JASON Hydrotherapy Integrity A6060 Installation and operating instructions

Jason International, Inc. • 501.771.4477 Page 1 of 9 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
OWNER’S MANUAL
Integrity®AirMasseur®
Baths
INSTALLATION, OPERATION, AND MAINTENANCE
“TO BE REMOVED FOR USE BY THE OCCUPANT.”
49-1013-200
Date 04/11
Jason International, Inc.
8328 MacArthur Drive
North Little Rock, AR 72118
www.jasoninternational.com
OWNER’S RECORD
Dealer:
Date Purchased:
Date Installed:
Installer:
PLACE SERIAL NUMBER CARD WITH
PRODUCT CONFIGURATION IN THIS BOX
CAUTION: DO NOT LIFT OR HANDLE THE BATH BY ITS PLUMBING.
INSPECTION
Inspect the unit prior to installation. In the event of a
problem, DO NOT install the unit.
All components are factory assembled to the bath and the
unit is water tested and inspected prior to leaving Jason
International, Inc.
If the carton shows sign of damage, inspect the product
before accepting and describe the problem on the Bill of
Lading.
NOTE: Transportation and insurance from Jason’s
factory are the buyer’s responsibility.
Damage sustained in transit is the responsibility of the
carrier. If damage is discovered,
If the carton shows sign of damage, inspect
the product before accepting and describe the
problem on the Bill of Lading.
the carrier must be immediately notified in writing with a
request for a representative to inspect the unit. Failure of
the carrier to respond should be reported to the seller and
carrier. Always file a freight claim promptly.
The installer is responsible for insuring that the unit is
free from defects or shipping damage. In the event of a
problem, DO NOT install the unit.
Jason International is not responsible for damage that
might have been avoided by inspection or testing prior to
installation.
Damage to the unit during installation will not be covered
by warranty and is the responsibility of the installer. ALL
WARRANTY CLAIMS ON ACRYLIC SURFACE DAMAGE
MUST BE MADE PRIOR TO INSTALLATION. Inspect
plumbing and bath surface for missing or damaged
components. Alert your dealer of any discrepancies.
To protect the unit from damage keep the bath in the
carton until ready for installation.

Jason International, Inc. • 501.771.4477 Page 2 of 9 Customer Service : 800.255.5766
Copyright © 2011 Jason International.
INSTALLATION INSTRUCTIONS
EQUIPMENT ACCESS
In accordance with Building Codes, service access to all
therapy bath equipment, controls and electrical connections
must be provided during installation (see Table 1 – Speci-
fications for minimum access size). Insufficient access will
hinder repair and maintenance. Warranty service will not
cover costs of providing equipment access.
Jason offers an optional removable lateral skirt for all rect-
angular baths. The skirts are available in matching acrylic
colors and provide convenient access to bath equipment
as well as an excellent finished appearance. However, if
Jason’s lateral skirt is not used, an access panel MUST be
provided to enable final electrical connections and service.
Please refer to the minimum recommended access panel
size in Table 1 - Specifications.
Table 1 Specications
60 x60 x20.5 53 36 x 17 i n 42.1
152 x152 x52 201 91 x 43 c m 206
60 x30 x20.5 29 36 x 17 i n 49.7
152 x76 x52 110 91 x 43 c m 243
60 x32 x20.5 32 36 x 17 i n 49.1
152 x81 x52 121 91 x 43 c m 240
60 x32 x20.5 32 --- 50.8
152 x81 x52 121 --- 248
60 x36 x20.5 37 36 x 17 i n 47.2
152 x91 x52 140 91 x 43 c m 230
60 x36 x20.5 37 --- 49
152 x91 x52 140 --- 239
66 x36 x20.5 39 36 x 17 i n 44.4
168 x91 x52 148 91 x 43 c m 217
72 x36 x20.5 45 36 x 17 i n 44.8
183 x91 x52 170 91 x 43 c m 219
72 x36 x20.5 45 --- 46.1
183 x91 x52 170 --- 225
60 x42 x20.5 44 36 x 17 i n 45.4
152 x107 x52 167 91 x 43 c m 222
60 x42 x20.5 44 --- 46.8
152 x107 x52 167 --- 229
72 x42 x20.5 49 36 x 17 i n 41.1
183 x107 x52 185 91 x 43 c m 201
72 x42 x20.5 49 --- 42.2
183 x107 x52 185 --- 206
60 x60 x20.5 54 36 x 17 i n 42.1
152 x152 x52 204 91 x 43 c m 206
60 x32 x20.5 36 36 x 17 i n 53.1
152 x81 x52 136 91 x 43 c m 259
60 x42 x20.5 43 36 x 17 i n 44.4
152 x107 x52 163 91 x 43 c m 217
66 x42 x20.5 46 36 x 17 i n 42.5
168 x107 x52 174 91 x 43 c m 208
72 x42 x20.5 49 36 x 17 i n 40.9
183 x107 x52 185 91 x 43 c m 200
60 x30 x20.5 38 36 x 17 i n 57.1
152 x76 x52 144 91 x 43 c m 279
60 x30 x20.5 38 36 x 17 i n 57.3
152 x76 x52 144 91 x 43 c m 280
60 x30 x20.5 38 59.1
152 x76 x52 144 289
60 x32 x20.5 39 36 x 17 i n 54.5
152 x81 x52 148 91 x 43 c m 266
60 x32 x20.5 39 36 x 17 i n 54.6
152 x81 x52 148 91 x 43 c m 267
60 x32 x20.5 39 56.3
152 x81 x52 148 275
66 x36 x20.5 48 36 x 17 i n 50.1
168 x91 x52 182 91 x 43 c m 245
66 x36 x20.5 48 36 x 17 i n 50.2
168 x91 x52 182 91 x 43 c m 245
66 x36 x20.5 48 51.6
168 x91 x52 182 252
60 x36 x20.5 44 36 x 17 i n 57.2
152 x91 x52 167 91 x 43 c m 279
60 x42 x20.5 49 36 x 17 i n 48.1
152 x107 x52 185 91 x 43 c m 235
72 x42 x20.5 52 36 x 17 i n 46.2
183 x107 x52 197 91 x 43 c m 226
66 x42 x20.5 43 36 x 17 i n 44.4
168 x107 x52 163 91 x 43 c m 217
72 x42 x20.5 46 36 x 17 i n 42.8
183 x107 x52 174 91 x 43 c m 209
66 x42 x20.5 40 36 x 17 i n 42.6
168 x107 x52 151 91 x 43 c m 208
