User manual
www.jabra.com
Jabra®ARROW

USER MANUAL - LANGUAGES
ENGLISH - EUROPE (click here for manual)..........................4
ENGLISH - ASIA PACIFIC (Click here for manual)....................15
DANSK (Klik her for at se vejledningen) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
FRANÇAIS (Cliquez ici pour le manuel). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
DEUTSCH (Klicken Sie hier für Handbuch) . . . . . . . . . . . . . . . . . . . . . . . . . 46
РУССКИЙ (Щёлкните здесь, чтобы скачать
руководство) ...................................................58
YКРАЇНА (Клацніть тут для завантаження посібника) .......70
NEDERLANDS (Klik hier voor de handleiding)......................82
SUOMI (Avaa käyttöohje napsauttamalla tässä) . . . . . . . . . . . . . . . . . . 93
SVENSKA (Klicka här för bruksanvisning) .........................104
ITALIANO (Fare clic qui per il manuale) . . . . . . . . . . . . . . . . . . . . . . . . . . .115
ESPAÑOL (Haga clic aquí para obtener el manual)................127
ČESKY (Zde klikněte pro manuál).................................138
POLSKI (Kliknij tutaj, żeby przejść do instrukcji) . . . . . . . . . . . . . . . . . . .149
ΕΛΛΗΝΙΚΑ (Κάντε κλικ εδώ για το εγχειρίδιο) . . . . . . . . . . . . . . . . . . . . .160
TÜRKÇE (Kullanım kılavuzu için buraya tıklayın)..................172
MAGYAR (Kattintson ide a kézikönyvért) . . . . . . . . . . . . . . . . . . . . . . . . .183
ROMÂNĂ (Faceţi clic aici pentru manual) . . . . . . . . . . . . . . . . . . . . . . . .194

简体中文（单击此处查看手册） ............................226
繁體中文（按下此處檢視手冊） ............................236
日本語 (取扱説明書をご覧になるには、ここをクリック
してくだ さ い ) ..................................................246
한국어(설명서를 보려면 여기를 클릭하십시오) ............258
BAHASA MELAYU (Kullanım kılavuzu için buraya tıklayın) . . . . . . . .269
ภาษาไทย (คลิกที่นี่เพื่ออ่านคู่มือ) .......................................279

1
english
JABRA ARROW
Contents
THANK YOU....................................................2
ABOUT YOUR JABRA ARROW...................................2
WHAT YOUR HEADSET CAN DO ................................2
GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
CHARGE YOUR HEADSET.......................................4
TURNING YOUR HEADSET ON AND OFF . . . . . . . . . . . . . . . . . . . . . . . . 4
PAIRING IT WITH YOUR PHONE.................................4
CONNECTING WITH YOUR PHONE .............................5
WEARING STYLE ...............................................5
HOW TO .......................................................6
WHAT THE LIGHTS MEAN ......................................7
USING YOUR JABRA ARROW WITH TWO MOBILE DEVICES ......7
TROUBLESHOOTING & FAQ ....................................8
NEED MORE HELP?.............................................9
TAKING CARE OF YOUR HEADSET .............................10
GLOSSARY ....................................................11

2
english
JABRA ARROW
tHAnK YoU
Thank you for purchasing the Jabra ARROW headset.
We hope you enjoy it! This instruction manual will get you started
and ready to make the most of your headset.
ABoUt YoUR JABRA ARRoW
A. Answer/end button
B. On/o slider
C. Charging socket
D. Earhook
E. LED light
F. Eargel
jabra
D
B
A
C
j
a
b
r
a
F
E
WHAt YoUR HeADset CAn Do
Your Jabra ARROW lets you do all this:
- Answer calls
- End calls
- See battery status
- See connection status
- Reject calls*
- Voice dialling*
- Last number redial*
- Transfer calls
* Phone dependent

3
english
JABRA ARROW
Specications
- Talk time 4.5 hours
- Standby time 8 days
- Weight 9 gram
- Size: 38.5mm x 18mm x 23.5mm (L x W x H)
- Digital sound enhancement via DSP technology
- Noise reduction on transmitted audio
- Automatic volume adjustment on receive audio
- Acoustic shock protection
- Rechargeable battery with charging option from AC power
supply, PC via USB cable or car charger
- Qualified for Specification version 2.1 + EDR
(enhanced data rate), supporting Headset and Hands-free
Profiles for phone conversations
- e-SCO for enhanced audio quality
- 128 bit encryption
- Operating range up to 10 meters (approximately 33 feet)
GettInG stARteD
You should follow three steps before using your headset:
1 Charge your headset
2 Activate on your mobile phone (refer to the
manual for your mobile phone)
3 Pair your headset to your mobile phone
The Jabra ARROW is easy to operate. The answer/end button on
the headset performs dierent functions depending on how long
you press it.
Instruction Duration of press
Tap Press briey (max 1 second)
Press Approx: 1-3 seconds
Press and hold More than 5 seconds

