jcb 21-CS1500 Planning guide

POWER TOOL
INSTRUCTION & USER MANUAL
EN
21-CS1500
Original Instructions
IM-CS1500-EN
Iss: 07/2021

221-CS1500
Instruction & User Manual
GENERAL WARNINGS & DISPOSAL
To reduce the risk of injury, the user must read the instruction manual.
The device must not be exposed to rain or immersed in water.
Do not allow any part of the device to come into contact with flames, or to
catch fire.
This product is equipped with a CLASS 2 laser. Do not
stare into beam.
This product has been marked with a symbol relating to removing electric
and electronic waste. This product should not be discarded with household
waste but must be returned to a collection system that conforms to the EU
Directive 2012/19/EU or the UK Waste Electrical and Electronic Equipment
Regulations 2013. It will then be recycled or dismantled in order to reduce
the impact on the environment. Electric and electronic equipment can be
hazardous for the environment and for human health since they contain
hazardous substances.
This symbol is used throughout this manual to warn the user about potential
risks. Please read & understand these sections before using the device.
Personal Protective Equipment (P.P.E.), such as ear defenders, eye protection,
safety gloves and a dust mask, must be worn during the operation of the
device.
The month and year of manufacture can be found within the product serial number e.g.
MMYYPPPAXXXXX. Where production month (MM) and production year (YY) are included.
21-CS1500 Designation of the tool CS: Circular Saw, 1500: 1500W Input Power.
λ: 650nm; P≤1mW EN 60825-1:2014

3
21-CS1500
Instruction & User Manual
Contents
GENERAL POWER TOOL SAFETY WARNINGS 4
1. Work area safety 4
2. Electrical safety 4
3. Personal safety 4
4. Power tool use and care 5
5. Service 5
TOOL SPECIFIC SAFETY WARNINGS 6
Additional Safety Rules For Saw Tools 6
Kickback Causes And Related Warnings 6
Lower Guard Function 7
COMPONENT LIST 10
TECHNICAL DATA 11
NOISE INFORMATION 11
VIBRATION INFORMATION 12
OPERATING INSTRUCTIONS 13
Intended Use 13
Circular Saw Assembly 13
Depth Adjustment 13
Angle Adjustment 13
Power Switch 13
Parallel Cut Adjustment 14
Laser Line Generator 14
General Cutting 14
Pocket Cutting 14
Cutting Large Sheets 15
Maintenance 15
WARRANTY STATEMENT 16
Terms and Conditions 16
EU/UK DECLARATION OF CONFORMITY 18

421-CS1500
Instruction & User Manual
Read all safety warnings, instructions and
specifications provided with this power
tool. Failure to follow all instructions listed below
may result in electric shock, fire and/or serious
injury. Save all warnings and instructions for
future reference.
WARNING!
The term “power tool” in the warnings refers to
your mains operated (corded) power tool or battery
operated (cordless) power tool.
1. Work area safety
m Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
m Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks which may ignite the dust or
fumes.
m Keep children and bystanders away while
operating a power tool. Distractions can
cause you to lose control.
2. Electrical safety
m Power tool plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of electric
shock.
m Avoid body contact with earthed or
grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There
is an increased risk of electric shock if your body
is earthed or grounded.
m Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
m Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep the cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of
electric shock.
m When operating a power tool outdoors,
use an extension cord suitable for
outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock.
m If operating a power tool in a damp
location is unavoidable, use a residual
current device (RCD) protected supply.
Use of an RCD reduces the risk of electric shock.
3. Personal safety
m Stay alert, watch what you are doing
and use common sense when operating
a power tool. Do not use a power tool
while you are tired or under the influence
of drugs, alcohol or medication. A moment
of inattention while operating power tools may
result in serious personal injury.
m Use personal protective equipment.
Always wear eye protection. Protective
equipment such as a dust mask, non-skid safety
shoes, hard hat or hearing protection used for
appropriate conditions will reduce personal
injuries.
m Prevent unintentional starting. Ensure
the switch is in the off position before
connecting to power source and/or
battery pack, picking up or carrying the
tool. Carrying power tools with your finger on
the switch or energising power tools that have
the switch on invites accidents.
GENERAL POWER TOOL SAFETY WARNINGS

