JASON Hydrotherapy forma AirMasseur RE630PS User manual

Jason International, Inc. • 501.771.4477 Page 1 of 24 Customer Service : 800.255.5766
Copyright © 2013 Jason International.
“TO BE REMOVED FOR USE BY THE OCCUPANT.”
49-1011-004
Date 11/13
OWNER’S MANUAL
RC/RE630PS & RC553PS forma®
Soaking, Airmasseur®, & MicroSilk®Baths
INSTALLATION, OPERATION, AND MAINTENANCE
OWNER’S RECORD
Dealer:
Date Purchased:
Date Installed:
Installer:
PLACE SERIAL NUMBER CARD WITH
PRODUCT CONFIGURATION IN THIS BOX
INSPECTION
Inspect the unit prior to installation. In the event of a
problem, DO NOT install the unit.
All components are factory assembled to the bath and the
unit is water tested and inspected prior to leaving Jason
International, Inc.
If the carton shows sign of damage, inspect the product
before accepting and describe the problem on the Bill of
Lading.
NOTE: Transportation and insurance from Jason’s
factory are the buyer’s responsibility.
Damage sustained in transit is the responsibility of
the carrier. If damage is discovered, the carrier must
be immediately notified in writing with a request for a
representative to inspect the unit. Failure of the carrier
to respond should be reported to the seller and carrier.
Always file a freight claim promptly.
The installer is responsible for insuring that the unit is
free from defects or shipping damage. In the event of a
problem, DO NOT install the unit.
If the carton shows sign of damage, inspect
the product before accepting and describe the
problem on the Bill of Lading.
Jason International is not responsible for damage that
might have been avoided by inspection or testing prior to
installation.
Damage to the unit during installation will not be covered
by warranty and is the responsibility of the installer.
ALL WARRANTY CLAIMS ON ACRYLIC SURFACE
DAMAGE MUST BE MADE PRIOR TO INSTALLATION.
Inspect plumbing and bath surface for missing or damaged
components. Alert your dealer of any discrepancies.
To protect the unit from damage keep the bath in the
carton until ready for installation.
EQUIPMENT ACCESS
In accordance with Building Codes, service access
to all therapy bath equipment, controls and electrical
connections must be provided during installation
(Recommended minimum 28" x 17" [71 x 43 cm]).
Insufficient access will hinder repair and maintenance.
Warranty service will not cover costs of providing
equipment access.
The Specification Sheet for this bath contains additional
technical information. This sheet can be provided by your
dealer or accessed online at www.jasoninternational.com.
Jason International, Inc.
8328 MacArthur Drive
North Little Rock, AR 72118
www.jasoninternational.com
MADE IN THE U.S.A.

Jason International, Inc. • 501.771.4477 Page 2 of 24 Customer Service : 800.255.5766
Copyright © 2013 Jason International.
INSTALLATION INSTRUCTIONS
INSTALLATION
Remove the product from its packaging. Read the entire
instructions prior to installing this product.
See the USER MAINTENANCE INSTRUCTIONS section of
this owner’s manual prior to installation for humidity and
mold prevention suggestions.
1. Remove the packing board from the skirt by placing the
bath and skirt assembly upside down and remove the four
press-in fasteners. See Figure 1.
Caution: Place bath deck on a surface that will not
scratch the acrylic surface of the bath.
2. Disassemble the bath from its skirt by removing the four (4)
nuts and washers located at the bottom of the bath with a
½" open ended wrench. Lift the skirt out of the bath. Place
the skirt and the bath in an upright position next to each
other. See Figure 1.
3. Set aside the template and locating stud kit, these will
be used later.
For AirMasseur®baths, remove the blower with stand,
check valve, tubing with (2) clamps, Sani Design™ Cleaning
System kit and electronics from the separate blower carton.
Set aside to be installed later.
For baths with the AEC Equipment Cabinet, set the
AEC carton aside to be installed later
4. Cardboard bath-well protector. Each bath is provided
with a cardboard bath-well protector that should be kept in
the unit throughout the bathroom construction process.
Note: Overflow drains, fill spouts, and valves must be
installed according to the instructions herein.
5. Installation template. An installation template is provided
to locate the floor drain position, sump area position, locat-
ing studs, remote blower tubing floor cutout position (when
applicable), water inlet stub-out position and skirt center
lines. Tape the template to the sub-floor in the desired loca-
tion.
6. Mark on the sub-floor the sump area position, the water
inlet stub-out position, and the remote blower-tubing floor
cut out position (when applicable). One remote blower
tubing, floor cutout position and four (4) water inlet stub-out
positions have been indicated on the template. Choose the
water inlet stub-out position that is preferable for your instal-
lation.
7. Remove the template and cut out the floor.
CAUTION: The floor drain location must be installed
according to the template. This location is critical to
the proper installation of this product.
Note: You must keep the template; it will be needed
during the next step of the installation process.
Note: Refer to Figure 2 to determine which cut-outs are
designed for use with your particular model.
Figure 1
Figure 2
RE-RC630PS RC553PS

Jason International, Inc. • 501.771.4477 Page 3 of 24 Customer Service : 800.255.5766
Copyright © 2013 Jason International.
INSTALLATION INSTRUCTIONS (cont.)
Figure 3
8. After the finished floor is installed, position the installation
template on the finished floor. Place the template to line up
with the existing floor drain location and orient the template
to the desired position.
Note: The sump area location cutout and remote
blower tubing floor location cutout (when applicable),
and water inlet stub-out must line up with the template.
Note: The keypad and Sani-Design™ cleaning system
(for AirMasseur®baths) have not been installed. See
the forma™ Collection FIELD INSTALLATION IN-
STRUCTIONS for the installation procedures.
9. Tape the template to the finished floor; using care to align
both center lines and assure that the template is lying flat on
the floor.
10. Transfer the center lines of the template to the finished
floor.
CAUTION: Use a marker that can be removed from the
finished floor after installation.
11. Position the Skirt (only) and align it with the centerlines on
the finished floor. Use the four existing 3/8" holes located
in the bottom four corners of the skirt to mark where to drill
the pilot holes for the four locating studs. If installing on a
wooden floor, 1/4" [6mm] holes are required, and a 5/16"
nut to install the locating studs into the wooden floor. When
installing on a cement slab, 3/8" [9.5mm] holes are required.
See Figure 3. After marking the hole locations, remove the
skirt and set aside.
12. Dry fit the drain and overflow to the bath.
a. Dry fit the drain and overflow to the bath. Use the
instructions included with the drain and overflow to
determine proper fit. It is recommended that flex
PVC pipe be used between the overflow and drain.
This will assure there is enough clearance between
the bath shell and the skirt for the drain.
b. Position bath in place and attach the drain and
overflow to the floor drain “P” trap. CAUTION:
Only dry fit the drain and overflow tee to the
“P” trap at this time.
c. Disconnect the drain and overflow from the bath
and leave the drain assembly free standing in the
“P” trap.
13. Align the drain with the center line on the template. See
Figure 4.
14. Permanently attach the drain tee to the “P” trap.
15. Remove the template from the floor.
16. Install the skirt location studs into the four (4) positions in
the floor. See Figure 5.
Locating Stud
Figure 4

