INVT BPD0K7TN User manual

BPD Series PV Pumping Inverter

BPD series PV pumping inverter Preface
-i-
Preface
BPD series photovoltaic (PV) pumping inverters are developed for outdoor PV power
supply of water pumps based on the core control algorithm of Goodrive series
high-performance inverters and the requirements of PV pumping application and control.
They provide multiple control and protection functions, such as tracking the maximum
power, hibernating at weak light, waking up at strong light, hibernating at high
water-level, and underload protection. The PV power supply can be automatically
switched to grid power supply as required by customers to ensure the proper operation
of the water pumps.
See the commissioning guide in this manual when performing commissioning on the
inverter.
If the product is ultimately used for military affairs or manufacture of weapon, it will be
listed on the export control formulated by Foreign Trade Law of the People's Republic
of China. Rigorous review and necessary export formalities are needed when they are
exported.
Our company reserves the right to update the information of our products without prior
notice.

BPD series PV pumping inverter Contents
-ii-
Contents
Preface .............................................................................................................................i
Contents........................................................................................................................... ii
1 Safety Precautions........................................................................................................1
1.1 Safety definition ...................................................................................................1
1.2 Warning symbols .................................................................................................1
1.3 Safety guidelines..................................................................................................2
2 Product overview ..........................................................................................................5
2.1 Product specifications..........................................................................................5
2.2 Name plate...........................................................................................................7
2.3 Model description.................................................................................................7
2.4 Power levels.........................................................................................................8
2.5 Control circuit wiring and terminals......................................................................8
2.6 Dimensions and installation...............................................................................14
2.7 Keypad operation procedure..............................................................................16
3 Function parameters...................................................................................................23
3.1 Parameters of common functions......................................................................23
3.2 Special function parameters...............................................................................35
4 Fault diagnosis and solution.......................................................................................47
5 Installation guide.........................................................................................................52
5.1 Unpacking inspection.........................................................................................52
5.2 Preparation for installation.................................................................................52
5.3 Mechanical installation.......................................................................................53
5.4 Electrical installation ..........................................................................................55
5.5 Inspection before operation ...............................................................................60
5.6 Description of LED indicators ............................................................................61
6 Commissioning guide .................................................................................................62
6.1 Commissioning on PV power supply .................................................................62
6.2 Commissioning on grid power supply................................................................64
6.3 Commissioning on automatic switching between PV and grid power supply....65
6.4 Advanced settings..............................................................................................66
6.5 Flow chart of the commissioning .......................................................................68
6.6 Simple parameter setting overview....................................................................69
Appendix: Recommended solar array configuration......................................................70

BPD series PV pumping inverter Safety Precautions
1
1 Safety Precautions
Read this manual carefully and follow all the safety precautions before moving, installing,
operating, and servicing the inverter. Otherwise, physical injury or death or damage to
the devices may be caused.
If any physical injury or death or damage to the devices caused by you or your
customers due to your neglect of the safety precautions in the manual, our company
shall not be held liable.
1.1 Safety definition
Danger:
Serious physical injury or even death may occur if related
requirements are not followed.
Warning:
Physical injury or damage to the devices may occur if related
requirements are not followed.
Note:
Steps to take for ensuring the proper running of the inverter.
Trained and
qualified electricians
People working on the device must have taken part in
professional electrical and safety training, obtained the
certification, and been familiar with all steps and requirements of
installing, commissioning, operating, and maintaining the device,
and are capable of preventing or dealing with all kinds of
emergencies.
1.2 Warning symbols
Warning signs are used to warn you about the conditions that may cause severe injury
or damage to the device. They instruct you to exercise caution to prevent danger. The
following table describes the warning signs used in this manual.
Symbols
Name
Instruction
Abbreviation
Danger
Danger
Serious physical injury or even
death may occur if related
requirements are not followed.
Warning
Warning
Physical injury or damage to the
devices may occur if related
requirements are not followed.
Electrostatic
discharge
Electrostatic
discharge
Damage to the PCBA board may
occur if related requirements are
not followed.
Hot sides
Hot sides
Sides of the device may become
hot. Do not touch.
Note
Note
Steps to take for ensuring the
proper running of the device.
Note

