Invacare MK5 EX Manual

Part No. 1114822 1Tilt/Recline Seating Systems®
DEALER: THIS MANUAL MUST BE GIVEN TO THE USER
OF THE WHEELCHAIR.
USER: BEFORE USING THIS WHEELCHAIR, READ THIS
MANUAL AND SAVE FOR FUTURE REFERENCE.
2nd Generation Tarsys®
Tilt
Recline
Tilt/Recline
on
Storm® TDX
Wheelchairs
Owner's Operator And Maintenance Manual

Tilt/Recline Seating Systems® 2Part No. 1114822
WARNING
WARNING
WARNING BEFORE INITIAL USE
A QUALIFIED TECHNICIAN MUST PERFORM THE INITIAL SET UP
OF THIS WHEELCHAIR. ALSO, QUALIFIED TECHNICIAN MUST
PERFORM ALL PROCEDURES IN THE SERVICE MANUAL.
WHEELCHAIR USERS: DO NOT SERVICE OR OPERATE THIS EQUIP-
MENT WITHOUT FIRST READING AND UNDERSTANDING (1) THE
OWNERS OPERATOR AND MAINTENANCE MANUAL (2) THE
SEATING SYSTEMS MANUAL (IF APPLICA LE). IF YOU ARE UN-
A LE TO UNDERSTAND THE WARNINGS, CAUTIONS AND IN-
STRUCTIONS, CONTACT INVACARE TECHNICAL SUPPORT E-
FORE ATTEMPTING TO SERVICE OR OPERATE THIS EQUIPMENT -
OTHERWISE, INJURY OR DAMAGE MAY RESULT.
DEALERS AND QUALIFIED TECHNICIANS: DO NOT SERVICE OR
OPERATE THIS EQUIPMENT WITHOUT FIRST READING AND UN-
DERSTANDING (1) THE OWNERS OPERATOR AND MAINTENANCE
MANUAL (2) THE SERVICE MANUAL (IF APPLICA LE) AND (3) THE
SEATING SYSTEMS MANUAL (IF APPLICA LE). IF YOU ARE UN-
A LE TO UNDERSTAND THE WARNINGS, CAUTIONS AND IN-
STRUCTIONS, CONTACT INVACARE TECHNICAL SUPPORT E-
FORE ATTEMPTING TO SERVICE OR OPERATE THIS EQUIPMENT -
OTHERWISE, INJURY OR DAMAGE MAY RESULT.
THIS INVACARE SEATING SYSTEM HAS EEN DESIGNED AND
TESTED FOR USE ON A TDX WHEELCHAIR (CWD) ONLY. DO NOT
USE ON OR WITH ANY OTHER CHAIR.

Part No. 1114822 3Tilt/Recline Seating Systems®
CONTENTS
TABLE OF CONTENTS
SPECIAL NOTES................................................................................ 4
SPECIFICATIONS .............................................................................. 5
SECTION 1SECTION 1
SECTION 1SECTION 1
SECTION 1 - GENERAL GUIDELINESGENERAL GUIDELINES
GENERAL GUIDELINESGENERAL GUIDELINES
GENERAL GUIDELINES ....................................................................................................
....................................................................................................
.................................................. 66
66
6
REPAIR OR SERVICE INFORMATION...................................................................................................6
OPERATING INFORMATION ................................................................................................................. 6
SAFETY/HANDLING OF SEATING SYSTEMS/WHEELCHAIRS .................................................. 12
SECTION 2SECTION 2
SECTION 2SECTION 2
SECTION 2 - SAFETY INSPECTION/TROUBLESHOOTINGSAFETY INSPECTION/TROUBLESHOOTING
SAFETY INSPECTION/TROUBLESHOOTINGSAFETY INSPECTION/TROUBLESHOOTING
SAFETY INSPECTION/TROUBLESHOOTING ......................................
......................................
................... 1616
1616
16
SAFETY INSPECTION AND MAINTENANCE CHECKLIST ........................................................ 16
TROUBLESHOOTING ............................................................................................................................. 17
SECTION 3SECTION 3
SECTION 3SECTION 3
SECTION 3 - TILT ONLYTILT ONLY
TILT ONLYTILT ONLY
TILT ONLY ....................................................................................................................................
....................................................................................................................................
.................................................................. 1818
1818
18
OPERATING TILT ONLY SYSTEMS .................................................................................................... 18
SECTION 4SECTION 4
SECTION 4SECTION 4
SECTION 4 - RECLINE ONLYRECLINE ONLY
RECLINE ONLYRECLINE ONLY
RECLINE ONLY ......................................................................................................................
......................................................................................................................
........................................................... 2020
2020
20
OPERATING RECLINE SYSTEMS ONLY............................................................................................ 20
SECTION 5SECTION 5
SECTION 5SECTION 5
SECTION 5 - TILT/RECLINETILT/RECLINE
TILT/RECLINETILT/RECLINE
TILT/RECLINE ..........................................................................................................................
..........................................................................................................................
............................................................. 2222
2222
22
OPERATING TILT/RECLINE SYSTEMS ............................................................................................... 22
SECTION 6SECTION 6
SECTION 6SECTION 6
SECTION 6 - VENTILATOR TRAYVENTILATOR TRAY
VENTILATOR TRAYVENTILATOR TRAY
VENTILATOR TRAY ........................................................................................................
........................................................................................................
.................................................... 2424
2424
24
USING THE OPTIONAL VENTILATOR TRAY ................................................................................ 2
SECTION SECTION
SECTION SECTION
SECTION - SHEAR REDUCTIONSHEAR REDUCTION
SHEAR REDUCTIONSHEAR REDUCTION
SHEAR REDUCTION ........................................................................................................
........................................................................................................
.................................................... 2525
2525
25
OPTIONAL VERNIER SHEAR ................................................................................................................ 25
SECTION 8SECTION 8
SECTION 8SECTION 8
SECTION 8 - RIGGINGSRIGGINGS
RIGGINGSRIGGINGS
RIGGINGS ......................................................................................................................................
......................................................................................................................................
................................................................... 22
22
2
MECHANICAL ELEVATING/GENIUS LEGRESTS ............................................................................ 27
INSTALLING/REMOVING THE POWERED LEGS .......................................................................... 31
ADJUSTING THE POWER LEGRESTS ................................................................................................ 32
SECTION 9SECTION 9
SECTION 9SECTION 9
SECTION 9 - ARMRESTSARMRESTS
ARMRESTSARMRESTS
ARMRESTS ..................................................................................................................................
..................................................................................................................................
................................................................. 3636
3636
36
RECLINING ARMRESTS .......................................................................................................................... 36
SECTION 10SECTION 10
SECTION 10SECTION 10
SECTION 10 - HEADRESTHEADREST
HEADRESTHEADREST
HEADREST ..............................................................................................................................
..............................................................................................................................
............................................................... 3838
3838
38
REMOVING/INSTALLING/ADJUSTING HEADREST...................................................................... 38
REPLACING HEADREST ......................................................................................................................... 39
LIMITED WARRANTYLIMITED WARRANTY
LIMITED WARRANTYLIMITED WARRANTY
LIMITED WARRANTY ..........................................................................................................................................
..........................................................................................................................................
..................................................................... 4040
4040
40
CONTENTS

