ION F-16 User manual

F-16
LINE INTERACTIVE UPS
UPS USER MANUAL
1KVA/1.5KVA/2KVA/3KVA

ION F-16
IMPORTANT SAFETY
INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This user manual contains important instructions for the
ION F-16 1000VA / 1500VA/ 2000VA / 3000VA series which
should be followed for the installation and maintenance of
the UPS and batteries. Please read all safety and operating
instructions before operating the UPS. Adhere to all
warnings on the unit and in this manual and follow all
operating and user instructions.

CONTENTS
1. Introduction ············································································································1
2. Safety Warning ·······································································································2
2.1 Description of Commonly Used Symbols····························································· 3
3. Installation··············································································································4
3.1 Inspection of Unit ·······························································································4
3.2 Unpacking the Cabinet ······················································································· 4
3.3 UPS Setup·········································································································4
3.4 EBM Installation (Optional) ················································································· 9
3.5 UPS Initial Startup···························································································· 15
4. Operation·············································································································· 16
4.1 Display Panel··································································································· 16
4.2 Operating Mode ······························································································· 20
4.3 Configuring Load Segment ··············································································· 20
4.4 Configuring UPS for EBM Numbers ·································································· 21
4.5 Configuring Green Function·············································································· 21
5. Communication Port····························································································· 22
5.1 RS-232 and USB Communication Ports···························································· 22
5.2 Emergency Power Off (EPO)············································································ 22
5.3 Network Management Card (Optional) ······························································ 23
6. UPS Maintenance ································································································· 24
6.1 UPS and Battery Care······················································································ 24
6.2 Storing the UPS and Batteries ·········································································· 24
6.3 Time to Replace Batteries················································································· 24
6.4 Replacing UPS Internal Batteries······································································ 25
6.5 Testing New Batteries······················································································· 27
6.6 Recycling the Used Battery:·············································································· 27
7. Specification········································································································· 28
7.1 Specification ···································································································· 28
7.2 Rear Panels····································································································· 30
8. Trouble Shooting·································································································· 33
8.1 Audible Alarm Trouble Shooting········································································ 33
8.2 General Trouble Shooting················································································· 33
9. Software Installation····························································································· 34

1
1. Introduction
This ION F-16 line-interactive series is compact and pure sine wave UPS and
designed for essential applications and environments, such as desktops, servers,
workstations, and other networking equipment. These models are available in the
output ratings of 1000VA, 1500VA, 2000VA and 3000VA. The series protects your
sensitive electronic equipment against power problems including power sags,
spike, brownouts, line noise and blackouts.
The series is convertible to rack and tower forms. It can be placed either in Rack
2U or Tower form. The front panel of the ION F-16 UPS includes LCD display and
four control buttons which allow users to monitor, configure and control the unit.
The LCD includes a graphical bar, two status indications and four alarm
indications. A control button on the front panel allows users to silence the AC fail
alarm and initiate the UPS self-test sequence. The UPS case for 1000VA ~
3000VA is made of metal. This series is powered from the AC mains and supply
AC outputs via receptacles on the rear panel. Communication and control of the
UPS is available through serial or USB ports located on the rear panel. The serial
port supports communications directly with a server.
Features:
Microprocessor control guarantees high reliability
High frequency design
Built-in boost and buck AVR
Easy battery replacement design
Selectable input and output range
Cold start capability
Built-in Dry contact/RS-232/USB communication port
SNMP allows for web-based remote or monitoring management
Enable to extend runtime with scalable external battery module(EBM)
Overload, short-circuit, and overheat protection
Rack/Tower 2 in 1 Design
19 inches rack mount available for all models

2
2. Safety Warning
DANGER:
This ION UPS contains high voltage. All repairs and service should be performed
by authorised service personnel only. There are no user serviceable parts inside
the UPS.
WARNING:
This ION UPS contains its own energy source (batteries).The UPS output may
carry live voltage even when the UPS is not connected to an AC supply.
To reduce the risk of fire or electric shock, install this UPS in a temperature and
humidity controlled, indoor environment, free of conductive
contaminants.(Ambient :0-40°C)
To reduce the risk of fire, connect to a circuit breaker provided with 20 amperes
maximum branch circuit over-current protection.
To comply with international standards and wiring regulations, the sum of the
leakage currents of the UPS and the connected loads must not exceed 3.5mA.
The socket outlet that supplies the UPS should be installed close to this unit
and be easily accessible.
Protective earthing connections - a disconnection of a protective earth should
be made at a point furthest away from the UPS, maintaining the dedicated line
in order to secure equipotential connection.
The UPS and EBMs connected in a series should be installed close to each
other so that the operators cannot touch the interconnecting wire which is basic
insulated from primary circuit.
CAUTION:
Batteries may present a risk of electrical shock or burnt from high short-circuit
current. Observe proper precautions. Servicing should be performed by
qualified service personnel experienced with batteries and required precautions.
Keep unauthorised personnel away from batteries.
Proper disposal of batteries is required. You should refer to your requirements
in your jurisdiction for disposal.

3
Never dispose of batteries by incineration. Batteries may explode when
exposed to flame.
Following figure shows the basic internal circuit configuration of the ION UPS
2.1 Description of Commonly Used Symbols
Some or all of the following notations in this manual may appear in your
application process. All UPS users should be familiar with and understand
these notations.
Table1. Description of Commonly Used Symbols
Symbol Description
Alert you to pay special attention
Caution of high voltage
Alternating current source (AC)
Direct current source(DC)
Protective ground
Recycle
Keep UPS in a clear area

4
3. Installation
3.1 Inspection of Unit
Inspect the UPS upon receiving. If the UPS appears to be damaged from
shipment, keep the box and packing material in its original form from the carrier
and notify the carrier and dealer immediately.
3.2 Unpacking the Cabinet
To unpack the system:
1. Open the outer carton and remove the accessories packaged with the
cabinet.
2. Carefully lift the cabinet out of the outer carton and set it on a flat, stable
surface.
3. Discard or recycle the packaging in a responsible manner, or store it for
future use.
3.3 UPS Setup
All model series are designed for tower and rack deployment and can be
installed into a 19 inch equipment rack. Please follow the instruction for Tower
Setup and Rack-Mount Setup.
Tower setup
This series of ION UPS can be placed horizontally and vertically. For a tower
configuration, stands have been provided to stabilise the UPS when it is
positioned vertically. The UPS stand must be attached to the bottom of the
tower.

5
Use the following procedure to install ION UPS in its stands.
1. Slide the UPS down vertically and put the two stands at the end of the tower.
2. Place the UPS down between the two stands carefully.

6
3. Pull out the LCD box and rotate it in a clockwise direction to 90 degrees and
then push it back in the front panel.

7
Rack-mount setup
The series can be installed in 19 inch racks. Both the UPS and external battery
enclosure need 2U of available rack space.
Use the following procedure to install the UPS in a rack.
1. Align the mounting ears with screw holes on the side of the UPS and tighten
the screw.
2. Assemble the rack rails with the rack-mounting.
