Jays j-JAYS User manual

j-JAYS
USER MANUAL
ANVÄNDARMANUAL
MODE D’EMPLOI
MANUALE PER L’UTENTE
MANUAL DE USUARIO
BEDIENUNGSANLEITUNG
ユーザー・マニュアル
사용자 매뉴얼
使用說明書
WWW.JAYS.SE
v1.6

j-JAYS

USER MANUAL

5
EN
CONTENTS
1. j-JAYS earphones
2. Sliding ring
3. Y-connection
4. 3.5 mm stereo mini-plug
5. Extension cord
6. Sleeves (various sizes)
7. Protective filters
8. Airplane Stereo Adapter
9. 3.5 mm Stereo Splitter
10. Carrying case
90cm (35in)
5.
1. 5.
6.
10
13
9
12
8.5
11
7.7
10
L
M
S
XS
2.
3.
4.
10
13
9
12
8.5
11
7.7
10
L
M
S
XS
6.
7. 8. 9.
10.

6
EN 1. INTRODUCTION
Thank you for choosing j-JAYS earphones. We strongly recommend that you read this manual
carefully before use. You can order accessories and get information about service and support at
our website: www.jays.se.
2. PRECAUTIONS
» Do not use the product in other ways than are described in this manual.
» Handle with care at all times and protect from external damage.
» Do not expose to heat, magnetism or cold, damp environments.
» To clean: use a mild, antiseptic detergent.
» Do not expose the cords and plugs to abnormal wear and tear, e.g. by bending or pulling them.
» Avoid winding the cord too tightly.
» Avoid dropping or strong impact. Always leave the sleeve on for shock protection.
3. PROPER USE
InsertIng and removIng the earphones We recommend that you take the time to get
accustomed to your j-JAYS earphones to really experience the difference in sound quality and
comfort. For the best sound isolation, bass frequency response and sound quality to be achieved,
the earphones must be inserted correctly.
When you have used them for a while you will see how simple they are to insert and remove.
» Turn the volume to minimum before insertion.
» For best results, moisten the sleeves before insertion.
» Holding the earphone at the rear, carefully insert the sleeve while pulling up and out on the back
of the ear. The earphone should seal deeply and comfortably in the ear canal.

7
EN
» If the bass frequency response seems too feeble or if external noise has not been eliminated, try
inserting the earphone deeper into the ear canal to obtain a better seal or try a different size.
» After use, remove carefully - avoid pulling on the cord.
there are two ways to wear the earphones, as shown below:
1. Cord runs downwards from ear.
2. Cord runs upwards behind the ear and comes back out in front of your head (A).You can also pull the
cord around the back of your head (B), in which case secure the cord in place using the adjustment
tube.This is an ideal way to wear your earphones at the gym, for example.
2.
1.

8
EN
CleanIng Clean your earphones regularly using an antiseptic cloth. Keep sleeves and protective
filters clean from wax and other dirt build-up. Wax and dirt can adversely affect sound quality and
can damage your earphones.
Furthermore, ensure that no moisture gets into the nozzle when cleaning as this may damage the
armature inside the earphones.
ChangIng the sleeves The sleeves can be replaced by carefully sliding them off and on the
earphones. Check that the sleeves’ rubber notches (C) are securely fastened in the locking groove.
ChangIng the proteCtIve fIlters Your j-JAYS comes with 4 pairs of replacement protective filters.
If the filter in your earphone becomes soiled or damaged, pull it off carefully. Ensure that there is
no dirt on the edges of the sound pipe. Carefully detach a new adhesive filter from the pack and
A.
B.

9
EN
fit in the same place as the old filter. Make sure the filter fits securely into position. You can use a
paperclip or tweezers for this purpose.
4. FOR YOUR SAFETY
hearIng These earphones are very powerful. Listening at high volumes for prolonged periods can
cause permanent hearing damage. Always listen at low volumes and remember to rest your ears
once in a while. If your ears start ringing, turn the sound off immediately and rest your ears.
traffIC Your j-JAYS effectively isolate external noise. This means you won’t hear what’s going on
around you, which can be very hazardous in traffic. Never use your j-JAYS while driving a car, moped,
bicycle or similar, or while jogging or walking through trafficated areas.We would like to remind you
that listening to music in trafficated environments can lead to accidents.
C.

