JASON Hydrotherapy forma AC553 User manual

Jason International, Inc. • 501.771.4477 Page 1 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
“TO BE REMOVED FOR USE BY THE OCCUPANT.”
49-1011-600
Date 03/11
OWNER’S MANUAL
forma®MicroSilkTM Baths
INSTALLATION, OPERATION, AND MAINTENANCE
Jason International, Inc.
8328 MacArthur Drive
North Little Rock, AR 72118
www.jasoninternational.com
OWNER’S RECORD
Dealer:
Date Purchased:
Date Installed:
Installer:
PLACE SERIAL NUMBER CARD WITH
PRODUCT CONFIGURATION IN THIS BOX
INSPECTION
Inspect the unit prior to installation. In the event of a
problem, DO NOT install the unit.
All components are factory assembled to the bath and the
unit is water tested and inspected prior to leaving Jason
International, Inc.
If the carton shows sign of damage, inspect the product
before accepting and describe the problem on the Bill of
Lading.
NOTE: Transportation and insurance from Jason’s
factory are the buyer’s responsibility.
Damage sustained in transit is the responsibility of the
carrier. If damage is discovered,
If the carton shows sign of damage, inspect
the product before accepting and describe the
problem on the Bill of Lading.
the carrier must be immediately notified in writing with a
request for a representative to inspect the unit. Failure of
the carrier to respond should be reported to the seller and
carrier. Always file a freight claim promptly.
The installer is responsible for insuring that the unit is
free from defects or shipping damage. In the event of a
problem, DO NOT install the unit.
Jason International is not responsible for damage that
might have been avoided by inspection or testing prior to
installation.
Damage to the unit during installation will not be covered
by warranty and is the responsibility of the installer. ALL
WARRANTY CLAIMS ON ACRYLIC SURFACE DAMAGE
MUST BE MADE PRIOR TO INSTALLATION. Inspect
plumbing and bath surface for missing or damaged
components. Alert your dealer of any discrepancies.
To protect the unit from damage keep the bath in the
carton until ready for installation.

Jason International, Inc. • 501.771.4477 Page 2 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
EQUIPMENT ACCESS
In accordance with Building Codes, service access to all
therapy bath equipment, controls and electrical connections
must be provided during installation (see Table 1 – Speci-
fications for minimum access size). Insufficient access will
hinder repair and maintenance. Warranty service will not
cover costs of providing equipment access.
INSTALLATION INSTRUCTIONS
Jason offers an optional removable lateral skirt for all rect-
angular baths. The skirts are available in matching acrylic
colors and provide convenient access to bath equipment
as well as an excellent finished appearance. However, if
Jason’s lateral skirt is not used, an access panel MUST be
provided to enable final electrical connections and service.
Please refer to the minimum recommended access panel
size in Table 1 - Specifications.
Table 1 Specications
Operating
Capacity
Min. Size
Access
Floor
Loading
66 x36 x22 39 36 x 17 in 50.2
168 x91 x56 148 91 x 43 cm 245
72 x36 x22 49 36 x 17 in 54.3
183 x91 x56 185 91 x 43 cm 265
72 x42 x22 56 36 x 17 in 50.8
183 x107 x56 212 91 x 43 cm 248
66 x36 x22 44 36 x 17 in 53.5
168 x91 x56 167 91 x 43 cm 261
60 x60 x20.5 55 36 x 17 in 46.8
152 x152 x52 208 91 x 43 cm 229
66 x36 x22 45 36 x 17 in 49.4
168 x91 x56 170 91 x 43 cm 241
72 x36 x22 50 36 x 17 in 48.9
183 x91 x56 189 91 x 43 cm 239
72 x42 x22 65 36 x 17 in 49.6
183 x107 x56 246 91 x 43 cm 242
60 x30 x20.5 38 36 x 17 in 57.1
152 x76 x52 144 91 x 43 cm 279
60 x30 x20.5 38 36 x 17 in 57.3
152 x76 x52 144 91 x 43 cm 280
60 x30 x20.5 38 -- 59.1
152 x76 x52 144 -- 289
60 x32 x20.5 39 36 x 17 in 54.6
152 x81 x52 148 91 x 43 cm 267
60 x32 x20.5 39 36 x 17 in 54.8
152 x81 x52 148 91 x 43 cm 268
60 x32 x20.5 39 -- 56.5
152 x81 x52 148 -- 276
66 x36 x22 48 36 x 17 in 51.3
168 x91 x56 182 91 x 43 cm 250
72 x36 x22 53 36 x 17 in 50.5
183 x91 x56 201 91 x 43 cm 247
fORMA COLLECTION (MicroSilk Bath)
Overall Dimensions
Gallons
Liters
lbs/ft2
kg/M2
L x W x H (in.)
L x W x H (cm)
W x H (in.)
W x H (cm)
RE525 SL/SR
RE527
AC553
AC630
AC635
AE553
DA500 (Round)
RC553
RE527 TL
RE527 SL/SR
RE553
RE630
Model
RC630
RC635
RE525
RE525 TL