4
english
JABRA ARROW
CHARGe YoUR HeADset
Make sure that your headset is fully charged for two hours before
you start using it. Use one of the charging solutions provided in
the box. When the light is solid, your headset is charging. When
the headset is fully charged the light is then turned o.
Use only the charger provided in the box – do not use chargers
from any other devices as this may damage your headset.
Please note: The lifetime of the battery will be signicantly
reduced if your device is left uncharged for a long period. We
therefore recommend that you recharge your device at least once
a month.
tURnInG YoUR HeADset on AnD oFF
- Slide the on/o button forward on the side of the headset to
turn on the headset. The LED will ash for a second when the
headset is on.
- Slide the on/o button backward to turn o the headset.
PAIRInG It WItH YoUR PHone
Headsets are connected to phones using a procedure called
‘pairing’. By following a few simple steps, a phone can be paired
with a headset in a matter of minutes.
1 Put the headset in pairing mode
- When you turn on your Jabra ARROW for the rst time, the
headset will automatically start up on pairing mode – i.e. it is
discoverable for your phone. When the headset is in pairing
mode the light is solid.
2 Set your phone to‘discover’the Jabra ARROW
- Follow your phone’s instruction guide. First make sure that
is activated on your mobile phone. Then set your
phone to discover new devices. This usually involves going
to a‘setup,’‘connect’or‘ ’menu on your phone and
selecting the option to‘discover’or‘add’a device.*
* Phone dependent

5
english
JABRA ARROW
3 Your phone will nd the Jabra ARROW
- Your phone will nd the headset under name“Jabra ARROW”.
Your phone then asks if you want to pair with the headset.
Accept by pressing‘Yes’or‘OK’on the phone. You may be asked
to conrm with a passkey or PIN. Then use 0000 (4 zeros). Your
phone will conrm when pairing is complete and the light on
the headset will ash a few times to conrm pairing.
CONNECTIVITY
SELECT
MobilSurf
BLUET O OT H
Infrared port
Wap options
Synchronization
Networks
DEVICES FOUND
Jabra ARROW
Jabra ARROW
OK
Passkey:
****
HANDSFREE
SELECT
Jabra ARROW
added.
The handsfree is
now ready for use
SELECT
Manual pairing mode
If you wish to use the headset with a dierent phone, or if the
pairing process was interrupted, you can manually set the headset
to pairing mode.
Make sure the headset is on. Press and hold the answer/end
button for approximately 5 seconds until the icon
turns from a steady light to a ashing light. Then repeat steps
2 and 3 in the above pairing guide.
ConneCtInG WItH YoUR PHone
Pairing is only needed the rst time a headset and phone are
used together. When the headset and phone have been paired
once, they will automatically connect when the headset is on and
is activated on the phone. The headset can be used
when it is“connected” to the phone. If the devices are paired, but
do not immediately connect, tap the answer/end button.
WeARInG stYLe
The Jabra ARROW can be worn on either ear with or without ear
hook. The ear hook can be removed and the headset can be worn
with one of the Ultimate Comfort EargelsTM. Replace the standard
ear gel with a small, medium or large Ultimate Comfort EargelsTM
included in the pack. You can twist the ear gel slightly to optimize
t and comfort.

6
english
JABRA ARROW
HoW to
Answer a call
- Tap the answer/end button on your headset to answer a call.
End a call
- Tap the answer/end button to end an active call.
Reject a call*
- Press the answer/end button when the phone rings to reject an
incoming call. Depending on your phone settings, the person
who called you will either be forwarded to your voice mail or
will hear a busy signal.
Make a call
- When you make a call from your mobile phone, the call will
(subject to phone settings) automatically transfer to your
headset. If your phone does not allow this feature, tap on the
Jabra ARROW’s answer/end button to transfer the call to the
headset.
Activate voice dialling*
- Press the answer/end button. For best results, record the voice
dialling tag through your headset. Please consult your phone’s
user manual for more information about using this feature.
Call waiting and placing a call on hold*
- This lets you put a call on hold during a conversation and answer
a waiting call.
- Press the answer/end button once to put the active call on hold
and answer the waiting call.
- Press the answer/end button to switch between the two calls.
- Tap the answer/end button to end the active conversation.
Redial last number*
- Double tap the answer/end button when the headset is on and
the phone is not in use.
* Phone dependent

