Jabra Contour LX-G User manual

For truly innovative features in a traditional call center headset, choose the GN Netcom
Contour LX-G. With its variable capsule adjustment, Contour LX-G offers call center pro-
fessionals the utmost in fit, comfort and stability, with a patented hinge that brings the
capsule to a gentle but snug rest behind the earlobe. The Contour LX-G also features a
noise-canceling microphone for crystal-clear communication, a non-kink flexible microphone
boom for long-term reliability and a choice of comfortable eartips for all-day wearability.
• Noise-canceling microphone
• Over-the-ear comfort
• Fully adjustable capsule
• Flexible microphone boom
• Foam EarTiplets™and Latex eartips
• Two-year “No Fine Print” warranty
CONTOUR LX-G
OPTIMUM CALL CENTER COMFORT AND CLARITY.
GN Netcom
*UNX-340 CONTOUR LX DS Net copy 5/26/00 10:41 AM Page 1 james Yosemite:Active Jobs:GNN Stuph:Disc 3:Unx-340 Contour LX DS Net .:

For more information:
GN Netcom, Inc.
77 Northeastern Blvd. Nashua NH 03062
1-800-826-4656 www.gnnetcom.com
Printed in USA.
10/99
GNI-136A
Standard Features LX-G
Universal Telephone Interface ∆
Noise-Canceling Microphone ∆
Flexible Microphone Boom ∆
Over-The-Ear Comfort ∆
Adjustable Lobe Hinge™ ∆
Foam & Latex Ear Tiplets ∆
GN Netcom-compatible Quick Disconnect ∆
Two-Year “No Fine Print” Warranty ∆
Great Sound, Comfort, Durability ∆
Contour LX-G Transmit Specifications
Microphone: Noise-canceling electret
Frequency Response: 300-3000 Hz
Distortion: Less than 5%
Current Consumption: 250 µa @ 3 V (DC)
Operating Voltage: 1.5-10 V (DC)
Receive Specifications
Speaker: Magnetic
Input Impedance: 300 ohms (typical)
Frequency Response: 300-3,300 Hz
Automatic Gain Control (AGC)
Threshold Level with amplifier: -41 dBV with an input at 1 kHz
Volume Control Range: 18 dB (typical)
Maximum Output: 114 dB spl peak unit
General Specifications
Operating Temperature: 0°–50°C
Polarity: Non-polar in amplified applications
Dielectric Withstand Voltage: 5,000 V AC or 7,000 V DC
Safety: Registered to UL 1459
FCC Parts 68 Registered
OSHA Part 1910 subpart S
CSA C22.2 No. 225-M90
The Contour LX-G headset features a noise-canceling microphone for call clarity,
our patented Adjustable Lobe Hinge for custom comfort and stability, and a choice
of foam or latex eartip styles.
The MPA-II Multi-Purpose
Amplifier works on most
phone systems with a modu-
lar handset connector. The
easiest amplifier to set up
and use, it features a sliding
volume control, headset/
handset switch, mute switch
and a built-in headset stand.
An optional on-line indicator
signals when the headset is
in use.
Our 0686 In-line Amplifiers
provide a cost-effective option
for standard carbon applica-
tions. Incredibly compact, they
feature a rotary wheel for a
broad range of volume adjust-
ments. Also available with a
mute button, 0686M.
The 0452 Two-Prong
Amplifier is designed for
telephones equipped with a
two-prong headset port. Its
3-position volume control
locks your volume preference
in place.
Also available: The 0911 Two-Prong 6-Wire Amplifier, for push-to-talk dispatch/911 environments;
and the HT One Headset Telephone (HT-1), the first professional-quality telephone with an inte-
grated headset—ideal for PBX and CTI applications.
There’s a GN Netcom amplifier for every need and every application. Like our headsets,
all GN Netcom amplifiers feature a two-year warranty.
