ION F15R User manual

[email protected]om.au
www.ionups.com.au
P: 1300 700 805
ION F15R 1RU

650/1200/1600VA
User Guide

ION F15R 1RU

ION F15R 1RU
User Guide
Contents
ION F15R 1RU User Guide
www.ionups.com.au
Installing your UPS System ________________ 4
 __________ 5
 ______________ 6
_________________________ 7
 _____________________ 8
 __________________ 9
 ______________________ 12
 _______________________ 13

ION F15R 1RU
4
The box should contain the following:
(1) UPS Unit x1


UPS 650/1200/1600VA
Installing your UPS System
Unpacking
How to determine the power
requirements of your equipment

1. Ensure that the equipment plugged into the
baery power-supplied outlets does not
exceed the UPS unit’s rated capacity. If rated
unit capacies are exceeded, an overload
condion may occur and cause the UPS unit to
shut down or the fuse blow.
2. There are many factors that can aect the
amount of power that your computer system
will require. For opmal system performance
keep the load below 80% of the unit’s rated
capacity.
1. Your new UPS may be used immediately upon
receipt. However, recharging the baery for at
least 8 hours is recommended to ensure that the
baery’s maximum charge capacity is achieved.
Charge loss may occur during shipping and storage.
To recharge the baery, simply leave the unit
plugged into an AC outlet. The unit will charge in
both the on and o posion.
2. With the UPS unit o and unplugged, connect the
computer, monitor, and any externally powered
data storage device.
3. Plug the UPS into a 2 pole, 3 wire grounded
receptacle (wall outlet). Make sure the wall branch
outlet is protected by a fuse or circuit breaker and
does not service equipment with large electrical
demands.
4. Depress the power switch to turn the unit on. The
LCD indicator light will illuminate and the unit will
“beep”.
5. To maintain opmal baery charge, leave the UPS
plugged into an AC outlet at all mes.
6. To store your UPS for an extended period, cover it
and store with the baery fully charged. Recharge
the baery every three months to ensure baery
life.


and Storage
 Storage
1. Use dry so clothes to clean the front panel
and plasc parts. Do not use any detergent
that contains alcoholic ingredients.
2. The expected lifeme of the baery is around
3 years. Improper operaon and harsh
environment will reduce the actual lifeme.
3. Unplug the UPS from the power inlet if the UPS
will not be operated for long periods of me.
1. First turn o your UPS and disconnect its power
cord from the wall outlet. Disconnect all cables
connected to the UPS to avoid baery drain.
2. The UPS should be stored in a cool dry locaon.
3. Make sure the baery is fully charged before the
UPS is stored.
4. For extended storage in moderate climates, the
baery should be charged for 12 hours every 3
months by plugging the power cord into the wall
receptacle and turning on the main switch. Repeat
it every 2 months in high temperature locaons.
ION F15R 1RU

5



To prevent the risk of re or electric shock, install in a temperature and
humidity controlled indoor area free of conducve contaminants. (See
the specicaons for the acceptable temperature and humidity range.)
To reduce the risk of overheang the UPS, do not cover the UPS’
cooling vents and avoid exposing the unit to direct sunlight or installing
the unit near heat eming appliances such as space heaters or
furnaces.
Do not aach non-computer-related items, such as medical equipment,
life-support equipment, microwave ovens, or vacuum cleaners to UPS.
Do not plug the UPS input into its own output.
Do not allow liquids or any foreign object to enter the UPS. Do not
place beverages or any other liquid containing vessels on or near the
unit.
In the event of an emergency, press the OFF buon and disconnect
the power cord from the AC power supply to properly disable the UPS.
Do not aach a power strip or surge suppressor to the UPS.
Unplug the UPS prior to cleaning and do not use liquid or spray
detergent.
This manual contains important safety instrucons. Please read and follow
all instrucons carefully during installaon and operaon of the unit. Read
this manual thoroughly before aempng to unpack, install, or operate
your UPS.
ION F15R 1RU
6

ION F15R 1RU
User Guide
7
To prevent the risk of re or electric shock, install in a temperature and
humidity controlled indoor area free of conducve contaminants. (See
the specicaons for the acceptable temperature and humidity range.)
To reduce the risk of overheang the UPS, do not cover the UPS’
cooling vents and avoid exposing the unit to direct sunlight or installing
the unit near heat eming appliances such as space heaters or
furnaces.
Do not aach non-computer-related items, such as medical equipment,
life-support equipment, microwave ovens, or vacuum cleaners to UPS.
Do not plug the UPS input into its own output.
Do not allow liquids or any foreign object to enter the UPS. Do not
place beverages or any other liquid containing vessels on or near the
unit.
In the event of an emergency, press the OFF buon and disconnect
the power cord from the AC power supply to properly disable the UPS.
Do not aach a power strip or surge suppressor to the UPS.
Unplug the UPS prior to cleaning and do not use liquid or spray
detergent.


1. AC Inlet
Connect to ulity power through the input power
cord.
2. Input Circuit Fuse
The fuse provides opmal overload protecon.
3. AC outlet
The UPS provides outlets for connected
equipment to insure temporary uninterrupted
operaon during a power failure and against
surges and spikes.
4. 
The SNMP/HTTP port provides remote
monitoring and management of your UPS over a
network.
5. Serial Port
This port allows connecon and communicaon
from the DB9 serial on the computer to the UPS
unit. The UPS communicates its status to the
soware.

650/1200/1600VA
6. USB Port
This port allows connecon and communicaon
form the USB port on the computer to the UPS unit.
7. EPO Port
Enables an emergency UPS Power-O from a
remote locaon. EPO terminal open, the UPS will
turn o and the output shutdown immediately.
8. 
The LCD will display the UPS status including input
voltage, output voltage, runme, percentage of load
and baery, etc.
9. 
Press the power switch to turn the UPS ON or OFF.