Jason International, Inc. • 501.771.4477 Page 4 of 24 Customer Service : 800.255.5766
Copyright © 2013 Jason International.
INSTALLATION INSTRUCTIONS (cont.)
Figure 5 Figure 6
17. Attach faucet accessories to the bath (if applicable).
CAUTION: There is not enough room to mount a deck
mounted diverter valve on the deck of the bath.
If a hand-held shower is desired consider a floor mounted
faucet or a faucet with an above deck diverter.
If a floor mounted faucet is desired, be sure to install the
faucet to allow for sufficient overhang into the well of the
bath. This will ensure an unobstructed water flow out of the
faucet when filling the bath. Follow the faucet manufacturer’s
installation instructions.
18. Flex plumbing. Attach stainless steel flex plumbing to the
deck-mounted faucet (if applicable).
Note: Flex plumbing lines must be long enough so the
bath can be removed from the skirt if access is re-
quired in the future.
½" [12mm] 4 foot [122cm] stainless steel flex hoses may be
purchased from Jason International, Inc.
19. Remote Mounting of Blower. If the blower for the AirMas-
seur bath is to be remote mounted, refer to the REMOTE
MOUNTING OF AIR BLOWER section of this manual,
before proceeding to the next step.
20. Reattach the skirt to the bath by positioning the skirt on
the bath and fastening the 5/16" nut and washers to the
5/16” leveling bolts, nuts and washers attached to the bath.
Be sure that the skirt is positioned correctly allowing the PS
skirt clips to rest against the back of the skirt.
21. Position the bath and skirt assembly over the four locat-
ing studs. Align the drain and overflow with the correspond-
ing bath holes. See Figure 6.
Place bath and skirt assembly on raised blocks approxi-
mately 8" tall.
22. Flex Plumbing. Attach stainless steel flex plumbing to stub-
outs (if applicable). Faucetry connections should be tested
for leaks at this time.
23. Route cables. When applicable, route any electronic
cables through the floor cutout and make the appropriate
connections to the control box. See the CONTROL BOX
CONNECTIONS section of this manual for locations.
24. Remove blocks and place bath and skirt assembly in posi-
tion.
Jason baths are designed to be supported at the base of
the bath. If the floor is smooth and level the bath’s Level
Form™ base will provide proper drainage and support.
See Figure 7.
Note: Do not use a sand bed to install or level the bath.
Note: The bottom of the bath’s Level Form™ base must
be 1/8" lower than the bottom of the skirt.
Figure 7

Jason International, Inc. • 501.771.4477 Page 5 of 24 Customer Service : 800.255.5766
Copyright © 2013 Jason International.
INSTALLATION INSTRUCTIONS (cont.)
ELECTRICAL
Electrical Power Supply: These instructions are written
assuming 60Hz, 120v (or 240V for Signature Edition) power
supply. Special notations are also included for the Export
versions of the control equipment, and power supply.
WARNING: Verification of electrical requirements
MUST be made before installation. Refer to the equip-
ment labels for voltage and frequency requirements.
NOTE: Verify that the electrical service matches either the
120v or 240v system requirements for this bath.
NOTE: The bath is designed for indoor use only. The elec-
trical equipment must not be exposed to direct or indirect
water or moisture contact. The electrical equipment must
also be protected from dust and other airborne debris be-
fore, during, and after installation.
1. Electrical Service: A licensed electrician must pro-
vide the “dedicated” electrical service protected by a
GFCI. The location of the GFCI must be at least five (5)
feet (152 cm) away from the inside surface of the bath,
accessible for regular testing. Use copper conductors
only.
DANGER — RISK OF ELECTRIC SHOCK: Connect
only to a circuit protected by a Ground Fault Circuit
Interrupter (GFCI). In the unlikely occurrence of a cur-
rent imbalance in the power conductors, the GFCI will
interrupt the power to the bath.
WARNING: The electrical service to the GFCI must
not be interrupted by any control device. Likewise, the
electrical service from the GFCI to the bath control
should be direct and not interrupted by a switch. Never
use a switch in conjunction with a control device. This
will VOID THE MANUFACTURER’S WARRANTY.
2. GROUNDING IS REQUIRED. The unit should be
installed by a qualified service representative and
properly grounded.
3. INSTALL SERVICE CONNECTION AT LEAST 6"
(15cm) ABOVE SUB FLOOR.
ALL LOCAL AND STATE ELECTRICAL AND
PLUMBING CODES MUST BE OBSERVED. Where
there are no local codes the National Electric Code
(NEC) and Uniform Plumbing Code (UPC) shall be ob-
served. It is the responsibility of the installer/owner to
determine specific code compliance prior to installation
of the product.
NOTE: In the Commonwealth of Massachusetts,
installation is to be done by a Massachusetts licensed
plumber.
25. Drain and overflow. Complete the installation of the
drain and overflow per the instructions included with
the drain and overflow.
26. Test bath controls. Before finishing the installation,
it is recommended that the bath controls be tested
without filling the bath with water to assure that all
electric connections are properly working.
Note: Refer to the Electrical section for correct
installation of electrical components.
Note: Refer to the Product Test Diagnostics in
the Operating, Features, and Controls section for
testing.
27. It is recommended that the bath be water tested (filled
and operated), and the bath be inspected for leaks
Refer to the FILLING AND DRAINING Instructions
in the Features and Controls section of this owner’s
manual.
28. Seal the joint between the skirt bottom and the floor
with a silicone caulk. See Figure 8.
Figure 8