Tilt/Recline Seating Systems® 4Part No. 1114822
SPECIAL NOTES
WARNING/CAUTION notices as used in this manual apply to hazards
or unsafe practices which could result in personal injury or property
damage.
NOTICE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS
SU JECT TO CHANGE WITHOUT NOTICE.
WHEELCHAIR USER
As a manufacturer of wheelchairs, Invacare endeavors to supply a wide
variety of wheelchairs to meet many needs of the end user. However,
final selection of the type of wheelchair to be used by an individual rests
solely with the user and his/her healthcare professional capable of
making such a selection. Invacare highly recommends working with a
certified rehab technology supplier and/or a member of NRRTS or
RESNA.
RESTRAINTS - SEAT POSITIONING STRAPS
Invacare recommends that wheelchair users NOT be transported in
vehicles of any kind while in wheelchairs. As of this date, the Depart-
ment of Transportation has not approved any tie-down systems for
transportation of a user while in a wheelchair, in a moving vehicle of any
type.
It is Invacares position that users of wheelchairs should be transferred
into appropriate seating in vehicles for transportation and use be made
of the restraints made available by the auto industry. Invacare cannot
and does not recommend any wheelchair transportation systems.
SPECIFICATIONS
NOTE: All specifications apply to Tilt only, Recline only and Tilt/Recline systems except where
specified. All specifications are approximate.
NOTE: Refer to the wheelchair owner's manual for complete specifications on ase and operation.
Seat Width Range: 16 to 22-inches - In 1-inch increments
Seat Depth Range: 16 to 22-inches - In 1-inch increments
ack Height Range:
Tilt and Recline: 20 to 26-inches - In 1-inch increments
Recline Only: 20 to 26-inches - In 1-inch increments
Tilt Only: 20 to 25-inches - In 1-inch increments
ack Angle Range:
Tilt Only Systems: 90o to 115o - in 5o increments
Tilt Range:
Tilt Only Systems and
Tilt/Recline Systems: 0o Seat Angle - 0o to 5o; 5o Seat Angle - 5o to 50o
SPECIAL NOTES/SPECIFICATIONS
SPECIAL NOTES/SPECIFICATIONS

