IOTA ETS20 DR Series User manual

IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed, including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. CAUTION – This unit operates in conjunction with more than one power supply output source. To reduce the
risk of electrical shock, disconnect both normal and emergency sources by turning o󰀨 the A.C. branch circuit.
2. CAUTION – This is a sealed unit with no servicable parts. Replace the entire unit when necessary.
3. DO NOT USE OUTDOORS. The ETS20 DR is for use with grounded, UL Listed xtures. Not for use in heated
air outlets or hazardous locations.
4. The ETS20 DR requires an unswitched A.C. power source of either 120 to 277 volts, 50/60Hz.
5. Do not mount near gas or electric heaters.
6. The ETS20 DR should be mounted in locations and at heights where it will not readily be subjected to tamper-
ing by unauthorized personnel.
7. The ETS20 DR is compatible with lighting xture loads on a 20 amp maximum circuit.
8. The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition, void
warranty, and result in non-compliance with UL specications.
9. Do not use this equipment for other than intended use.
10. Mount only to an approved electrical enclosure.
11. Install in accordance with the National Electrical Code and local regulations.
12. Installation and servicing should be performed by qualied personnel.
13. Lighting xture manufacturers, electricians, and end-users need to ensure product system compatibility before
nal installation.
SAVE THESE INSTRUCTIONS
INSTRUCTION MANUAL
ETS20 DR
SERIES HI-TEMP
20-AMP
EMERGENCY LIGHTING
CONTROL DEVICE
[phone] • iotaengineering.com

Page 2
INSTALLATION INSTRUCTIONS
CAUTION: Before installing, make certain the A.C. power is o󰀨 on both normal
and emergency circuits.
1. Mounting the ETS20 DR
The ETS20 DR is designed for connection to a junction box or electrical enclosure tted with a 7/8″
diameter (1/2″knockout). Remove the locking nut and insert the threaded nipple through the knockout.
Tighten the locking nut so that the unit is secured to the junction box or enclosure. See Illustration 1.
Illustration 1
2. Wiring
Refer to the wiring diagram on Page 4 for the appropriate Normal Circuit and Emergency Circuit wiring
connections. Install in accordance with the National Electrical Code and local regulations.
3. Remote Device Installation (optional)
The ETS20 DR features an optional Remote Device lead for connection to a switch or other device
to activate the unit and power the circuit from the emergency supply (such as a test switch or alarm
system). The Remote Device lead is a blue jumper loop that must be cut for connection to the remote
device. Do not cut this blue wire unless remote activation is desired.
NOTE: Perform Initial Testing (Section 4) before proceeding with Remote Device installation.
1) Cut the blue jumper lead.
2) Connect the two ends of the blue leads to the single pole contacts on the test switch or remote
device (observe the proper polarity of the blue wires and device connection, if necessary.) The device
must provide a normally closed, maintained, dry contact closure. The remote device must open the
circuit in order to force activation of the ETS20 DR into the Emergency Mode. If the device is a test
switch, it must be installed in an accessible location. Note: No more than (5) ETS20 DR units can be
installed in parallel with a remote device.
4. Initial Testing
After completing installation, verify that the ETS20 DR is functioning properly in both normal and emer-
gency operation. Testing should be conducted at a time and in a manner that does not a󰀨ect building
occupants and operations.
NOTE: Initial Testing should be performed with the blue jumper loop intact.
1) Turn on the circuit breaker in the emergency panel for the designated circuit. The Emergency Power
indicator (Red) should be lit. With only the emergency circuit on (Normal Power o󰀨), verify that all emer-
gency xtures are lit.
INSURE WIRING IS IN ACCORDANCE WITH THE NATIONAL ELECTRICAL CODE AND LOCAL REGULATIONS.
LOCKING NUT
JUNCTION BOX
ETS 20

