Jason.L Quadro Loop User manual

ASSEMBLY INSTRUCTIONS
Quadro Loop
Boardroom table
Size: 3200mm x 1100mm
Page 1 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Tools Required: Power screwdriver; Allen key set (provided)
2 persons required for installation

ASSEMBLY INSTRUCTIONS
Quadro Loop
Boardroom table
Size: 3200mm x 1100mm
Table top x2
Leg Quadro x2
Leg Quadro Loop x2
Connector frame x1
Beam x2
Plastic bracket x8
A
B
C
D
E
F
Allen key x2K
M8x20MM CSK x4
M8x20MM Socket head x4
M6x20MM Socket head x8
M6x30MM Socket head x8
G
H
I
J
COMPONENTS
SCREWS
Page 2 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
E
F
D
A
B
C
J
G H I

H
I
ASSEMBLY INSTRUCTIONS
Quadro Loop
Boardroom table
Size: 3200mm x 1100mm
STEP 01
Using Allen Key provided, attach 2 plastic brackets per leg (F)
(as per picture above) using M6x20MM (I) Socket head screw.
Do the same with Connector frame (D). Connect Loop Legs (C)
to Bottom of Quadro Legs (B) by using 4 bolts per leg.
Using Allen Key provided, attach M8x20MM Socket head (H)-
screw socket half way into leg for both legs (B) and into
Connector frame (D).
STEP 02
Page 3 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
C
B
D

ASSEMBLY INSTRUCTIONS
Quadro Loop
Boardroom table
Size: 3200mm x 1100mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
STEP 03
Adjust extendable beam to desired
length using markers and secure beam
at that length using screws provided
Page 4 of 6
50
1200
1300
1400
1500
1600
1700
1800
1900
2000
50

ASSEMBLY INSTRUCTIONS
Quadro Loop
Boardroom table
Size: 3200mm x 1100mm
STEP 04
TOP VIEW
Attach beam (E) to legs (B) and Connector frame (D)
using nut insert in legs. See point attached
Frame looks like this. Using Allen Key, attach beam (E) with Socket (G)
STEP 05
Page 5 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
G
G
G
G

STEP 07
Please drill M6x30MM Socket head (J) through the plastic
brackets into the underneath of the tops.
J
300 mm
ASSEMBLY INSTRUCTIONS
Quadro Loop
Boardroom table
Size: 3200mm x 1100mm
STEP 06
Page 6 of 6
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Place the desktop on top of the frame. Please place the legs ideally indent-
ed around 300mm from each end left and right of the Tops, Place the legs
centred at the same distance equally from the front and back of the top.