7
english
JABRA ARROW
Volume Control
- Jabra ARROW adjusts volume automatically according to level
of background noise and incoming audio to have a suitable
speaker volume level. If you want to adjust volume manually
please use volume controls on phone*.
Battery indicator
- Tap the answer/end button to see the battery level.
What you see Talk time left
3 ashes 1-4.5 hours
2 ashes 10 min. – 1 hour
1 ash <10 min
WHAt tHe LIGHts MeAn
What you see Call/connection status
Solid light In pairing mode
Slow triple ash Not connected to phone
Quick double ash Incoming or outgoing call in
headset
4 ashes
(repeated every 5 seconds)
Low battery
UsInG YoUR JABRA ARRoW WItH tWo MoBILe
DeVICes
The Jabra ARROW is capable of having two mobile phones (or
devices) connected to the headset at the same time.
This will give you the freedom of having only one headset to
operate both of your mobile phones.
How to pair your Jabra ARROW with 2 devices:
1 Pair device number 1 with your headset using the pairing
instruction above for re-pairing your headset (if device 1 is
paired to your headset already go to step 2)
* Phone dependent

8
english
JABRA ARROW
2 Turn your headset off manually by pressing the Answer/End
button for 4-5 seconds
3 Pair device number 2 with your headset using the same pairing
instruction again
4 Connect to device 1 again
Please note that it is important to connect to device 1 again after
pairing device 2 to ensure connection to both devices.
tRoUBLesHootInG & FAQ
I hear crackling noises
- is a radio technology, which means it is sensitive to
objects between the headset and the connected device. It is
designed for the headset and the connected device to be used
within 33 feet (10 meters) of each other, with no major objects
in the way (walls, etc.).
I cannot hear anything in my headset
- Increase the volume on your phone.
- Ensure that the headset is paired to the device that you wish
to use.
- Make sure your phone is connected to the headset by tapping
the Answer/End button.
I am having pairing problems
- You may have deleted your headset pairing connection in your
mobile phone.
Follow the pairing instructions.
I am experiencing low battery standby time
- Turn o headset in between calls. Your headset will quickly and
automatically reconnect with your phone when powered on so
you do not miss a call.
- Make sure the headset is only paired with the devices you use
it with. Eg. if you get a new phone it is recommended that you
reset the headset before pairing it with the new phone (see
instructions below).

9
english
JABRA ARROW
I want to reset the headset
- It is possible to reset and test the headset by the following:
’Press and hold’the answer/end button while at the same time
turning the headset‘on’by sliding the on/o button to the‘on’
position. Continue to hold the answer/end button until the
light ashes 5 times. In this mode, the pairing list is reset, and
you can test if the headset works as you will be able to hear
audio in the speaker from the microphone.
- The next time you power on, the headset will go into pairing
mode as the rst time you powered your Jabra ARROW on.
Will the Jabra ARROW work with other equipment?
- The Jabra ARROW is designed to work with mobile
phones. It can also work with other devices that are
compliant with version 1.1 or higher and support
a headset and /or hands-free prole.
I cannot use Reject call, call on hold, Redial or voice dialling
- These features are dependent on the ability of your phone
to support a hands-free prole. Even if the hands-free prole
is implemented reject call, call hold and voice dialling are
optional features which are not supported by all devices. Please
consult your device manual for details.
neeD MoRe HeLP?
1. Web: www.jabra.com
(for the latest support info and online User Manuals)
2. E-mail:
Deutsch suppor[email protected]
English suppor[email protected]
Español suppor[email protected]
Français suppor[email protected]
Italiano suppor[email protected]
Nederlands suppor[email protected]
Polska suppor[email protected]
Scandinavian suppor[email protected]
Россия suppor[email protected]
Information: [e-mail]

10
english
JABRA ARROW
3. Phone:
Belgique/Belgie 00800 722 52272
Danmark 70 25 22 72
Deutschland 0800 1826756
Die Schweiz 00800 722 52272
España 900 984572
France 0800 900325
Italia 800 786532
Luxembourg 00800 722 52272
Nederland 0800 0223039
Norge 800 61272
Österreich 00800 722 52272
Polska 0801 800 550
Portugal 00800 722 52272
Suomi 00800 722 52272
Sverige 020792522
United Kingdom 0800 0327026
Россия [phone]
International 00800 722 52272
tAKInG CARe oF YoUR HeADset
- Always store the Jabra ARROW with the power o and safely
protected.
- Avoid storage at extreme temperatures (above 45°C/113°F –
including direct sunlight – or below -10°C/14°F). This can shorten
battery life and may aect operation. High temperatures may
also degrade performance.
- Do not expose the Jabra ARROW to rain or other liquids.