Part No. 1114822 5Tilt/Recline Seating Systems®
SPECIFICATIONS (CONTINUED)
SPECIFICATIONS
Recline Range:
Recline Only 0o Seat Angle - 90o to 175o
5o Seat Angle - 95o to 175o
10o Seat Angle - 100o to 175o
15o Seat Angle - 105o to 175o
Tilt/Recline Systems: 0o Seat Angle - 90o to 175o
5o Seat Angle - 95o to 175o
Seat-to-Floor: 0o Seat Angle - 18-1/2-inches
5o Seat Angle - 20-inches
*Overall Width: 28.9 with -way switch
*Overall Height: 0.9-inches w/o headrest
*Overall Length: 1.5 w/Center Mount Riggings
39.3 w/o front riggings; full lngth arm and MPJ joystick
Weight of Seating System: 105 lbs.
Armrests
Tilt Only: Flip Back, Adjustable Height (9 to 13-inches) -
Desk or Full Length
**Recline Only and Tilt/
Recline Systems: Adjustable Height (11 to 16-inches) - Desk or Full
Legrests: Mechanical Elevating/Genius Legrests
Power Legrests
Headrests: Curved, Contoured, Small or Large
Weight Limitation: Standard Tilt only, Recline only and Tilt/Recline
systems have a weight limitation of 250 lbs. Tilt only,
Recline only and Tilt/Recline systems with the heavy
duty option have a weight limitation of 350 lbs.
If wheelchair is equipped with vent tray then the
weight limitation mentioned above are reduced by
50 lbs. (200 and 300 LBS. respectively).
attery Requirements: See TDX Owners Manual, part number 111 809.
Electronics: MK5 EX or MK5TT-EX with MK5
MPJ or DPJjoystick
SPECIFICATIONS
*NOTE: 18-inch deep X 18-inch wide with 20-inch high ack.

Tilt/Recline Seating Systems® 6Part No. 1114822
GENERAL GUIDELINESSECTION 1
This Section Includes the Following:
Repair or Service Information; Operating Information; Safety/Handling of heelchairs
GENERAL GUIDELINES
REPAIR OR SERVICE INFORMATION
Setup of the Electronic Control Unit is to be performed ONLY by indi-
viduals certified by Invacare. The final tuning adjustments of the control-
ler may affect other activities of the wheelchair. Damage to the equip-
ment could occur under these circumstances. If non-certified individuals
perform any work on these units, the Limited Warranty is void.
OPERATING INFORMATION
GENERAL WARNINGS
Professionals of the healthcare field or other persons should only make
performance adjustments fully conversant with this process and the
wheelchair operators capabilities. Incorrect settings could cause injury to
the driver, bystanders, damage to the chair and to surrounding property.
After the wheelchair has been set up/adjusted, check to make sure that
the wheelchair performs to the specifications entered during the setup
procedure. If the wheelchair does NOT perform to specifications, turn
the wheelchair OFF immediately and re-enter setup specifications. Re-
peat this procedure until the wheelchair performs to specifications.
DO NOT leave the power button ON when entering or exiting your
wheelchair.
DO NOT attempt to drive over curbs or obstacles greater than 3-inches
for TDX 5 and TDX 4 or greater than 2-inches for TDX 3. Doing so may
cause your wheelchair to turn over and cause bodily harm or damage to
the chair. Always stop before climbing an obstacle. Approach slowly until
casters contact the obstacle. Apply power and the action of the Sure-
Stepfeature will lift the casters over the obstacle. Weight is trans-
ferred to the drive wheels providing traction and motor strength to
power the wheelchair over the obstacle.
ELECTRICAL
Grounding Instructions:
DO NOT, under any circumstances, cut or remove the round grounding
prong from any plug used with or for Invacare products. Some devices
are equipped with three-prong (grounding) plugs for protection against
possible shock hazards. Where a two-prong wall receptacle is encoun-
tered, it is the personal responsibility and obligation of the customer to
contact a qualified electrician and have the two-prong receptacle re-
placed with a properly grounded three-prong wall receptacle in accor-
dance with the National Electrical Code. If you must use an extension
cord, use ONLY a three-wire extension cord having the same or higher
electrical rating as the device being connected. In addition, Invacare has
placed RED/ORANGE WARNING TAGS on some equipment. DO NOT
remove these tags.

Part No. 1114822 7Tilt/Recline Seating Systems®
GENERAL GUIDELINES SECTION 1
GENERAL GUIDELINES
ATTERIES
The warranty and performance specifications contained in this manual
are based on the use of deep cycle gel cell or sealed lead acid batteries.
Invacare strongly recommends their use as the power source for this unit.
Carefully read battery/battery charger information prior to installing,
servicing or operating your wheelchair.
RAIN TEST
INVACARE has tested its power wheelchairs in accordance with ISO
7176 Rain Test. This provides the end user or his/her attendant suffi-
cient time to remove his/her power wheelchair from a rain storm and
retain wheelchair operation.
CAUTION
Failure to follow these instructions will void your limited warranty.
Do determine and establish your particular safety limits by practicing
bending, reaching and transferring activities in the presence of a qualified
healthcare professional EFORE attempt active use of the wheelchair.
DO NOT attempt to reach objects if you have to move forward in your
seat.
DO NOT attempt to reach objects if you have pick them up from the
floor by reaching between your knees.
DO NOT lean over the top of the back upholstery to reach objects from
behind, as this may cause the wheelchair and/or seating system (if any) to
tip over.
DO NOT shift your weight or sitting position toward the direction you
are reaching as the wheelchair and/or seating system (if any) may tip
over.
DO NOT use an escalator to move a wheelchair between floors. Serious
bodily injury may occur.
CAUTION
Wheel Locks are NOT brakes. DO NOT attempt to stop a moving
wheelchair with the wheel locks.
DO NOT service or adjust your wheelchair while occupied, unless other-
wise noted.
DO NOT operate on roads, streets or highways.
DO NOT climb, go up or down ramps or traverse slopes greater than 9o.
DO NOT attempt to move up or down an incline that has a water, ice or
oil film.