BPD series PV pumping inverter Safety Precautions
2
1.3 Safety guidelines
Only qualified electricians are allowed to operate the inverter.
Do not carry out any wiring or inspection or change components when the
power supply is applied. Ensure that all the input power supplies are
disconnected before wiring and checking, and always wait at least the time
designated on the inverter or until the DC bus voltage is lower than 36 V.
The following table describes the waiting time.
Inverter model
Min. waiting time
220 V
0.75 kW–4 kW
5 minutes
380 V
2.2 kW–5.5 kW
5 minutes
Do not refit the inverter unauthorizedly. Otherwise, fire, electric shocks, or
other injury may be caused.
The base of the radiator may become hot when the device is running. Do
not touch it. Otherwise, you may get burnt.
The electrical parts and components inside the inverter are electrostatic.
Take measurements to avoid electrostatic discharge when performing
operation involved with them.
1.3.1 Delivery and installation
Install the inverter on noncombustibles and keep the inverter away from
inflammables.
Do not operate the inverter when it is damaged or any of its components
are lost.
Do not touch the inverter with wet items or body. Otherwise, electric
shocks may occur.
Note:
Use proper handling and installation tools to avoid damage to the device or
physical injury. Installers must take mechanical protective measures, such as
wearing anti-smashing shoes and working uniforms, to protect personal safety.
Do not carry the inverter by its cover. The cover may fall off.
Do not open the cover plates of the inverter. Only professional technicians are

BPD series PV pumping inverter Safety Precautions
3
allowed to perform such operation.
Ensure that no physical impact or vibration occurs on the product during its
transport and installation.
Install the product in a place that will prevent children or other people from touching
it.
The leakage current of the product may be larger than 3.5 mA during operation.
Perform reliable grounding and ensure that the grounding resistance is lower than
10 Ω. The conductivity of PE grounding conductor is the same as that of the phase
conductor (with the same cross sectional area).
DC INPUT is the PV input terminal, AC INPUT is the power input terminal, andAC
OUTPUT is the motor output terminal. Connect the input power cable and motor
cable properly. Otherwise, damage to the inverter may be caused.
Before connecting the 1PH AC grid cable to the inverter, take protection measures
such as the lightning protection and short circuit protection according to the local
electrical safety standard.
The distance between the DC output line of the PV panel and the DC terminal of
the inverter cannot exceed 10 meters. Otherwise, measures need to be taken to
prevent overvoltage.
1.3.2 Commissioning and running
Before performing terminal wiring, disconnect all the power supplies of
the inverter and wait at least 5 minutes.
The voltage inside the inverter is high when it is running. Do not perform
any operation except keypad-based setting.
The inverter may automatically start when P01.21=1. Do not get close to
the inverter and motor.
The inverter cannot be used as an "Emergency-stop device".
Note:
Do not switch on/off the input power supply of the inverter frequently.
For inverters that have been stored for a long time, check it, adjust the capacitance
and perform a test run before using it.
Cover the front cover plate before the running of the inverter. Otherwise, electric

BPD series PV pumping inverter Safety Precautions
4
shocks may be caused.
1.3.3 Maintenance and replacement of components
Only qualified electricians are allowed to perform the maintenance,
inspection, and component replacement on the inverter.
Before performing terminal wiring, disconnect all the power supplies of
the inverter and wait at least 5 minutes.
Take measures to prevent screws, cables and other conductive matters
from falling into the inverter during maintenance and component
replacement.
Note:
Use proper torque to tighten screws.
Keep the inverter, parts, and components away from inflammables during
maintenance and component replacement.
Do not carry out any isolation and voltage withstanding test on the inverter, and do
not measure the control circuit of the inverter by megameter.
1.3.4 Waste disposition
There is heavy metal in the product. Deal with it as industrial waste.
When the life cycle ends, the product should enter the recycling system.
Dispose of it separately at an appropriate collection point instead of
placing it in the normal waste stream.