Jason International, Inc. • 501.771.4477 Page 6 of 24 Customer Service : 800.255.5766
Copyright © 2013 Jason International.
4. AirMasseur®Equipment
The AirMasseur®equipment may be shipped separate-
ly from the bath. The blower is prewired to the control
box. The control box has a 36" (91cm) cord with plug
end (junction box connection for 240v). The blower
control box is mounted on a stand. During installation,
the control box stand and controls must be positioned
horizontally and located to permit access for inspection
and servicing.
Standard/Premier Edition AirMasseur®Control Box
(120v). The blower control box must be plugged into a
dedicated 120v (volt), 15A (amp), 60Hz (hertz), Ground
Fault Circuit Interrupter (GFCI) protected circuit. See
Figure 9.
INSTALLATION INSTRUCTIONS (cont.)
Standard/Premier Edition AirMasseur®Control Box
(240v). The blower control box must be plugged into a
dedicated 240v (volt), 15A (amp), 50Hz (hertz), Ground
Fault Circuit Interrupter (GFCI) protected circuit. See
Figure 9.
Signature Edition AirMasseur®Control Box.
The blower junction box must be connected into a
dedicated 240v, 15A, 50 or 60Hz, GFCI protected
circuit. See Figure 9a.
Control Box
Light Cable
Check Valve
Blower
Blower Mount
Control Box
Keypad Cable
Light Cable
Keypad Cable
Low Water/Temp Cable
(Signature Edion)
Check Valve
Blower
Blower Mount
Ground - Green Wire
Neutral - White Wire
Hot - Black Wire
Dedicated
120V, 50 or 60 Hz
GFCI Protected
Service
L2
L1
GROUND
DEDICATED
240V,50 or 60 Hz
GFCI PROTECTED
SERVICE
NOTE: USE THE ABOVE
DIAGRAM FOR 240V, 50Hz
OR 60Hz SYSTEMS.
L2
L1
GROUND
DEDICATED
240V,50 or 60 Hz
GFCI PROTECTED
SERVICE
O
R
Figure 9
Standard/Premier Edition
AirMasseur®
Figure 9a
Signature Edition
AirMasseur®
Control Box
Light Cable
Check Valve
Blower
Blower Mount
Control Box
Keypad Cable
Light Cable
Keypad Cable
Low Water/Temp Cable
(Signature Edion)
Check Valve
Blower
Blower Mount
Ground - Green Wire
Neutral - White Wire
Hot - Black Wire
Dedicated
120V, 50 or 60 Hz
GFCI Protected
Service
L2
L1
GROUND
DEDICATED
240V,50 or 60 Hz
GFCI PROTECTED
SERVICE
NOTE: USE THE ABOVE
DIAGRAM FOR 240V, 50Hz
OR 60Hz SYSTEMS.
L2
L1
GROUND
DEDICATED
240V,50 or 60 Hz
GFCI PROTECTED
SERVICE

Jason International, Inc. • 501.771.4477 Page 7 of 24 Customer Service : 800.255.5766
Copyright © 2013 Jason International.
5. MicroSilk Equipment
The MicroSilk equipment will be shipped separate
from the bath with the AEC Equipment Cabinet. Follow
the instructions for the AEC EQUIPMENT CABINET
INSTALLATION section of this owner’s manual. The
control box has a 36" (91cm) cord with plug end (junc-
tion box connection for 240v). The MicroSilk control
box is mounted on a stand.
Standard/Premier Edition MicroSilk®Control Box
(120v). The MicroSilk control must be plugged into a
dedicated 120v, 20A, 60Hz, GFCI protected circuit.
See Figure 10.
INSTALLATION INSTRUCTIONS (cont.)
Standard/Premier Edition MicroSilk®Control Box
(240v). The MicroSilk control must be plugged into a
dedicated 240v, 15A, 60Hz, GFCI protected circuit.
See Figure 10.
Signature Edition MicroSilk®Control Box (240v).
The MicroSilk control must be plugged into a dedicated
240v, 15A, 60Hz, GFCI protected circuit.
See Figure 10a.
DANGER: Do not alter the factory installed wiring. All
building materials and wiring should be routed away
from the equipment or other heat-producing compo-
nents of the unit.
Figure 10
Standard/Premier Edition
MicroSilk®
m
MICROSILK™
Control Box
Dedicated
120V, 50 or 60 Hz
GFCI Protected
Service
Ground
L2
L1
Dedicated
240V, 50 or 60 Hz
GFCI Protected
Service
L2
L1
GROUND
DEDICATED
240V,50 or 60 Hz
GFCI PROTECTED
SERVICE
NOTE: USE THE ABOVE
DIAGRAM FOR 240V, 50Hz
OR 60Hz SYSTEMS.
Control Box
Ground - Green Wire
Neutral - White Wire
Hot - Black Wire
Control Box
Dedicated
120V, 50 or 60 Hz
GFCI Protected
Service
Ground
L2
L1
Dedicated
240V, 50 or 60 Hz
GFCI Protected
Service
L2
L1
GROUND
DEDICATED
240V,50 or 60 Hz
GFCI PROTECTED
SERVICE
NOTE: USE THE ABOVE
DIAGRAM FOR 240V, 50Hz
OR 60Hz SYSTEMS.
Control Box
Ground - Green Wire
Neutral - White Wire
Hot - Black Wire
Figure 10a
Signature
Edition MicroSilk®
m
AIRMASSEUR®& MICROSILK®
SIGNATURE EDITION ONLY
L2-WHITE WITH
RED MARK
L1-BLACK
GND-GREEN
FROM BLOWER CONTROL
FROM MICROSILK CONTROL
L2
240 V
L1
NO CONNECTION
(LOAD NEUTRAL)
BREAKER BOX
Note: The load neutral terminal is not used. There should be no connection to the load neutral
terminal on the GFCI circuit breaker. The green wire (GND-GREEN) is the equipment ground
and should be connected to the neutral bus found in the main breaker box.
BREAKER BOX CONNECTIONS