Jason International, Inc. • 501.771.4477 Page 3 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
INSTALLATION INSTRUCTIONS (cont.)
INSTALLATION
E a c h b a t h is p r o v i d e d w i t h a c a r d b o a r d b a t h w e l l p r o t e c -
tor that should be kept in the unit during the installation
and throughout the bathroom construction process.
Overflow drains, fill spouts, and valves must be installed
according to the instructions herein.
See the USER MAINTENANCE INSTRUCTIONS section
of this owner’s manual, prior to Installation, for humidity
and mold prevention suggestions.
FinishFrame1. Afinishframeundertheshellrimshould also
alwaysbeconstructedto supportthebathdeckandinsure
proper drainage toward the bath well. This frame is not in-
tended to support the full bath weight (see Figures 1 & 2).
Jason offers a removable lateral skirt for most baths.
The skirts are available in matching acrylic colors
and provide convenient access to bath equipment as
well as an excellent finished appearance. However,
if Jason’s lateral skirt is not used, an access panel
MUST be provided to enable final electrical connec-
tions and service. Please refer to the minimum recom-
mended access panel size in Table 1 - Specifications.
If a Jason lateral skirt is to be used, the bath deck must
be leveled at 20.5” (52cm) from the support floor or the
skirt will not fit properly.
100% Silicone with mildew resistant proper-2.
ties should be applied between the water re-
sistant backer board and the deck of the bath.
NOTE: If you use a tile flange kit, modify the framing
to support the bath lip as shown in Figure 1.
Install the drain and overflow assembly to the bath shell3.
according to the instructions provided with the drain and
position the bath in the area of intended installation.
Finish plumbing rough-in of drain and overflow assem-4.
bly. At this time, considerations should be made for the
position and mounting of the faucet set, as well as all
related plumbing.
Remove the packing board5. before installing the
bath. The bath is equipped with separate bath equip-
ment support bases which are joined for shipment
with packing boards. Detach the packing board
from the bath and from underneath the equipment.
WARNING: Any modification to the equipment is not
recommended and will void the Manufacturer’s war-
ranty.
Install the bath level for proper drainage.6. Jason baths
are designed to be supported at the base of the bath.
If the floor is smooth and level, the baths’ Level Form™
Base will provide proper drainage and support (See
Figure 3).
Mortar is required when the subfloor is not smooth and7.
level; when additional sound insulation is desired; or when
SILICONE BEAD
TILE
DRYWALL DRYWALL
TILE
OPTIONAL
TILE FLANGE
KIT
OPTIONAL
INTEGRATED
TILE LIP
1" X 2"
SUPPORT
SCREW
Figure 1
Figure 2
Full Support Base
Figure 3

Jason International, Inc. • 501.771.4477 Page 4 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
INSTALLATION INSTRUCTIONS (cont.)
the bath is installed in a drop-in application. In alcove
installations, a bed of mortar may also be recommended
to aid in leveling the bath. Note: Do not use a sand bed
to install or level the bath.
Secure the bottom of all equipment mounts so that it8.
is level with the bottom of the bath. Position the bath
in the area of intended installation and cut the equipment
support strap(s) to allow the equipment to rest firmly
on the floor. We recommend securing the equipment
mounts to the floor with removable fasteners for ease
of servicing.
Protect the acrylic bath surface from damage during9.
installation with a suitable material, i.e., cardboard
and/or plastic film. The acrylic surface of this bath has
been provided with a protective film which helps protect
the bath during shipment and installation. Additional
protection may also be required to protect the acrylic sur-
face during installation. If the bath is tiled in, remove the
necessary portion of the film when installing the tile.
Installing the MicroSilkTM Pump Assembly
INSTALLING THE MICROSILK ™PUMP ASSEMBLY
NOTE: These instructions can also be found in the
Installation, Operation and Maintenance manual of the
seperately packaged MicroSilk therapy bath unit.
WARNING: SYSTEM UNDER PRESSURE — NEVER
PERFORM MAINTENANCE WHILE SYSTEM IS RUN-
NING.
The Jason MicroSilk™ system has been factory assembled
following ETL and IAPMO guidelines. For shipping purposes,
the MicroSilk™ Pump Assembly is packaged separately and
disconnected from the bath.
NOTE: Verify the MicroSilk Pump Assembly is the
same unit that was provided for the bath being in-
stalled. The serial number listed on the label provided
on the MicroSilk Pump Assembly carton should match
the serial number of the bath.
WARNING: ANY MODIFICATION TO THE EQUIPMENT
IS NOT RECOMMENDED AND WILL VOID THE
MANUFACTURER’S WARRANTY.
To install the MicroSilk™ Pump Assembly to the bath, the
following procedures must be followed.
NOTE: Do not install the MicroSilk Pump Assembly
further than the length of the tubing that is factory
installed on the bath. These tubing lengths have been
designed for proper drainage of the system.
Position the bath in the area of intended installation.1.
Before beginning any work, the installer is to determine2.
the proper location of the MicroSilk™ Pump Assembly
and service access.
Do not disconnect the tubing with the MicroSilk™ Jet Flex3.
Hose or the tubing from the MicroSilk™ Suction Line that
are secured to the bath with nylon tie straps (See Figure 4)..
CAUTION: Do not allow any dirt or debris to enter into
the system plumbing or MicroSilkTM Pump Assembly.
Figure 4
Figure 5
Figure 6

Jason International, Inc. • 501.771.4477 Page 5 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
INSTALLATION INSTRUCTIONS (cont.)
This could cause system blockage and equipment
damage.
Remove the protective caps from the MicroSilk™ Jet Flex4.
Hose and the MicroSilk™ Suction Line that are located on
the bath (See Figure 5), also remove the protective caps
Figure 7
from the MicroSilk™ Saturation Tank and the MicroSilk™
Suction Barb that are located on the MicroSilk™ Pump
Assembly (See Figure 6).
Thread the MicroSilk™ Jet Flex Hose onto the MicroSilk™5.
Saturation Tank, located on the MicroSilk™ Pump
Assembly. Verifythatallconnectionsonthedischargeside
are tight (See Figure 7). Assure the MicroSilk™ Jet Flex
Figure 8
Hose will allow proper drainage to the jets. All hoses must
have a continuous drop from the saturation tank to the jets.
NOTE: Verify the pump wet-end is angled to allow
for proper drainage.
Clamp the MicroSilk™ Suction Line to the MicroSilk™6.
SuctionBarbusingtheclampprovidedonthetubing. Assure
the MicroSilk™ Suction Line will allow proper drainage to
the suction (See Figure 8). The suction hose must have a
continuous drop from the suction barb to the suction fitting.
CAUTION: Confirm all tubing is fully engaged on
its respective barb and its clamp has secured the
tubing to the barb.
7. If an Automatic Ozone Sanitation System is installed,
connect the ozone system tubing to the tee above the
MicroSilk Saturation Tank (See Figure 9).
8. The bottom of the Pump Mount must be secured and
level with the bottom of the bath, it is recommended
removable fasteners be used in case any future servicing
is required.
9. Continue bath installation per the Jason Owner’s Manual
Installation, Operation, and Maintenance guide.
Figure 9

