Installation/Operation Instructions
for
Shower Towers
EC30000 Ristorre™ Onda™
EC31000 Ristorre™ Ovale™
EC33000 Ristorre™ Metallo™
Installer: Leave this manual for homeowner.
Homeowner: Read this manual and keep for future reference.
Save These Instructions for Future Use.
Complete and mail-in the product registration card provided with your unit.
Write and save the model and serial number of your unit.
Metallo™Onda™Ovale™
Copyright © by Jacuzzi Whirlpool Bath FZ71000B • 09/07

Jacuzzi Whirlpool Bath: Shower Towers Page 2 FZ71000B • 09/07
SAFETY INSTRUCTIONS
WARNING: WHEN USING THIS UNIT, BASIC PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING
THE FOLLOWING:
DANGER: DO NOT PLACE OR USE ELECTRICALLY CONNECTED DEVICES, SUCH AS TELEVISION, RADIO,
OR STEREO SPEAKERS, LIGHTS, HAIR DRYERS, OR TELEPHONES, WITHIN 1.5 M (5 FEET) OF SHOWER.
Owner's Record
Date Purchased ____________________________________________________________
Purchased From ____________________________________________________________
Installed By ________________________________________________________________
Model_____________________________________________________________________
IMPORTANT: Read all instructions before beginning installation. Consult local codes for requirements.
CONTENTS
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Component Identication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Common Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Finish Wall Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Assemble and Install Shower Tower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Warranty
NOTE: MINIMUM WATER PRESSURE FOR THESE SYSTEMS IS 40 PSI.

Jacuzzi Whirlpool Bath: Shower Towers Page 3 FZ71000B • 09/07
Ristorre™ Ovale™ Shower Tower — Specications
DIMENSIONS
3" ( 76 mm) D (Depth)
10-1/4" ( 260 mm) W
46-5/8" (1184 mm) H
PRODUCT WEIGHT
22 lb
(10 kg)
SHIPPING WEIGHT
27 lb
(13.3 kg)
Product specications are subject to change without
notice.
Minimum Working Water Pressure 21.76 psi (1.5 bar)
Maximum Working Water Pressure 72.52 psi (5.0 bar)
Recommended Working Water Pressure 43.51 psi (3.0 bar)
Maximum Working Water Temp. 140-158° F (60 – 70° C)
Minimum Working Water Temp. 41-68° F (5-20° C)
Recommended Working Temp. 100° F (38° C)
Under water pressure at
21.76 psi (1.5 bar)
Flow Rate of Hand Shower 1.61 US gal/min (6.1 L/min)
Flow Rate of Wall Mount 1.69 US gal/min (6.4 L/min)
Flow Rate of Body Jet 1.66 US gal/min (6.3 L/min)
Flow Rate of Temp Check Spout 1.69 US gal/min (6.4 L/min)
Optional-Supplied
Temperature
Check Spout

Jacuzzi Whirlpool Bath: Shower Towers Page 4 FZ71000B • 09/07
DIMENSIONS
3" ( 76 mm) D (Depth)
13-1/2" ( 343 mm) W
51-1/4" (1302 mm) L
PRODUCT WEIGHT
25 lb
(11 kg)
SHIPPING WEIGHT
29 lb
(13.2 kg)
Product specications are subject to change without
notice.
Ristorre™ Onda™ Shower Tower — Specications
Minimum Working Water Pressure 21.76 psi (1.5 bar)
Maximum Working Water Pressure 72.52 psi (5.0 bar)
Recommended Working Water Pressure 43.51 psi (3.0 bar)
Maximum Working Water Temp. 140-158° F (60 – 70° C)
Minimum Working Water Temp. 41-68° F (5-20° C)
Recommended Working Temp. 100° F (38° C)
Under water pressure at
21.76 psi (1.5 bar)
Flow Rate of Hand Shower 1.51 US gal/min (6.0 L/min)
Flow Rate of Wall Mount 1.69 US gal/min (6.4 L/min)
Flow Rate of Body Jet 1.71 US gal/min (6.5 L/min)
Flow Rate of Temp Check Spout 1.69 US gal/min (6.4 L/min)
Optional-Supplied
Temperature
Check Spout