5
21-CS1500
Instruction & User Manual
m Remove any adjusting key or wrench
before turning the power tool on. A
wrench or a key left attached to a rotating part of
the power tool may result in personal injury.
m Do not overreach. Keep proper footing
and balance at all times. This enables
better control of the power tool in unexpected
situations.
m Dress properly. Do not wear loose
clothing or jewellery. Keep your hair and
clothing away from moving parts. Loose
clothes, jewellery or long hair can be caught in
moving parts.
m If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce dust-
related hazards.
m Do not let familiarity gained from
frequent use of tools allow you to become
complacent and ignore tool safety
principles. A careless action can cause severe
injury within a fraction of a second.
4. Power tool use and care
m Do not force the power tool. Use the
correct power tool for your application.
The correct power tool will do the job better
and safer at the rate for which it was designed.
m Do not use the power tool if the switch
does not turn it on and off. Any power
tool that cannot be controlled with the switch is
dangerous and must be repaired.
m Disconnect the plug from the power
source and/or remove the battery pack,
if detachable, from the power tool before
making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
m Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands of
untrained users.
m Maintain power tools and accessories.
Check for misalignment or binding of
moving parts, breakage of parts and any
other condition that may affect the power
tool’s operation. If damaged, have the
power tool repaired before use. Many
accidents are caused by poorly maintained power
tools.
m Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier
to control.
m Use the power tool, accessories and
tool bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to
be performed. Use of the power tool for
operations different from those intended could
result in a hazardous situation.
m Keep handles and grasping surfaces
dry, clean and free from oil and grease.
Slippery handles and grasping surfaces do not
allow for safe handling and control of the tool in
unexpected situations.
5. Service
m Have your power tool serviced by a
qualified repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.

621-CS1500
Instruction & User Manual
m Wear ear protectors. Exposure to noise
can cause hearing loss.
m Wear eye protection. Wear goggles
to prevent eyes from exposure to flying
particles.
m Wear dust mask. Take protective
measures against inhalation of dust. Some
materials can contain toxic materials. Also
work with dust/ chip extraction when
connectable.
Additional Safety Rules For Saw
Tools
m Keep hands away from cutting area
and the blade. Keep your second
hand on auxiliary handle, or motor
housing. If both hands are holding the saw,
they cannot be cut by the blade.
m Do not reach underneath the
workpiece. The guard cannot protect you
from the blade below the workpiece.
m Adjust the cutting depth to the
thickness of the workpiece. Less than a
full tooth of the blade teeth should be visible
below the workpiece.
m Never hold the workpiece in your
hands or across your leg while
cutting. Secure the workpiece to a
stable platform. It is important to support
the work properly to minimise body
exposure, blade binding, or loss of control.
m Hold the power tool by insulated
gripping surfaces, when performing
an operation where the cutting tool
may contact hidden wiring or its own
cord. Contact with a “live” wire will also
make exposed metal parts of the power
tool “live” and could give the operator an
electric shock.
m When ripping, always use a rip fence
or straight edge guide. This improves
the accuracy of cut and reduces the chance
of blade binding.
m Always use blades with correct size
and shape (diamond versus round) of
arbour holes. Blades that do not match
the mounting hardware of the saw will run
off-centre, causing loss of control.
m Never use damaged or incorrect
blade washers or bolt. The blade
washers and bolt were specially designed
for your saw, for optimum performance and
safety of operation.
Kickback Causes And Related
Warnings
m Kickback is a sudden reaction to a pinched,
jammed or misaligned saw blade, causing
an uncontrolled saw to lift up and out of the
workpiece toward the operator
m When the blade is pinched or jammed
tightly by the kerf closing down, the blade
stalls and the motor reaction drives the unit
rapidly back toward the operator
TOOL SPECIFIC SAFETY WARNINGS