Jason International, Inc. • 501.771.4477 Page 6 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
INSTALLATION INSTRUCTIONS (cont.)
ELECTRICAL
ELECTRICAL POWER SUPPLY: These instructions are written
assuming 60Hz, 120v (or 240v for Signature Edition) power supply.
Special notations are also included for the Export versions of the
pump, control equipment and power supply.
WARNING: VERIFICATION OF ELECTRICAL REQUIREMENTS
MUST BE MADE BEFORE INSTALLATION. REFER TO THE
EQUIPMENT LABELS FOR VOLTAGE AND FREQUENCY
REQUIREMENTS.
NOTE: Verify that the electrical service matches either the
120v or 240v system requirements for this bath.
NOTE: The bath is designed for indoor use only. The electrical
equipment must not be exposed to direct or indirect water
or moisture contact. The electrical equipment must also be
protected from dust and other airborne debris before, during,
and after installation.
Electrical Service:1. A licensed electrician must provide
the “dedicated” electrical service protected by a GFCI.
The location of the GFCI must be at least five (5) feet
(152 cm) away from the inside surface of the bath,
accessible for regular testing. Use copper conductors only.
DANGER — RISK OF ELECTRIC SHOCK: Connect
only to a circuit protected by a Ground Fault Circuit
Interrupter (GFCI). In the unlikely occurance of
a current imbalance in the power conductors,
the GFCI will interrupt power to the bath.
WARNING: THE ELECTRICAL SERVICE TO THE GFCI
MUST NOT BE INTERRUPTED BY ANY CONTROL
DEVICE. LIKEWISE, THE ELECTRICAL SERVICE FROM
THE GFCI TO THE BATH CONTROL SHOULD BE DIRECT
AND NOT INTERRUPTED BY A SWITCH. NEVER USE A
SWITCH IN CONJUNCTION WITH A CONTROL DEVICE.
THIS WILL VOID THE MANUFACTURER’S WARR ANTY.
GROUNDING IS REQUIRED2.
The unit should be installed by a qualified
service representative and properly grounded.
INSTALL SERVICE CONNECTION AT3.
LEAST 6” (15cm) ABOVE SUB FLOOR.
ALL LOCAL AND STATE ELECTRICAL AND PLUMBING
CODES MUST BE OBSERVED. Where there are no
local codes the National Electric Code (NEC) and
Uniform Plumbing Code (UPC) shall be observed. It
is the responsibility of the installer/owner to determine
specific code compliance prior to installation of the product.
NOTE: In the Commonwealth of Massachusetts, installation
is to be done by a Massachusetts licensed plumber.
Standard/Premier Edition MicroSilk™ Control Box (120v).4.
The MicroSilk generator unit is shipped separate from the bath.
Follow the instructions for the MicroSilk Pump Assembly
Field Installation in the Installation section of this owner’s
manual (instructions are also packaged with the MicroSilk
unit packaging). The control box has a 36” (91cm) cord with
plug end. The MicroSilk control box is mounted on a stand
that is temporarily secured to the packing board for shipping.
During installation, the control box bracket and controls must
be positioned horizontally and located to permit access for
inspection and servicing. The MicroSilk pump’s power cord will
need to be plugged into the control box. Connect the pump’s
male NEMA plug to the female NEMA plug of the control box’s
load line. The MicroSilk control must be plugged into a dedicated
120v, 20A, 60Hz, GFCI protected circuit. (See Figure 9)
Standard/Premier Edition MicroSilk™ Control Box (240v).5.
The MicroSilk generator unit is shipped separate from the bath.
Follow the instructions for the MicroSilk Pump Assembly
Field Installation in the Installation section of this owner’s
manual (instructions are also packaged with the MicroSilk
unit packaging). The control box has a 36” (91cm) cord with a
junction box connection. The MicroSilk control box is mounted
on a stand that is temporarily secured to the packing board for
shipping. During installation, the control box bracket and controls
must be positioned horizontally and located to permit access for
inspection and servicing. The MicroSilk pump’s power cord will
need to be plugged into the control box. Connect the pump’s
male J+J plug to the female J+J plug of the control box’s load
line. The MicroSilk control must be plugged into a dedicated
240v 20A, 50 Hz, GFCI protected circuit. (See Figure 9)
Signature Edition Control Box.6. The MicroSilk generator
unit is shipped separate from the bath. Follow the instructions
for the MicroSilk Pump Assembly Field Installation in the
Installation section of this owner’s manual (instructions are
also packaged with the MicroSilk unit packaging). The control
box has a 36” (91 cm) cord with a junction box connection. The
MicroSilk control box is mounted on a stand that is temporarily
secured to the packing board for shipping. During installation,
the control box bracket and controls must be positioned
horizontally and located to permit access for inspection and
servicing. The MicroSilk pump’s power cord will need to be
plugged into the control box. Connect the pump’s male J+J
plug to the female J+J plug of the control box’s load line. The
MicroSilk control junction box must be plugged into a dedicated
240v 20A, 50 or 60 Hz, GFCI protected circuit. (See Figure
9A)
DANGER: Do not alter the factory installed wiring. All
building materials and wiring should be routed away from
the equipment or other heat-producing components of
the unit.