11
english
JABRA ARROW
GLossARY
1 is a radio technology that connects devices, such
as mobile phones and headsets, without wires or cords over
a short distance (approx. 10 meters/33 feet). is safe
to use. It is secure too, so once a connection has been made
no-one can listen in and there is no interference from other
devices either. Get more information at
www.bluetooth.com.
2 proles are the dierent ways that
devices communicate with other devices. phones
support the headset prole, the hands-free prole or both. In
order to support a certain prole, a phone manufacturer must
implement certain mandatory features within the phone’s
software.
3 Pairing creates a unique and encrypted link between two
devices and lets them communicate with each other.
devices will not work if the devices have not been
paired.
4 Passkey or PIN is a code that you enter on your enabled
device (e.g. a mobile phone) to pair it with your Jabra ARROW.
This makes your device and the Jabra ARROW recognize each
other and automatically work together.
5 Standby mode is when the Jabra ARROW is passively waiting
for a call. When you‘end’a call on your mobile phone, the
headset goes into standby mode.
Dispose of the product according
to local standards and regulations.
www.jabra.com/weee

1
english
JABRA ARROW
Contents
THANK YOU....................................................2
ABOUT YOUR JABRA ARROW...................................2
WHAT YOUR HEADSET CAN DO ................................2
GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
CHARGE YOUR HEADSET.......................................4
TURNING YOUR HEADSET ON AND OFF . . . . . . . . . . . . . . . . . . . . . . . . 4
PAIRING IT WITH YOUR PHONE .................................4
CONNECTING WITH YOUR PHONE .............................5
WEARING STYLE ...............................................5
HOW TO .......................................................6
WHAT THE LIGHTS MEAN ......................................7
USING YOUR JABRA ARROW WITH TWO MOBILE DEVICES ......7
TROUBLESHOOTING & FAQ ....................................8
NEED MORE HELP?.............................................9
TAKING CARE OF YOUR HEADSET ..............................9
GLOSSARY ....................................................10

2
english
JABRA ARROW
tHAnK YoU
Thank you for purchasing the Jabra ARROW headset.
We hope you enjoy it! This instruction manual will get you started
and ready to make the most of your headset.
ABoUt YoUR JABRA ARRoW
A. Answer/end button
B. On/o slider
C. Charging socket
D. Earhook
E. LED light
F. Eargel
jabra
D
B
A
C
j
a
b
r
a
F
E
WHAt YoUR HeADset CAn Do
Your Jabra ARROW lets you do all this:
- Answer calls
- End calls
- See battery status
- See connection status
- Reject calls*
- Voice dialling*
- Last number redial*
- Transfer calls
* Phone dependent

3
english
JABRA ARROW
Specications
- Talk time 4.5 hours
- Standby time 8 days
- Weight 9 gram
- Size: 38.5mm x 18mm x 23.5mm (L x W x H)
- Digital sound enhancement via DSP technology
- Noise reduction on transmitted audio
- Automatic volume adjustment on receive audio
- Acoustic shock protection
- Rechargeable battery with charging option from AC power
supply, PC via USB cable or car charger
- Qualified for Specification version 2.1 + EDR
(enhanced data rate), supporting Headset and Hands-free
Profiles for phone conversations
- e-SCO for enhanced audio quality
- 128 bit encryption
- Operating range up to 10 meters (approximately 33 feet)
GettInG stARteD
You should follow three steps before using your headset:
1 Charge your headset
2 Activate on your mobile phone (refer to the
manual for your mobile phone)
3 Pair your headset to your mobile phone
The Jabra ARROW is easy to operate. The answer/end button on
the headset performs dierent functions depending on how long
you press it.
Instruction Duration of press
Tap Press briey (max 1 second)
Press Approx: 1-3 seconds
Press and hold More than 5 seconds