7
21-CS1500
Instruction & User Manual
m If the blade becomes twisted or misaligned
in the cut, the teeth at the back edge of the
blade can dig into the top surface of the
wood causing the blade to climb out of the
kerf and jump back toward the operator.
Kickback is the result of saw misuse and/or
incorrect operating procedures or conditions
and can be avoided by taking proper
precautions as given below.
m Maintain a firm grip with both
hands on the saw and position your
arms to resist kickback forces.
Position your body to either side of
the blade, but not in line with the
blade. Kickback could cause the saw to
jump backwards, but kickback forces can
be controlled by the operator, if proper
precautions are taken.
m When blade is binding, or when
interrupting a cut for any reason,
release the trigger and hold the
saw motionless in the material until
the blade comes to a complete
stop. Never attempt to remove
the saw from the work or pull the
saw backward while the blade is
in motion or kickback may occur.
Investigate and take corrective actions to
eliminate the cause of blade binding.
m When restarting a saw in the
workpiece, centre the saw blade
in the kerf so that the saw teeth
are not engaged into the material.
If a saw blade binds, it may walk up or
kickback from the workpiece as the saw is
restarted.
m Support large panels to minimise
the risk of blade pinching and
kickback. Large panels tend to sag
under their own weight. Supports must
be placed under the panel on both sides,
near the line of cut and near the edge of
the panel.
m Do not use dull or damaged blades.
Unsharpened or improperly set blades
produce narrow kerf causing excessive
friction, blade binding and kickback.
m Blade depth and bevel adjusting
locking levers must be tight and
secure before making the cut. If
blade adjustment shifts while cutting, it
may cause binding and kickback.
m Use extra caution when sawing into
existing walls or other blind areas.
The protruding blade may cut objects that
can cause kickback.
Lower Guard Function
m Check the lower guard for proper
closing before each use. Do not
operate the saw if the lower guard
does not move freely and close
instantly. Never clamp or tie the
lower guard into the open position.
If the saw is accidentally dropped,
the lower guard may be bent. Raise
the lower guard with the retracting handle
and make sure it moves freely and does
not touch the blade or any other part, in all
angles and depths of cut.

821-CS1500
Instruction & User Manual
m Check the operation of the lower
guard spring. If the guard and the
spring are not operating properly,
they must be serviced before use.
Lower guard may operate sluggishly due to
damaged parts, gummy deposits, or a build-
up of debris.
m The lower guard may be retracted
manually only for special cuts such
as “plunge cuts” and “compound
cuts”. Raise the lower guard by the
retracting handle and as soon as the
blade enters the material, the lower
guard must be released. For all other
sawing, the lower guard should operate
automatically.
m Always observe that the lower guard
is covering the blade before placing
the saw down on bench or floor. An
unprotected, coasting blade will cause the
saw to walk backwards, cutting whatever is
in its path. Be aware of the time it takes for
the blade to stop after switch is released.

9
21-CS1500
Instruction & User Manual

10 21-CS1500
Instruction & User Manual
COMPONENT LIST
1
3
10
6
12
1. HAND GRIP AREA
2. POWER ON INDICATOR (NOTE: ON/OFF TRIGGER LOCATED UNDER HAND GRIP)
2a. LASER ON/OFF SWITCH (BELOW INDICATOR)
3. AUXILLARY HANDLE
4. BEVEL SCALE
5. PARALLEL GUIDE LOCKING SCREW
6. BEVEL LOCK BUTTON
7. FIXED GUARD
8. SAW BLADE
9. LOWER BLADE GUARD
10. LOWER GUARD LEVER
11. BASE PLATE
12. DUST PORT
22a
11
987
4
5

11
21-CS1500
Instruction & User Manual
TECHNICAL DATA
NOISE INFORMATION
Input Voltage 230-240V, 50Hz
Power 1500W
No Load Speed n0: 5800/min
Saw Blade Diameter 185mm
Max. Cutting
Depth
90°65mm
45°43mm
Product Weight 4.6 kg
A-Weighted Sound Pressure (LpA) 99 dB(A)
A-Weighted Sound Power (LwA) 110 dB(A)
KpA & KwA 3 dB(A)
Wear ear protection when sound pressure is over 80 dB(A)