BPD series PV pumping inverter Product overview
5
2 Product overview
2.1 Product specifications
Model
BPD0K7
TN(AC)
BPD1K5
TN(AC)
BPD2K2
TN(AC)
BPD004
TNAC
BPD2K2
TRAC(S)
BPD004
TRAC(S)
BPD5K5
TRAC(S)
DC input
Maximum DC
voltage (V)
450
800
Starting voltage
(V)
80
100
220
Minimum
working voltage
(V)
60
80
180
Recommended
MPPT voltage
(V)
80–400
100–400
220–750
Number of
input channels
1/MC4
connector
2/MC4 connector
1/MC4
connector
2/MC4 connector
Maximum input
DC current (A)
9
12
12
20
12
20
20
Bypass AC input (supporting mains input)
Input voltage
(V AC)
220/230/240(1PH) (-15%–+10%)
380 (3PH) (-15%–+10%)
Input frequency
(Hz)
47–63
AC input
terminal
L, N, PE
R, S, T, PE
AC output
Rated power
(W)
750
1500
2200
4000
2200
4000
5500
Rated current
(A)
5.1 (1PH)
4.2 (3PH)
10.2
(1PH)
7.5 (3PH)
14 (1PH)
10 (3PH)
25 (1PH)
16 (3PH)
5.5
9.5
14
Output voltage
(V AC)
0–Input voltage

BPD series PV pumping inverter Product overview
6
Model
BPD0K7
TN(AC)
BPD1K5
TN(AC)
BPD2K2
TN(AC)
BPD004
TNAC
BPD2K2
TRAC(S)
BPD004
TRAC(S)
BPD5K5
TRAC(S)
Output wiring
mode
1P2L: 1PH motor 1PH control
2P3L: 1PH motor 2PH control
3P3L: Connected to a 3PH asynchronous
motor
3P3L: Connected to a 3PH
asynchronous motor
Output
frequency (Hz)
1–400
Control performance
Control mode
V/F
Motor type
Asynchronous motor (1PH/3PH)
Asynchronous motor (3PH)
Other parameters
Dimensions
(WxDxH) (mm)
255×300
×137
280×300×137
410×360
×154.5
331×360
×154.5
454×360×154.5
Net weight (kg)
6.4
7
13.15
10.1
14.1
Package weight
(kg)
8.5
9
16
12
16
Ingress
protection
rating
IP65
Cooling
Natural cooling
HMI
External LED keypad
Communication terminals
External
communication
RS485/3 digital inputs
Communication
interface
Multi-core waterproof connector
Certification
Standards
CE; EMC meets the requirements of IEC61800-3 C3.
Operating environment
Ambient
temperature
-25–60°C (derated at temperature higher than 45°C)
Altitude
3000 m (derated at altitude higher than 2000 m)

BPD series PV pumping inverter Product overview
7
2.2 Name plate
2.3 Model description BPD - XKX - TN - AC
①②③④
No.
Field
Field description
Naming rule
①
BPD
Product series name
Name of the PV pumping inverter
series
②
XKX
AC output power
Rated AC output power
1500W: 1K5
5000W: 005
③
TN
Technical type
TL: 1PH
TR: 3PH
TN: 1PH/3PH
④
AC
Extension code
The default is a standard model;
AC indicates that AC input is
supported; and ACS indicates that
AC input is provided and a DC
switch is configured.

BPD series PV pumping inverter Product overview
8
2.4 Power levels
BPDXKXTN
0K7
1K5
2K2
004
Rated output power (kW)
0.75
1.5
2.2
4
Max. DC input current (A)
9
12
12
20
Rated AC input current––AC model (A)
9.3
15.7
24
38
Rated output current (A)
5.1 (1PH)
4.2 (3PH)
10.2 (1PH)
7.5 (3PH)
14 (1PH)
10 (3PH)
25 (1PH)
16 (3PH)
BPDXKXTRAC(S)
2K2
004
5K5
Rated output power (kW)
2.2
4
5.5
Max. DC input current (A)
12
20
20
Rated AC input current––AC model (A)
5.8
13.5
19.5
Rated output current (A)
5.5
9.5
14
2.5 Control circuit wiring and terminals
2.5.1 Wiring diagram of the control circuit
The COM interfaces are the control circuit interfaces, including one 485 communication
channel and three digital input channels. Figure 2.1 shows the wiring. For interface
definitions and specifications, see section 2.5.4 "Description of function terminals".