The audible alarm can be turned o/on by
pressing this buon.

8
ION F15R 1RU

Power Master management soware provides a user-friendly
interface for your power systems. The graphic user-interface is
intuive and displays essenal power informaon at a glance.
Please follow procedures below to install the soware.
Po
System
Summary
UPS
Status
Information
Conguration
Diagnostics
Load
Input
Status
Voltage
Frequency
Normal
229.9V
49.90Hz
ent Action
Events
Recipient
Settings
Logs
Events Logs
Status Records
Settings
Schedule
Shutdown
Output
Status
Voltage
Frequency
Load
Normal / Eco Mode
230.0V
49.90Hz
0% (0 Watts)
Battery
Status
Capacity
Normal /Charging
46%
UPS Status

1. Download Power Master from the website:

2. Double-click the le and follow the installaon
steps.
3. When your computer restarts, the Power
Master soware will appear as a blue icon
located in the system tray.

ION F15R 1RU
User Guide
9


  
OUTPUT
Output power capacity 390W/650VA 720W/1200VA 960W/1600VA
Max Congurable Power (Was) 390W/650VA 720W/1200VA 960W/1600VA
Output voltage 220-240Vac
Boost Rao(AVR) 118%
Buck Rao(AVR) 85%
Ac voltage regulaon(ba.mode) ±10%
Frequency Range(ba.mode) 50/60±1% Hz
Transfer me 4ms typical
waveform (ba.mode) Pure Sine Wave
Outlet IEC(4)
THDv <5% @ Linear Load
Full protecon Overload, short circuit, over discharger and over charger
Line mode overload >110% only Sounding
Baery mode overload >110% Sounding and fault aer 1min
INPUT
Voltage 220-240Vac
Voltage Range 165~290Vac
Frequency Range 50/60Hz(Auto sensing)
Input Type IEC 320 C14
Input Fuse Yes

ION F15R 1RU
10
TECHNICAL
SPECIFICATIONS
  
BATTERY
Baery voltage 12Vdc 24Vdc 24Vdc
Baery type & number 6V 7AH *2 6V7AH *4 6V 9AH *4
Charging Current 1A
Typical Recharge Time 4 hours
Easy baery replacement YES

Display LCD
Alarm
Baery mode: Sounding every 30 seconds
Low Baery: Sounding every 2 seconds
Over Load: Sounding every 0.5 seconds
Fault: Connuous sounding
PHYSICAL
Dimensions (W * H * D) (mm) 433*44*216 433*44*485

Humidity 0-90 % RH @ 0-40°C (non-condensing)
Noise Level Less than 40 dB
INTERFACE
RS232 Yes
USB Yes
EPO Yes
Smart Slot Yes
REGULATION
Safety CE
Standard warranty 3 Year Advance Replacement*

ION F15R 1RU
User Guide
11

Inial AC INPUT
(Voltage) V
OUTPUT
(Voltage) V
Line mode Bat-mode
Alarm/Fault Sound disable
(Press the mute key 3s to disable
and enable the buzzer sound)

Line mode:
1. Baery charging: cycle lighng
2. Baery full charged: lighng
3. Line mode without charger: baery
capacity
Load capacity

ION F15R 1RU
12

 
O Normal
Beep 1 me In Every 30 Seconds Ulity Failure – The UPS is providing baery power to outlets.
Beep 1 me In Every 2 Seconds Ulity Failure – The UPS is providing baery power.
The rapid beeps indicate the baery will run out of power shortly.
Beep 1 me In Every 0.5 Second Overload - Occurs when connected equipment exceeds the rang of the unit.
Turn the UPS o and unplug at least one piece of equipment from the UPS.

ION F15R 1RU
User Guide
13

 POSSIBLE CAUSE SOLUTION
O The UPS does not per-
form expected runme.
Baeries are not fully charged. Recharge the baery by leaving the UPS plugged in.
Baery is slightly worn out. Contact Technical Support.
The UPS will not turn on. The on/o switch is designed to prevent damage
by rapidly turning it o and on.
Turn the UPS o. Wait 10 seconds and then turn the UPS on.
The unit is not connected to an AC outlet. The unit must be connected to a 220-240V 50Hz outlet.
The baery is worn out. Contact Technical Support.
Mechanical problem. Contact Technical Support.
Outlets do not provide power
to equipment
Fuse is blown due to overload Turn the UPS o and unplug at least one piece connected
equipment. Unplug the power cord of the UPS then remove the fuse
compartment beneath the power inlet of the UPS and replace the
blown fuse with a spare one. Lock the compartment back to the UPS.
Connect power cord then turn the UPS on. Make sure that your spare
fuse meets the specicaon.
Baeries are discharged Allow the unit to recharge for at least 4 hours.
Unit has been damaged by a surge or spike. Contact Technical Support.
Soware is inacve The network cable is not connected. Connect the network cable to the UPS unit and a network port on the
hub.
Soware seng problem. Please read and follow NetAgent ulity instrucon during installaon
and operaon of the NetAgen soware, or contact technical support.
Fault code F09 Output Short :
Output circuit short.
Shut down the UPS
Your aached equipment may have problems, please remove them
and check again.
Fault code F12 Baery voltage is too low. Shutdown your computer and recharge the baery immediately.
Fault code F13 Baery is overcharged. Contact Technical Support.
Fault code F14 Overload occurs:
Your equipment requires more power than the
UPS can provide. It will shut down.
Shut o non-essenal equipment.
If this solves the overload problem, the UPS will transfer to normal
operaon.
Pb Pb
Reproducon without permission is prohibited.
