Invacare Pronto M50TM Instruction Manual

Yes, you can. ™
Pronto® M50™/ M51™
with SureStep®
(After 1/19/05)
Pronto® M61™
with SureStep®
MWD
Power Wheelchair
Parts Catalog Issued: Apr 23, 2012

The information contained in this document is subject to change without notice. This catalog contains
service parts for Form No. 04-050. If you have any questions regarding this catalog, please contact one
of our Customer Service Representatives.
For Customer Service Support Call:
1-800-333-6900
For Faxed In Orders Call:
1-800-678-4682 or
1-440-366-0709
For Technical Service Call:
1-800-832-4707
Literature Can Be Found at:
www.invacare.com or
1-800-828-6272
SYMBOL DEFINITION
Throughout this catalog you will notice letters to draw your attention to specific footnotes which are located at the
bottom of the page or below specified charts.
HARDWARE MEASUREMENTS
Examples: = Special Comments
= General information pertaining to that specific page
= No Longer Available
NOTE:
NLA
The measurements for the hardware will be listed as follows:
Screws, Bolts
Washers
Spacers
For your convenience, we have supplied an area for you to list your Invacare Representatives.
A,B,C etc.
Diameter X Thread Count/Pitch X Length
Inside Diameter X Outside Diameter X Thickness
Inside Diameter X Outside Diameter X Length
Name Phone Numbers
©2012 Invacare Corporation. Elyria, Ohio. Invacare, Yes, you can., the Medallion Design, Pronto, and SureStep are registered trademarks and Formula,
MKIV, MK5, NX, SPJ, M50, M51, and M61 are trademarks of Invacare Corporation.
Parts Catalog Usage Guide
1
Form No. 04-050
To order call toll free 1-800-333-6900, or www.invacare.com

A: READ THIS FIRST (THIS CATALOG IS DIFFERENT!) ...................................................... 5
Accessories - Miscellaneous .................................................................................................... 124
Accessories - Power Wheelchair Tool Kit ................................................................................ 122
Accessories - Walker Holder .................................................................................................... 121
Adapter - Seat ADJASBA and Mounting Hardware (After 4/29/08) ......................................... 33
Adapter - Seat ADJASBA and Mounting Hardware with TRRO/TRBKTS ................................ 35
Arms - ASBA & AdjASBA Seat (Adjustable Height) ................................................................. 60
Arms - ASBA & AdjASBA Seat (Fixed Height) ......................................................................... 57
Arms - Front/Rear Arm Socket Asbly. & Hdwr. - ADJASBA M51 After 04/29/08 .................... 62
Arms - Mtg. Front/Rear Arm Socket Asbly. & Hdwr. For M51 ADJASBA Seats with TRRO After
4/29/08
63
Arms - Van Seat ....................................................................................................................... 54
Back Cane Attaching Hardware - M51 ADJASBA (After 04/29/08) .......................................... 39
Back Canes and Spreader Bar - M51 ADJASBA (After 4/29/08) ............................................. 41
Back Canes, Spreader Bars and Attaching Hardware ............................................................. 37
Battery Harnesses .................................................................................................................... 75
Casters and Forks .................................................................................................................... 69
Electronics - MK5 NX Controllers and Battery Chargers .......................................................... 107
Electronics - MK5 SPJ/SPJ+ and MK6i SPJ+ ACC Joysticks and Mounting Hardware .......... 104
Electronics - Quad Link Assembly (Before 4/07/06) ................................................................. 109
Electronics - Quad Link Assembly (QL) (After 4/06/06) ........................................................... 112
Elevating Seat Actuator, Proximity Sensor, and Hardware ...................................................... 52
TABLE of CONTENTS
Description
Page
Number
2
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 04-050