Tilt/Recline Seating Systems® 8Part No. 1114822
CAUTION
For safe product function, material compatibility, proper installation,
operation and maintenance, you must only use parts, accessories and
adapters manufactured or supplied by Invacare. DO NOT use any other
parts, accessories, or adapters - otherwise the warranty is void.
DO NOT stand on the frame of the wheelchair.
DO NOT use the footplates as a platform. When getting in or out of the
wheelchair, make sure that the footplates are in the upward position or
swing footplates toward the outside of the wheelchair.
DO NOT attempt to drive over curbs or obstacles, unless your wheel-
chair has a climbing feature. Doing so may cause your wheelchair to turn
over and cause bodily harm or damage to the chair.
WARNING
Never leave an unoccupied wheelchair unattended at any time, especially
on an incline.
DO NOT attempt to lift the wheelchair by any removable (detachable)
parts. Lifting by means of any removable (detachable) parts of a wheel-
chair may result in injury to the user or damage to the wheelchair.
DO NOT overtighten hardware attaching to the frame. This could cause
damage to the frame tubing.
ALWAYS DO keep hands and fingers clear of moving parts to avoid
injury.
ALWAYS DO wear your seat positioning strap. If the seat positioning
strap is an option for the wheelchair, Invacare strongly recommends
ordering such a strap as an additional safeguard for the user.
ALWAYS DO check foam grips for looseness before using the wheel-
chair. If loose, contact a qualified technician for instructions.
ALWAYS DO engage both wheel locks AND reduce the gap distance
EFORE transferring to and from the wheelchair. Turn both casters
toward the object you are transferring onto.
WEIGHT TRAINING WARNING
Invacare DOES NOT recommend the use of its wheelchairs and seating
systems as a apparatus for weight training. Invacare wheelchairs and
seating systems have NOT been designed or tested as a seat for any kind
of weight training. If you use the wheelchair or seating system for weight
training, INVACARE SHALL NOT E LIA LE FOR ODILY INJURY
AND THE LIMITED WARRANTY IS VOID.
GENERAL GUIDELINESSECTION 1
GENERAL GUIDELINES

Part No. 1114822 9Tilt/Recline Seating Systems®
TIRE PRESSURE WARNING
The recommended tire pressure is listed on the side wall of each tire.
DO NOT use your wheelchair unless it has the proper tire pressure.
(P.S.I.). DO NOT overinflate the tires. A qualified technician MUST
perform replacement of a pneumatic tire or tube. Failure to follow these
warnings may cause the tire to explode and cause bodily harm.
CAUTION: WEIGHT LIMITATION
Please refer to SPECIFICATIONS to determine the weight limit (total
combined weight of user and any attachments) of your wheelchair model.
Do not exceed the limit - otherwise, injury or damage may result.
WARNING
DO NOT operate the seating system while on an incline.
DO NOT operate the seating system while the wheelchair is moving.
TILT ONLY SYSTEMS - NEVER operate the wheelchair while in any
recline/back angle combination over 20o relative to the VERTICAL POSI-
TION. If the drive lock-out does not stop the wheelchair from operating
in a tilt position 20o relative to the VERTICAL position, DO NOT operate
the wheelchair. Have the wheelchair serviced by a dealer or qualified
technician.
RECLINE ONLY SYSTEMS - NEVER operate the wheelchair while in any
recline/back angle combination over 20o relative to the VERTICAL posi-
tion. If the drive lock-out does not stop the wheelchair from operating in
a tilt/recline/back angle combination 20o relative to the VERTICAL posi-
tion, DO NOT operate the wheelchair. Have the wheelchair serviced by a
dealer or qualified technician.
TILT/RECLINE ONLY SYSTEMS - NEVER operate the wheelchair while
in any tilt/recline/back angle combination over 20° relative to the VERTI-
CAL position. If the drive lock-out does not stop the wheelchair from
operating in a recline/back angle combination 20° relative to the VERTI-
CAL position, DO NOT operate the wheelchair. Have the wheelchair
serviced by a dealer or qualified technician.
Use only TAC, SAC, TRSS and TRCM actuator controls to activate the
tilt/recline functions. DO NOT USE any other actuator controls. Such
devices may result in excess heating and cause damage to the actuator
and associated wiring and could cause a fire, death, physical injury or
property damage. If such devices are used, Invacare shall not be liable and
the limited warranty is void.
CAUTION: CHAIRS EQUIPPED WITH VENT TRAY
Reduced tilt/recline limits apply. See MK5 EX and MK5 TT-EX
ELECTRONICS OWNERS/SERVICE MANUAL, part number 1114808.
GENERAL GUIDELINES SECTION 1
GENERAL GUIDELINES

