IPC CT110 User manual

CT110 Quick guide
This guide is intended for quick consultation only and does not replace the user and maintenance manual.
Before using the machine, read the user and maintenance manual contained in the machine’s packaging thoroughly and strictly follow all the
instructions.
PREPARATION & OPERATION
1 2
6
54
PLDC01850
ON
CHEM
H2O
+
+
+
O
On
O
On
SELECT
O
On
O
On
SELECTSELECT
O
On
O
On
SELECTSELECT
O
On
O
On
SELECT
+
+
O
On
O
On
SELECT
3
O
On
O
On
SELECT
O
On
O
On
O
On
SELECT
STANDARD AUTOMATIC
ECONOMY

REPLACING THE SQUEEGEE BLADES
ATTACHING/REMOVING THE BRUSHES
Open the clip (Ref. 1).
Remove the two blade retainers (Ref. 2) by pushing them outwards then extracting them.
Remove the blade.
Reuse the same blade by reversing the edge in contact with the oor until all four edges are worn out, or replace with a new blade, tting it onto the
screws on the body of the squeegee.
Reposition the two blade pressing devices by centering the wider part of the slots on the squeegee body fastening pins, then push the blade pressing
devices inwards.
Close the hook again.
Attaching the brushes: THIS MUST BE DONE WITH THE MACHINE OFF, remove the side aps, then position the brushes under the head drive disk. Lift the right brush with your hands and turn it clockwise, locking it in
position on the drive disk. Lift the left brush with your hands and turn it anticlockwise, locking it in position on the drive disk.
Removing the brushes: THIS MUST BE DONE WITH THE MACHINE OFF, turn the right brush anticlockwise to release it from the drive disk. Turn the left brush clockwise to release it from the drive disk.
DAILY MAINTENANCE
Clean the dirty
water tank.
Check the suction lter is
undamaged and clean.
Check that the
detergent outlet lter
is clean.
Check that the
brushes are clean.
Check that the
squeegee is clean
and the blades are not
worn.
PLDC01850
1
2
24V