12 21-CS1500
Instruction & User Manual
The vibration emission value of the power
tool is tested under EN 62841-1 and EN
62841-2-11, and can vary during operation
depending on the following usage conditions:
WARNING!
m How the tool is used and the materials
being cut or drilled.
m The tool being in good condition and well
maintained.
m Using the correct accessory for the tool and
ensuring it is sharp and in good condition.
m The tightness of the grip on the handles and
if any anti-vibration accessories are used.
m The tool being used as intended by its
design and these instructions.
m The declared vibration total value may also
be used in a preliminary assessment of
exposure.
THIS TOOL MAY CAUSE HAND-ARM
VIBRATION SYNDROME IF USAGE IS
NOT ADEQUATELY MANAGED.
To be accurate, an estimation of exposure
level in the actual conditions of use should
also take account of all parts of the operating
cycle. These include times when the tool is
switched off and when it is running idle but
not actually doing work. This may significantly
reduce the total exposure level over the
working period, helping to minimize your
vibration exposure risk.
WARNING!
m ALWAYS use sharp chisels, drills and blades.
m Maintain this tool in accordance with these
instructions and keep well lubricated (where
appropriate).
m If the tool is to be used regularly then invest
in anti-vibration accessories.
m Avoid using tools in temperatures of 10°C
or less.
m Plan your work schedule to spread any high
vibration tool use across a number of days.
VIBRATION INFORMATION
Vibration total values (triax vector sum) determined according to EN 62841
Vibration Emission
Value (ah)
Main Handle 2.01 m/s2
Auxillary Handle 1.48 m/s2
Uncertainty (K) 1.5 ms-2

13
21-CS1500
Instruction & User Manual
OPERATING INSTRUCTIONS
Intended Use
This circular saw is intended for fully supported
cross and rip cuts and bevel sawing of hard and
soft woods and board/sheet materials. It can
also be used for plunge cutting.
The tool must not be modified or used for
any other purposes than the ones described in
these instructions.
Circular Saw Assembly
Prior to any assembly and adjustment always
disconnect the tool from the power supply.
WARNING!
m Place this circular saw on its side on a flat
surface. Bring the base plate down to the
minimum depth cut as it’s easier to change
the blade.
m Push the spindle lock button toward motor
housing and hold it firmly.
m Turn the blade clamp bolt anti-clockwise.
m Remove the blade clamp bolt and outer
flange.
m Raise the lower guard by using the lever
for lower guard, and then remove the saw
blade.
m Clean the saw blade flanges then mount the
new saw blade onto the output spindle and
against the inner flange.
m Make sure the saw teeth and arrow on the
blade point in the same direction as the
arrow on the lower guard.
m Reinstall the outer flange and tighten the
blade clamp bolt.
m Make sure that the saw blade runs freely by
turning the blade by hand.
Depth Adjustment
m Loosen the lock lever for depth adjustment.
m Hold the baseplate flat against the edge
of the work piece and lift the body of the
saw until the blade is at the right depth
determined by the depth of cut scale (align
the scale line).
m Tighten the lock lever for depth adjustment.
Angle Adjustment
m Loosen the Lock knob for angle adjustment.
m Adjust the shoe to the desired angle
between 0°to 45°. [See miter scale].
m Tighten the lock knob for angle adjustment.
Power Switch
Before engaging the ON/OFF switch, check
that the saw blade is properly fitted and runs
smoothly and that the blade clamp bolt is
well tightened.
WARNING!
m Connect the plug to the power supply. The
power-on indicator light will remain lit until
the tool is disconnected from the power
supply.
m To switch on the circular saw, press the
lock-off button and pull the ON/OFF switch
trigger.
m When you release the switch trigger the
tool turns off.

