INVENTOR EVP-WF20L User manual

1
WiFi FUNCTION
DEHUMIDIFIERS
ENGLISH
• USER’S MANUAL
MODELS:
EVP-WF16L
EVP-WF20L

2
IMPORTANT NOTE:
Read the manual carefully before connecting your
Smart kit(Wireless module). Make sure to save this
manual for future reference.
DECLARATION OF CONFORMITY
Hereby, we declare that this AC is in compliance
with the essential requirements and other
relevant provisions of Directive 2014/53/EU.
A copy of the full DoC is attached.
1 Specication
Model: OSK102
Standard: IEEE 802. 11b/g/n
Antenna Type: Printed PCB Antenna
Frequency : WLAN 2400~2483.5 MHz
Operation Temperature:0 C~45 C/32 F~113 F
Operation Humidity: 10%~85%
Power Input: DC 5V/300mA
Maximum Transmitted Power: 19.8dBm Max
2 Precautions
Applicable system: iOS, Android.
- Please keep you APP up to date with the latest
version.
- Due to special situation may be occurred, we
explicitly claims below: Not all of the Android
and iOS system are compatible with APP. We
will not be responsible for any issue as a result
of the incompatibility.
Wireless safety strategy
Smart kit only support WPA-PSK/WPA2-PSK
encryption and none encryption . WPA-PSK/
WPA2-PSK encryption is recommended.

Cautions
- Due to dierent network situation, control
process may return time-out sometimes. If this
situation occurs, the display between board and
App may not be the same, please do not feel
confused.
- Smart Phone camera needs to be 5 million
pixels or above to make sure scan QR code well.
- Due to dierent network situation, sometimes,
request time-out could happen, thus, it is
necessary to do network conguration again.
- The APP system is subject to update without
prior notice for product function improvement.
The actual network conguration process may
be slightly dierent from the manual, the actual
process shall prevail.
- Please Check The Service Website For More
information.
3 Download And Install App
CAUTION: The following QR Code is only
available for downloading APP. It is totally
dierent with the QR code packed with unit.
Android Phone users: scan Android QR code or
go to google play, search ‘NetHome Plus” app
and download it.
iOS users: scan iOS QR code or go to APP
Store, search ‘NetHome Plus” app and
download it.
[1] Click “Login “ [2] Enter your email address
and password, and then
click “Registration”
4 Network Conguration
Cautions
It is necessary to forget any other around
network and make sure the Android or iOS
device just connect to the Wireless network
you want to congure.
Make sure the Android or iOS device Wireless
function works well and can be connected back
to your original Wireless network automatically.
Kindly reminder:
User must nish all the steps in 8 minutes after
powering on AC, otherwise you need to power on
it again.
USER MANUAL OF SMART KIT

3
■ Using Android device to do network
conguration
1. Make sure your mobile device has already
been connect to the Wireless network which
you want to use.
Also, you need to forget other irrelevant
Wireless network in case it inuences your
conguration process.
2. Activate the AP mode (Read the WIRELESS
MODE IN OWNER’S MANUAL for detailed
operations.).
[5] Press “ + Add
Device ”
[6] Select the appliance you
are setting up
[7] Follow the above steps to enter “AP” mode.
[8] Choose the network
conguration
method.
[9] Choose the “ Scan the QR
code ” method.
Align the Q R co de within the fram e to scan
8:08 AM 50%
QR Code
[10] Please enter password
[9] Or choose the
“Manual Setup”
method.
[11] Network conguration is successful
[12] Conguration Succes,
you can see the device
on the list.
ENGLISH

4
■ Using iOS device to do network
conguration
1. Make sure your mobile device has already
been connect to the Wireless network which
you want to use.
Also, you need to forget other irrelevant
Wireless network in case it inuences your
conguration process.
2. Activate the AP mode (Read the WIRELESS
MODE IN OWNER’S MANUAL for detailed
operations.).
[5] Press “ + Add
Device ”
[6] Select the appliance you
are setting up
[7] Follow the above steps to enter “AP” mode.
[8] Connect to the
Wireless network.
[10] Network conguration is successful
NOTE:
 When nishing network conguration, APP will
display success cue words on the screen.
 Due to dierent internet environment, it is
possible that the device status still display
“oine”. If this situation occurs, it is necessary
to pull and refresh the device list on the APP
and make sure the device status become
“online”. Alternatively, user can turn o the AC
power and turn on it again, the device status
will become “online” after few minutes.
[6] Conguration Success,
you can see the device
on the list.
[9] Please enter password

5
6 How To Use App
Please ensure both your mobile device and air
conditioner are connected to the Internet before
using app to control the air conditioner via
internet, please follow the next steps:
[1] Click “Login “
082
[3] Make sure the Bucket is not removed and place it in
right position.
From left to the right, these button
means Power, Fan, Continuous, Auto
Dehumidication, and Pump.
1. Power
Press to turn on/o humidier.
2. Fan mode
Press Fan icon to activate high ,med(on some
models),low fan speed.
3. Continuous mode
Press Continuous icon to activate. Press again
to deactivate.
4. Auto dehumidication mode(on some models)
Press auto dehumidication icon to activate.
Press again to deactivate.
5. Pump mode(on some models)
Press Pump icon to activate.Press again to
deactivate.
6. Humidity control.
The range of humidity is 35%RH-85%RH.
User can add humitidy by clockwise adjusting
the white pointer. Similarily, user can minus
humidity by anticlockwise adjusting the white
pointer. The yellow pointer means current
indoor humidity.
NOTE:
Not all the function of the APP is available on air
conditioner. please check the user manual to
nd more information.
7 Special Functions
Including: Timer on, Timer o,
NOTE: If the air conditioner do not support the
above function, the function will be hided from
the function list.
Timer on/Timer o
■Weekly, user can make an appointment to
turn on or o AC on specic time.
[2] Choose the air
conditioner.

6
■ Share Device
The air conditioner can be controlled by
multi-users at the same time by Share Device
function.
[1] Click “Share
device”
[2] Let the others to scan the
displayed QR code.
[3] Click “Add Share
Device”
[4] Add the shared device.
CAUTIONS:
CONTAINS FCC ID: 2ADQOMDNA15
CONTAINS IC : 1257 5A-MDNA15
This device complies with Part 15 of the FCC
Rules and Industry Canada’s licence-exempt
RSSs.
Operation is subject to the following two
conditions:
(1) This device may not cause interference; and
(2) Thisdevice must accept any interference,
including interference that may cause
undesired operation of the device.
Only operate the device in accordance with the
instructions supplied.
Changes or modications to this unit not
expressly approved by the party responsible for
compliance could void the user’s authority to
operate the equipment.
This device complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. In order to avoid the possibility of
exceeding the FCC radio frequency exposure
limits, human proximity to the antenna shall
not be less than 20cm (8 inches) during normal
operation.
NOTE: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is
no guarantee that interference will not occur
in a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be determined
by turning the equipment o and on, the user
is encouraged to try to correct the interference
by one or more of the following measures:
-Reorient or relocate the receiving antenna.
- Increase the separation between the
equipment and receiver.
- Connect the equipment into an outlet on a
circuit dierent from that to which the receiver
is connected. -Consult the dealer or an
experienced radio/TV technician for help.

7
Company will not be liable for any issues
and problems caused by Internet, Wireless
Router and Smart Devices. Please contact
the original provider to get further help.
NOTE:
All the illustrations in the manual are for
explanation purpose only. Your unit may be
slightly dierent.
The actual shape shall prevail.

8
Scan here to download the latest version of this manual.
