Invacare 9000 series User manual

ThismanualMUSTbegiventotheuseroftheproduct.
BEFOREusingthisproduct,readthismanualandsaveforfuturereference.
Ien I
1General
1.1Anti-tipperKit
DescriptionQuantity
Anti-tipper2
Anti-rattle2
1.2SeverityDefinitionBlock
Signalwordsareusedinthismanualandapplytohazardsorunsafe
practiceswhichcouldresultinpersonalinjuryorpropertydamage.
Seetheinformationbelowfordefinitionsofthesignalwords.
DANGER!
–Dangerindicatesaimminentlyhazardoussituation
which,ifnotavoided,couldresultindeathorserious
injury.
WARNING!
–Warningindicatesapotentiallyhazardoussituation
which,ifnotavoided,couldresultindeathorserious
injury.
CAUTION!
–Cautionindicatesapotentiallyhazardoussituation
which,ifnotavoided,mayresultinpropertydamage
orminorinjuryorboth.
IMPORTANT
–Indicatesahazardoussituationthatcouldresultin
damagetopropertyifitisnotavoided.
Givesusefultips,recommendationsandinformationfor
efficient,trouble-freeuse.
1.3GeneralGuidelines
Thissectioncontainsimportantinformationforthesafeoperation
anduseofthisproduct.
THEINFORMATIONCONTAINEDINTHISDOCUMENT
ISSUBJECTTOCHANGEWITHOUTNOTICE.
Checkallpartsforshippingdamage.Incaseofdamage,DO
NOTuse.ContactCarrier/Invacareforfurtherinstructions.
ToensurethesafeinstallationanduseoftheAnti-tippers,
theseinstructionsmustbefollowed:
DANGER!
RiskofDeath,InjuryorDamage
Improperuseofthisproductmaycauseinjuryordamage
–Ifyouareunabletounderstandthewarnings,cautions
orinstructions,contactahealthcareprofessionalor
dealerbeforeattemptingtousethisequipment.
–DONOTusethisproductoranyavailableoptional
equipmentwithoutfirstcompletelyreadingand
understandingtheseinstructionsandanyadditional
instructionalmaterialsuchasusermanual,service
manualsorinstructionsheetssuppliedwiththis
productoroptionalequipment.
WARNING!
RiskofSeriousInjuryorDamage
Useofnon-Invacareaccessoriesmayresultinserious
injuryordamage.
–Invacareproductsarespecificallydesignedand
manufacturedforuseinconjunctionwithInvacare
accessories.Accessoriesdesignedbyother
manufacturershavenotbeentestedbyInvacareand
arenotrecommendedforusewithInvacareproducts.
–DONOTusenon-Invacareaccessories.
–ToobtainInvacareaccessories,contactInvacareby
phoneoratwww.invacare.com
9000Series,9000P,andJymni
Anti-tipperInstallation
AdjustableAnti-tipperKitNos.1058752,1058836,1064520
and1101960,Non–adjustableAnti-tipperKitNos.1113764,
1113765and1113766
en9000Series,9000PandJymniAnti-tippers
UserManual

9000Series,9000P,andJymniAnti-tipperInstallation
DANGER!
RiskofDeath,SeriousInjury,orDamage
Incorrectrepairand/orservicingofthiswheelchair
performedbyusers/caregiversorunqualifiedtechnicians
canresultindeath,seriousinjury,ordamage.
–Users/Caregivers—DONOTattempttorepair
and/orservicethiswheelchair.
–Repairand/orserviceofthiswheelchairMUSTbe
performedbyaqualifiedtechnician.Contactadealer
orInvacaretechnician.
DANGER!
RiskofDeath,SeriousInjury,orDamage
Useofincorrectorimproperreplacement(service)parts
maycausedeath,seriousinjury,ordamage.
–ReplacementpartsMUSTmatchoriginalInvacareparts.
–ALWAYSprovidethewheelchairserialnumberto
assistinorderingthecorrectreplacementparts.
WARNING!
RiskofSeriousInjuryorDamage
Movingtheseatingsystemfromthefactorysettingmay
reducedrivercontrol,wheelchairstability,tractionand
increasecasterwearresultinginseriousinjuryordamage.
–MovetheseatingsystemONLYwhennecessarytofit
thewheelchairtotheuser.
–Iftheseatingsystemmustbemoved,ALWAYSinspect
thewheelchairtoensurethefrontriggingDOESNOT
interferewiththefrontcasters.