14 21-CS1500
Instruction & User Manual
Parallel Cut Adjustment
m Loosen the lock knob of edge guide.
m Slide the parallel guide through the slots in
the shoe to the desired width.
m Tighten the lock bolt to fit it in the position.
m Ensure that the edge guide rests against
the wood along its entire length to give a
consistent parallel cuts.
Laser Line Generator
Do not stare directly at the laser beam, do
not deliberately aim the beam at personnel
and ensure that it is not directed towards
the eye of a person for longer than 0.25
seconds.
WARNING!
m Turn on: Press the laser generator switch
once.
m Turn off: Press the switch again.
m Mark the cutting line on the work piece.
m Adjust the angle of cut as required.
m Plug in the machine and start the motor.
m When the blade is at its maximum speed
(after approximately 2 seconds), place the
saw on the work-piece.
m Switch on the laser generator from the laser
aperture using the laser generator switch.
m Align the beam with the mark on the work-
piece and slowly push the saw forward using
both hands, keeping the red light beam on
the mark.
m Switch off the laser beam when the cut is
completed.
General Cutting
m When starting, always hold the saw handle
with one hand and the auxiliary handle with
the other hand. Never force the saw but
maintain a light and continuous pressure
after completing the cut allow the saw to
come to a complete stop. When cutting
is interrupted, resume cutting by allowing
the blade to reach full speed and then
reentering the cut slowly.
m When cutting across the grain, the fibers of
the wood have a tendency to lift and tear,
moving the saw slowly minimizes this effect.
m Use only saw blades recommended by
the manufacturer, which conform to EN
847-1, if intended for wood and analogous
materials.
m Use only blade diameter(s) and speeds/
specifications etc in accordance with the
rating plate of the product.
Pocket Cutting
m Disconnect the plug from the power supply
before making any adjustments. Set the
depth adjustment based on the thickness of
the line drawing for the cut. Raise the lower
guard by using the lift lever.
m With the blade barely above the material
to be cut, start the saw and allow the blade
to come to full speed. Gradually lower the
blade into the material to be cut using the
front end of the shoe as a pivot point.
m When the blade starts cutting, release the
lower guard.
m When the shoe is resting flat on the surface
being cut, proceed cutting in a forward
direction to the end of the cut.
m Allow the blade to come to a full stop
before removing it from the cut.

15
21-CS1500
Instruction & User Manual
Never pull the saw backward since the blade
will climb out of the cut and kickback will
occur.
WARNING!
m Turn the saw around and finish the cut in
a normal manner, sawing forward. Use a
jigsaw or a hand saw to finish the cut in the
corners, if required.
Cutting Large Sheets
m Large sheet or boards require support to
prevent bends or sags. If you attempt to cut
without levelling and properly supporting
the work piece, the blade will tend to bind,
causing kickback.
m Support the panel or board close to the
cut. Be sure to set the blade adjustment
so that you can cut through the material
without cutting into the table or workbench.
Suggestion: use two by fours to support the
board or panel to be cut. If the piece is too
large for the workbench, use the floor with
the two-by fours supporting the wood.
Maintenance
Switch off the tool and disconnect the power
(remove battery/unplug) before cleaning
and maintenance – risk of electric shock and
accidental start.
WARNING!
m Wipe the tool with a dry or damp cloth. Do
not use a wet cloth. Do not use detergent
that contains solvent or corrosive, abrasive
additives – risk of damaging the surface.
m Clear the tool vents and the accessory
mount of dust and dirt after each use.
m Do not clean ventilation holes by inserting
sharp objects in them, such as screwdrivers
and other similar objects.
m Stubborn contamination in areas hard to
access can be removed with compressed air
(max 3. bar).
m Regularly check all fasteners, screws and
bolts to make sure that they are tight.
Tighten any loose screws immediately –
serious injury could occur.
m If the power cord becomes damaged and
replacement is necessary, this must be
carried out by an authorised warranty agent.
Transport and Storage
m If the tool shall remain unused for any
length of time, it should be stored in the
original packaging.
m Store the tool in a dry, frost-free, well
ventilated place with a temperature of no
more than 40°C and out of the reach of
children.
m Always Switch off the tool and disconnect it
from the power supply (remove the battery/
unplug the power cord) before transport.
m Always carry the tool using the purpose-
designed handle.
m Always carry the tool using the purpose-
designed handle.
m Ensure that the tool is not at risk of tipping
over or exposed to vibration and shocks
during transport, especially if the tool will be
transported by car or other vehicle.
Never open the tool. The tool has no
internal parts that the user can service or
repair. Never try to repair the tool yourself.
Take to an authorised service centre.
WARNING!