Jason International, Inc. • 501.771.4477 Page 8 of 24 Customer Service : 800.255.5766
Copyright © 2013 Jason International.
INSTALLATION INSTRUCTIONS (cont.)
REMOTE MOUNTING OF AIR BLOWER
The Jason AirMasseur®system has been factory installed
following E.T.L. guidelines. During installation, if remote
mounting of the blower and its control box is desired, follow
these procedures.
Note: Do not remote mount the blower and control box
more than 15 feet [457 cm] away from the air inlet of the
bath. Choose a location as close as possible to the bath to
assure maximum efficiency.
1. Determine layout. The installer is to determine the
layout of the piping, exact remote mount location, and
service access before beginning any work.
a. Use 1.5" [38 mm] ABS or PVC plastic tubing.
b. Locate the control box with the blower in an area
accessible for servicing.
c. To ensure proper functioning of the system, avoid
remote mounting in a location which requires more
than six (6) piping direction changes. A 90° direc-
tion change should be made up of two 45° elbows
for maximum efficiency.
2. Install the blower and control box in the remote
location.
a. A minimum ventilation opening of 2" x 4"
[5 cm x 10 cm] for the blower is required, and
should be designed to draw in indoor ambient air at
a minimum of 72°F (22°C).
b. Attach the blower mount firmly to the floor.
c. Attach the piping to the blower’s check valve. Use
screws to attach the pipe to the check valve and
route the hose to the remote blower tubing floor
cutout location.
CAUTION: Do NOT use ABS or PVC glue near
the blower, it could ignite and cause a fire.
3. Attach hose. Attach one end of the blower hose to the
bath connection with the included clamp.
4. Pipe stub out. Extend piping stub-out through the
floor as illustrated in Figure 9. Piping between the
remote blower location and the bath can be insulated
using a minimum of 1/2" [12 mm] thick insulation.
WARNING: ANY MODIFICATION TO THE EQUIP-
MENT IS NOT RECOMMENDED AND WILL VOID
THE MANUFACTURER’S WARRANTY.
5. Attach hose. Attach the other end of the hose to the
1-1/2" [38 mm] PVC pipe that is plumbed to the blower
with the included clamp.
6. Route cables. Route the keypad cable, low water
level/temperature sensor cable (if applicable), and the
light cable through the floor cutout to be connected to
the control box.
WARNING: When routing cables, do not allow the
cable to be pinched under the bath shell.
Use the tie buttons attached to the bath to support the
cables.
Note: A minimum of 4 feet [122 cm] of hose and
cable must be free from binding to allow for pull-
ing the cables back up through the floor cutout.
During installation if it is preferred to run the blower
hose on top of the floor, a 2 1/2" [6.35 cm] diameter
hole can be drilled at the bottom of the skirt. A means
to cover the hole, hose, and wires is not provided.
See Figure 7.
7. Return to the bath installation section to finish installa-
tion of the freestanding bath.

Jason International, Inc. • 501.771.4477 Page 9 of 24 Customer Service : 800.255.5766
Copyright © 2013 Jason International.
CAUTION: Do not allow the cabinet to touch the bath
or the skirt. This could produce excessive noise.
The PVC trim, around the opening in the cabinet, has a
flexible sweep and is used to help obscure the plumbing
between the enclosure and the skirt.
3. Remove the four (4) decorative caps and screws
on the bottom sides of the cabinet and lift the cabinet
off of the metal frame and set it aside. Use the (4)
included #12 screws to attach the frame to the floor.
See Figure 13.
INSTALLATION INSTRUCTIONS (cont.)
ACRYLIC EQUIPMENT CABINET INSTALLATION
The Jason Acrylic Equipment Cabinet (AEC ) can be
used to house the bath equipment that cannot be remote
mounted away from the bath. The cabinet is standard on
freestanding MicroSilk®baths and is available as an option
for freestanding AirMasseur®baths. To install the AEC,
follow these procedures
Figure 11
1. Remove the preassembled AEC assembly from the
box and detach all components from the packing board
by removing the tie straps. See Figure 11.
2. Place the AEC assembly only in the front of the
bath skirt access opening. The center of the cabinet
should be aligned with the center of the opening leav-
ing a 1/8" gap between the top of the cabinet and the
bath skirt. See Figure 12.
Figure 12a
Figure 12b
Figure 13a

Jason International, Inc. • 501.771.4477 Page 10 of 24 Customer Service : 800.255.5766
Copyright © 2013 Jason International.
INSTALLATION INSTRUCTIONS (cont.)
Figure 13b
4. Place the equipment inside the frame and attach
all the plumbing and electrical connections. See
Figure 14a for AirMasseur®and 14b for MicroSilk®
baths.
Note: The electrical service can be provided inside
or outside the enclosure. Refer to the ELECTRICAL
section of this manual for service requirements. If the
service is outside the cabinet, position cord through the
slot provided in the frame and enclosure.
5. For MicroSilk baths, clamp the plumbing lines to
the appropriate barb using the clamp provided.
Assure the line will allow proper drainage to the bath
fitting. The hose must have a continuous drop from the
barb to the fitting. See Figure 14c.
Figure 14b
Figure 14c
6. Refer to faucet manufacturer’s installation instruc-
tions if a faucet is intended to be mounted on the top of
the cabinet and position the plumbing stub outs inside
the cabinet.
Caution: Use long enough stainless steel flexible
hose to lift the enclosure up to provide access
for disassembly in the future. Be sure to install a
faucet that will reach the well of the bath from the
enclosure. Refer to the bath specification sheet for
deck width dimensions.
7. Fill the bath and test all connections for leaks.
8. Place cabinet on the frame and attach with the four (4)
screws and decorative caps.
Figure 14a

Jason International, Inc. • 501.771.4477 Page 11 of 24 Customer Service : 800.255.5766
Copyright © 2013 Jason International.
INSTALLATION INSTRUCTIONS (cont.)
CLEANING
1. Remove all loose debris. Construction plaster or
excess grout can be removed with the use of a wood
(edge) trowel.
2. Paint or tar stains may need to be removed with a
cleaner such as paint thinner, turpentine, or isopropyl
alcohol (rubbing alcohol). Never allow the cleaner to
soak against the acrylic surface for long periods of
time. Always rinse the surface immediately follow-
ing the use of cleaners.
3. Follow the manufacturer’s instructions for safe use of
cleaning products. If the surface becomes scratched
or dulled, it may be restored by using a quality plastic
polish, like Novus Plastic Polish No. 2 (available from
the Jason Dealer). It is always preferable to protect
the acrylic surface during installation to minimize
cleanup and prevent surface damage.
WATER TESTING
Before finishing the installation, it is recommended that the
bath be water tested and the plumbing tested for leaks.
1. Before water testing the bath, make sure all plumb-
ing connections are tight. DO NOT OVERTIGHTEN.
2. Fill and operate the bath. Close the drain and fill the
bath with water to at least 10 inches [25 cm] below the
bath deck. The inlet temperature should not exceed
104°F (40°C). Refer to the FILLING AND DRAINING
section of this owner’s manual for more information.
NEVER RUN THE PUMP WITHOUT ENOUGH
WATER IN THE BATH TO COVER THE JETS.
3. Inspect the plumbing for leaks.
4. Turn the equipment Off and then drain the water.
The bath unit and its plumbing are designed to drain
after each use whether used as a hydrotherapy bath,
soaking bath, or when taking a shower.