Frame - ASBA Seat and Mounting Hardware - M50/M51 ........................................................ 27
Frame - ASBA Seat and Mounting Hardware - M50/M51 Center Post Attachment ................. 18
Frame - ASBA Seat and Mounting Hardware - M61 ................................................................ 29
Frame - Base, Bearings, Hdwr. and Van Seat Post Assembly ................................................ 14
Frame - Seat ADJASBA, Seat Pan & Hdwr. (16"-20" W x 16"-22" D) (After 4/29/08) .............. 50
Frame - Van Seat and Mounting Hardware - Center Post Attachment .................................... 16
Frame - Van Seat and Mounting Hardware - M50/M51 ........................................................... 22
Frame - Van Seat, Mounting Hardware, and Seat Spacer Retro-fit Kit - M61 .......................... 24
Frame Finish, Touch Up Paint and Shroud Colors ................................................................... 6
Frame, Base, Bearings, & Hdwr. - M51 w/ Formula CG Tilt (CGT) & M51PR After 4/29/08 .... 10
Front Rigging - Adjustable Angle Footplate Assemblies - AT5543 .......................................... 98
Front Rigging - Footboard Assembly - 90FB ............................................................................ 77
Front Rigging - Footrest and Legrest Accessories ................................................................... 101
Front Rigging - Footrest Supports, (Hemi) - PHW93 ................................................................ 86
Front Rigging - Front Rigging Hangers (Hemi) ......................................................................... 79
Front Rigging - Hanger Assembly - ADJASBA After 4/29/08 ................................................... 81
Front Rigging - Legrest Supports, (Hemi) - PH904A ................................................................ 88
Front Rigging - Legrest Supports, Articulating (Hemi) - PHAL4A ............................................. 91
Front Rigging - Pivot/Slide Tube and Composite Footplate - PHW93 ...................................... 100
Front Rigging - Pivot/Slide Tube and Footplates - PH904A and PHAL4A ............................... 96
Front Rigging - Pivot/Slide Tube and Footplates - PHW93 ...................................................... 94
TABLE of CONTENTS
Description
Page
Number
3
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 04-050

Front Rigging - Reference Chart .............................................................................................. 83
Motor, Gearbox, and Drive Wheel ............................................................................................ 72
Oxygen Holder Assembly - ADJASBA Seats After 4/29/08 ..................................................... 116
Oxygen Holder Assembly - ASBA Seat Before 4/28/08 ........................................................... 114
Oxygen Holder Assembly - Fold Down Medium Back Van Seat .............................................. 118
Oxygen Holder Assembly - Semi-Recline Van Seat & Office Style Van Seat .......................... 119
Packaging, Literature and Decals ............................................................................................ 7
Seat Height Adjustment Slide Tubes - M51 PR After 4/29/08 .................................................. 12
Seat Pan and Hardware - ASBA Center Post Mounted ........................................................... 45
Seat Release Hardware ........................................................................................................... 34
Shrouds - Top Assembly - M51 with Formula CG Tilt (CGT) & M51 Rehab After 4/29/08 ...... 67
Shrouds and Attaching Hardware ............................................................................................ 65
TRRO and TRBKTS Option Clarification Reference ................................................................ 9
Upholstery - Back - ASBA and ADJASBA ................................................................................ 43
Van Seat Assembly .................................................................................................................. 47
Van Seat Frame and Actuator Hardware - 4 Post attachment ................................................. 31
Walking Beams and Hardware - SureStep ............................................................................... 20
Warranty Replacement Chart ................................................................................................... 125
TABLE of CONTENTS
Description
Page
Number
4
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 04-050

A: READ THIS FIRST (THIS CATALOG IS DIFFERENT!)
5
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 04-050

Frame Finish
Color Number Part Number Bottle Size Color
Flat Black.6 oz104632734P
Shroud Colors
Color Number Color
Deep BlueBL (DBLM) Candy RedRD (CRDM)
Frame Finish, Touch Up Paint and Shroud Colors
6
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 04-050

Packaging, Literature and Decals
7
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 04-050

