS2700
The VixOne Nebulizer is an economical choice in small-volume nebulizers.
It is available with a variety of inputs, including a T-piece mouthpiece, adult,
pediatric clear or pediatric Dragon mask and Pedi-NebTM pacifier.
VixOne™Nebulizers
Model nos. MS2100, MS2110, MS2120
Features
•Nebulizes 3cc within 7 minutes or less at 7 PM in
horizontal or vertical position
•Removable color-coded cone design
•Incorporates integral anti-drool feature
•MS2500 is top rack dishwasher safe
MS2300
MS2600
MS2500
Features
•Nebulizes at angles up to 45˚
•Graduated volume marking on medication chamber
•Anti-spill designed T-piece mouthpiece option
•Creative pediatric mask and infant pacifier options
Salter Labs®Disposable Nebulizers
Model nos. MS2300, MS2500
MS2700

Invacare®Asthma Management
Invacare®Asthma Management
Invacare Corporation
www.invacare.com
USA
One Invacare Way
Elyria, Ohio
44035-4190
[phone]
Canada
570 Matheson Blvd. E.
Unit 8
Mississauga, Ontario
4Z 4G4 Canada
[phone]
© 2008 Invacare Corporation.
All rights reserved.
Trademarks are identified by
the symbols ™ and ®.
All trademarks are
owned by or licensed to
Invacare Corporation
unless otherwise noted.
VixOne and Pedi-Neb are
trademarks of
Westmed, Inc.
Salter abs is a registered
trademark of Salter abs.
ComfortSeal, Color Zone,
TruZone, F OWSIGnal and
AeroChamber are registered
trademarks and Z-Stat Plus is
a trademark of Monaghan
Medical Inc.
American Thoracic Society is
a registered trademark of the
American ung Association.
Specifications are
subject to change
without notification.
Form No. 04-220
Rev. 01/08
Specifications
Range 60-800 lpm
Dimensions 17.4 cm l x 3.2 cm w x 3.2 cm h
Weight 33.1 g
Model Selection Guide*
Model no. Units/Case imited warranty Description
IRC1198 10 1 year TruZone Peak Flow Meter
Distribution limited to U.S. customers onl .
Model no. IRC1198
The TruZone Peak Flow Meter (PFM) makes it easy to monitor
peak expiratory flow rates at home. The small size and shape
enhance portability and ease of use. The unique logarithmic
scale allows the TruZone to be used in low flow rate conditions
(pediatrics) or for standard flow rates. And through the use of
Color Zone®decals, each TruZone can be customized easily for
color-zone management of asthma as recommended by the
NAEPP (National Asthma Education and Prevention Program)
Each TruZone is packaged with 4 Color Zone tapes and a daily
record..
Features
Appl cat on of the ColorZone decal by
the health care prov der custom zes the
TruZone for the pat ent. V sual zat on of the
green, yellow and red zones makes t easy
to follow the NAEPP gu del nes for asthma
management.
Monaghan AeroChamber®-Stat Plus™
Model nos. HC78510, HC88510, HC79510
The Monaghan AeroChamber Z-Stat Plus helps improve the
delivery of medications from metered-dose inhaler (MDI)
canisters. It also reduces the coordination required between
canister activation and inhalation, making it easier for the
patient to use the MDI correctly. And it reduces drug deposition
to the mouth and throat, helping to eliminate unpleasant
medication taste or hoarseness. AeroChamber Plus VHC with
ComfortSeal®mask comes in three sizes, permitting MDI
therapy to be administered to infants and small children.
Features
Tru one®Peak Flow Meter
Model Selection Guide8
Model no. Units/Case Description
HC78510 10 AeroChamber Z-Stat Plus with medium
ComfortSeal mask
HC88510 10 AeroChamber Z-Stat Plus with small
ComfortSeal mask
HC79510 10 AeroChamber Z-Stat Plus with mouthpiece
Distribution limited to U.S. customers onl .
These prod cts are Latex Free.
The fam ly of ant -stat c valved hold ng chambers has been tested w th CFC and HFAformulat ons.
•Z-Stat custom anti-static
polymer minimizes static
charge which maximizes
performance with all MDI
formulations
•Clear chamber for easy visu-
alization of proper activation
of the MDI
•One-way valve to hold and
protect the aerosol until
inhalation begins
•Universal MDI adapter allows
use with most MDIs
•F OWSIGnal®whistle alerts
patient to excessive flow
rates (adult versions only)
•ComfortSeal®masks available
in two sizes allow use by
infants and small children
•Fifteen years of clinical
research about AeroChamber
use
•Small size makes it easy to
use or transport
•Clear body for easy reading
of flow rate
•Internal indicator is protected
from accidental mishandling
•Accurate measure of PEFR in
low flows (pediatrics) and
standard flows (adults)
•Simple cleanup with soap
and water
•Color Zone®decals easily
customize the TruZone®for
color-zone management of
asthma—no calculations
required
•Meets the current American
Thoracic Society®waveform
26 standards