BPD series PV pumping inverter Product overview
9
RUN/STOP button
COM
+24V
S2
J4
485
communication
J5
S3
S4
PE
Screen
Twisted pair 120Ω
485+
485-
Digital input 2
Screen
COM
Digital input 1
Digital input 3
Figure 2.1 Control circuit wiring diagram
Note: For models of BPD2K2–5K5TRAC(S), the RUN/STOP button on the enclosure
corresponds to the S4 terminal,
2.5.2 Terminal arrangement
1 3 4 652
(a) BPD0K7–2K2TN(AC) terminals

BPD series PV pumping inverter Product overview
10
⑤
⑦
⑥
①
②
③
②
③
④
(b) BPD004TNAC terminals
①
⑧
②
③
⑥
②
③
⑤
⑦
④
⑨
(c) BPD2K2–5K5TRAC(S) terminals
Figure 2.2 Wiring terminal arrangement
No.
Terminal name
Pin definition
①
AC input
terminal (AC
model)
-TN model
1. L
2. N
3. PE
-TR model
1. R
2. S
3. T

BPD series PV pumping inverter Product overview
11
No.
Terminal name
Pin definition
4. PE
②
PV input terminal-
-DC INPUT
③
PV input terminal+
+DC INPUT
④
External keypad terminal
RJ45
⑤
Function terminal
1. 485+
2. 485-
3. S2
4. S3
5. COM
6. S4Note*
7. COM
8. PE
⑥
AC output terminal
1. V
2. W
3. U
4. PE
⑦
GPRS connection terminal
1. + 5V
2. 485+
3. 485-
4. GND
⑧
DC switch
/
⑨
RUN/STOP button
/
Note*: For the models of BPD2K2–5K5TRAC(S), Pin6 does not provide any functions.
2.5.3 Instruction of power terminals
1. ①is an AC input terminal and the model supporting mains input provides this terminal.
(Note: For safety, ensure that PE is properly connected.)
2. ⑥is an AC output terminal connected to the water pump motor. When using a 3PH
motor, connect U, V and W of the motor to U, V and W of the inverter, and connect the
motor enclosure to PE of ⑥.
3. The wiring varies with control modes if a 1PH motor is used:
(1) 1PH control: Connect the motor phase line to U and W of inverter terminal ⑥,
connect the motor enclosure to the PE pin. There is no need to remove the starting
capacitor and the wiring is easy. But the starting performance is not as good as that in
2PH control mode, so this wiring mode is applicable only to some motors.
(2) 2PH control: It is necessary to remove the starting capacitor and operation capacitor

BPD series PV pumping inverter Product overview
12
(if any). The wiring of a general motor is shown in Figure 2.3: L1 is the running winding,
L2 is the starting winding, C1 is the running capacitor, C2 is the starting capacitor, and
when the motor speed exceeds 75% of the rated speed, the starting capacitor is
switched off through the centrifugal switch K.
U1
U2
V2
V1
L
N
L1
L2
C1
C2
K
Figure 2.3 Internal wiring of the 1PH motor with starting and running capacitors
Figure 2.4 shows the internal wiring after the starting and running capacitors are
removed.
U1
U2
V2
V1
L1
L2
C1
C2
W
U
V
U1
U2
V2
V1
L1
L2
L
N
K
Figure 2.4 Wiring of a 1PH motor in 2PH control mode
U1 and V1 are the common terminal of the windings, and connect with the W output of
the PV pumping inverter, U2 of the running winding connect with the U output of the PV