Packaging, Literature and Decals
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1127752 Carton, Tray Top 1 11 1115174 Carton, Corner Reinforcement 1 42 1127753 Carton, Cover 1 13 1015592 Bag, Poly (72" L x 35" W x 19" D) 1 14 40131X161 Insert, Plain Pad 1 15 1127755 Carton, Pad 1 16 1127756-NLA NLA - Carton, Tray 1 17 B 1127754 Carton, Insert 1 28 1127296 Carton, Cover Base 1 19 1043198-NLA NLA - Tube, Paper 1 110 1127294 Insert, Carton 1 111 1127295 Tray, Carton 1 112 1125085 Owner's Manual, Pronto M50/M51/M61 1 1A 1110532 Instruction Manual, MK5 NX/NX-LP 1 1A 1125093 Instruction Sheet, Battery Installation 1 1A 1110604-NLA NLA - Decal, Shroud - M50 1 2A 1110605 Decal, Shroud - M51 1 2A 1127292 Decal, Shroud - M61 1 2A 1104797 Decal, Drive/Push 1 2A 1035900 Decal, Transportation 1 1A 1119281 Plate, Name, Patent Numbers 1 1A 1107651 Decal, Front Battery Cover 1 1A 1107652 Decal, Rear Battery Cover 1 1A 1148076 Owner's Manual, Pronto M51 Formula CG Tilt
(CGT) Base 1 1A
A - Not Shown
B - No longer available, use 1127752 as its replacement.
NOTE
: When adjusting or replacing parts, please refer to your owner's manual for assistance.
NOTE:
8
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 04-050

TRRO and TRBKTS Option Clarification Reference
9
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 04-050

Base Frame, Bearings, & Hardware
M51 w/ Formula CG Tilt (CGT) & M51PR After 4/29/08
10
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 04-050

Base Frame, Bearings, & Hardware
M51 w/ Formula CG Tilt (CGT) & M51PR After 4/29/08
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1062095 Fastener, Loop with Adhesive Back (1" W x 4" L) 1 21 40117X006 Bearing (5/8") 1 42 1110717 Ring, Tolerance 1 43 1142189 Fastener, Hook with Adhesive Back (1" W x 2" L) 1 34
NOTE: Base Frame is a non-serviceable part.
11
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 04-050

Seat Height Adjustment Slide Tubes
M51 PR After 4/29/08
12
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 04-050

Seat Height Adjustment Slide Tubes
M51 PR After 4/29/08
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1110707 Kit, Seat Height Adjustment Slide Tubes and
Hardware 1 11 A,B
Slide Tube Assembly, Seat Height Adjustment, Rear 1 22 Screw, Socket Head (5/16-18 x 1-1/2") 1 43 Locknut (5/16-18) 1 44 Slide Tube Assembly, Seat Height Adjustment,
Front 1 25
1152529 Slide Tube Assembly, Seat Height Adjustment, Rear 1 22 1021344 Screw, Socket Head (5/16-18 x 1-1/2") 1 43 1026158 Locknut (5/16-18) 1 44 1109215 Slide Tube Assembly, Seat Height Adjustment,
Front 1 25 B
A - Includes Items 2-5
B - 300 Lb. capacity
NOTE:
13
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 04-050

Base Frame, Bearings, Hdwr. and Van Seat Post Assembly
14
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 04-050

Base Frame, Bearings, Hdwr. and Van Seat Post Assembly
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1127404 Frame Assembly, Base, Non-Elevating Seat, Black 1 11 A Bearing (5/8") 1 42 Ring, Tolerance 1 43 Hook (1" W) 1 24 Fastener, Loop with Adhesive (1") 1 25 Screw, Socket Head w/ Patch (3/8-16 x 2") 1 16 NLA - Frame, Base, Non-Elevating Seat, Black 1 17 1127300 Kit, Base Frame Hardware 1 18 B Bearing (5/8") 1 42 Ring, Tolerance 1 43 Hook (1" W) 1 24 Fastener, Loop with Adhesive (1") 1 25 Screw, Socket Head w/ Patch (3/8-16 x 2") 1 16 1127268 Frame Assembly, Base, Elevating Seat, Black 1 19 C Bearing (5/8") 1 42 Ring, Tolerance 1 43 Hook (1" W) 1 24 Fastener, Loop with Adhesive (1") 1 25 NLA - Frame, Base, Elevating Seat, Black 1 110 1143697 Post, Seat Pivot 1 111 D
A - Includes items 2-7.
B - Includes items 2-6. Although included in frame hardware kit, item 6 (Screw) is not required for chairs with elevating seat.
C - Includes items 2-5 and 10.
D - Effective 10/05/06, the Seat Pivot Post has been updated to give the seat the capability to lock in a 90 degree position
from straight either right or left.
NOTE:
15
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 04-050