Jason International, Inc. • 501.771.4477 Page 7 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
INSTALLATION INSTRUCTIONS (cont.)
Figure 9
Standard/ Premier Edition MicroSilk
Figure 9A
Signature Edition MicroSilk
NOTE: The load neutral terminal is not
used. There should be no connection
to the load neutral terminal on the GFCI
circuit breaker. The green wire (GND-
GREEN) is the equipment ground and
should be connected to the neutral
bus found in the main breaker box.
Key Pad
Light
Key Pad Cable
Control Box
Control Mount
Ground - Green Wire
Neutral - White Wire
Hot - Black Wire
Dedicated
120V, 50 or 60 Hz
GFCI Protected
Service
L2
L1
GROUND
DEDICATED
240V,50 or 60 Hz
GFCI PROTECTED
SERVICE
NOTE: USE THE ABOVE
DIAGRAM FOR 240V, 50Hz
OR 60Hz SYSTEMS.
Key Pad
Light
Key Pad Cable
Control Box
Control Mount
Ground - Green Wire
L2 - White Wire
L1 - Black Wire
Dedicated
240V, 50 or 60 Hz
GFCI Protected
Service
L2-WHITE WITH
RED MARK
L1-BLACK
GND-GREEN
FROM CONTROL
L2
240 V
L1
NO CONNECTION
(LOAD NEUTRAL)
BREAKER BOX
BREAKER BOX CONNECTIONS

Jason International, Inc. • 501.771.4477 Page 8 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
INSTALLATION INSTRUCTIONS (cont.)
CLEANING
Remove all loose debris.1. Construction plaster or
excess grout can be removed with the use of a wood
(edge) trowel.
Paint or tar stains2. may need to be removed with a
cleaner such as paint thinner, turpentine, or isopropyl
alcohol (rubbing alcohol). Never allow the cleaner to
soak against the acrylic surface for long periods of time.
Always rinse the surface immediately following the use
of cleaners.
Follow the manufacturer’s instructions for safe use of3.
cleaning products. If the surface becomes scratched
or dulled, it may be restored by using a quality plastic
polish, like Novus Plastic Polish No. 2 (available from
the Jason Dealer). It is always preferable to protect
the acrylic surface during installation to minimize
cleanup and prevent surface damage.
WATER TESTING
Before finishing the installation, it is recommended that the
bath be water tested and the plumbing tested for leaks.
Before water testing the bath,1. make sure any pump
unions are hand tight. Do not over tighten or use a pipe
wrench. This will damage the unions and cause leaking.
If the unit leaks with the unions hand tight, then loosen
the unions(s) and check the O-ring seal to ensure it is
properly seated.
Fill and operate the bath.2. Close the drain and fill the
bath with water to at least 10 inches [25 cm] below the
bath deck. The inlet temperature should not exceed 104°F
(40°C) as this could damage the acrylic surface. Refer
to the FILLING AND DRAINING section of this owner’s
manual for more information.
Inspect the plumbing for leaks.3.
Turn the equipment Off and then drain the water.4.
The bath unit and its plumbing are designed to drain
after each use whether used as a hydrotherapy bath,
soaking bath, or when taking a shower.

Jason International, Inc. • 501.771.4477 Page 9 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
Jason’s Standard Edition MicroSilk system features the best
in luxury bathing for the leisure bath industry. To assure that
your bath functions properly, the MicroSilk pump control box
must be properly connected.
NOTE: For 120v systems, the power cord for the pump
control box must be plugged into a 120v, 20 amp GFCI
dedicated circuit.
THE MICROSILK CONTROL
The MicroSilk unit, Keypad, and Water Level/Vacuum Sensor
must be plugged into the proper receptacles for correct
operation of the system. See Figure 10 for connections: (A)
The power cord for the MicroSilk unit control box must be
plugged into a 120 or 240v, 20 amp, GFCI dedicated circuit.
(B) The MicroSilk pump’s power cord will need to be plugged
into the control box (C). Refer to the ELECTRICAL section
of this manual for connecting the pump to the control box.
(D) Two-pin terminal for installation of the water sensor to
the pump control box. (E) Eight-pin mini-DIN terminal for the
MicroSilk keypad. (F) Six-pin mini-DIN terminal for optional
LED light.
STANDARD EDITION MICROSILK PARTS LIST
MicroSilk Pump Unit Pump Control Box
Control Box Stand Water Level/Vacuum Sensor
Keypad Keypad Cable
MICROSILKTM CONTROL BOX CONNECTIONS
STANDARD EDITION MICROSILKTM
PREMIER EDITION MICROSILK PARTS LIST
MicroSilk Pump Unit Pump Control Box
Control Box Stand Water Level/Vacuum Sensor
Keypad Keypad Cable
LED Light Assembly LED Light Cable
Ozone Sanitation Unit
Jason’s Premier Edition MicroSilk system incorporates all
the features of the Standard Edition system and includes
the benefits of an ozone sanitation system, and an LED
Chromatherapy light. To assure that your bath functions
properly, the MicroSilk pump control box must be properly
connected.
NOTE: For 120v systems, the power cord for the pump
control box must be plugged into a 120v, 20 amp GFCI
dedicated circuit.
THE MICROSILK CONTROL
The MicroSilk unit, Keypad, LED light, Ozone Sanitation Unit,
and Water Level/Vacuum Sensor must be plugged into the
proper receptacles for correct operation of the system. See
Figure 11 for connections: (A) The power cord for the Mi-
croSilk unit control box must be plugged into a 120 or 240v,
20 amp, GFCI dedicated circuit. (B) The MicroSilk pump’s
power cord will need to be plugged into the control box (C).
Refer to the ELECTRICAL section of this manual for con-
necting the pump to the control box. (D) Two-pin terminal
for installation of the water sensor to the pump control box.
(E) Eight-pin mini-DIN terminal for the MicroSilk keypad.
(F) Six-pin mini-DIN terminal for LED light. (G) Ozone Unit
pre-wired to control box.
PREMIER EDITION MICROSILKTM
Figure 10
Figure 11
NOTE: This diagram (Figure 10) also applies to 50Hz, 240v
pumps, controls and power supply systems. Except that
the MicroSilk control junction box must be connected into a
dedicated 240v, 20 Amp GFCI circuit.
NOTE: This diagram (Figure 11) also applies to 50Hz, 240v
pumps, controls and power supply systems. Except that
the MicroSilk control junction box must be connected into a
dedicated 240v, 20 Amp GFCI circuit.

