Jabra rox wireless User manual

jabra.com/roxwireless
User Manual
JABRA ROX WIRELESS

© 2013 GN Netcom A/S. All rights reserved. Jabra®is a registered
trademark of GN Netcom A/S. All other trademarks included herein
are the property of their respective owners. The Bluetooth®word
mark and logos are owned by the Bluetooth SIG, Inc. and any use
of such marks by GN Netcom A/S is under license. (Design and
specifications subject to change without notice).
Declaration of Conformity can be found on www.jabra.com/CP/US/declarations-of-
conformity
MADE IN CHINA
MODEL: OTE16

3
english
jabra rox WIrELESS
CONTENTS
1. WELCOME.......................................... 4
2. HEADSET OVERVIEW......................... 5
2.1 INCLUDED ACCESSORIES
3. HOW TO WEAR.................................. 6
3.1 CHANGING EARGELS
3.2 WEARING THE EARWINGS
3.3 WEARING THE FITCLIP
3.4 HOWTOWEAR VIDEOS
3.5 MAGNETIC EARBUDS
4. HOW TO CHARGE THE BATTERY..... 10
5. HOW TO CONNECT...........................11
5.1 CONNECT WITH A BLUETOOTH DEVICE
5.2 CONNECT WITH AN NFC DEVICE
5.3 CONNECT MULTIPLE DEVICES
6. HOW TO USE ...................................13
6.1 MULTIPLE CALL HANDLING
6.2 LIST OF VOICE GUIDANCE
7. SUPPORT..........................................18
7.1 FAQ
7.2 HOW TO CARE FOR YOUR HEADSET
8. TECHNICAL SPECIFICATIONS ...........19

4
english
jabra rox WIrELESS
1. WELCOME
Thank you for using the Jabra Rox Wireless. We
hope you will enjoy it!
JABRA ROX WIRELESS FEATURES
High definition Dolby® Digital Plus enhanced
sound with the exclusive Jabra Sound App
Cable controls for easy music and call
management
Life proof: weather and dust resistant
Premium materials: Kevlar reinforced cable
design, solid steel earbuds
Magnetic earbuds: Save battery when the
headset is not in use
NFC for easy pairing

5
english
jabra rox WIrELESS
2. HEADSET OVERVIEW
2.1 INCLUDED ACCESSORIES
4 ColorCore EarGelsTM 3 EarWings
(Small, medium, large)
USB cable
ColorCore
EarGelTM
Volume up
button
Multi-function
button
Volume down
button
NFC zone
(button side)
LED
indicator
Charging
cover Magnetic
earbuds
Fitclip
(optional
wearing
style)
Charging cover
Charging
port
Microphone

6
english
jabra rox WIrELESS
3. HOW TO WEAR
jabra
jabra
3.1 CHANGING EARGELS
Choose between 4 Colorcore Eargels for optimal
fit and comfort.

7
english
jabra rox WIrELESS
3.2 WEARING THE EARWINGS
Choose between 3 EarWing sizes for optimal fit
and stability.
1. Align the L or R on the EarWing with the L or R
on the earbud and gently pull the EarWing onto
the earbud. Adjust by rotating, if needed.
2. When wearing the headset, the EarWing fits into
the ridge of the ear. Ensure the EarWing does
not cover the microphone.

8
english
jabra rox WIrELESS
3.3 WEARING THE FITCLIP
Attach the fitclip to the cable, and adjust for
optimal fit.
jabra
jabra
3.4 HOWTOWEAR VIDEOS
You can watch how-to-wear instructional videos
for the ColorCore EarGelsTM, EarWings and fitclip at
jabra.com/roxwireless.

9
english
jabra rox WIrELESS
3.5 MAGNETIC EARBUDS
The earbuds are magnetic. Join or separate them
to turn Standby mode on/off, or end/answer a
call.
Standby mode ON Standby mode OFF
jabra
jabra
NOTE:The headset will power off after 5 minutes when the
magnetic earbuds are separated and the headset is not
connected to a mobile device.

10
english
jabra rox WIrELESS
4. HOW TO CHARGE THE
BATTERY
Remove the charging cover on the right earbud to
expose the micro-USB port. Plug the USB cable into
the headset and the PC to begin charging.
jabra
It takes approx. 2.5 hours to fully charge the
headset.
NOTE:For safety reasons, it is recommended not to use the
headset while it is charging.

11
english
jabra rox WIrELESS
5. HOW TO CONNECT
5.1 CONNECT WITH A BLUETOOTH DEVICE
1. Ensure the headset earbuds are separated.
2. Press and hold (5 secs) the Multi-function
button until the LED rapidly flashes blue.
3. Wear the headset, and follow the voice-guided
pairing instructions to pair to your Bluetooth
device.
NOTE:After you have connected once, simply turn on the device
to connect automatically.
jabra

12
english
jabra rox WIrELESS
5.2 CONNECT WITH AN NFC DEVICE
1. Ensure that NFC is enabled on your mobile
device.
2. Ensure that the magnetic earbuds are separated.
3. Slowly slide the NFC zone of the headset (button
side of the control box) directly against the NFC
device until an NFC connection is confirmed.
5.3 CONNECT MULTIPLE DEVICES
It is possible to connect multiple mobile devices to
the headset using Bluetooth or NFC.
If two mobile devices are connected to the headset
at the same time and one of the devices loses
connection, the Multi-function button will control
the remaining connected device (Pause/Play for
Music and Answer/End for calls). To reconnect the
disconnected device go to it’s Bluetooth menu and
reconnect.
NFC zone

13
english
jabra rox WIrELESS
6. HOW TO USE
Volume up
button
Multi-function
button
Volume down
button
NFC zone
(button side)
LED indicator
Standby on/
off
Fitclip
(optional
wearing
style)
ColorCore
EarGelTM
Charging
cover

14
english
jabra rox WIrELESS
FUNCTION ACTION
jabra
Standby mode
on/off
Join/separate the Magnetic
earbuds
Turn on/off
Press and hold (3 sec) the Multi-
function button until the LED
flashes
Play/pause
music Tap the Multi-function button
Answer/end
call
Tap the Multi-function button,
or separate/join the magnetic
earbuds
Reject call Double-tap the Multi-function
button
Redial last
number
Double-tap the Multi-function
button when not on a call

15
english
jabra rox WIrELESS
Adjust volume Tap the Volume up or Volume
down button
Mute Tap the Volume up and Volume
down button at the same time
Skip track
forward
Press and hold (2 secs) the
Volume up button
Skip track back
Press and hold (2 secs) the
Volume back button until you
hear a beep, and press and hold
the Volume back button again
Restart track Press and hold (2 secs) the
Volume back button
Battery status
Tap the Volume up or Volume
down button when not on a call
or listening to music

16
english
jabra rox WIrELESS
6.1 MULTIPLE CALL HANDLING
The headset can accept and handle multiple calls
simultaneously.
FUNCTION ACTION
End current call and
answer incoming call
Tap the Multi-
function button
Switch between held call
and active call
Press and hold (2
secs) the Multi-
function button
Put current call on hold
and answer incoming call
Press and hold (2
secs) the Multi-
function button
Reject incoming call,
when on a call
Double-tap the
Multi-function
button

17
english
jabra rox WIrELESS
6.2 LIST OF VOICE GUIDANCE
CLICK TO LISTEN WHAT YOU HEAR
To connect Jabra Rox wireless, go to
the Bluetooth menu on your phone and
select it from the list
Connected
Two devices connected
Disconnected
Call ended
Redialling
Recharge battery
Battery low
Battery medium
Battery full
Muted
Unmuted

18
english
jabra rox WIrELESS
7. SUPPORT
7.1 FAQ
View the comprehensive FAQ on Jabra.com/roxwireless
Q Why do I hear crackling noises?
A Bluetooth is a radio technology that is sensitive to
objects between the headset and the connected
device. Ensure the headset and the connected device
are within range (up to 10m/33ft).
Q What is the range of the headset?
A The Jabra Rox Wireless supports the following maxi-
mum ranges:
10m/33ft.
Q Why do I not hear anything?
A You might need to increase the speaker volume, or
ensure that the headset is connected to a device.
Q I am having Bluetooth connection problems
A Check your mobile device’s Bluetooth menu and
delete/forget the headset. Re-connect the headset to
your Bluetooth device following the Bluetooth connec-
tion instructions.
7.2 HOW TO CARE FOR YOUR HEADSET
Always store the headset with the power off
and safely protected.
Avoid storage at extreme temperatures (above
65°C/149°F or below -10°C/14°F). This can
shorten battery life and may affect the headset.

19
english
jabra rox WIrELESS
8. TECHNICAL
SPECIFICATIONS
JABRA ROX WIRELESS SPECIFICATION
Weight: 19g
Dimensions: H 16.5mm x W 20mm x D
16mm
Microphones: MEMS microphone
Speaker: 6 mm dynamic speaker
Operating range: 10m/33ft (phone dependent)
Bluetooth version: 4.0
Paired devices: Up to 8, connected to two at
the same time (MultiUse™)
Supported Bluetooth
profiles:
A2DP (v1.2), Hands Free Profile
(v1.6), Headset profile (v1.2),
AVRCP (v1.4)
Talk/music time: Up to 5.5 hours
Standby time: Up to 18 days
Operating temperature: -10°C to 55°C (14°F to 133°F)
Storage temperature: -10°C to 65°C (14°F to 149°F)
Pairing passkey or PIN: 0000

20
english
jabra rox WIrELESS
REV B
www.jabra.com/roxwireless