Jason International, Inc. • 501.771.4477 Page 12 of 24 Customer Service : 800.255.5766
Copyright © 2013 Jason International.
AIRMASSEUR® CONTROL BOX CONNECTIONS
STANDARD EDITION AIRMASSEUR®
Jason’s Standard Edition AirMasseur®system features
the best in luxury bathing for the leisure bath industry. To
assure that your bath functions properly the blower control
must be properly connected.
NOTE: For 120v systems, the power cord for the Blower
control box must be plugged into a 120v, 15 amp GFCI
dedicated circuit.
THE BLOWER CONTROL BOX
The blower and keypad must be plugged into the proper re-
ceptacles for correct operation of the AirMasseur® system.
See Figure 15 for connections:
(A) The power cord for the blower control box must be con-
nected into the proper GFCI dedicated circuit for the system
(see note above).
(B) Pre-wired power cord to the blower.
(C) 8-pin mini-DIN terminal for the AirMasseur® keypad.
Figure 15
NOTE: This diagram (Figure 15) also applies to 50 Hz,
240v controls, and power supply systems. Except that the
Blower junction box must be connected into one dedicated
240v, 15 Amp GFCI circuit.
PREMIER EDITION AIRMASSEUR®
Jason’s Premier Edition AirMasseur®system incorporates
all the features of the Standard Edition system and includes
the benefits of ozone sanitation system, and an LED
Chromatherapy light. To assure that your bath functions
properly, the blower control box must be properly
connected.
NOTE: For 120v systems, the power cord for the Blower
control box must be plugged into a 120v, 15 amp GFCI
dedicated circuit.
THE BLOWER CONTROL BOX
The blower and keypad must be plugged into the proper re-
ceptacles for correct operation of the AirMasseur® system.
See Figure 16 for connections:
(A) The power cord for the blower control box must be con-
nected into the proper GFCI dedicated circuit for the system
(see note above).
(B) Pre-wired power cord to the blower.
(C) 8-pin mini-DIN terminal for the AirMasseur® keypad.
(D) Pre-wired power cord for the ozone unit.
(E) 6-pin mini-DIN terminal for LED light.
NOTE: This diagram (Figure 16) also applies to 50 Hz,
240v controls, and power supply systems. Except that the
Blower junction box must be connected into one dedicated
240v, 15 Amp GFCI circuit.
Figure 16

Jason International, Inc. • 501.771.4477 Page 13 of 24 Customer Service : 800.255.5766
Copyright © 2013 Jason International.
CONTROL BOX CONNECTIONS (cont.)
SIGNATURE EDITION AIRMASSEUR®
Jason’s Signature Edition AirMasseur®system is the most
advanced bath manufactured by Jason International, Inc.
and features the ultimate in luxury bathing for the leisure
bath industry. The blower control box must be properly
connected for the bath to function correctly.
THE BLOWER CONTROL BOX
The blower, keypad, LED light, ozone sanitation unit, and
water level/temperature sensor must be plugged into the
proper receptacle for correct operation of the AirMasseur®
system. See Figure 17 for connections:
(A) The junction box for the blower control box must be
connected into a 240v, 15 amp GFCI dedicated circuit.
(B) Pre-wired power cord to blower (C).
(D) 6-pin mini-DIN terminal for the water/temperature sensor
(E) 6-pin mini-DIN terminal for the LED light.
(F) 8-pin mini-DIN terminal for installation of AirMasseur®
keypad
(G) Pre-wired power cord to ozone unit.
Figure 17
NOTE: This diagram (Figure 17) also applies to 50 Hz,
240v controls, and power supply systems.
MICROSILK® CONTROL BOX CONNECTIONS
STANDARD EDITION MICROSILK®
Jason’s Standard Edition MicroSilk®system features the
best in luxury bathing for the leisure bath industry. To as-
sure that your bath functions properly, the MicroSilk®pump
control box must be properly connected.
NOTE: For 120v systems, the power cord for the Mi-
croSilk®control box must be plugged into a 120v, 20
amp GFCI dedicated circuit.
THE MICROSILK®CONTROL BOX
The MicroSilk®unit and Keypad must be plugged into the
proper receptacles for correct operation of the MicroSilk®
system. See Figure 18 for connections:
(A) The power cord for the MicroSilk®control box must be
connected into the proper GFCI dedicated circuit for the
system (see note above).
(B) Pre-wired power cord from MicroSilk pump to control (C).
(D) Eight-pin mini-DIN terminal for the MicroSilk®Keypad.
(E) Six-pin mini-DIN terminal for optional LED light.
Figure 18
NOTE: This diagram (Figure 18) also applies to 50 Hz,
240v pumps, controls, and power supply systems. Except
that the MicroSilk®Pump junction box must be connected
into one dedicated 240v, 20 Amp GFCI circuit.