BPD series PV pumping inverter Product overview
13
pumping inverter, and V2 of the starting winding connect with the V output of the PV
pumping inverter.
The operation direction of the motor can be changed by changing the V voltage phase
through the tens place of P04.34. After the forward direction is adjusted, the operation
direction can be changed through P00.13.
2.5.4 Description of function terminals
Terminal
name
Description
PE
Grounding terminal
COM
+24V common terminal
S2
Digital input 2
1. Internal impedance: 3.3kΩ
2. Applicable to 12–30V voltage input
3. Supporting NPN wiring
4. Max. input frequency: 1 kHz
5. All are programmable digital input terminal. Users
can set terminal functions through function codes.
6. S1 is short circuited with COM in the inverter by
default and it is not connected externally.
Note: The RUN/STOP button is provided only on –TR
models, and S4 is used.
S3
Digital input 3
S4
Digital input 4
(Used by the
RUN/STOP button)
485+
485 communication interface
If it is a standard 485 communication interface, use twisted pairs or shielded
cables.
Note: When a GPRS module is used, the 485 communication interface is not
available. If 485 communication is required, you need to remove the GPRS
module.
485-

BPD series PV pumping inverter Product overview
14
2.6 Dimensions and installation
W1
H1
D
W2
H2
Figure 2.5 Dimensions of BPD0K7TN(AC)
(Unit: mm)
Model
H1
W1
D
H2
W2
Installation
hole
BPD0K7TN(AC)
255
300
137
118.5
195
8
W1
H1
D
W2
H2
Figure 2.6 Dimensions of BPD1K5/2K2TN(AC)

BPD series PV pumping inverter Product overview
15
(Unit: mm)
Model
H1
W1
D
H2
W2
Installation
hole
BPD1K5TN(AC)
BPD2K2TN(AC)
280
300
137
131
195
8
H1
W2
H3 H2
D
W1
Figure 2.7 Dimensions of BPD004TNAC (Unit: mm)
Model
H1
W1
D
H2
W2
H3
Installation
Hole
BPD004TNAC
410
360
154.5
159
260
45
8

BPD series PV pumping inverter Product overview
16
H3 H2
W2
W1
H1
D
Figure 2.8 Dimensions of BPD2K2–5K5TRAC(S)
(Unit: mm)
Model
H1
W1
D
H2
W2
H3
Installation
Hole
BPD2K2TRAC(S)
331
360
154.5
122.5
260
45
8
BPD004TRAC(S)
454
360
154.5
184
260
45
8
BPD5K5TRAC(S)
454
360
154.5
184
260
45
8
2.7 Keypad operation procedure
2.7.1 Keypad introduction
The keypad is used to control the PV pumping inverter, read the state data and adjust
parameters.
1
2
4
3
5
RUN/TUNE FWD/REV LOCAL/REMOT TRIP
RPM
H2
A
V
%
PRG
ESC DATA
ENT
QUICK
JOG SHIFT
RUN STOP
RST
Figure 2.9 External keypad

BPD series PV pumping inverter Product overview
17
No.
Name
Description
1
Status
indicato
r
RUN/TUNE
Running status indicator.
LED off means that the inverter is in the
stopping state; LED blinking means the
inverter is in the parameter autotuning state;
LED on means the inverter is in the running
state.
FWD/REV
FED/REV indicator.
LED off means the inverter is in the forward
rotation state; LED on means the inverter is in
the reverse rotation state
LOCAL/REMOT
LED for keypad operation, terminals
operation and remote communication control;
LED off means that the inverter is in the
keypad operation state; LED blinking means
the inverter is in the terminals operation state;
LED on means the inverter is in the remote
communication control state.
TRIP
Fault indicator.
LED on when the inverter is in the fault state;
LED off in normal state; LED blinking means
the inverter is in the overload pre-alarm state.
2
Unit
indicato
r
Indicating the unit of the displayed digits
Hz
Unit of frequency
A
Unit of current
V
Unit of voltage
RPM
Unit of rotating speed
%
Percentage
3
Code
displayi
ng
zone
5-digit LED display, displaying various monitoring data and alarm code
such as set frequency and output frequency.