Van Seat Models M50/M5/M61 & Solid Base Van Seats
Before 4/28/08 with Center Post attachment
If converting a chair from Office Style Van Seat to Semi-Recline Van Seat items 1, 13, and 15 must be
ordered in addition to the seat.
16
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 04-050

Van Seat Models M50/M5/M61 & Solid Base Van Seats
Before 4/28/08 with Center Post attachment
If converting a chair from Office Style Van Seat to Semi-Recline Van Seat items 1, 13, and 15 must be
ordered in addition to the seat.
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1119577 Kit, Van Seat Mounting Hardware 1 11 A,B Screw, Hex Head w/ Patch (1/4-20 x 1") 1 42 Washer (1/4 x 23/32 x 1/16") 1 63 Screw, Hex Head w/ Patch (1/4-20 x 1-1/4") 1 24 Spacer (1/4 x 5/8 x 1/4") 1 25 Spacer, Coved (1/4 x 11/16 x 1/2") 1 46 Screw, Hex Head w/Patch (1/4-20 x 2-1/2") 1 27 Plug Button, Black (1") 1 28 Locknut (5/16-18) 1 49 Washer, Steel (5/16 x 1-1/4 x 1/16") 1 410 Screw, Hex Head w/ Patch (5/16-18 x 1") 1 411 Knob, Adjustment, Black (5/16-18 x 1-1/2") 1 112 1092409 Washer, Steel (5/16 x 1-1/4 x 1/16") 1 410 1104258 Screw, Hex Head w/ Patch (5/16-18 x 1") 1 411 1116919 Bracket, Seat Mounting, Black 1 113 C 1129722 Bracket, Seat Mounting, Black 1 113 D 1116413 Pivot, Seat 1 114 1123391 Frame, Van Seat, Black (16" W) 1 115 1116392 Frame, Van Seat, Black (18" W) 1 115 1116393 Frame, Van Seat, Black (20" W) 1 115 1136494 Kit, Van Seat Mounting Hardware - Office Style 1 116 E Washer, Steel (5/16 x 1-1/4 x 1/16") 1 417 Screw, Hex Head w/ Patch (1/4-20 x 1-1/2") 1 418
A - Item 8, Plug Buttons, are only used in the absence of front riggings.
B - Includes items 2-12
C - Van Seats without Solid Seat Base
D - Van Seats with Solid Seat Base
E - Includes items 17-18
NOTE:
17
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 04-050

ASBA Seat Frame and Mounting Hardware
M50/M51 Center Post Attachment before 4/29/08
18
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 04-050

ASBA Seat Frame and Mounting Hardware
M50/M51 Center Post Attachment before 4/29/08
Item
Number Part Number DescriptionNote
Quantity Per
Package Assembly
1134543 Kit, Seat Frame Hardware 1 11 A Screw, Hex Head (5/16-18 x 1") 1 42 Screw, Hex Head (5/16-18 x 1-3/4") 1 43 Washer, Steel (5/16 x 3/4 x 1/16") 1 44 Locknut (5/16-18) 1 85 Knob, Adjustment, Black (5/16-18 x 1-1/2") 1 16 See Chart #7 Seat Frame, ASBA 1 17 1134542 Plate, Seat Frame 1 18 1116413 Pivot, Seat 1 19 A - Includes items 2-6
NOTE:
#7 Seat Frame, ASBA
Chair Depth 16" Wide 17" Wide 18" Wide 19" Wide 20" Wide
1132437113243611324351132434113243316-17" Deep 1132446113244511324441132443113244218-19" Deep 1132455113245411324531132452113245120" Deep
19
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 04-050