Jason International, Inc. • 501.771.4477 Page 14 of 24 Customer Service : 800.255.5766
Copyright © 2013 Jason International.
CONTROL BOX CONNECTIONS (cont.)
SIGNATURE EDITION MICROSILK®
Jason’s Signature Edition MicroSilk®system is the most
advanced bath manufactured by Jason International, Inc.
and features the ultimate in luxury bathing for the leisure
bath industry. The MicroSilk®control box must be properly
connected for the bath to function correctly.
THE MICROSILK®CONTROL BOX
The MicroSilk®unit, Keypad, LED light, Ozone Sanita-
tion Unit and Water Level/Temperature Sensor must be
plugged into the proper receptacles for correct operation of
the MicroSilk®system. See Figure 20 for connections:
(A) The junction box for the MicroSilk®control box must be
connected into a 240v, 20 amp GFCI dedicated circuit.
(B) The MicroSilk®pump’s power cord will need to be
plugged into the control box
(C). Refer to the ELECTRICAL section of this manual for
connecting the pump to the control box.
(D) Six-pin mini-DIN terminal for installation of the water
sensor to the pump control box.
(E) Eight-pin mini-DIN terminal for the MicroSilk®Keypad.
(F) Six-pin mini-DIN terminal for LED light.
(G) Ozone Unit pre-wired to control box.
PREMIER EDITION MICROSILK®
Jason’s Premier Edition MicroSilk®system incorporates all
the features of the Standard Edition system and includes
the benefits of an ozone sanitation system and an LED
Chromatherapy light. To assure that your bath functions
properly, the MicroSilk®control box must be properly con-
nected.
NOTE: For 120v systems, the power cord for the
MicroSilk®control box must be plugged into a 120v, 20
amp GFCI dedicated circuit.
THE MICROSILK®CONTROL BOX
The MicroSilk®unit, Keypad, LED light, and Ozone Sanita-
tion Unit must be plugged into the proper receptacles for
correct operation of the MicroSilk®system. See Figure 19
for connections:
(A) The power cord for the MicroSilk®control box must be
connected into the proper GFCI dedicated circuit for the
system (see note above).
(B) Pre-wired power cord from MicroSilk pump to control (C).
(D) Eight-pin mini-DIN terminal for the MicroSilk®Keypad.
(E) Six-pin mini-DIN terminal for LED light.
(F) Ozone Unit pre-wired to control box.
NOTE: This diagram (Figure 19) also applies to 50 Hz,
240v pumps, controls, and power supply systems. Except
that the MicroSilk®Pump junction box must be connected
into one dedicated 240v, 20 Amp GFCI circuit.
NOTE: This diagram (Figure 20) also applies to 50 Hz,
240v pumps, controls, and power supply systems.
Figure 19
Figure 20

Jason International, Inc. • 501.771.4477 Page 15 of 24 Customer Service : 800.255.5766
Copyright © 2013 Jason International.
OPERATING INSTRUCTIONS, FEATURES, & CONTROLS
INTRODUCTION
This manual contains all of the information needed for
the proper installation and operation of your Jason bath.
The bath has been designed to give you years of relaxing
trouble-free service, provided the unit is maintained and
operated in accordance with these instructions. Thoroughly
clean and disinfect the unit as described in the CLEANING
section of the USER MAINTENANCE INSTRUCTIONS
section of this owner’s manual before its first use and peri-
odically thereafter.
All Jason baths are pre-plumbed at the factory.
WARNING: Before operating, refer to the instructions
at the end of this owner’s manual pertaining to the risk
of fire, electric shock, or injury to persons.
AIRMASSEUR®OPERATION
STANDARD AND PREMIER EDITION AIRMASSEUR®
The Jason Standard Edition AirMasseur®bath includes
a variable-speed, 1-HP air blower with heater, automatic
purge cycle; and three (3) massage modes: Continuous,
Wave, or Pulse; an electronic control; and a 20-minute
timer.
The Jason Premier Edition AirMasseur®bath provides all
the features of the Standard Edition with the included ben-
efits of a LED Chromatherapy Mood Light, and an Ozone
Sanitation system.
Standard/Premier Touchpad
One main control touchpad mounted on the bath deck con-
tains several icons used by the bather to control the blower,
and LED mood light. A built in timer shuts the blower off 20
minutes after being activated.
Standard/Premier Automatic Purge
Fifteen (15) minutes after the control has shut off and the
bath is completely drained, the blower will start again for a
two-minute purge cycle that dries the air channel. Note that
the blower light will flash during the 15-minute pause be-
fore the purge cycle begins. Once the purge cycle begins,
all indicators will light and the keypad operation will be
disabled for two (2) minutes.
SIGNATURE EDITION AIRMASSEUR®
The Jason Signature Edition AirMasseur®bath includes
a variable-speed, 1-HP air blower with heater, automatic
purge cycle; and three (3) massage modes: Continuous,
Wave, or Pulse; Chromatherapy mood light, Automatic
Ozone System that will be operated any time the blower
is powered; a digital control with LCD display window; low
water and temperature sensors; and a 20-minute timer.
Signature Touchpad
A main control touchpad mounted on the bath deck features
a LCD readout which alternately indicates the water tem-
perature (+/- 5°F) and time remaining. The Signature Edition
touchpad allows the bather to control the blower, pump,
LED mood light and optional jetted neck pillow. A built in
timer shuts the pump and blower off 20 minutes after being
activated.
Signature Automatic Purge
Twenty (20) minutes after the control has shut off and the
bath is completely drained, the blower will start again for a
two minute purge cycle that dries the air channel. Note that
the LCD display will read “PURGE” and begin to countdown
the 10 or 20 minute pause before the purge cycle begins.
The readout will display “PURGE ON” during the purge
cycle. Any time during the pause before the purge cycle
begins, pressing and holding the Blower Speeds icon will
reduce the pause from 20 minutes to 10 minutes. During
the two-minute purge, pressing the “Blower On/Off” icon
will stop the purge.
Signature Daily Purge
The daily purge can be activated through the customized
settings of the Signature Edition touchpad. When activated,
the daily purge will start the blower for two-minutes at the
same time every day to dry the air channel. See ‘Operat-
ing the Signature Edition AirMasseur Touchpad’ section for
details on activating this setting.
Signature Remote Control
In addition to the main control touchpad installed on the
bath deck, a floating, waterproof Universal Remote Control
is provided with all Signature Edition AirMasseur®baths.
This remote control provides the same control functions
as the bath’s main control console, plus the bather may
remotely operate a TV, DVD, VCR, CD, etc. Refer to the
Instruction Manual provided with the remote control for
detailed instructions.
Blower
The blower generates warm air and pushes it through the
air jets. Blowers provided on Jason AirMasseur®baths are
factory tested when assembled and again retested after
installation on the bath.
Filling And Draining
Close the drain and fill the bath with water at least two (2)
inches (50mm) above the jets. The inlet temperature should
not exceed 104°F (40°C). When bath is in use, turn the unit
Off before draining the water. The bath unit and its plumb-
ing are designed to drain after each use whether used as a
hydrotherapy bath, soaking bath, or just taking a shower.