10
EN other Please note that the product and accompanying parts are very small. You should therefore
store them safely out of children’s reach.
5. SPECIFICATIONS
Driver: Dynamic Driver
Isolation: JAYS Silicon Sleeves
Sensitivity: 106 dB SPL @ 1 kHz
Impedance: 32 Ohm @ 1 kHz
Frequency response: 50 Hz–20,000 Hz
Cord length: 60 cm (24in)
Cord diameter: 2 mm/1.5 mm (0.079in/0.059in)
Weight: 8 grams
Plug: Gold-plated 3.5 mm stereo mini-plug
6. SERVICE AND SUPPORT
If you need help with your product, please contact your retailer or JAYS. Our contact details are
printed on the back of this manual. If the product needs to be replaced your retailer will arrange
it unless you have been informed otherwise. Your product has a 2-year warranty unless otherwise
specified. It covers production faults. Read more about our warranty terms in item 8.
7. ACCESSORIES
We have an ever-growing range of accessories for your earphones. Here are some of the accessories
that are currently available. For an up-to-date list, please visit www.jays.se.

11
EN
ACCESSORIES
10
13
9
12
8.5
11
7.7
10
6.8
8.8
L
M
S
XS
XXS
90cm 35in
90cm (35in)
3,5 mm
3,5mm
Sleeves Extension cables Filters
Airplane Stereo
Adapter
3.5 mm Stereo
Splitter
Leather carrying case

12
EN 8. WARRANTY
JAYS extends a 2-year warranty. This limited warranty applies to buyers of JAYS AB’s products. If any
other party that resells the product after it has left JAYS AB issues a different warranty from this one,
the most recently issued warranty shall apply. JAYS AB guarantees that the product is free from faults
in the materials, design and manufacture when it was transferred to the buyer. The warranty is only
valid if the following requirements are satisfied:
1) This warranty only applies to buyers who are end-customers, and who can show a receipt or
certificate of warranty containing details about the place of purchase, date and serial number.
This warranty does not infringe upon the provisions of binding legislation or the buyer’s rights in
relation to the seller of the product.
2) This limited warranty can, with respect to the main product, apply 24 months from when the
customer receives the product. If the buyer sells the product to another party, the purchaser can
claim warranty cover for the same period as the original buyer on the condition that the terms
of item 1 are fulfilled.
3) If there are faults in the design, materials or manufacture, JAYS AB will undertake to redress the
fault through repairs or a replacement. JAYS AB hereby undertakes to provide the buyer with a
product that is in full working order during the warranty period. Ownership rights to components
that are replaced during repairs belong to JAYS.
4) This warranty does not cover product deterioration caused by normal wear and tear. Furthermore,
the warranty does not apply if:
a) the fault is caused by the product being exposed to damp, moisture, extreme temperatures
or temperature changes, chemical products, abnormal impact damage or force majeure that is
not directly caused by faults in the materials, design or manufacture.
b) the customer fails to notify JAYS AB within 30 days of the fault being discovered (within the
warranty period).
c) it is not possible to identify the product by checking the serial number that should be

13
EN
identical to the product the warranty is supposed to cover.
d) the product has been used in an incorrect manner or has been connected to an accessory
which JAYS AB has advised the customer not to use with the product.
9. CERTIFICATIONS
The aim of EU’s Waste Electrical and Electronic Equipment (WEEE) directives 2002/96/EC and the
ROHS directive is to reduce waste from electric and electronic products and to recycle as much of
the materials as possible.Any remaining waste should be virtually risk-free to handle and the risk of
hazardous emissions should be minimal.
Pb
R o H S
COMPLIANT
10. RECYCLING
For detailed information about how to recycle this product, please contact your local recycling centre
or store where you purchased the product.
11. CONTACT
At www.jays.se you will find information, a contact form and a forum where you can ask questions
about JAYS products. You can also reach us directly, our contact details are printed on the back of
this manual.

14
EN faQ
Can I use the earphones at the gym? Yes, of course. They are designed to give exceptional
results when you are exercising. They fit snugly in your
ears, won’t fall out and they eliminate most of the noise
in your surroundings.
Can I use j-JAYS with my MP3 player
which has an impedance of 16 ohms?
j-JAYS are very easy to drive.An MP3 player with 16 ohms
impedance will therefore power the earphones without
a problem.
I need an L-shaped plug for my MP3
player. Where can I get one?
JAYS’s L-shaped plugs are available from your retailer
and can also be ordered from our website: www.jays.se.
How long is the warranty on my
earphones?
j-JAYS comes with a 2-year warranty unless otherwise
arranged at the time of purchase.
Who do I contact if I have questions
or problems?
Contact your retailer or our Customer Service.Our contact
details can be found at www.jays.se.
Where can I buy extra sleeves and
protective filters for my earphones?
You can buy accessories at your retailer or at our website
www.jays.se.
My earphones fit badly. What should
I do?
Try a different size. You can also try wearing them over
your ear as shown in the instructions in item 3.