16 21-CS1500
Instruction & User Manual
WARRANTY STATEMENT
JCB Power Tools are guaranteed against manufacturing defects for
up to 3 years from date of purchase by simply registering your prod-
uct online within 30 days. Proof of purchase required. This does not
affect your statutory rights.
To register your JCB Power Tool, please visit: jcb-tools.com
Online registration is required within 30 days to receive a warranty certificate to activate your
standard 3 year warranty. Registration is only available online via www.jcb-tools.com. You will
need your original sales receipt, the model number and the serial number (if applicable) of your
product. Kits comprising of two or more tools are excluded from single registration and must
registered individually for full warranty cover.
Upon successful registration, a warranty certificate will be available to download, print or save as
a PDF document. The relevant warranty certificate together with the original sales receipt will be
required in the event of any claim within the warranty period.
Should you choose not to register your product within 30 days of purchase, your statutory
consumer rights will not be affected. You will need the original sales receipt as proof of purchase in
the event of a warranty claim.
Warranty cover commences from the date of purchase on the retail sales receipt and is valid only
for JCB Tools products purchased within the UK bearing the CE and UKCA mark and a visible
serial number.
In the unlikely event your JCB Power Tool is subject to a manufacturing fault within the warranty
period, JCB Tools may repair the product by replacing defective parts free of charge at our
discretion. In the event parts are irreplaceable JCB Tools may replace your product free of
charge. The original product will remain the property of JCB Tools in this situation.
The above repair or replacement of products will be undertaken providing that:
m The product has been subject to fair wear and tear only.
m The product has not been subject to accidental or cosmetic damage.

17
21-CS1500
Instruction & User Manual
m The product has not been misused and has been used only in accordance with the instruction
manual provided.
m The product has not been subject to overload or insufficient servicing and maintenance.
m The product has not been subject to any abnormal environmental conditions or inappropriate
operating conditions.
m Repairs have not been attempted by an unauthorised person and no modifications have been
made to the product.
m Repairs have not been undertaken using non-genuine spare parts.
JCB Power Tools used for Hire Fleets or as part of B2B and Service Contracts are not covered by
these terms and conditions.
JCB Tools 3 Year Warranty excludes the following (where applicable):
m Components normally subject to wear such as carbon brushes.
m Batteries, Chucks and Chargers.
m Accessories and consumable items.
m Cases and tool storage products.
If your product develops a fault within 30 days of purchase, return it to the retailer where it was
purchased together with your sales receipt. If a product develops a fault after 30 days a warranty
claim must be submitted.
If you have a warranty claim please take your product, original sales receipt and if applicable, a copy
of your extended warranty certificate to your place of purchase or nearest JCB Tools retailer.
If you wish to send your product to us directly, please send to JCB Tools, Unit 55, Romsey
Industrial Estate, Greatbridge Road, Romsey, Hampshire, SO51 0HR, along with your original
receipt and, if applicable, a copy of your extended warranty certificate. Delivery and repair charges
may apply at our discretion should the warranty claim be invalid for any of the reasons illustrated
above. In the event charges are not accepted the product will be retained by JCB Tools and
remain the property of JCB Tools.
The information on both your sales receipt and your extended warranty certificate must match.
JCB TOOLS WILL NOT BE LIABLE FOR ANY INJURIES OR CONSEQUENTIAL DAMAGES
RESULTING FROM USE OF THIS PRODUCT.