Jason International, Inc. • 501.771.4477 Page 10 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
SIGNATURE EDITION MICROSILK PARTS LIST
MicroSilk Pump Unit Pump Control Box
Keypad Keypad Cable
Control Box Stand Water Level/Temp Sensor
LED Light Assembly LED Light Cable
Vacuum Sensor Ozone Sanitation Unit
Jason’s Signature Edition MicroSilk system is the most ad-
vanced bath manufactured by Jason International, Inc. and
features the ultimate in luxury bathing for the leisure bath
industry. The MicroSilk pump control box must be properly
connected for the bath to function correctly.
THE MICROSILK CONTROL
The MicroSilk Unit, Keypad, LED light, Ozone Sanitation Unit,
Vacuum sensor, and Water Level/Temperature sensor must
be plugged into the proper receptacles for correct operation
of the MicroSilk system. See Figure 12 for connections: (A)
The junction box for the MicroSilk Unit control box must be
connected into a 240v, 20 amp GFCI dedicated circuit. (B)
The MicroSilk pump’s power cord will need to be plugged
into the control box (C). Refer to the ELECTRICAL section
of this manual for connecting the pump to the control box.
Eight-pinmini-DIN terminal forinstallationofMicroSilk keypad
(E). Six-pin mini-DIN terminals for the water/temperature
sensor (D), and LED light (F) to the pump control box. (H)
Two-pin terminal for installation of the vacuum switch to the
water/temperature sensor.
SIGNATURE EDITION MICROSILKTM
Figure 12
CONTROL BOX CONNECTIONS (cont.)
NOTE: This diagram (Figure 12) also applies to 50Hz, 240v
pumps, controls and power supply systems.

Jason International, Inc. • 501.771.4477 Page 11 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
OPERATING INSTRUCTION, FEATURES, AND CONTROLS
INTRODUCTION
This manual contains all of the information needed for the
proper installation and operation of your Jason MicroSilk bath.
The MicroSilk bath has been designed to give you years of
relaxing trouble-free service, provided the unit is maintained
and operated in accordance with these instructions.
Thoroughly clean and disinfect the unit as described in
the CLEANING section of the USER MAINTENANCE
INSTRUCTIONS section of this owner’s manual before its first
use and periodically thereafter.
CAUTION: Keep hair, towels, and clothing away from the
suction fitting whenever the equipment is On. Never operate
the equipment with the suction cover off, doing so voids the
manufacturer’s warranty--it is a safety cover designed to
eliminate the potential of hair and body entrapment.
All Jason MicroSilk baths are pre-plumbed at the factory.
WARNING: BEFORE OPERATING REFER TO THE
INSTRUCTIONS AT THE END OF THIS OWNER’S MANUAL
PERTAINING TO THE RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS.
FEATURES AND CONTROLS
STANDARD AND PREMIER EDITION MICROSILK
The Jason Standard Edition MicroSilk bath includes a
Microbubble generator unit; an electronic control with a low
water level sensor to prevent the pump from operating without
water; flow and pressure sensors to ensure proper pump
operation; and a 20-minute timer.
The Jason Premier Edition MicroSilk bath provides all the features
of the Standard Edition with the included benefits of a LED
Chromatherapy Mood Light, and an Ozone Sanitation system.
Standard/Premier Touchpad
One main control touchpad mounted on the bath deck contains
several icons used by the bather to control the pump, and LED
mood light. A built in timer shuts the pump off 20 minutes after
being activated.
SIGNATURE EDITION MICROSILK
The Jason signature Edition MicroSilk bath includes a
Microbubble generator unit; Chromatherapy mood light,
Automatic Ozone System that will be operated any time the
pump is powered; a digital control with LCD display window;
low water and temperature sensors; flow and pressure sensors
to ensure proper pump operation; and a 20-minute timer.
Signature Touchpad
A main control touchpad mounted on the bath deck features a LCD
readout which alternately indicates the water temperature (+/- 5o
F) and time remaining. The Signature Edition touchpad allows
the bather to control the MicroSilk pump and LED mood light. A
built in timer shuts the pump off 20 minutes after being activated.
Signature Remote Control
In addition to the main control touchpad installed on the bath
deck, a floating, waterproof Universal Remote Control is
provided with all Signature Edition MicroSilk baths. This remote
control provides the same control functions as the bath’s main
control console, plus the bather may remotely operate a TV,
DVD, VCR, CD, etc. Refer to the Instruction Manual provided
with the remote control for detailed instructions.
Jets
Strategically placed MicroSilk jets are provided for complete
enjoyment of your bath.
MicroSilk Unit
The MicroSilk generates oxygen rich microbubbles that fill
the bath. MicroSilk units provided on Jason baths are factory
tested when assembled and again retested after installation
on the bath.
MicroSilk Suction Fitting
The MicroSilk suction fitting is designed to provide a safe
water return to the pump. The suction fitting has an internal
filter screen and an external suction cover EZ Clean Pre-
Filter made from Lycra® material. The EZ Clean Pre-Filter is
designed to allow for easy cleaning. If the pre-filter becomes
soiled or dirty, it should be removed and cleaned with soap and
water. Periodically the internal filter screen should be removed
and cleaned with soap and water. The suction cover can be
removed by unscrewing the single Philips head screw in the
center of the suction cover (See the USER MAINTENANCE
INSTRUCTIONS section of this owner’s manual for cleaning
instructions). This will keep the system running properly.
Never operate the system without the pre-filter, internal
filter screen and suction cover installed.