15
EN
Isn’t it dangerous to block out external
noise while in traffic?
With conventional earphones, the only way to drown
out background noise is to turn up the volume. But as
j-JAYS eliminate virtually all noise, you can listen at lower
volumes.
In both cases, you will hardly be able to hear the traffic.
We thus recommend that you never listen to music while
you are in trafficated areas.
The volume levels in left and right
earphones is uneven. What is the
problem?
Check that the plug is correctly connected to your
listening device. Check for a loose connection by
connecting to a different sound source. If the problem
persists, check if there is dirt on the filter or inside the
sleeve, if so, remove it.

ANVÄNDARMANUAL

17
SV
90cm (35in)
5.
1. 5.
6.
10
13
9
12
8.5
11
7.7
10
L
M
S
XS
2.
3.
4.
10
13
9
12
8.5
11
7.7
10
L
M
S
XS
6.
7. 8. 9.
FÖRPACKNINGENS INNEHÅLL
1. j-JAYS hörlur
2. Glidring
3. Y-Koppling
4. 3,5 mm stereoplugg
5. Förlängningskabel
6. Sleeves i olika storlekar
7. Skyddsfilter
8. Flygplansadapter, stereo
9. 3,5mm Stereo-splitter
10. Väska
10.

18
SV
1. INLEDNING
Tack för att du har valt ett par j-JAYS. Det är viktigt att du läser igenom manualen noga innan du
börjar använda hörlurarna. På hemsidan www.jays.se kan du köpa tillbehör samt få information
om service och support.
2. VARNINGAR
» Använd inte produkten på annat sätt än vad som beskrivs i denna manual.
» Hantera alltid din produkt varsamt och skydda den mot yttre åverkan.
» Utsätt inte produkten för hetta, magnetism, kyla eller fuktiga miljöer.
» Använd endast milt antiseptisk medel vid rengöring av produkten.
» Utsätt inte kablar och kontakter för onödigt slitage genom att medvetet böja och dra i dem.
» Undvik att linda kabeln för hårt.
» Undvik att tappa produkten. Låt alltid sleevsen sitta på som skydd.
3. ANVÄNDNING
sätta In oCh ta ur lurarna Det är viktigt att ta du tar dig tid att vänja dig vid dina j-JAYS för
att uppleva skillnaden i ljudkvalitet och komfort. Först när de är placerade korrekt i örat uppnår du
maximal ljudisolering, bas och ljudkvalitet. När du använt dem ett tag kommer du märka hur enkelt
det är att sätta i och ta ur dem.
» Ställ ner volymen till lägsta position innan du sätter in hörlurarna i öronen
» Fukta sleevsen en aning för enklare isättning
» Dra örat utåt och uppåt, håll i bakre delen av luren vid kabeln och för in sleeven djupt framåt/inåt
i öronkanalen
» Om du upplever för avsaknad av bas eller att ljud utifrån inte stängs ute ordentligt, justera
hörlurarna för att skapa en bra förslutning eller prova en annan storlek av sleeves
» Efter användning dras hörlurarna försiktigt ut – undvik att dra i sladden

19
SV
nedan vIsas två sätt hörlurarna kan bäras på
1. Kabeln riktas ner från örat.
2. Kabeln riktas uppåt, och läggs bakom örat för att sedan komma fram framför huvudet (A). Det
går även att dra kabeln bakom huvudet (B), spänn i så fall kablarna mot huvudet med glidringen.
Detta sätt lämpar sig särskilt vid exempelvis träning.
2.
1.

20
SV
rengöra Rengör dina hörlurar regelbundet med en antiseptisk trasa. Se till så att inget vax eller
annan smuts finns på sleevesen eller på skyddsfiltrena.Vax och smuts försämrar ljudkvaliteten och
kan skada dina hörlurar. Se även till att ingen vätska tar sig in i ljudröret vid rengöring, detta kan
skada armaturen inuti hörlurarna.
byta sleeves Dra försiktigt bort den gamla sleeven från hörluren. Tryck sedan den nya sleeven på
plats. Känn efter så gummihakarna (C) i sleeven fastnat ordentligt i låsspåret på hörluren.
byta skyddsfIlter Dina j-JAYS levereras med 4 par skyddsfilter. Om ett filter på dina hörlurar blir
för smutsigt eller skadat – avlägsna det försiktigt. Se till att inget smuts finns på fästkanterna på
ljudröret. Ta varsamt loss ett nytt självhäftande filter från kartan och placera den där det gamla
A.
B.