Jason International, Inc. • 501.771.4477 Page 16 of 24 Customer Service : 800.255.5766
Copyright © 2013 Jason International.
O
AirMasseur
Mode Blower Speeds
Option
STANDARD EDITION AIRMASSEUR®TOUCHPAD
The Jason Standard Edition AirMasseur®touchpad is used to access all the functions of the blower control.
Blower Speeds Icon
The Blower Speeds icon is used to increase or decrease
the blower speed once the blower is On.
- Press and hold the icon to decrease the blower speed
until the desired intensity is reached, then release.
- Press and hold the icon again to increase the blower
speed until the desired intensity is reached.
The blower will return to its highest speed on any mode
change.
Option
The Option icon is used to operate an optional LED light (if
installed).
- Press the icon for less than two (2) seconds to turn the
lights Off or On.
- Hold the icon for more than two (2) seconds to change
modes.
This function has a two (2) hour timer and remembers the
last mode.
OPERATING INSTRUCTIONS
AirMasseur®Icon
The AirMasseur®icon is used to activate the blower and
the 20-minute timer.
- Pressing the Icon once starts the blower in the Constant
high speed mode.
- Pressing the icon again will turn the blower off.
Note: The blower will always turn on in high speed.
Mode Icon
The Mode icon is used to move the blower from Constant
mode to the Wave or Pulse modes.
- Press and release the icon once to change the blower
to the Wave mode, indicated by a slow flashing light.
- Pressing the icon again will change the blower to Pulse
mode. This is indicated by a rapid light flash.
- Pressing the icon a third time moves the blower back to
Constant mode.
OPERATING INSTRUCTIONS, FEATURES, ANd CONTROLS (cont.)

Jason International, Inc. • 501.771.4477 Page 17 of 24 Customer Service : 800.255.5766
Copyright © 2013 Jason International.
Figure 9
SIGNATURE EDITION AIRMASSEUR®TOUCHPAD
The Jason Signature Edition Digital AirMasseur®touchpad is used to access all
of the functions of the control box used in a Jason Signature Edition AirMasseur®bath.
Customized Settings
The 12 character LCD display can be customized
by pressing the Blower and Blower Speeds icons
simultaneously for five (5) seconds, while the system is
Off. Note: The Blower Speeds icon will not be illuminated
during this process. Use the above figure to locate the
icon. A menu (see below) will be displayed to choose the
following: Purge 24, (starts the blower every 24 hours for
two (2) minutes at the time the purge was set); Product
Test Diagnostics (see below); Temperature (Fahrenheit or
Celsius); and Language (English or Spanish).
Menu Instructions
Use the Blower icon to scroll through the different menu
items. Use the Blower Speeds icon to change an option.
For example, press and release the Blower icon to change
from Purge 24 to Product Test; press and release again to
arrive at the Temperature option. Then press and release
the Blower Speeds icon to change the temperature display
from F (Fahrenheit) to C (Celsius).
Product Test Diagnostics
After selecting the Product Test option from the menu,
the unit will perform a series of tests to confirm correct
installation of components. The test will begin by displaying
the configuration number, followed by the software revision
number. Next, the display will test the Temperature and
Low Water Level sensor (ITW-209). Next, each of the six
(6) icons will begin to light. Press the illuminated icon to
proceed to the next icon. After the icon test, the blower will
start for two (2) seconds on the High setting. Lastly, the
LED Light unit will be tested. If you receive an error on any
of the tests, confirm proper installation of the component
to the correct control box. (See the CONTROL BOX
CONNECTIONS section).
Remote Control
The Signature Edition control system includes a waterproof
floating Universal Remote Control. It controls all bath
functions plus a TV, DVD, CD, etc. which can be heard
through the optional Sound Immersion Transducers
(optional).
Blower On/Off, Modes
Blower Speeds
LED Light
IR for Remote
OPERATING INSTRUCTIONS, FEATURES, AND CONTROLS (cont.)
OPERATING INSTRUCTIONS
Blower On/Off and Modes Icon
To control the operation of the blower, simply press and
release to change the setting to Constant, Wave, Pulse
or Off. A 20 minute decreasing timer will be initiated when
the blower motor starts. Press and hold the Blower icon to
cycle though blower modes. The Blower icon should remain
lit as long as the bath is connected to a power supply. The
LCD will display “Const Air” and blower speed, “Wave Air”
and blower speed, or “Pulse Air” and blower speed, while
the key is pressed. The time remaining on the purge cycle
is displayed after the bath has drained. “Purge Stop” is
displayed while the key is pressed during the purge cycle.
This action will terminate the purge cycle. The mode settings
will be remembered on the next startup.
Blower Speeds Icon
Hold the key in Constant mode to go from High to Low then
release and hold again to go from Low to High. Hold the
key in Wave and Pulse mode to go from High to Medium
and Medium to High. The system remembers the last speed
setting on the next startup. The Blower Speeds icon will light
up when the blower is running. The LED displays the blower
speed from “10” (Low) or “55"(Med) to “99” (High) while the
key is pressed. You can reduce the auto purge idle time
from 20 minutes to 10 minutes, by pressing and holding the
key for more than 5-seconds during the purge idle period.
LED Light Icon
Hold the icon for less than two (2) seconds to turn the lights
Off or On. Hold the icon for more than two (2) seconds to
change modes. The Light icon should remain lit as long as
the bath is connected to a power supply. This function has a
two (2) hour timer and remembers the last mode. The LCD
displays “Light On” or “Light Off” while the icon is pressed
for less than two (2) seconds. “Light Cycle” is displayed if
pressed for more than two (2) seconds.