Jacuzzi Whirlpool Bath: Shower Towers Page 5 FZ71000B • 09/07
DIMENSIONS
2-1/2" ( 63.5 mm) D (Depth)
12-3/4" ( 1905 mm) W
55-7/8" (1419 mm) L
PRODUCT WEIGHT
26 lb
(12 kg)
SHIPPING WEIGHT
29 lb
(13.2 kg)
Product specications are subject to change without
notice.
Ristorre™ Metallo™ Shower Tower — Specications
Minimum Working Water Pressure 21.76 psi (1.5 bar)
Maximum Working Water Pressure 72.52 psi (5.0 bar)
Recommended Working Water Pressure 43.51 psi (3.0 bar)
Maximum Working Water Temp. 140-158° F (60 – 70° C)
Minimum Working Water Temp. 41-68° F (5-20° C)
Recommended Working Temp. 100° F (38° C)
Under water pressure at
21.76 psi (1.5 bar)
Flow Rate of Hand Shower 1.58 US gal/min (6.0 L/min)
Flow Rate of Wall Mount 1.58 US gal/min (6.0 L/min)
Flow Rate of Body Jet 1.98 US gal/min (7.5 L/min)
Flow Rate of Temp Check Spout 1.98 US gal/min (7.5 L/min)
Optional-Supplied
Temperature
Check Spout

Jacuzzi Whirlpool Bath: Shower Towers Page 6 FZ71000B • 09/07
Ristorre™ Ovale™ Shower Tower — Component Identication
Parts List
The parts list table common to all Ristorre shower towers is located on Page 9. Please refer to this table for com-
ponent identication of parts list in all Ristorre shower towers.
1
14
2
20a
20b
20c
12
15
17
13
13
28
18
7
8910
18
27
16
4
25
21
5
6
19
26
11
22
24
23
17
RemarkNo. Name Qty RemarkNo. Name Qty
Tempered Glass Front Plate
Included1Gasket
28
Included
Included
Included
Washer Plate
Spring Washer
Brass Nut
2
2
2
25
24
23
Included
Included
Body Jet
Screw Nut
S.S.Flexible Hose
Sealing Washer
Threaded Connector
1
20b
6
1
1
21
Thermo-Static Control
Flow Control
Diverter
1
20c
Square-shaped Temperature Check Spout
1
Glass Shelf With Pillar Included
1
18
1
3
5
1
Included
Included
Included
Included
Included
Included
Included
Included
Washer
19
Tube-shaped Temperature Check Spout13
Screw Cap
Rubber Washer
Screw(M4.2X35mm)
Wall Mount Fixing Rod
Plastic Anchor
Screw(M3.5x25mm)
Hand Shower Bracket
Shower Arm
Wall Mount Shower
Back Housing
1
3
3
4
1
3
3
5
5
11
12
3
20a
1
26 Silica Gel Washer 2 Included
Included2Ring2714
7
6
Hand Shower15 Included
16
17
1
8
1 Included
22
Included
1
1
9
10
1 Included
1
2
Included

Jacuzzi Whirlpool Bath: Shower Towers Page 7 FZ71000B • 09/07
Ristorre™ Onda™ Shower Tower — Component Identication
Parts List
The parts list table common to all Ristorre shower towers is located on Page 9. Please refer to this table for com-
ponent identication of parts list in all Ristorre shower towers.
RemarkNo. Name Qty RemarkNo. Name Qty
Tempered Glass Front Plate
Included1Gasket
28
Included
Included
Included
Washer Plate
Spring Washer
Brass Nut
2
2
2
25
24
23
Included
Included
Body Jet
Screw Nut
S.S.Flexible Hose
Sealing Washer
Threaded Connector
1
20b
6
1
1
21
Thermo-Static Control
Flow Control
Diverter
1
20c
Square-shaped Temperature Check Spout
1
Glass Shelf With Pillar Included
1
18
1
3
5
1
Included
Included
Included
Included
Included
Included
Included
Included
Washer
19
Tube-shaped Temperature Check Spout13
Screw Cap
Rubber Washer
Screw(M4.2X35mm)
Wall Mount Fixing Rod
Plastic Anchor
Screw(M3.5x25mm)
Hand Shower Bracket
Shower Arm
Wall Mount Shower
Back Housing
1
3
3
4
1
3
3
5
5
11
12
3
20a
1
26 Silica Gel Washer 2 Included
Included2Ring2714
7
6
Hand Shower15 Included
16
17
1
8
1 Included
22
Included
1
1
9
10
1 Included
1
2
Included
27
5
19
15
13
14
16
10
9
8
17
18
7
6
1
2
3
20b
20c
20a
11
12
18
22
21
Optional
4
17
26
23
24
25
13
FRONT BACKSIDE
28