Page 3
2) Temporarily disconnect and cap the wire connected to the Normal Switch Sense lead on the ETS20
DR. This will disable the normal control function and allow testing of the “fail-to-ON” function.
3) Turn on the circuit breaker in the normal panel of the designated circuit. The Normal Power (Green)
will be lit indicating that normal power is present and that emergency lighting is not required. Emergency
lighting should be o󰀨. Conrm automatic Emergency On operation by turning o󰀨 the normal circuit break-
er. The emergency lighting should immediately turn on.
4) With the normal circuit breaker o󰀨, reconnect the wire to the Switch In lead. Turn on the normal circuit
breaker. The control device now controls both the normal and emergency lighting together.
Ready to Test Indicator
After installation of the remote switch or device (Section 3), the remote device should be in normal mode
(contacts closed) and the Ready to Test (Yellow) indicator on the ETS20 DR will be lit. When the remote
device is activated, or the remote test switch is pushed, the ETS20 DR bypasses the control device set-
tings, allowing operation of the emergency load. To conrm that the ETS20 DR is operating properly, set
the wall switch or control device in the ‘OFF’ position. Designated emergency xtures should come on
when pressing the Test Button. Note: for testing, the ETS20 DR will only bypass the control devices
and operate the emergency xtures from the normal supply; it does not activate nor conrm readi-
ness of the auxiliary supply itself. The Ready to Test (Yellow) indicator will extinguish and the Emer-
gency Power (Red) indicator will remain lit.
If the Ready to Test Indicator is extinguished, it is an indication that Normal Power is lost or the unit is be-
ing forced into Emergency Power mode by the remote device or test switch. See Table A.
5. Labeling
A󰀩x a self-adhesive caution label in a visible location on the enclosure and on each xture controlled by
the ETS20 DR noting that the load is supplied from both normal and emergency power sources. Both
power sources must be disconnected before servicing the xture(s).
OPERATION
Normal Mode –A.C. power is present. Fixtures are operating normally and all indicators on the ETS20 DR will
be lit: Normal Power (Green), Emergency Power (Red), and Ready to Test (Yellow). See Table A.
Emergency Mode – The A.C. power fails. The ETS20 DR senses the A.C. power failure and automatically
activates the emergency load. All designated xtures are illuminated at full light output for as long as auxiliary
power is available regardless of the normal wall switch position. The Emergency Power Indicator (Red) on the
ETS20 DR is lit and the Normal Power (Green) and Ready to Test (Yellow) indicators are o󰀨. When the A.C.
power is restored, the ETS20 DR switches the system back to the Normal Mode. See page 1 of the Instruction
Manual.
TESTING & MAINTENANCE
The ETS20 DR is a maintenance free unit, however, periodic inspection and testing is required. Refer to the
NFPA 101, Life Safety Code and local codes for required emergency testing schedules.
Testing should be conducted following maintenance or re-working of any of the xtures connected to the
emergency circuit.
“Written records of testing shall be kept by the owner for inspection by the authority having jurisdiction.”
SERVICING SHOULD BE PERFORMED BY QUALIFIED PERSONNEL.
Consult Customer Service or visit www.iotaengineering.com for current warranty information.
READY TO TEST
(YELLOW)
NORMAL POWER
(GREEN)
EMERGENCY POWER
(RED)
ON
ON
ON
STATUS
DESCRIPTION
--
--
ON
All OK
Normal
Power
not present
Emergency
Power
not present
--
ON
ON --
--
--
Normal and
Emergency Power
not present
Test Button is pressed or
Fire Alarm/Remote Device
is open
ON
ON
--
TABLE A: ETS20 DR INDICATOR DESCRIPTIONS

Page 4
TYPICAL WIRING DIAGRAMS
For additional wiring information, consult Customer Service.
Rev. 2200
68388-021
1. ETS20 DR STANDARD WIRING FOR DUAL DIMMING ZONES
ETS-20-DR WIRING WITH DUAL DIMMING ZONES
ETS_20_DR_WIRES.EPS
EMERGENCY CIRCUIT
BLK (12 AWG) - NORMAL/EM POWER INPUT
NORMAL LINE
NORMAL NEUTRAL
EMERGENCY NEUTRAL
ETS20 DR
ZONE 1
NORMAL AND
EMERGENCY
LIGHTING LOAD
GRAY (18 AWG) - NORMAL/EM NEUTRAL
RED (12 AWG) - NORMAL/EM POWER OUTPUT
BLUE - REMOTE DEVICE JUMPER (OPTIONAL)
RED (18 AWG) - MASTER SWITCH SENSE
WHT (18 AWG) - NORMAL NEUTRAL
BLK (18 AWG) - NORMAL POWER SENSE
NORMAL
LIGHTING LOAD
ONLY
CUT BLUE JUMPER TO CONNECT WITH
REMOTE DEVICE (OPTIONAL)
The RED and BLACK wires of the ETS 20 DR are distinguished by wire gauge. Use the 12 AWG wires fo
r connection to the emergency circuit.
The BLACK (Normal Power Sense) lead should be connected to the line side of the Master Switch Control that serves the same area
as the emergency lighting, ensuring that the emergency lighting in the controlled area turns on during a localized power failure.
NEUTRAL BUS
FOR NORMAL PANEL
NEUTRAL BUS
FOR EMERGENCY PANEL
NORMAL
POWER
EMERGENCY
POWER
NORMAL
PANEL
EMERGENCY
PANEL
TRANSFER
SWITCH
N
G
BROWN (COMMON 1)
BROWN/WHITE (NORMALLY OPEN 1)
BROWN/BLACK (NORMALLY CLOSED 1)
ORANGE (COMMON 2)
ORANGE/WHITE (NORMALLY OPEN 2)
ORANGE/BLACK (NORMALLY CLOSED 2)
ZONE 1
DIMMER
CONTROL
VIOLET
GRAY
VIOLET
VIOLET
GRAY
GRAY
ZONE 2 LEADS
DUPLICATE ZONE 1
CONNECTIONS FOR
ZONE 2 DEVICE.
Cap unused lead.
MASTER
SWITCH
CONTROL
Observe proper polarity, if necessary. No more than (5) ETS 20 DR units may be installed in parallel with a remote device.