Jason International, Inc. • 501.771.4477 Page 18 of 24 Customer Service : 800.255.5766
Copyright © 2013 Jason International.
MICROSILK®OPERATION
STANDARD AND PREMIER EDITION MICROSILK®
The Jason Standard Edition MicroSilk®bath includes a
Microbubble generator unit, an electronic control, and a
20-minute timer.
The Jason Premier Edition MicroSilk®bath provides all the
features of the Standard Edition with the included benefits
of an LED Chromatherapy Mood Light, and an Ozone
Sanitation system.
Standard/Premier Touchpad
One main control touchpad mounted on the bath deck
features several icons used by the bather to control the
MicroSilk®unit and LED mood light. A built-in timer shuts
the pump off 20 minutes after being activated.
SIGNATURE EDITION MICROSILK®
The Jason Signature Edition MicroSilk bath includes a
Microbubble generator unit; Chromatherapy mood light,
Automatic Ozone System that will be operated any time
the pump is powered; a digital control with LCD-display
window; low water and temperature sensors;
and a 20-minute timer.
Signature Touchpad
A main control touchpad mounted on the bath deck fea-
tures an LCD readout which alternately indicates the water
temperature (+/- 5° F) and time remaining. The Signature
Edition touchpad allows the bather to control the MicroSilk®
pump and LED mood light. A built-in timer shuts off the
pump 20 minutes after being activated.
OPERATING INSTRUCTIONS, FEATURES, AND CONTROLS (cont.)
Signature Remote Control
In addition to the main control touchpad installed on the
bath deck, a floating, waterproof Universal Remote Control
is provided with all Signature Edition MicroSilk®baths. This
remote control provides the same control functions as the
bath’s main control console, plus the bather may remotely
operate a TV, DVD, VCR, CD, etc. Refer to the Instruc-
tion Manual provided with the remote control for detailed
instructions.
Port
A strategically placed MicroSilk®port is provided for com-
plete enjoyment of your bath.
MicroSilk®Unit
The MicroSilk®unit generates oxygen-rich microbubbles
that fill the bath. MicroSilk®units provided on Jason baths
are factory tested when assembled and again retested
after installation on the bath.
Filling and Draining
Close the drain and fill the bath with water at least two (2)
inches (50mm) above the jet. The inlet temperature should
not exceed 104°F (40°C). When bath is in use, turn the unit
Off before draining the water. The bath unit and its plumb-
ing are designed to drain after each use whether used as a
hydrotherapy bath, soaking bath, or just taking a shower.
NOTE: If the unit fails to operate, check the breaker
panel to ensure that the circuit breaker is on. Check
the GFCI by testing and resetting it. Also check the
water level in the bath; it must be above the water
level sensor located on the sidewall of the bath for the
pump to operate. If the unit still fails to operate, refer
to the Trouble Shooting Guide section of this manual.
If the unit still fails to operate and is out of warranty,
contact an authorized service technician for repair.
If the unit is within the warranty period,
contact JASON Technical Services at 800-255-5766.
DO NOT ATTEMPT TO RESOLVE THE PROBLEM.

Jason International, Inc. • 501.771.4477 Page 19 of 24 Customer Service : 800.255.5766
Copyright © 2013 Jason International.
STANDARD AND PREMIER EDITION
MICROSILK®TOUCHPAD
The Jason Standard and Premier Edition MicroSilk®
touchpad is used to access all of the functions of the pump
control.
OPERATING INSTRUCTIONS
MicroSilk
®
On/Off Icon
The MicroSilk
®
icon is used to activate the MicroSilk
®
unit
and the 20-minute timer.
• Press the icon the first time to start the MicroSilk
®
unit.
• Press the icon again to shut off the MicroSilk
®
unit.
LED Light Icon
The LED Light icon is used to operate an LED light (if
installed).
• Press the icon for less than two (2) seconds to turn the
lights Off or On.
• Hold the icon for more than two (2) seconds to change
modes.
This function has a two-(2) hour timer and remembers the
last mode.
m
MICROSILK
LED Light
MicroSilk™ On/Off
®
®
OPERATING INSTRUCTIONS, FEATURES, AND CONTROLS (cont.)

Jason International, Inc. • 501.771.4477 Page 20 of 24 Customer Service : 800.255.5766
Copyright © 2013 Jason International.
The Jason Signature Edition MicroSilk
®
digital touchpad is
used to access all the functions of the MicroSilk
®
bath.
OPERATING INSTRUCTIONS
MicroSilk
®
On/Off Icon
To control the operation of the MicroSilk
®
pump motor,
press and release for each setting: ON or OFF. A
20-minute decreasing timer will be initiated when the
pump motor starts. Press and hold the Pump icon to cycle
through each pump setting. The Pump icon lights when
the water is at operating level and the LCD displays
“System Ready”. The LCD will display “Pump On”, or
“Pump Off” when the key is pressed. It also toggles
between Temperature and Timer at 5 second intervals.
“Low Water” is displayed for 5 seconds if no water is
detected.
LED Light Icon
Hold the key for less than two (2) seconds to turn the
lights Off or On. Hold the key for more than two (2)
seconds to change modes. The Light icon should remain
lit as long as the bath is connected to a power supply.
This function has a two-hour timer and remembers the
last mode. The LCD displays “Light On” or “Light Off”
while the key is pressed for less than two (2) seconds,
“Light Cycle” is displayed if pressed for more than two (2)
seconds.
Customized Settings
The 12-character LCD display can be customized
by pressing the two Diagnostic Function icons
simultaneously for five (5) seconds, while the system
is off. Note: Use the above figure to locate the icons. A
menu will be displayed to choose the following: Product
Test Diagnostics, Temperature (°F or °C) and Language
(English or Spanish).
Menu Instructions
Use the top Diagnostic Function icon to scroll through the
different menu items. Use the bottom Diagnostic Function
icon to change an option. For example, press and
release the top icon to change from Product Test to the
Temperature option. Press and release the bottom icon to
change the temperature display from °F (Fahrenheit) to °C
(Celsius).
Product Test Diagnostics
After selecting the Product Test option from the menu,
the unit will perform a series of tests to confirm correct
installation of components. The test will begin by
displaying the configuration number, followed by the
software revision number. Next, the display will then test
the Temperature and Low Water level sensor (ITW-209).
Next, each of the six (6) icon buttons will begin to light.
Press the illuminated button to proceed to the next icon.
After the icon test, the LED Light unit will be tested. If
you receive an error on any of the tests, confirm proper
installation of component to the correct control box. (See
the CONTROL BOX CONNECTIONS section).
Remote Control
The Signature Edition control system includes a
waterproof floating Universal Remote Control. It controls
all bath functions plus a TV, DVD, CD, etc., which can
be heard through the Sound Immersion Transducers
(optional).
SIGNATURE EDITION
MICROSILK®TOUCHPAD
m
IR for Remote
LED Light
For Diagnostic Functions
For Diagnostic Functions
MicroSilk™ On/Off
Display Panel
®
OPERATING INSTRUCTIONS, FEATURES, AND CONTROLS (cont.)