–Iftheseatingsystemmustbemoved,ALWAYS
inspecttoensurethewheelchairDOESNOTeasily
tipforwardorbackward.
WARNING!
RiskofMinortoSeriousInjury
Pinchpointscancauseminortoseriousinjury.
–Bemindfulofpotentialpinchpointsandusecaution
whenusingthisproduct.
WARNING!
RiskofDeath,SeriousInjury,orDamage
Operatingthewheelchairwithoutanti-tipperscould
resultindeath,seriousinjuryordamage.
–DONOToperatethewheelchairwithoutanti-tippers
installed.
WARNING!
RiskofSeriousInjury
Sharpedgescancauseseriousinjury.
–Bemindfulthatsomepartsmayhavesharpedges.Use
cautionwhenencounteringthesesharpedges.
WARNING!
–Anti-tippersarespecifictothedifferentseat-to-floor
anglesand/orseat-to-floorheights.Refertothe
chartinthisinstructionsheetforcorrectusageand
adjustment.IftheserequirementsCANNOTbe
achieved,DONOTusethewheelchair.Contacta
qualifiedtechnician.Ifchangingtheseat-to-floorheight
withorwithoutachangetoseat-to-floorangle,the
correctanti-tippersmustbeusedtomaintaina1–1/2
to2inchgroundclearance.
–9000WHEELCHAIRSWITHASEAT-TO-FLOOR
ANGLEOF6°OR3°ANDJYMNINON-RECLINERS
ONLY—Ifsoequipped,anti-tippersMUSTbe
attachedatalltimes.Inasmuchastheanti-tippersare
anoptionfor0°or3°onthesewheelchairs(Youmany
orderwithorwithoutanti-tippers),Invacarestrongly
recommendsorderingtheanti-tippersasasafeguard
forthewheelchairuser.
WARNING!
–9000WHEELCHAIRSWITHASEAT-TO-FLOOR
ANGLEOF6°ONLY—Ifchangingtheseat-to-floor
angleto6°,anti-tippersMUSTBEORDEREDAND
INSTALLED .
–JYMNIRECLINERSANDJYMNIWHEELCHAIRS
WITH1–INCHFORWARDREARWHEEL
POSITIONERSONLY—Anti-tippersMUSTbe
attachedatalltimes.
–Anti-tippersMUSTbefullyengagedandspringbuttons
fullyprotrudingoutofadjustmentholes,BEFOREusing
thewheelchair.
–Ensurebothanti-tippersareadjustedtothesame
mountinghole.
2InstallationandAdjustment
2.1InstallingAnti-tippers
1.Removeplugbutton(notshown)fromendofrearframetubing
Eandinstallanti-rattlesAifnotalreadyinstalled.
2.PressthereleasebuttonsDINandinserttheanti-tippersB
withtheanti-tipperwheelsCpointingtowardtheground/floor
intotherearframetubinguntilthebottomreleasebuttonlocks
inplace.
3.Measurethedistancebetweenthebottomoftheanti-tipper
wheelsandtheground/floor.
A1–1/2to2inchclearancebetweenthebottomof
theanti-tipperwheelsandtheground/floorMUSTbe
maintainedatalltimes.
4.ADJUSTABLEANTI-TIPPERSONLY—Ifthedistancebetween
thebottomoftheanti-tipperwheelsandtheground/floorisnot
1–1/2to2inches,adjustanti-tippers.RefertoADJUSTINGTHE
ANTI-TIPPERS
2.2AdjustingAnti-tippers
Thisprocedureisforadjustableanti-tippersonly.
21058751-E~01

1.PressthereleasebuttonsAonthewheeledportionofthe
anti-tipperandslideitupordowntoachievethe1–1/2to2inch
clearance.
2.Checktomakesurethatthereleasebuttonsarefullyengagedin
adjustmentholes.
3Anti-tipperMeasurementCharts
3.19000SeriesandP9000Anti-TipperKitCharts
Refertothefollowingcharttoensurethecorrectanti-tipper
isinstalledonthewheelchair.Seat-to-Floorheightsare
approximatedependingonfrontcastersizeandtype.Refer
toServiceManualpartnumber1076155,foranexplanation
offrametypes.Anti-tipperlengthCmeasurementistaken
withtheextensiontubeintheLONGESTpositionavailable.
Theanti-tipperheightAmeasurementMUSTbetakenwith
theanti-tipperonaflatsurfaceB.