Jason International, Inc. • 501.771.4477 Page 12 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
FILLING AND DRAINING
Close the drain and fill the bath with water at least two
(2) inches (50mm) above the jets. The inlet temperature
should not exceed 40oC (104
oF) as this could damage
the acrylic surface. When bath is in use, turn the unit Off
before draining the water. The bath unit and its plumbing
are designed to drain after each use whether used as a
hydrotherapy bath, soaking bath, or just taking a shower.
NOTE: If the unit fails to operate, check the breaker panel
to insure that the circuit breaker is on. Check the GFCI by
testing and resetting it. Also check the water level in the
bath; it must be above the water level sensor located on
the sidewall of the bath for the pump to operate. If the unit
still fails to operate, refer to the Trouble Shooting Guide
section on page 15 of this manual. If the unit still fails
to operate and is out of warranty, contact an authorized
service technician for repair. If the unit is within the
warranty period, contact JASON Technical Services at
800-255-5766. DO NOT ATTEMPT TO RESOLVE THE
PROBLEM.
OPERATING INSTRUCTIONS, FEATURES, AND CONTROLS (cont.)

Jason International, Inc. • 501.771.4477 Page 13 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
STANDARD AND PREMIER EDITION
MICROSILKTM TOUCHPAD
The Jason Standard and Premier Edition MicroSilk touchpad
is used to access all of the functions of the pump control.
OPERATING INSTRUCTIONS
MicroSilk On/O Icon
The MicroSilk icon is used to activate the MicroSilk pump
and the 20-minute timer.
Pressing the icon the first time starts the pump.•
Pressing the icon again will shut the pump off.•
Figure 13
LED Light (Light Icon)
The LED Light icon is used to operate an LED light (if installed).
Press the icon for less than two (2) seconds to turn the•
lights Off or On.
Hold the icon for more than two (2) seconds to change•
modes.
This function has a two (2) hour timer and remembers the
last mode.
m
MICROSILK
LED Light
MicroSilk™ On/Off

Jason International, Inc. • 501.771.4477 Page 14 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
The Jason Signature Edition MicroSilk digital touchpad is
used to access all the functions of the Jason Signature
Edition MicroSilk bath.
OPERATING INSTRUCTIONS
MicroSilk On/O Icon
To control the operation of the MicroSilk pump motor, press
and release for each setting: ON or OFF. A 20 minute de-
creasing timer will be initiated when the pump motor starts.
Press and hold the Pump icon to cycle through each pump
setting. The Pump icon lights when the water is at operating
level and the LCD displays “System Ready”. The LCD will
display “Pump On”, or “Pump Off” when the key is pressed.
It also toggles between Temperature and Timer at 5 second
intervals. “Low Water” is displayed for 5 seconds if no water
is detected. “Vacuum Error” is displayed if the MicroSilk
suction is blocked.
LED Light Icon
Hold the key for less than two (2) seconds to turn the lights
Off or On. Hold the key for more than two (2) seconds to
change modes. The Light icon should remain lit as long as
the bath is connected to a power supply. This function has
a two-hour timer and remembers the last mode. The LCD
displays “Light On” or “Light Off while the key is pressed
for less than two (2) seconds, “Light Cycle” is displayed if
pressed for more than two (2) seconds.
Customized Settings
The 12 character LCD display can be customized by pressing
the two Diagnostic Function icons simultaneously for five (5)
seconds, while the system is off. Note : Use the above figure
to locate the icons. A menu will be displayed to choose the
following: Product Test Diagnostics, Temperature (F or C)
and Language (English or Spanish).
Menu Instructions
Use the top Diagnostic Function icon to scroll through the
different menu items. Use the bottom Diagnostic Function
icon to change an option. For example, press and release
the top icon to change from Product Test to the Temperature
option. Press and release the bottom icon to change the
temperature display from F (Fahrenheit) to C (Celsius).
Product Test Diagnostics
After selecting the Product Test option from the menu, the unit
will perform a series of tests to confirm correct installation of
components.Thetestwillbeginby displayingthe configuration
number, followed by the software revision number. Next, the
display will test the Temperature and Low Water level sensor
(ITW-209). Then, each of the six (6) icon buttons will begin
to light. Press the illuminated button to proceed to the next
icon. After the icon test, the LED Light unit will be tested.
If you receive an error on any of the tests, confirm proper
installation of component to the correct control box (See the
CONTROL BOX CONNECTIONS section).
Remote Control
The Signature Edition control system includes a waterproof
floatingUniversal RemoteControl.It controls allbath functions
plus a TV, DVD, CD, etc. which can be heard through the
Sound Immersion Transducers (optional).
SIGNATURE EDITION
MICROSILKTM TOUCHPAD
Figure 14
m
IR for Remote
LED Light
For Diagnostic Functions
For Diagnostic Functions
MicroSilk™ On/Off
Display Panel