Tilt/Recline Seating Systems® 10 Part No. 1114822
GENERAL GUIDELINESSECTION 1
WARNING
CAUTION: IT IS VERY IMPORTANT THAT YOU READ THIS INFOR-
MATION REGARDING THE POSSI LE EFFECTS OF ELECTRO-
MAGNETIC INTERFERENCE ON YOUR POWERED WHEELCHAIR.
Electromagnetic Interference (EMI) From Radio Wave Sources
Powered wheelchairs and motorized scooters (in this text, both will be
referred to as powered wheelchairs) may be susceptible to electro-
magnetic interference (EMI), which is interfering electromagnetic energy
(EM) emitted from sources such as radio stations, TV stations, amateur
radio (HAM) transmitters, two way radios and cellular phones. The inter-
ference (from radio wave sources) can cause the powered wheelchair to
release its brakes, move by itself or move in unintended directions.
It can also permanently damage the powered wheelchair's control sys-
tem. The intensity of the interfering EM energy can be measured in volts
per meter (V/m). Each powered wheelchair can resist EMI up to a certain
intensity. This is called its "immunity level." The higher the immunity
level, the greater the protection. At this time, current technology is
capable of achieving at least a 20 V/m immunity level, which would pro-
vide useful protection from the more common sources of radiated EMI.
There are a number of sources of relatively intense electromagnetic fields
in the everyday environment. Some of these sources are obvious and easy
to avoid. Others are not apparent and exposure is unavoidable. However,
we believe that by following the warnings listed, your risk to EMI will be
minimized.
The sources of radiated EMI can be broadly classified into three types:
1) Hand-held Portable transceivers (transmitters-receivers with the
antenna mounted directly on the transmitting unit. Examples include:
citizens band (C ) radios, "walkie talkie," security, fire, and police
transceivers, cellular telephones and other personal communication
devices.
NOTE: Some cellular telephones and similar devices transmit signals while they are ON, even
when not eing used.
2) Medium-range mobile transceivers, such as those used in police cars,
fire trucks, ambulances and taxis. These usually have the antennas
mounted on the outside of the vehicle.
3) Long-range transmitters and transceivers, such as commercial
broadcast transmitters (radio and TV broadcast antenna towers) and
amateur (HAM) radios.
NOTE: Other types of hand-held devices, such as cordless phones, laptop computers, AM-FM
radios, TV sets, CD players, cassette players and small appliances, such as electric shavers and
hair dryers, so far as we know, are not likely to cause EMI pro lems to your powered wheelchair.
GENERAL GUIDELINES

Part No. 1114822 11 Tilt/Recline Seating Systems®
GENERAL GUIDELINES SECTION 1
WARNING (CONTINUED)
Powered Wheelchair Electromagnetic Interference (EMI):
ecause EM energy rapidly becomes more intense as one moves closer to
the transmitting antenna (source), the EM fields from hand-held radio
wave sources (transceivers) are of special concern. It is possible to unin-
tentionally bring high levels of EM energy very close to the powered
wheelchair's control system while using these devices. This can affect
powered wheelchair movement and braking. Therefore, the warnings
listed are recommended to prevent possible interference with the control
system of the powered wheelchair.
Electromagnetic interference (EMI) from sources such as radio and TV
stations, amateur radio (HAM) transmitters, two-way radios, and cellular
phones can affect powered wheelchairs and motorized scooters.
WARNING (CONTINUED)
The warnings listed below should reduce the chance of unintended brake
release or powered wheelchair movement which could result in serious
injury.
1) Do not operate hand-held transceivers (transmitters receivers), such
as citizens band (C ) radios or turn ON personal communication
devices, such as cellular phones, while the powered wheelchair is
turned ON
2) e aware of nearby transmitters, such as radio or TV stations, and try
to avoid coming close to them.
3) If unintended movement or brake release occurs, turn the powered
wheelchair OFF as soon as it is safe.
4) e aware that adding accessories or components, or modifying the
powered wheelchair, may make it more susceptible to EMI (Note:
There is no easy way to evaluate their effect on the overall immunity
of the powered wheelchair); and
5) Report all incidents of unintended movement or brake release to the
powered wheelchair manufacturer and note whether there is a source
of EMI nearby.
IMPORTANT INFORMATION
1) 20 volts per meter (V/m) is a generally achievable and useful immunity
level against EMI (as of May 1994) (the higher the level, the greater
the protection);
2) The immunity level of this product is not known.
Modification of any kind to the electronics of this wheelchair as manufa-
tured by Invacare may adversely affect the RFI immunity levels.
GENERAL GUIDELINES