9000XTandP9000—SuperLowFrame
CasterSize6inch
Seat-to-FloorHeight13–1/2and14–1/2inch
Anti-tipperLength10–1/2inch
Anti-tipperHeight2inch
OnChair1360SH
OffChairKitNumber1064520
9000XDTandP9000—AdultTallFrame
CasterSize8inch8inch
Seat-to-Floor
Height
17–1/2and19–1/2
inch
21–1/2inch
Anti-tipper
Length
11–5/8inch13–1/2inch
Anti-tipper
Height
2–3/4inch3–1/2inch
OnChair1360A1360
OffChairKit
Number
10587521058836
9000XTandP9000with0°Seat-to-FloorAngle
—Adult/HemiFrame
CasterSize8inch6inch
Seat-to-
FloorHeight
17–1/2and
18–1/2inch
16–1/2inch
and17–1/2
inch
15–1/2inch
Anti-tipper
Length
13–1/2inch13–1/2inch11–5/8inch
9000XTandP9000with0°Seat-to-FloorAngle
—Adult/HemiFrame
Anti-tipper
Height
3–1/2inch3–1/2inch2–3/4inch
OnChairN/AN/AN/A
OffChairKit
Number
105883610588361058752
9000XTandP9000with3°Seat-to-FloorAngle
and9000SL—Adult/HemiFrame
CasterSize8inch6inch
Seat-to-Floor
Height
17–1/2,18–1/2and
19–1/2inch
15–1/2inch,16–1/2
and17–1/2inch
Anti-tipper
Length
13–1/2inch11–5/8inch
Anti-tipper
Height
3–1/2inch2–3/4inch
OnChair13601360A
OffChairKit
Number
10588361058752
9000XTandP9000with6°Seat-to-FloorAngle
—Adult/HemiFrame
CasterSize8inch6inch
Seat-to-
FloorHeight
17–1/2,18–1/2
and19–1/2
inch
16–1/2and
17–1/2inch
15–1/2inch
Anti-tipper
Length
13–1/2inch12–1/2inch9–1/2inch
Anti-tipper
Height
2–7/8inch2–3/4inch2–3/8inch
OnChairN/AN/AN/A
OffChairKit
Number
111376611137651113764
3.2JymniAnti-TipperKitChart
Toensurethecorrectmodelanti-tipperisusedrefertothe
imagebelow.Measurementsforanti-tippersaretakenwith
theextensiontubeintheLONGESTpositionavailable.The
anti-tipperheightAmeasurementMUSTbetakenwiththe
anti-tipperonaflatsurfaceBsothattheanti-tipperlength
Cisfullyextended.
Jymni
WheelchairRear
WheelSize
20inch22inch
Anti-tipper
Length
11–1/16inch11–5/8inch
Anti-tipper
Height
2–1/16inch2–3/4inch
OnChair1360B1360A
OffChairKit
Number
11019601058752
1058751-E~013

9000Series,9000P,andJymniAnti-tipperInstallation
3.3WearandTearInformation
GeneralInformation
Normalwearandtearitemsandcomponentsincludebutarenot
limitedto:allupholsteryitemsincludingseatandbackupholstery,arm
andcalfpads,cushions,wheels,tiresandcasters,alltypesofbatteries,
joystickoverlaysandinductiverubberizedprotectiveboots.
Invacarereservestherighttoaskforanyitembackthathasanalleged
defectinworkmanship.RefertotheWarrantysectionintheuser
manualforspecificwarrantyinformation.
RefertotheInspectionChecklistsintheusermanualshippedwiththe
productforproperpreventativemaintenanceschedule.
Thisisjustageneralguidelineanddoesnotincludeitemsdamaged
duetoabuseandmisuse.
ProductTypeProductWearandTear
WheelchairsWheels,BrakeAssembly,HandGrips
ScootersWheels,BrakingSystem,Armrest,Seat
MobilityHardware
andElectronics
RubberUrethaneTiresandCasters,
Handgrips,JoystickInductiveTops,
JoystickOverlays,Motorsand
Gearboxes(ifexposedtoprolonged
moisture,urine,etc.),StabilityLock
Upholsteryand
Seating
Armpads,SeatCushionFoam,Seat
CushionCovers,BackCushionFoam,
BackCushionCovers,HeadrestFoam,
HeadrestCovers,FootplateCovers,
CalfPad(ifapplicable)FoamandCover
BatteriesLeadacid/Lithium,Coincell(watch
type),Gel(6months)
41058751-E~01