Jason International, Inc. • 501.771.4477 Page 15 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
Ifscratchesaretoodeeptorubout,orifthedamage penetrates
the acrylic surface, consult your dealer for recommendations
on surface repair.
FLUSHING / SANITIZING
Upon start-up and not to exceed 90 days, your bath and
plumbing system should be flushed. To do so, close the
drain and fill the bath with warm water to at least two (2)
inches [5.1 cm] above the highest jet. Pour in Jason Bath
System Cleaner and follow the directions on the bottle. DO
NOT use bleach or other chlorinated cleansers directly on
the metal trim.
SUCTION FITTING CLEANING
The cloth suction EZ Clean Pre-Filter is designed to allow for
easy cleaning. If the EZ Clean Pre-Filter becomes soiled or
dirty, it should be removed and cleaned with soap and water.
Once clean, the pre-filter can be fitted around the suction
cover (See Figure 15). Replacement pre-filters are available
from your Jason dealer or from www.jasoninternational.com.
Periodically, the internal screen filter should be removed by
unscrewing the single Philips head screw in the center of the
suction cover. Remove the internal screen filter and clean
with soap and water. Replace the screen into the suction
cover as shown and reassemble the cover to the fitting (See
Figure 16).
NOTE: To ensure safety and avoid equipment damage,
never operate the system without the Pre-filter, internal
screen filter and suction cover installed.
REPAIR
Refer all plumbing or electrical repair to a qualified service
technician. DO NOT ATTEMPT TO RESOLVE THE
PROBLEM. This can result in danger of electrical shock
or damage to the unit and will VOID THE WARRANTY.
Remember, when contacting your dealer or service
representative, always have your serial number, proof
of purchase, and model number. This will insure a quick
response on warranty items. The serial number can be found
on the front page of this manual or on the small card adhered
to the back of the bath just above the equipment.
HUMIDITY
WARNING: AVOID HIGH HUMIDITY LEVELS IN YOUR HOME. MOLD,
MILDEW, FUNGI AND BACTERIA WHICH MAY BE HARMFUL TO
HEALTH THRIVE IN AREAS WITH CONTINUED HIGH HUMIDITY
LEVELS;THEREFORE,EVERYPRECAUTIONSHOULDBETAKENTO
MAKE SURE YOUR PLUMBING FIXTURES INCLUDING BATHTUBS,
THERAPY BATHS, OR SHOWERS DO NOT BECOME A SOURCE OF
HIGH HUMIDITY DUE TO IMPROPER INSTALLATIONS OR LEAKS.
To avoid having your plumbing fixtures become a source of unwanted
humidity, please make sure the following steps are taken prior to
installation.
1. Make sure the area where the bathtub or shower is
installed is well vented and allows enough ventilation and
air circulation to dry the bathroom environment within a
short time after taking a bath or shower.
2. If your bath or shower unit is tiled-in, use units with an
integral tile flange or make sure a tile flange kit or a similar
mechanical barrier is installed to prevent shower spray,
splash, or overflow to leak behind the bathtub.
3. Make sure the plumber properly tests your therapy bath
before it is roughed in to make sure there are no leaks and
it is installed with proper access to bath equipment.
4. Make sure that all the plumbing and fixtures in the bathroom
are in good working order and have no leaks.
5. Do not use carpeting or other materials or furniture, which
can hold moisture in your bathroom.
6. Use disinfectant to clean any bathroom surfaces which
are regularly exposed to moisture.
7. Clean and disinfect humidifier and dehumidifiers as
recommended by the manufacturer. Replace the air filter
on the HVAC unit once a month.
8.Cleanmoldysurfacesas soonasanymoldappearsby using
a detergent/soapy solution and appropriate household
cleaner. Always use gloves during cleaning. Dispose of
any sponges or rags used to clean mold.
CLEANING
With minimum care, your acrylic-surfaced bath will retain its
high-luster finish for many years. For regular cleaning use
Jason Bath Cleaner or a mild NONABRASIVE liquid detergent
solution (i.e. glass cleaner) and a soft, wet cloth or sponge.
Do not run the hydrotherapy system with foaming cleaners
or soaps. Rinse the bath thoroughly after cleaning.
SURFACE MAINTENANCE
Areas with minor scratches or dull surfaces can be restored
by applying commercially available plastic polish (i.e. Novus
Plastic Polish No. 2, available at your Jason dealer), followed
by an application of acrylic paste wax. Buff the surface with
a clean, soft cloth. Do not use sandpaper, steel wool, or
abrasive rubbing compounds.
USER MAINTENANCE INSTRUCTIONS
Figure 15
Figure 16

