Jason.L Switch System 4 Person Workstation User manual

Note: Please ignore any pre-drilled holes or nut inserts that maybe present in your top(s). They will not match your particular
table/desk base and woods screws will be required to be screwed directly into the underside of the top.
Note: It is important to fully tighten all bolts and screws before attaching the top(s) so that the frame is suciently rigid.
Failure to do this may aect stability once the tops are attached.
Tools Required: Power screwdriver.
INSTALLATION GUIDE
Switch System
4 Person Workstation
Size: 1200mm
Page 1 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au

Table Top x4 (1200x800mm)
Leg x6
Leg Bracket x6
Beam Bracket x10
T Beam Bracket x2
Long Beam x3 (1150mm)
Short Beam x4 (915mm)
L-Bracket x15
1
2
3
4
5
6
7
8
Hex Nut x6
L-Bracket screws x15
Hex Head screws x26
M8x25mm Dome Head x6
9
10
11
12
COMPONENTS
SCREWS
Page 2 of 5
INSTALLATION GUIDE
Switch System
4 Person Workstation
Size: 1200mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
7
4
3
810
12
2
1
6
9
5

Page 3 of 5
INSTALLATION GUIDE
Switch System
4 Person Workstation
Size: 1200mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Join 2 L-Bracket through each 1150mm Beam
and 1 L-Bracket through each 915mm Beam.
Join Leg Brackets to each Leg using screws to secure them, as follow.
Securely connect each Beam to each Beam Bracket. Screw to secure. Insert Hex Nut on each Beam Bracket.
01
03 04
02

For the 2 central legs, attach as presented, using T Beam Bracket.
Page 4 of 5
INSTALLATION GUIDE
Switch System
4 Person Workstation
Size: 1200mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
06
Position as presented, and proceed to screw to ensure each corner of the frame.
05
If this bolt does not drop into the joint
use the Allen key to screw it all the way
in so that it creates its own thread.
This will ensure a nice, tight joint.

Once we get the whole frame ready, ensure the worksurface is centered
over the frame. and fully tighten all M6x40mm Hex Head to Table Tops,
through each L-Bracket.
Page 5 of 5
INSTALLATION GUIDE
Switch System
4 Person Workstation
Size: 1200mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
09
Once we get the whole frame ready, ensure the worksurface is
centered over the frame. If you are planning to install a divider
screen, leave a 25mm gap between tables.
25mm
07
Directly screw into table tops, using L-Bracket
screws through each L-Bracket.
08
Note: If you are planning to install Pincer Brackets
like the image to the right, you need to attach these
brackets before continuing.
Note: It is important to fully tighten all bolts and screws before attaching the top(s) so that the
frame is suciently rigid. Failure to do this may aect stability once the tops are attached.
