JASON Hydrotherapy BY630 User manual

Jason International, Inc. • 501.771.4477 Page 1 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
“TO BE REMOVED FOR USE BY THE OCCUPANT.”
49-1012-100
Date 03/11
OWNER’S MANUAL
Designer Whirlpool Baths
INSTALLATION, OPERATION, AND MAINTENANCE
Jason International, Inc.
8328 MacArthur Drive
North Little Rock, AR 72118
www.jasoninternational.com
OWNER’S RECORD
Dealer:
Date Purchased:
Date Installed:
Installer:
PLACE SERIAL NUMBER CARD WITH
PRODUCT CONFIGURATION IN THIS BOX
INSPECTION
Inspect the unit prior to installation. In the event of a
problem, DO NOT install the unit.
All components are factory assembled to the bath and the
unit is water tested and inspected prior to leaving Jason
International, Inc.
If the carton shows sign of damage, inspect the product
before accepting and describe the problem on the Bill of
Lading.
NOTE: Transportation and insurance from Jason’s
factory are the buyer’s responsibility.
Damage sustained in transit is the responsibility of the
carrier. If damage is discovered,
If the carton shows sign of damage, inspect
the product before accepting and describe the
problem on the Bill of Lading.
the carrier must be immediately notified in writing with a
request for a representative to inspect the unit. Failure of
the carrier to respond should be reported to the seller and
carrier. Always file a freight claim promptly.
The installer is responsible for insuring that the unit is
free from defects or shipping damage. In the event of a
problem, DO NOT install the unit.
Jason International is not responsible for damage that
might have been avoided by inspection or testing prior to
installation.
Damage to the unit during installation will not be covered
by warranty and is the responsibility of the installer. ALL
WARRANTY CLAIMS ON ACRYLIC SURFACE DAMAGE
MUST BE MADE PRIOR TO INSTALLATION. Inspect
plumbing and bath surface for missing or damaged
components. Alert your dealer of any discrepancies.
To protect the unit from damage keep the bath in the
carton until ready for installation.

Jason International, Inc. • 501.771.4477 Page 2 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
EQUIPMENT ACCESS
In accordance with Building Codes, service access to all
therapy bath equipment, controls and electrical connections
must be provided during installation (see Table 1 – Speci-
fications for minimum access size). Insufficient access will
hinder repair and maintenance. Warranty service will not
cover costs of providing equipment access.
INSTALLATION INSTRUCTIONS
Jason offers an optional removable lateral skirt for all rect-
angular baths. The skirts are available in matching acrylic
colors and provide convenient access to bath equipment
as well as an excellent finished appearance. However, if
Jason’s lateral skirt is not used, an access panel MUST be
provided to enable final electrical connections and service.
Please refer to the minimum recommended access panel
size in Table 1 - Specifications.
Table 1 Specications
72 x36 x20.5 45 36 x 17 in 45.5
183 x91 x52 170 91 x 43 cm 222
72 x42 x20.5 58 36 x 17 in 45.4
183 x107 x52 220 91 x 43 cm 222
60 x60 x20.5 53 36 x 17 in 42.4
152 x152 x52 201 91 x 43 cm 207
60 x60 x20.5 54 36 x 17 in 42
152 x152 x52 204 91 x 43 cm 205
72 x72 x23 90 36 x 17 in 49.2
183 x183 x58 341 91 x 43 cm 240
55 x55 x20.5 59 36 x 17 in 54.1
140 x140 x52 223 91 x 43 cm 264
60 x32 x20.5 36 36 x 17 in 52.1
152 x81 x52 136 91 x 43 cm 254
60 x36 x20.5 44 36 x 17 in 56.6
152 x91 x52 167 91 x 43 cm 276
60 x42 x20.5 49 36 x 17 in 48.1
152 x107 x52 185 91 x 43 cm 235
72 x42 x20.5 52 36 x 17 in 46.4
183 x107 x52 197 91 x 43 cm 227
60 x32 x20.5 32 36 x 17 in 50.5
152 x81 x52 121 91 x 43 cm 247
60 x36 x20.5 37 36 x 17 in 46.6
152 x91 x52 140 91 x 43 cm 228
60 x36 x20.5 37 36 x 17 in 48.8
152 x91 x52 140 91 x 43 cm 238
60 x42 x20.5 44 36 x 17 in 44.7
152 x107 x52 167 91 x 43 cm 218
60 x42 x20.5 44 36 x 17 in 46
152 x107 x52 167 91 x 43 cm 225
66 x36 x20.5 39 36 x 17 in 44.2
168 x91 x52 148 91 x 43 cm 216
72 x36 x20.5 45 36 x 17 in 44.6
183 x91 x52 170 91 x 43 cm 218
72 x36 x20.5 45 36 x 17 in 45.9
183 x91 x52 170 91 x 43 cm 224
60 x42 x20.5 49 36 x 17 in 40.5
152 x107 x52 185 91 x 43 cm 198
60 x42 x20.5 49 36 x 17 in 41.6
152 x107 x52 185 91 x 43 cm 203
60 x32 x20.5 32 36 x 17 in 49
152 x81 x52 121 91 x 43 cm 239
66 x36 x20.5 47 36 x 17 in 50.7
168 x91 x52 178 91 x 43 cm 248
60 x60 x20.5 58 36 x 17 in 44.6
152 x152 x52 220 91 x 43 cm 218
66 x42 x20.5 46 36 x 17 in 41.9
168 x107 x52 174 91 x 43 cm 205
60 x30 x20.5 38 36 x 17 in 56.8
152 x76 x52 144 91 x 43 cm 277
60 x30 x20.5 38 -- 58.8
152 x76 x52 144 -- 287
60 x32 x20.5 39 36 x 17 in 54.1
152 x81 x52 148 91 x 43 cm 264
60 x32 x20.5 39 -- 56.0
152 x81 x52 148 -- 273
66 x36 x20.5 48 36 x 17 in 49.8
168 x91 x52 182 91 x 43 cm 243
66 x36 x20.5 48 -- 51.4
168 x91 x52 182 -- 251
72 x42 x25 66 36 x 17 in 56.2
183 x107 x64 250 91 x 43 cm 274
72 x42 x25 66 36 x 17 in 51.4
183 x107 x64 250 91 x 43 cm 251
72 x48 x23 100 36 x 17 in 60.8
183 x122 x58 379 91 x 43 cm 297
66 x36 x25 52 36 x 17 in 60.5
168 x91 x64 197 91 x 43 cm 295
72 x42 x25 66 36 x 17 in 56
183 x107 x64 250 91 x 43 cm 273
60 x36 x20.5 40 36 x 17 in 49.4
152 x91 x52 151 91 x 43 cm 241
72 x48 x20.5 53 36 x 17 in 46.9
183 x122 x52 201 91 x 43 cm 229
72 x42 x20.5 60 36 x 17 in 46.6
183 x107 x52 227 91 x 43 cm 228
72 x42 x20.5 58 36 x 17 in 50
183 x107 x52 220 91 x 43 cm 244
72 x48 x23 64 36 x 17 in 47.6
183 x122 x58 242 91 x 43 cm 232
60 x60 x20.5 55 36 x 17 in 43.2
152 x152 x52 208 91 x 43 cm 211
68 x42 x23 46 36 x 17 in 49.9
173 x107 x58 174 91 x 43 cm 244
55 x55 x22 66 36 x 17 in 50.1
140 x140 x56 250 91 x 43 cm 245
72 x48 x20.5 72 36 x 17 in 47.5
183 x122 x52 273 91 x 43 cm 232
66 x42 x20.5 40 36 x 17 in 42.1
168 x107 x52 151 91 x 43 cm 206
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
PS5735
MA640
MI635
LS640
LX553
1.5
1.5
1.5
1.5
EM630 SL/SR
1.5
1.5
1.5
1.5
MA553
MA635
EM635
FL550
LC635
1.5
EM635 SL/SR
ES527
ES553
KT553 SL/SR
KT527
EM530 SL/SR
EM535
EM553
EM630
KT527 SL/SR
EM527 SL/SR
EM530
CS600 (Round)
DE4646
EC527
EL530
DESIGNER COLLECTION (Whirlpool)
Model
Pump
Min. Size
Access
W x H (in.)
W x H (cm)
Gallons
Liters
Operating
Capacity
HP
1.5
Floor
Loading
lbs/ft2
kg/M2
Overall Dimensions
1.5
1.5
1.5
1.5
BY630
EM535 SL/SR
1.5
L x W x H (in.)
L x W x H (cm)
CC550
1.5
BY635
CA550
EL535
EL635
LD635
1.5
VE5535
SQ4646
1.5
1.5
LX635
MK550
SV640
MI640
KT553
1.5
JL5535
1.5
KT525
1.5
KT525 SL/SR
1.5

Jason International, Inc. • 501.771.4477 Page 3 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
INSTALLATION INSTRUCTIONS (cont.)
72 x36 x20.5 45 36 x 17 in 45.5
183 x91 x52 170 91 x 43 cm 222
72 x42 x20.5 58 36 x 17 in 45.4
183 x107 x52 220 91 x 43 cm 222
60 x60 x20.5 53 36 x 17 in 42.4
152 x152 x52 201 91 x 43 cm 207
60 x60 x20.5 54 36 x 17 in 42
152 x152 x52 204 91 x 43 cm 205
72 x72 x23 90 36 x 17 in 49.2
183 x183 x58 341 91 x 43 cm 240
55 x55 x20.5 59 36 x 17 in 54.1
140 x140 x52 223 91 x 43 cm 264
60 x32 x20.5 36 36 x 17 in 52.1
152 x81 x52 136 91 x 43 cm 254
60 x36 x20.5 44 36 x 17 in 56.6
152 x91 x52 167 91 x 43 cm 276
60 x42 x20.5 49 36 x 17 in 48.1
152 x107 x52 185 91 x 43 cm 235
72 x42 x20.5 52 36 x 17 in 46.4
183 x107 x52 197 91 x 43 cm 227
60 x32 x20.5 32 36 x 17 in 50.5
152 x81 x52 121 91 x 43 cm 247
60 x36 x20.5 37 36 x 17 in 46.6
152 x91 x52 140 91 x 43 cm 228
60 x36 x20.5 37 36 x 17 in 48.8
152 x91 x52 140 91 x 43 cm 238
60 x42 x20.5 44 36 x 17 in 44.7
152 x107 x52 167 91 x 43 cm 218
60 x42 x20.5 44 36 x 17 in 46
152 x107 x52 167 91 x 43 cm 225
66 x36 x20.5 39 36 x 17 in 44.2
168 x91 x52 148 91 x 43 cm 216
72 x36 x20.5 45 36 x 17 in 44.6
183 x91 x52 170 91 x 43 cm 218
72 x36 x20.5 45 36 x 17 in 45.9
183 x91 x52 170 91 x 43 cm 224
60 x42 x20.5 49 36 x 17 in 40.5
152 x107 x52 185 91 x 43 cm 198
60 x42 x20.5 49 36 x 17 in 41.6
152 x107 x52 185 91 x 43 cm 203
60 x32 x20.5 32 36 x 17 in 49
152 x81 x52 121 91 x 43 cm 239
66 x36 x20.5 47 36 x 17 in 50.7
168 x91 x52 178 91 x 43 cm 248
60 x60 x20.5 58 36 x 17 in 44.6
152 x152 x52 220 91 x 43 cm 218
66 x42 x20.5 46 36 x 17 in 41.9
168 x107 x52 174 91 x 43 cm 205
60 x30 x20.5 38 36 x 17 in 56.8
152 x76 x52 144 91 x 43 cm 277
60 x30 x20.5 38 -- 58.8
152 x76 x52 144 -- 287
60 x32 x20.5 39 36 x 17 in 54.1
152 x81 x52 148 91 x 43 cm 264
60 x32 x20.5 39 -- 56.0
152 x81 x52 148 -- 273
66 x36 x20.5 48 36 x 17 in 49.8
168 x91 x52 182 91 x 43 cm 243
66 x36 x20.5 48 -- 51.4
168 x91 x52 182 -- 251
72 x42 x25 66 36 x 17 in 56.2
183 x107 x64 250 91 x 43 cm 274
72 x42 x25 66 36 x 17 in 51.4
183 x107 x64 250 91 x 43 cm 251
72 x48 x23 100 36 x 17 in 60.8
183 x122 x58 379 91 x 43 cm 297
66 x36 x25 52 36 x 17 in 60.5
168 x91 x64 197 91 x 43 cm 295
72 x42 x25 66 36 x 17 in 56
183 x107 x64 250 91 x 43 cm 273
60 x36 x20.5 40 36 x 17 in 49.4
152 x91 x52 151 91 x 43 cm 241
72 x48 x20.5 53 36 x 17 in 46.9
183 x122 x52 201 91 x 43 cm 229
72 x42 x20.5 60 36 x 17 in 46.6
183 x107 x52 227 91 x 43 cm 228
72 x42 x20.5 58 36 x 17 in 50
183 x107 x52 220 91 x 43 cm 244
72 x48 x23 64 36 x 17 in 47.6
183 x122 x58 242 91 x 43 cm 232
60 x60 x20.5 55 36 x 17 in 43.2
152 x152 x52 208 91 x 43 cm 211
68 x42 x23 46 36 x 17 in 49.9
173 x107 x58 174 91 x 43 cm 244
55 x55 x22 66 36 x 17 in 50.1
140 x140 x56 250 91 x 43 cm 245
72 x48 x20.5 72 36 x 17 in 47.5
183 x122 x52 273 91 x 43 cm 232
66 x42 x20.5 40 36 x 17 in 42.1
168 x107 x52 151 91 x 43 cm 206
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
PS5735
MA640
MI635
LS640
LX553
1.5
1.5
1.5
1.5
EM630 SL/SR
1.5
1.5
1.5
1.5
MA553
MA635
EM635
FL550
LC635
1.5
EM635 SL/SR
ES527
ES553
KT553 SL/SR
KT527
EM530 SL/SR
EM535
EM553
EM630
KT527 SL/SR
EM527 SL/SR
EM530
CS600 (Round)
DE4646
EC527
EL530
DESIGNER COLLECTION (Whirlpool)
Model
Pump
Min. Size
Access
W x H (in.)
W x H (cm)
Gallons
Liters
Operating
Capacity
HP
1.5
Floor
Loading
lbs/ft2
kg/M2
Overall Dimensions
1.5
1.5
1.5
1.5
BY630
EM535 SL/SR
1.5
L x W x H (in.)
L x W x H (cm)
CC550
1.5
BY635
CA550
EL535
EL635
LD635
1.5
VE5535
SQ4646
1.5
1.5
LX635
MK550
SV640
MI640
KT553
1.5
JL5535
1.5
KT525
1.5
KT525 SL/SR
1.5

Jason International, Inc. • 501.771.4477 Page 4 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
INSTALLATION INSTRUCTIONS (cont.)
INSTALLATION
Each bath is provided with a cardboard bath well
protector that should be kept in the unit during the
installation and throughout the bathroom construction
process. Overflow drains, fill spouts, and valves must be
installed according to the instructions herein.
See the USER MAINTENANCE INSTRUCTIONS section
of this owner’s manual, prior to Installation, for humidity
and mold prevention suggestions.
Finish Frame1. Afinishframeundertheshellrimshouldalso
always be constructed to support the bath deck and insure
proper drainage toward the bath well. This frame is not
intended to support thefull bathweight( s e e F i g u r e s 1 & 2 ) .
Jason offers a removable lateral skirt for most baths.
The skirts are available in matching acrylic colors and
provide convenient access to bath equipment as well
as an excellent finished appearance. However, if Ja-
son’s lateral skirt is not used, an access panel MUST
be provided to enable final electrical connections and
service. Please refer to the minimum recommended
access panel size in Table 1 - Specifications.
If a Jason lateral skirt is to be used, the bath deck must
be leveled at 20.5” (52cm) from the support floor or the
skirt will not fit properly.
100% Silicone with mildew resistant properties should2.
be applied between the water resistant backer board and
the deck of the bath. NOTE: If you use a tile flange kit,
modify the framing to support the bath lip as shown
in Figure 1.
Install the drain and overflow assembly to the bath shell3.
according to the instructions provided with the drain and
position the bath in the area of intended installation.
Finish plumbing rough-in of drain and overflow assembly.4.
At this time, considerations should be made for the posi-
tion and mounting of the faucet set, as well as all related
plumbing.
Remove the packing board before installing5.
the bath. The bath is equipped with separate bath
equipment support bases which are joined for ship-
ment with packing boards. Detach the packing board
from the bath and from underneath the equipment.
WARNING: ANYMODIFICATION TOTHEEQUIPMENT
I S N O T R E C O M M E N D E D A N D W I L L V O I D T H E M A N U -
FACTURER’S WARRANTY.
Install the bath level for proper drainage.6. Jason baths
are designed to be supported at the base of the bath. If the
floor is smooth and level, the baths’ Level Form™ Base will
provide proper drainage and support (See Figure 3).
SILICONE BEAD
TILE
DRYWALL DRYWALL
TILE
OPTIONAL
TILE FLANGE
KIT
OPTIONAL
INTEGRATED
TILE LIP
1" X 2"
SUPPORT
SCREW
Figure 1
Figure 2
Figure 3

Jason International, Inc. • 501.771.4477 Page 5 of 18 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
INSTALLATION INSTRUCTIONS (cont.)
Mortar is required when the subfloor is not smooth and7.
level; when additional sound insulation is desired; or when
the bath is installed in a drop-in application. In alcove
installations, a bed of mortar may also be recommended
to aid in leveling the bath. NOTE: Do not use a sand bed
to install or level the bath.
Secure the bottom of all equipment mounts so that it8.
is level with the bottom of the bath. Position the bath
in the area of intended installation and cut the equipment
support strap(s) to allow the equipment to rest firmly on the
floor. We recommend securing the equipment mounts to
the floor with removable fasteners for ease of servicing.
Protect the acrylic bath surface from damage during9.
installation with a suitable material, i.e., cardboard
and/or plastic film. The acrylic surface of this bath has
been providedwith a protective filmwhichhelpsprotectthe
bathduringshipmentandinstallation. Additionalprotection
may also be required to protect the acrylic surface during
installation. If the bath is tiled in, remove the necessary
portion of the film when installing the tile.