Tilt/Recline Seating Systems® 12 Part No. 1114822
SAFETY/HANDLING OF SEATING SYSTEMS/
WHEELCHAIRS
Safety and Handling of the wheelchair requires the close attention of the seating
system/wheelchair user as well as the assistant. This manual, as well as the owners
manual provided with the wheelchair, points out the most common procedures and
techniques involved in the safe operation and maintenance of the seating system/wheel-
chair. It is important to practice and master these safe techniques until you are comfort-
able in maneuvering around the frequently encountered architectural barriers.
Use this information only as a basic guide. The techniques that are discussed on the
following pages have been used successfully by many.
Individual seating system/wheelchair users often develop skills to deal with daily living
activities that may differ from those described in this manual. Invacare recognizes and
encourages each individual to try what works best for him/her in overcoming architec-
tural obstacles that they may encounter. However, ALL WARNINGS and CAUTIONS
given in this manual MUST be followed. Techniques in this manual are a starting point
for new seating system/wheelchair users and assistants with safety as the most impor-
tant consideration for all.
STABILITY AND BALANCE
WARNING
Always wear your seat positioning strap.
To assure stability and proper operation of your seating system/wheelchair, you must at
all times maintain proper balance. Your seating system/wheelchair has been designed to
remain upright and stable during normal daily activities as long as you do not move
beyond the center of gravity.
DO NOT lean forward out of the seating system/wheelchair any further than the length
of the armrests. Make sure the casters are pointing in the forward position whenever
you lean forward. This can be achieved by advancing the wheelchair and then reversing
it in a straight line.
COPING WITH EVERYDAY OBSTACLES
Coping with the irritation of everyday obstacles can be alleviated somewhat by learning
how to manage your wheelchair. Keep in mind your center of gravity to maintain stabil-
ity and balance.
A NOTE TO WHEELCHAIR ASSISTANTS
When assistance to the seating system/wheelchair user is required, remember to use
good body mechanics. Keep your back straight and bend your knees.
Also, be aware of any detachable parts. These must NEVER be used to move the wheel-
chair or lifting supports, as they may be inadvertently released, resulting in possible
injury to the user and/or assistant(s).
When learning a new assistance technique, have an experienced assistant help you
before attempting it alone.
GENERAL GUIDELINESSECTION 1
SAFETY AND HANDLING

Part No. 1114822 13 Tilt/Recline Seating Systems®
PERCENTAGE OF WEIGHT DISTRIBUTION
WARNING
DO NOT attempt to reach objects if you have to move forward in the seat
or pick them up from the floor by reaching down between your knees.
Many activities require the wheelchair owner to reach, bend and transfer in and out of
the wheelchair. These movements will cause a change to normal balance, center of
gravity and weight distribution of the wheelchair. To determine and establish your
particular safety limits, practice bending, reaching and transferring activities in several
combinations in the presence of a qualified health professional BEFORE attempting
active use of the wheelchair.
Proper positioning is essential for your safety. When reaching, leaning, bending or
bending forward, it is important to use the front casters as a tool to maintain stability
and balance.
GENERAL GUIDELINES SECTION 1
SAFETY AND HANDLING
REACHING, BENDING -BACKWARDS
WARNING
DO NOT lean over the top of the
back upholstery. This will change
your center of gravity and may
cause you to tip over.
Position wheelchair as close as possible to
the desired object. Point front casters
forward to create the longest possible
wheelbase. Reach back only as far as your
arm will extend without changing your
sitting position.
REACHING, LEANING, BENDING AND BENDING -
FORWARD
WARNING
DO NOT attempt to reach objects if
you have to pick them up from the
floor by reaching down between your
knees.
Position the front casters so that they are
extended as far forward as possible and
engage wheel locks.

Tilt/Recline Seating Systems® 14 Part No. 1114822
GENERAL GUIDELINESSECTION 1
SAFETY AND HANDLING
WARNING
The weight of the wheelchair without the user and without batteries is
between 255 and 316 lbs. Use proper lifting techniques (lift with your
legs) to avoid injury.
1. Remove the occupant from the wheelchair.
2. Remove battery/batteries from wheelchair. Refer to the TDX
Owners Manual, part number 111 809.
3. Bend your knees and keep your back straight.
. Using non-removable (non-detachable) parts of the wheelchair,
lift the wheelchair off of the ground and transfer the wheelchair
up or down the stairs.
5. The wheelchair should not be lowered until the last stair has
been negotiated and the wheelchair has been carried away from the stairway.
ESCALATORS? SORRY!
DO NOT use an escalator to move a wheelchair between floors. Serious
bodily injury may occur.
STAIRWAYS - POWER CHAIRS
WARNING
DO NOT attempt to move an occupied power wheelchair between floors
using a stairway. Use an elevator to move an occupied power wheelchair
between floors. If moving a power wheelchair between floors by means of
a stairway, the occupant MUST be removed and transported indepen-
dently of the power wheelchair.
Extreme caution is advised when it is necessary to move an UNOCCU-
PIED power wheelchair up or down the stairs. Invacare recommends
using two (2) assistants and making thorough preparations. Make sure to
use ONLY secure, non-detachable parts for hand-hold supports.
DO NOT attempt to lift the wheelchair by any removable (detachable)
parts. Lifting by means of any removable (detachable) parts of a wheel-
chair may result in injury to the user or damage to the wheelchair.
Follow this procedure for moving the wheelchair between floors when an
elevator is NOT available:

Part No. 1114822 15 Tilt/Recline Seating Systems®
MINIMIZE
GAP
DISTANCE
TRANSFERRING TO AND FROM OTHER SEATS
WARNING
ALWAYS turn the wheelchair power OFF and engage the motor locks/
clutches to prevent the wheels from moving EFORE attempting to transfer
in or out of the wheelchair. Also make sure every precaution is taken to
reduce the gap distance. Align both casters parallel with the object you are
transferring onto.
CAUTION
When transferring, position yourself as far back as possible in the seat. This
will prevent broken screws, damaged upholstery and the possibility of the
wheelchair tipping forward.
NOTE: Adequate mo ility and upper ody
strength is required to perform this activity
independently. Use of an assistant is strongly
recommended.
1. Position the wheelchair as close as
possible along side the seat to which
you are transferring, with the cast-
ers aligned parallel with the object.
2. Engage motor locks. Refer to the
TDX Owners Manual, part number
111 809. Shift body weight into seat
with transfer.
3. During independent transfer, little or no seat platform will be beneath you. Use a
transfer board if at all possible.
GENERAL GUIDELINES SECTION 1
SAFETY AND HANDLING
PINCH POINTS
WARNING
Pinch point exists between head tube cap and walking beam.
Headtube
Cap
Walking
Beam
Front
Caster

Tilt/Recline Seating Systems® 16 Part No. 1114822
SAFETY INSPECTION
This Section Includes the Following:
Safety Inspection checklist Troubleshooting
SECTION 2
SAFETY INSPECTION
SAFETY INSPECTION CHECKLIST
Initial adjustments should be made to suit personal body structure/user capability and
preference. Thereafter follow these maintenance procedures.
NOTE: Refer to the wheelchair owners manual for a complete safety inspection checklist on the
ase.
Item Initially Ins ect Ins ect Ins ect
Adjust Adjust Adjust
Weekly Monthly Periodically
✓✓
✓✓
ARMS
lSecure but easy to release;
adjustment levers engage properly. oo o o
lAdjustable height arms operate
and lock securely. oo o o
✓✓
CLOTHING GUARDS
lEnsure all fasteners are secure. oo o o
✓✓
✓
ELECTRICAL CONNECTIONS
lMake sure all electrical connections
are secure. oo o o
lCheck Limit Switch Position oo o o
NOTE: Every six (6) months, or as necessary, take your wheelchair to a qualified dealer for a thorough
inspection and servicing. Regular cleaning will reveal loose or worn parts and enhance the smooth
operation of your wheelchair. To operate properly and safely, your wheelchair must e cared for just like
any other vehicle. Routine maintenance will extend the life and efficiency of your wheelchair.
✓
TILT MECHANISM
lMake sure tilt operates smoothly
and properly. oo o o
✓✓
RECLINE MECHANISM
lMake sure recline operates smoothly
and properly. oo o o
✓✓
✓✓
DRIVE LOCK-OUT
lMake sure Drive Lock-Out
works properly oo o o

Part No. 1114822 17 Tilt/Recline Seating Systems®
TROUBLESHOOTING
NOTE: Refer to wheelchair owner's manual for complete mechanical and electrical
trou leshooting guides on ase.
NOTE: Refer to the individual CONTROLLER MANUAL supplied with each wheelchair for addi-
tional trou leshooting information and explanation of error codes.
SYMPTOM PROBABLE SOLUTIONS
CAUSE
Wheelchair Power ON System tilted beyond Tilt to neutral
but does not drive. drive lock-out angle. (u right) osition.
Contact Dealer/Invacare for
service.
Seating system Low batteries. Charge batteries.
not functioning.
Faulty electrical Check all connections.
connection. Contact Dealer/Invacare for
service.
Blown fuse. Re lace fuse. Contact
Dealer/Invacare for service.
SAFETY INSPECTIONSECTION 2
SAFETY INSPECTION
✓✓
✓✓
ARMRESTS
lInspect for rips in upholstery. oo o o
lArmrest pad sits flush against arm tube. oo o o
✓✓
SEAT AND BACK CUSHIONS
lInspect for rips or sagging. oo o o
Item Initially Ins ect Ins ect Ins ect
Adjust Adjust Adjust
Weekly Monthly Periodically

Tilt/Recline Seating Systems® 18 Part No. 1114822
This Section Includes the Following:
Operating Tilt Only Systems
OPERATING TILT ONLY SYSTEMS (FIGURE 1)
WARNING
NEVER operate the wheelchair while in any tilt/back angle combination
over 20o RELATIVE TO THE VERTICAL POSITION. If the drive lock-out
does not stop the wheelchair from operating in a tilt/back angle combina-
tion 20o RELATIVE TO THE VERTICAL POSITION, DO NOT operate
the wheelchair. Have the wheelchair serviced by a dealer or qualified
technician.
Use only TAC, SAC, TRSS and TRCM actuator controls to activate the
tilt/recline functions. DO NOT USE any other actuator controls. Such
devices may result in excess heating and cause damage to the actuator
and associated wiring and could cause a fire, death, physical injury or
property damage. If such devices are used, Invacare shall not be liable and
the limited warranty is void.
A NOTE ABOUT DRIVE LOCK-OUT
Drive lock-out is a safety feature designed to prevent the wheelchair from being driven
while in any recline/back angle combination over 20o RELATIVE TO THE VERTICAL
POSITION. When the drive lock-out feature has been activated, the LED on the single
function toggle switch will light.
NOTE: The tilt angle range is from 0o to 45o with a 0o seat-to-floor angle and 5o to 50o with a 5o
seat-to-floor angle.
SINGLE FUNCTION TOGGLE SWITCH
Incr asing Tilt Angl .
1. Make sure the wheelchair is on a level surface.
2. Pull single function toggle switch back towards rear of the wheelchair until the
desired angle is achieved.
D cr asing Tilt Angl .
1. Push the single function toggle switch forward toward the front of the wheelchair
until the desired angle is achieved.
OPTIONAL FOUR-WAY TOGGLE SWITCH
Incr asing/D cr asing Tilt Angl .
1. Make sure the wheelchair is on a level surface.
2. Push four-way toggle switch forward toward the front of the wheelchair until the
desired tilt angle is achieved.
TILT ONLYSECTION 3
TILT ONLY

Part No. 1114822 19 Tilt/Recline Seating Systems®
TILT ONLY SECTION 3
FIGURE 1 - OPERATING TILT ONLY SYSTEMS
NOTE: If the wheelchair is equipped with switch options, scan to the correct ECU or Auxiliary
Mode and activate the control device in the corresponding forward direction to operate the tilt
function. Refer to MK5 EX and MK5 TT-EX ELECTRONICS OWNERS/SERVICE MANUAL, part
num er 1114808, for complete switch option operating instructions.
3. Release four-way toggle switch to neutral position.
NOTE: The four-way toggle switch will alternate functions (increase tilt angle, decrease tilt
angle) after it has een released to the neutral position for a minimum of one (1) second.
NOTE: Refer to MK5 EX and MK5 TT-EX ELECTRONICS OWNERS/SERVICE MANUAL, part
num er 1114808 for complete four-way toggle switch operating instructions.
LED
Single Function
Toggle Switch
FULL UPRIGHT POSITION FULL TILT POSITION
LED
Optional Four Way
Toggle Switch (Shown
in Neutral Position)
TILT ONLY

Tilt/Recline Seating Systems® 20 Part No. 1114822
This Section Includes the Following:
Operating Recline Only Systems
OPERATING RECLINE ONLY SYSTEMS (FIGURE 1)
WARNING
NEVER operate the wheelchair while in any recline/back angle combination
over 20o RELATIVE TO THE VERTICAL POSITION. If the drive lock-out
does not stop the wheelchair from operating in a recline/back angle combi-
nation 20o RELATIVE TO THE VERTICAL POSITION, DO NOT operate
the wheelchair. Have the wheelchair serviced by a dealer or qualified tech-
nician.
Reduced recline limits apply with optional vent tray. Refer to MK5 EX and
MK5 TT-EX ELECTRONICS OWNERS/SERVICE MANUAL, part num-
ber 1114808.
Use only TAC, SAC, TRSS and TRCM actuator controls to activate the tilt/
recline functions. DO NOT USE any other actuator controls. Such devices
may result in excess heating and cause damage to the actuator and associated
wiring and could cause a fire, death, physical injury or property damage. If such
devices are used, Invacare shall not be liable and the limited warranty is void.
A NOTE ABOUT DRIVE LOCK-OUT
Drive lock-out is a safety feature designed to prevent the wheelchair from being driven
while in any recline/back angle combination over 20o RELATIVE TO THE VERTICAL
POSITION. When the drive lock-out feature has been activated, the LED on the four-
way toggle switch will light.
INCREASING/DECREASING RECLINE ANGLE
NOTE: The recline angle range is from 95o to 175o with a 5o seat-to-floor angle. The recline angle
range is from 90o to 175o with a 0o seat-to-floor angle.
1. Make sure the wheelchair is on a level surface.
2. Pull the four-way toggle switch back towards the rear of the wheelchair until the
desired recline angle is achieved.
NOTE: If the wheelchair is equipped with switch options, scan to the correct ECU or Auxiliary
Mode, then activate the control device in the corresponding reverse direction to operate the
recline function. Refer to MK5 EX and MK5 TT-EX ELECTRONICS OWNERS/SERVICE MANUAL,
part num er 1114808, for complete switch option operating instructions.
3. Release the four-way toggle switch to the neutral position.
NOTE: The four-way toggle switch will alternate functions (increase recline angle, decrease
recline angle) after it has een released to the neutral position for a minimum of one (1) second.
NOTE: Refer to MK5 EX and MK5 TT-EX ELECTRONICS OWNERS/SERVICE MANUAL, part
num er 1114808 for complete four-way toggle switch operating instructions.
RECLINE ONLYSECTION 4
RECLINE ONLY