Jason International, Inc. • 501.771.4477 Page 16 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
TROUBLE SHOOTING GUIDE
If you believe the unit to be within the warranty period, you must contact Jason Customer Service:
1-800-255-5766 with the bath’s Product and Serial numbers before work is started.
All warranty repairs must be authorized by Jason before work is started.
FOR SERVICE, ALWAYS CONTACT YOUR DEALER OR AUTHORIZED SERVICE CENTER
WARNING: Always turn off power at the main electrical service panel when servicing the bath.
WARRANTY REGISTRATION: Register your product’s warranty online at www.jasoninternational.com.
MICROSILK PUMP SYSTEM
SYMPTOMS POSSIBLE CAUSES RECOMMENDED ACTION
MicroSilk system fails to oper-
ate.
a) No power to the MicroSilk unit.
b) Motor is not plugged in.
c) Touch Control — insufficient water
in bath.
a) Reset circuit breakers and GFCI if tripped. Check fuses
and replace if bad.
Check voltage at motor when control is on. If no voltage,
the control is defective. If voltage is present, motor is
defective.
b) Make sure plug is fully inserted into the outlet.
c) Fill bath to recommended level (4” above jets).
Pump operates, but no Micro
Bubbles are injected into water.
a) Venturi clogged.
b) Float valve no operating
a) Refer to installer/dealer.
b) Refer to installer/dealer.
Pump operates, but water is
not being pumped.
a) Suction or discharge blocked.
b) Suction air leak. (System usually
surges.)
a) Remove obstruction.
b) Make sure connection is tight on suction side
of the pump.
Pump does not manually shut
off.
a) Digital or Touch Control defective. a) Refer to installer / dealer.
Pump shuts off by itself, or
before set time elapses.
a) Internal filter restricting flow
b) Pump motor overheated and thermal
protection device deactivated motor.
(Possibly low voltage.)
c) GFCI tripped.
d) Water level fell below recommended
level.
a) Clean internal screen filter
b) Make sure motor air cooling vents are not blocked, clear
and allow motor to cool down. (Check service & wire size.)
c) Refer to Jason Customer Service.
d) Fill to recommended level.
Pump does not turn off after
set time elapses.
a) Wiring error or control problem. a) Refer to installer / dealer.
Pump will not turn off when
water is drained from the bath.
a) Water level sensor wires or ribbon
cables are shorted.
a) Inspect all sensor wires or ribbon cables for exposed
or touching wires. Separate touching wires and replace
exposed wires. If pump continues, replace water level
sensor.
Pump leaks at shaft. a) Damaged or defective shaft seal. a) Refer to installer / dealer.
LED Light will not operate a) Light bulb is loose in the socket. a) Access light bulb and assure that it is properly installed in
the socket
Jason International, Inc. (Jason), warrants its baths to be free from defects in workmanship and materials as provided in the enclosed Warranty
Statement and Warranty validation card.
The pre-addressed warranty registration card MUST be filled out by the purchaser within thirty (30) days from purchase and mailed to Jason Inter-
national, Inc., in order for limited warranty to become effective.
WARRANTY

Jason International, Inc. • 501.771.4477 Page 17 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
IMPORTANT SAFETY INSTRUCTIONS
INSTRUCTIONS PERTAINING TO THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO
PERSONS.
This manual contains information and instructions for proper operation and maintenance of your therapy bath. Failure to
follow these instructions could result in personal injury, electrical shock, or fire.
WARNING: When using this unit, basic precautions should always be followed, including the
following:
READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY
DANGER: TO REDUCE THE RISK OF INJURY FOLLOW THESE PRECAUTIONS:
A. Do not permit children to use this product unless they are closely supervised at all times.
B. Use this unit only for its intended use as described in this manual. Do not use attachments not recommended by the
manufacturer.
C. The water in a therapy bath should never exceed 40°C (104°F). Water temperatures between 38°C (100°F) and 40°C
(104°F) are considered safe for a healthy adult. Use time should be limited to approximately 30 minutes, followed by a
shower to cool down. Longer exposures may result in hyperthermia. The symptoms of this condition are nausea, dizzi-
ness and fainting, and it can be fatal. Lower water temperatures are recommended for extended use (exceeding 10 -15
minutes) and for young children.
D. Since excessive water temperatures have a high potential for causing fetal damage during the early months of pregnancy,
pregnant or possibly pregnant women should limit therapy bath water temperatures to 38°C (100°F).
E. The use of drugs or alcoholic beverages before or during therapy bath use may lead to unconsciousness with the
possibility of drowning. Never use the therapy bath while under the influence of alcohol, anticoagulants, stimulants,
antihistamines, vasoconstrictors, vasodilators, hypnotics, narcotics, or tranquilizers.
F. Persons with a medical history of heart disease, low or high blood pressure, circulatory system problems, or diabetes
should consult a physician before using a therapy bath.
G. Persons using medication should consult a physician before using a therapy bath since some medication may induce
drowsiness while other medication may affect heart rate, blood pressure, and circulation.
DANGER: To reduce the risk of injury, enter and exit the bath slowly. Do not operate this unit unless the suction cover is at-
tached over the suction inlet fitting and the jet assemblies are installed. There should be at least two (2) inches of water
above the highest jet location during therapy bath operation. NEVER RUN UNIT DRY.
WARNING: Never operate electrically connected devices in or near the bath. Never drop or insert any object into any opening.
This unit must be connected to a supply circuit that is protected by a GFCI. Such a device should be installed by a licensed
electrician and should be tested on a regular basis (at least monthly). To test the GFCI push the TEST button. The GFCI
should interrupt the power. Push the RESET button and the power should be restored. If the GFCI fails to operate in this
manner, there is the possibility of an electric shock. DO NOT USE. Disconnect the unit and have the problem corrected by a
qualified service technician.
To avoid the possibility of personal injury and discoloration of the acrylic surface, the inlet water temperature should not
exceed 40°C (104°F). The bath should be drained after each use. Each bather should start their bath with fresh water. Do
not use oil base additives in your therapy bath.
CAUTION: Do not use harsh abrasives or solvents for cleaning this unit.
INSTALLER/OWNER BEARS ALL RESPONSIBILITY TO COMPLY WITH ALL STATE
AND LOCAL CODES WHEN INSTALLING THIS PRODUCT.
SAVE THESE INSTRUCTIONS
Jason InternatIonal, Inc.
8328 MacArthur Drive • North Little Rock • Arkansas • 72118
www.jasoninternational.com