4
english
JABRA ARROW
CHARGe YoUR HeADset
Make sure that your headset is fully charged for two hours before
you start using it. Use one of the charging solutions provided in
the box. When the light is solid, your headset is charging. When
the headset is fully charged the light is then turned o.
Use only the charger provided in the box – do not use chargers
from any other devices as this may damage your headset.
Please note: The lifetime of the battery will be signicantly
reduced if your device is left uncharged for a long period. We
therefore recommend that you recharge your device at least once
a month.
tURnInG YoUR HeADset on AnD oFF
- Slide the on/o button forward on the side of the headset to
turn on the headset. The LED will ash for a second when the
headset is on.
- Slide the on/o button backward to turn o the headset.
PAIRInG It WItH YoUR PHone
Headsets are connected to phones using a procedure called
‘pairing’. By following a few simple steps, a phone can be paired
with a headset in a matter of minutes.
1 Put the headset in pairing mode
- When you turn on your Jabra ARROW for the rst time, the
headset will automatically start up on pairing mode – i.e. it is
discoverable for your phone. When the headset is in pairing
mode the light is solid.
2 Set your phone to‘discover’the Jabra ARROW
- Follow your phone’s instruction guide. First make sure that
is activated on your mobile phone. Then set your
phone to discover new devices. This usually involves going
to a‘setup,’‘connect’or‘ ’menu on your phone and
selecting the option to‘discover’or‘add’a device.*
* Phone dependent

5
english
JABRA ARROW
3 Your phone will nd the Jabra ARROW
- Your phone will nd the headset under name“Jabra ARROW”.
Your phone then asks if you want to pair with the headset.
Accept by pressing‘Yes’or‘OK’on the phone. You may be asked
to conrm with a passkey or PIN. Then use 0000 (4 zeros). Your
phone will conrm when pairing is complete and the light on
the headset will ash a few times to conrm pairing.
CONNECTIVITY
SELECT
MobilSurf
BLUET O OT H
Infrared port
Wap options
Synchronization
Networks
DEVICES FOUND
Jabra ARROW
Jabra ARROW
OK
Passkey:
****
HANDSFREE
SELECT
Jabra ARROW
added.
The handsfree is
now ready for use
SELECT
Manual pairing mode
If you wish to use the headset with a dierent phone, or if the
pairing process was interrupted, you can manually set the headset
to pairing mode.
Make sure the headset is on. Press and hold the answer/end
button for approximately 5 seconds until the icon
turns from a steady light to a ashing light. Then repeat steps
2 and 3 in the above pairing guide.
ConneCtInG WItH YoUR PHone
Pairing is only needed the rst time a headset and phone are
used together. When the headset and phone have been paired
once, they will automatically connect when the headset is on and
is activated on the phone. The headset can be used
when it is“connected” to the phone. If the devices are paired, but
do not immediately connect, tap the answer/end button.
WeARInG stYLe
The Jabra ARROW can be worn on either ear with or without ear
hook. The ear hook can be removed and the headset can be worn
with one of the Ultimate Comfort EargelsTM. Replace the standard
ear gel with a small, medium or large Ultimate Comfort EargelsTM
included in the pack. You can twist the ear gel slightly to optimize
t and comfort.

6
english
JABRA ARROW
HoW to
Answer a call
- Tap the answer/end button on your headset to answer a call.
End a call
- Tap the answer/end button to end an active call.
Reject a call*
- Press the answer/end button when the phone rings to reject an
incoming call. Depending on your phone settings, the person
who called you will either be forwarded to your voice mail or
will hear a busy signal.
Make a call
- When you make a call from your mobile phone, the call will
(subject to phone settings) automatically transfer to your
headset. If your phone does not allow this feature, tap on the
Jabra ARROW’s answer/end button to transfer the call to the
headset.
Activate voice dialling*
- Press the answer/end button. For best results, record the voice
dialling tag through your headset. Please consult your phone’s
user manual for more information about using this feature.
Call waiting and placing a call on hold*
- This lets you put a call on hold during a conversation and answer
a waiting call.
- Press the answer/end button once to put the active call on hold
and answer the waiting call.
- Press the answer/end button to switch between the two calls.
- Tap the answer/end button to end the active conversation.
Redial last number*
- Double tap the answer/end button when the headset is on and
the phone is not in use.
Volume Control
- Jabra ARROW adjusts volume automatically according to level
of background noise and incoming audio to have a suitable
speaker volume level. If you want to adjust volume manually
please use volume controls on phone*.
* Phone dependent