18 21-CS1500
Instruction & User Manual
Product:
UK Product Code No.
EU Product Code No.
Factory Reference No.
Name:
Address:
Country:
Name:
Address:
Country:
2006/42/EC The Machinery Directive
2014/30/EU The Electromagnetic Compatibility Directive
2011/65/EU The Restriction of Hazardous Substances Directive
2008 No. 1597 The Supply of Machinery (Safety) Regulations 2008
2016 No. 1091 The Electromagnetic Compatibility Regulations 2016
2012 No. 3032 The Restriction of the Use of Certain Hazardous Substances in
Electrical and Electronic Equipment Regulations 2012
EN 62841-1:2015
EN 62841-2-5:2014
EN 55014-1:2017
EN 55014-2:2015
EN 61000-3-2:2014
EN 61000-3-11:2000
EN 60825-1:2014
Name:
Address:
Country:
SIGNATURE:
FUNCTION:
PRODUCT(S) COVERED BY THIS
DECLARATION:
4.
IDENTIFICATION DETAILS OF
MANUFACTURER:
1.
6.
REFERENCES TO THE RELEVANT
HARMONISED SAFETY
STANDARDS USED OR
REFERENCES TO THE OTHER
TECHNICAL SPECIFICATIONS IN
RELATION TO WHICH
CONFORMITY IS DECLARED:
7.
OBJECT OF THE DECLARATION:
PLACE OF ISSUE:
NAME:
ADDITIONAL INFORMATION. THE
TECHNICAL DOCUMENTATION
FOR THE MACHINERY IS
AVAILABLE FROM:
SIGNED FOR AND ON BEHALF OF:
DATE OF ISSUE:
THIS DECLARATION OF CONFORMITY IS ISSUED UNDER THE SOLE RESPONSIBILITY OF THE MANUFACTURER
UK
Authorised Representative Service
77 Camden Street Lower
UK DECLARATION
OF CONFORMITY
JCB-CS1500-E
76337
Yellow and Black Tools Ltd. (T/A: JCB Tools)
AUTHORISED REPRESENTATIVE:
2.
3.
Product:
Function:
5i.
THE OBJECT OF THE
DECLARATION DESCRIBED IN
POINT 4 IS IN CONFORMITY WITH
THE RELEVANT UK STATUTORY
INSTRUMENTS:
5ii.
184mm 1500W Corded Circular Saw
Cross Cuts, Rip Cuts and Bevel Cuts Sawing
QA MANAGER
TIM BURGOYNE
Dublin DO2 XE80
Ireland
Electromagnetic compatibility. Requirements for household appliances, electric tools and similar apparatus.
Emission
Electromagnetic compatibility. Requirements for household appliances, electric tools and similar apparatus.
Immunity
Electromagnetic compatibility (EMC). Limits. Limits for harmonic current emissions (equipment input current ≤ 16
A per phase)
Electric motor-operated hand-held tools, transportable tools and lawn and garden machinery. Safety. General
requirements
EU DECLARATION OF
CONFORMITY
Ireland
YELLOW & BLACK TOOLS LTD.
ROMSEY, UK.
14/06/2021
Safety of laser products. Equipment classification and requirements
Authorised Representative Service
77 Camden Street Lower
Dublin DO2 XE80
Electric motor-operated hand-held tools, transportable tools and lawn and garden machinery. Safety. Particular
requirements for hand-held circular saws
Electromagnetic compatibility (EMC). Limits. Limitation of voltage changes, voltage fluctuations and flicker in
public low-voltage supply systems, for equipment with rated current ≤ 16 A per phase and not subject to
JCB 184mm 1500W Corded Circular Saw
JCB-CS1500, 21-CS1500
Unit 55 Romsey Industrial Estate, Greatbridge Road
Romsey, Hampshire SO51 0HR
THE OBJECT OF THE
DECLARATION DESCRIBED IN
POINT 4 IS IN CONFORMITY WITH
THE RELEVANT UNION
HARMONISATION LEGISLATION:
