Jason.L Quadro A L-Shaped Desk User manual

ASSEMBLY INSTRUCTIONS
Quadro A
L-Shaped Desk
Sizes: 1200, 1400, 1600, 1800 mm
Page 1 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Tools Required: Power screwdriver; Allen key set (provided)
2 persons required for installation

ASSEMBLY INSTRUCTIONS
Quadro A
L-Shaped Desk
Sizes: 1200, 1400, 1600, 1800 mm
Table top x1
Table top Return x1
Legs Quadro A x2
Legs Quadro A Return x1
Beam x1
Beam Return x1
Plastic bracket x6
Joiner plates x2
A
B
C
D
E
F
G
H
Allen key x2N
M8x20MM CSK x3
M8x20MM Socket head x4
M6x20MM Socket head x6
M6x30MM Socket head x8
Join plates Screws
I
J
K
L
M
COMPONENTS
SCREWS
Page 2 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au
E
F
G
H
I J K L M
A
B
C
D

J
K
ASSEMBLY INSTRUCTIONS
Quadro A
L-Shaped Desk
Sizes: 1200, 1400, 1600, 1800 mm
STEP 01
Using Allen Key provided, attach 2 plastic brackets (G) per legs (C & D)
(as per picture above) using M6x20MM (K) Socket head screw
Using Allen Key provided, attach M8x20MM Socket head (J)-
screw socket half way into leg for three legs (C & D)
STEP 02
Page 3 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au

ASSEMBLY INSTRUCTIONS
Quadro A
L-Shaped Desk
Sizes: 1200, 1400, 1600, 1800 mm
STEP 03
Adjust extendable beam (E) to desired
length using markers and secure beam
at that length using screws provided
Page 4 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au
50
1200
1300
1400
1500
1600
1700
1800
1900
2000
50

ASSEMBLY INSTRUCTIONS
Quadro A
L-Shaped Desk
Sizes: 1200, 1400, 1600, 1800 mm
STEP 04
TOP VIEW
Attach beam (E) to legs (C) using nut insert in legs.
See point attached
Frame looks like this. Using Allen Key, attach beam (E) with Socket (I)
STEP 05
Page 5 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au
I
I

ASSEMBLY INSTRUCTIONS
Quadro A
L-Shaped Desk
Sizes: 1200, 1400, 1600, 1800 mm
STEP 06
Now attach the return beam (F) to return leg (D) using nut insert in legs. See point attached.
Then, connect the hook of the return beam to the beam of the main structure.
Page 6 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au
I
F
D

M
H
B
ASSEMBLY INSTRUCTIONS
Quadro A
L-Shaped Desk
Sizes: 1200, 1400, 1600, 1800 mm
STEP 07
Page 7 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Attach Connector Plates (H) to Return Top (B) by tightening Screws (M)

ASSEMBLY INSTRUCTIONS
Quadro A
L-Shaped Desk
Sizes: 1200, 1400, 1600, 1800 mm
STEP 08
Page 8 of 8
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Place table top (A) ontop of frame - with cutout at the back of the desk. Using nut inserts in the desk, use
M6x30mm socket (L) and attach desktop to the frame.
Using nut inserts in the desktop, use M6x30mm socket (L) and attach desktop (B) to the frame. Once desktop are
attached and secure to the frame, use woods screws and secure joiner plates to the underside of desktop A.
nut insert nut insert
TABLE TOP
BOTTOM VIEW
L
H
M
B
A
nut insertnut insert
