ISOtunes Landscaper User manual

Table of Contents
ENGLISH (EN)
Location of Controls � � � � � � � � � � � � � � � � � � � � � � � � � �3
Power On/O � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �4
Bluetooth Pairing � � � � � � � � � � � � � � � � � � � � � � � � � � � � �5
Bluetooth Reset � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �6
Music & Volume � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �7
Line Input Option� � � � � � � � � � � � � � � � � � � � � � � � � � � � �7
Phone Calls � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �8
Charging � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �9
Legalities � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10
ESPAÑOL (ES)
Localización de los controles � � � � � � � � � � � � � � � � � �36
Encendido/apagado � � � � � � � � � � � � � � � � � � � � � � � � �37
Conexión Bluetooth� � � � � � � � � � � � � � � � � � � � � � � � � �38
Restablecimiento de Bluetooth � � � � � � � � � � � � � � � �39
Música y volumen � � � � � � � � � � � � � � � � � � � � � � � � � � �40
Opción de entrada de línea � � � � � � � � � � � � � � � � � � �40
Llamadas telefónicas� � � � � � � � � � � � � � � � � � � � � � � � �41
Carga � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �42
Legalities � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �43
AA TABLE OF CONTENTS

EN | 3
Location of Controls
1. Power Button
2. Volume Up Button
3. Volume Down Button
4. Multifunction Button (MFB)
5. LED Indicator Light
6. Line Input
7. Charging Port
2
5
431
6
76
ENGLISH (EN)

EN | 4
Power On/Off
Power On: Press and hold the power button
(1) (you will hear “Power On”)
Power Off: Press and hold the power button
(1) (you will hear “Power O”)
1

EN | 5
Bluetooth Pairing
Open the Bluetooth settings
on your device.
A B
Search for “ISOtunes
LANDSCAPER.” Pair and connect.
You will hear “Bluetooth
Connected” once connected.
Press and hold the Multifunction Button (4) to enable Bluetooth. You will hear
“Bluetooth On” and the headphones will automatically enter Pairing Mode.

EN | 6
Bluetooth Reset
Press and hold the Multifunction Button (4) for ten seconds. The Bluetooth LED (5)
will ash quickly eight times if successful.
4
5

EN | 7
Music & Volume
Play/Pause: Short Single Press MFB (4)
Next Track: Short Double Press MFB (4)
Previous Track: Short Triple Press MFB (4)
Volume Up: Press + button (2)
Volume Down: Press – button (3)
Line Input Option
To listen to music via the line input (6), use the
3.5mm audio cable included. Insert one end into the
ISOtunes LANDSCAPER and insert the other end into
your phone or other personal media device. Will not
work for phone calls with line input.
4
2
3
6

EN | 8
Phone Calls
Answer Call: Short Press MFB (4)
End Call: Long Press MFB (4)
Reject Call: Press and hold MFB (4)
Mute/Unmute Microphone: Short Press MFB (4)
4

EN | 9
Charging
This product is charged with a micro-USB charger and hold up to 40 hours of music
and talk time between charges.
Charge the ISOtunes LANDSCAPER by
plugging the included micro-USB cable
into the product and a USB Port (6). The
built in battery will charge, as indicated
by a solid blue light. The light will turn o
once charging is complete.
1 2
Only charge your ISOtunes LANDSCAPER with
a maximum 5 Volt charger. Using a charger
higher than 5 Volts could be dangerous and
may damage your ISOtunes LANDSCAPER
product. Be especially careful with “quick
charge” or “turbo charge” chargers, which often
supply 9, 12, or 15 Volts.
LED Indicator Light (5)
Solid Red = Charging
(Cable Plugged In)
No Light = Fully Charged
(Cable Plugged In)
6

EN | 10
ANSI S3.19-1974 Table (NRR Table)
Bluetooth® Input
FIG 1 FIG 2 FIG 3
Frequency, Hz 125 250 500 1000 2000 3150 4000 6300 8000 NRR
Grand Mean Attenuation, dB 16.0 18.8 26.1 32.5 35.3 39.6 43.0 41.6 40.6 24
Standard Deviation, dB 2.4 1.9 2.3 2.2 2.5 3.6 4.0 4.5 3.8
Requirement: Result
The maximum sound pressure level 73.9 dB(A) at -10 dBFS
Important
Please read, understand, and follow
all safety information.
Full manual can be found at
ISOtunes.com/manuals
Fitting
1. Pull the earcups apart
2. Place the product on your head
3. Adjust the earcup position by extending the headband to
ensure a good t around the ears
LEGALITIES
Fitting Introduction
Thank you for purchasing ISOtunes® LANDSCAPER professional
noise isolating headphones. These headphones have been
specically designed for use in noisy environments – allowing you
to block out much of the surrounding noise so that you can listen to
your music or talk on the phone with less interruption.
Noise Attenuation APPROVAL
This product has been tested to the European Safety Standard
EN 352-1:2020 and the ANSI S3.19-1974 standard for a hearing
protector, with a Single Number Rating (SNR) of 30 dB and a Noise
Reduction Rating (NRR) of 24 dB. Full testing details are available in
the Noise Attenuation section of this booklet.
ANSI S3.19-1974
The level of noise entering a person’s ear, when ISOtunes®
LANDSCAPER headphones are worn as directed, is closely
approximated by the dierence between the A-weighted
environmental noise level and the Noise Reduction Rating (NRR).
Improper t of this device will reduce its eectiveness in attenuating
noise. Consult the enclosed instructions for proper tting.
A1: Frequency (Hz)
A2: Mean Attenuation (dB)
A3: Standard Deviation (dB)
Example:
1. The surrounding noise level measured at the ear is 100 dB.
2. The NRR of ISOtunes® LANDSCAPER is 24 dB.
3. The noise level entering the ear is approximately equal to 76dB.
Please note that the NRR is based on the attenuation of continuous
noise and may not be an accurate indicator of the protection
attainable against impulsive noise, such as gunre.
SafeMax™ Technology
ISOtunes® LANDSCAPER incorporates SafeMax™ Technology,
therefore its volume output has been limited to 85 decibels (IT-33).
ISOtunes® devices with SafeMax™ Technology are OSHA, and ANSI