Jacuzzi Whirlpool Bath: Shower Towers Page 8 FZ71000B • 09/07
Ristorre™ Metallo™ Shower Tower — Component Identication
Front Plate
Wall Mount Shower 1
1
RemarkNO. Name Qty
19
3
7
6
8
10
1
2
Mirror
6Body Jet
1
IncludedScrew 2
IncludedConnection rod 1
IncludedHanger 2
Included6Screw
Parts List
The parts list table common to all Ristorre shower towers is located on Page 9. Please refer to this table for com-
ponent identication of parts list in all Ristorre shower towers.
7
19 18
13
13
26
9
8
20b
1
3
6
2
20a
20c
12
22
21
16
17
15
10 11
14 27
23
25
24
28
21
18
19
Wall
7
Blue means connect to cool water
Red means connect to hot water

Jacuzzi Whirlpool Bath: Shower Towers Page 9 FZ71000B • 09/07
Common Parts List
Qty
Name Remark
20b
17
18
19
13
12
20a
14
15
16
Tube Temp Check Spout
(M3.5X25mm) Screws
Flow Control
Glass Shelf Assembly
Plastic Anchors
Hand Shower
Square Temp Check Spout
Diverter
Hand Shower Bracket
Shower Flexible Hose
1
1
1
1
6
1
1
1
1
6
2
2
5
1
1
1
2
2
2
28
25
24
23
21
20c
26
27
22
Washer Plate
Spring Washer
Brass Nut
Thermo-Static Control
Sealing Washer
Threaded Connector
Silica Gel Washer
Ring
Washer
Qty
Name Remark

Jacuzzi Whirlpool Bath: Shower Towers Page 10 FZ71000B • 09/07
NOTE: Parts with item number listed are included.
Determine the installation height of the shower tower. The height of the top row of the body jets should be level
with the users’ shoulders. Place a mark on the wall at the top of the unit when the top jets are at the desired
position. Begin installation using the following instructions.
Finish Wall Preparation
1. Drill three holes 1/4" diameter by 1-3/8” deep in
the wall at the locations and dimensions shown
in Figure 1.
2. Insert plastic anchors (18) into each of the
holes, then mount the wall mount xing rods (7)
to the wall using the M4.2x35mm screws (8),
see Figure 2.
NOTE: Figure 3 is for Metallo only.
3. The User can adjust the height. Drill four holes at 1/4" diameter by 1-3/8" deep.
The distance of the holes are 1-3/16" and 35-3/16" apart. Insert the anchor (18)
to the holes. Then use the screw (8) to x the location of the hanger on the wall,
see Figure 3.
Each unit arrives ready for installation, completely equipped with plumbing and ttings. Remove the unit from the
carton. Retain the shipping carton until satisfactory inspection of the product has been made.
CAUTION: Do not drop the shower tower. Dropping the unit may damage its appearance and function.
Immediately upon receipt, inspect the unit before installing. Should inspection reveal any damage or defect in the
nish, do not install. Damage or defect to the nish claimed after the unit is installed is excluded from the warranty.
Jacuzzi Whirlpool Bath's responsibility for shipping damage ceases upon delivery of the products in good order to
the carrier. Refer any claims for damage to the carrier. For denitions of warranty coverage and limitations, refer
IMPORTANT: Read all instructions before beginning installation. Consult local codes for requirements.
Ovale Onda
- - - - - - - - - - - - - - - - -
A 5-1/8 7-3/16
B 2-3/8 4-1/2
C 33-1/4 46-1/2
D 3-1/2 2-1/4
- - - - - - - - - - - - - - - - -
Measurements in inches
Figure 2
Figure 3
1-3/16"
35"
1-3/16"
8
18
7
1-3/16"
35-3/16"
INSTALLATION
Figure 1
A
B
C
D
To
p
o
f U
n
it
