Jensen MR-80 User manual

AM/FM POCKET RADIO
MODEL: MR-80
USER MANUAL
PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATING THIS UNIT
AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE

E-1
COMPLIANCE WITH FCC REGULATIONS
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B Digital
Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV technician for help.
WARNING
Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.

E-2
DEAR JENSEN®CUSTOMER
Selecting fine audio equipment such as the unit you've just purchased is only the start of
your musical enjoyment. Now it's time to consider how you can maximize the fun and
excitement your equipment offers. This manufacturer and the Electronic Industries
Association's Consumer Electronics Group want you to get the most out of your equipment
by playing it at a safe level. One that lets the sound come through loud and clear without
annoying blaring or distortion and, most importantly, without affecting your sensitive
hearing. Sound can be deceiving. Over time your hearing "comfort level" adapts to higher
volumes of sound. So what sounds "normal" can actually be loud and harmful to your
hearing. Guard against this by setting your equipment at a safe level BEFORE your hearing
adapts.
To establish a safe l e v e l :
• Start your volume control at a low setting.
• Slowly increase the sound until you can hear it comfortably and clearly, and without
distortion.
• Once you have established a comfortable sound l e v e l : Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing damage or loss in the future.
After all, we want you listening for a lifetime.
We Want You Listening For a Li f e t i m e
Used wisely, your new sound equipment will provide a
lifetime of fun and enjoyment. Since hearing damage from
loud noise is often undetectable until it is too late, this
manufacturer and the Electronic Industries Association ' s
Consumer Electronics Group recommend you avoid
prolonged exposure to excessive noise.
Customer's Re c o r d :
The serial number of this product is found on its bottom cover. You should note the serial
number of this unit in the space provided as a permanent record of your purchase to aid in
identification in the event of theft of loss.
Model Number : MR-80 Serial Number :

E-3
LOCATION OF CONTROLS
1. TELESCOPIC ANTENNA
2.
EARPHONE JACK
3.
TUNING SCALE
4.
TUNING CONTROL
5. POWER INDICATOR
6.
ON-OFF/VOLUME CONTROL
7.
SPEAKER
8.
BATTERY DOOR
9. BAND SELECTOR
10. BELT CLIP (ON BACK)
POWER SOURCE
The MR-80 operates on 2 ‘AAA' (UM-4) batteries.
For better performance and longer operating time, we recommend using alkaline-type
batteries.
1. Remove the BATTERY DOOR (#8) on the back of the MR-80.
2. Following the polarity diagram inside the battery compartment, insert 2 ‘AAA' (UM-4)
batteries (not included). Replace the BATTERY DOOR (#8).
CAUTIONS
1. Use only the size and type of battery specified.
2. Do not mix old and new batteries.
3. Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium) batteries.
4. If the unit is not to be used for an extended period of time, remove the batteries. Old or
leaking batteries can cause damage to the unit and may void the warranty.
5. Do not try to recharge batteries not intended to be recharged; they can overheat and
rupture (Follow battery manufacturer’s directions).
6. Do not dispose of batteries in fire, batteries may explode or leak.
7. Replace all the batteries at the same time, no matter exhausted or not.

E-4
LI STENING TO THE R A DIO
1. Use the BAND SELECTOR (#9) to select the AM or FM band.
2. Turn on the radio by rotating the ON/OFF/VOLUME CONTROL (#6). The Power Indicator
(#5) will turn on.
3. Use the TUNING CONTROL (#4) to tune to your desired radio station.
4. Adjust the ON/OFF/VOLUME CONTROL (#6) to obtain the desired sound level.
5. Rotate the ON/OFF/VOLUME CONTROL (#6) to turn off the radio when finish listening.
TIPS FOR BEST RADIO RECEPTION
AM - The AM antenna is built inside the radio. If AM reception is weak, change the position
of the unit until the internal antenna picks up the strongest signal
FM - To obtain the best FM reception, fully extend the TELESCOPIC FM ANTENNA (#1).
Avoid close to the speakers or other electrical appliance.
USING HEADPHONES
Headphones are not supplied with the unit. You will require headphones fitted with a 3.5mm
diameter stereo plug and an impedance of 8-32 ohms. Plug your headphones into the
EARPHONE JACK (#2) on the top of the unit for private listening. When using headphones,
the built-in Speaker will be disconnected.
WARNING : ALWAYS LOWER THE VOLUME LEVEL BEFORE PUTTING ON YOUR
HEADPHONES. OTHERWISE YOUR HEARING COULD BE DAMAGED.
CARE AND MAINTENANCE
1. Clean the unit with soft cloth. Solvent or detergent should never be used.
2. Avoid operating your unit under direct sunlight.
3. Keep your unit away from heating appliances and sources of electrical noise such as
fluorescent lamps or motors.

E-5
TROUBLESHOOTING GUIDE
If you experience difficulties in the use of this clock radio, please check the following or
call 1-800-777-5331 for Customer Service and support
SYMPTOM
POSSIBLE CAUSE
POSSIBLE SOLUTION
No sound.
VOLUME control at minimum
position.
Increase Volume
Radio noise or sound
distorted.
- Station not tuned properly
- reception is weak
- Retune Broadcast station
- change the position of the
unit for stronger signal
SPECIFICATION
Power Supply : DC 3V 2 x AAA (UM4) Batteries (not included)
Frequency : FM 87.5 - 108 MHz
AM 520 -1710 KHz
At Spectra, environmental and social responsibility is a core value
of our business. We are dedicated to continuous implementation
of responsible initiatives with an aim to conserve and maintain the
environment through responsible recycling.
Please visit us at http://www.spectraintl.com/green.htm for more information on Spectra’s
green initiatives or to find a recycler in your area.

E-6
90 DAY LIMITED WARRANTY AND SERVICE
VALID IN THE U.S.A. ONLY
SPECTRA MERCHANDISING INTERNATIONAL, INC. warrants this unit to be free from
defective materials or factory workmanship for a period of 90 days from the date of original
customer purchase and provided the product is utilized within the U.S.A. This warranty is
not assignable or transferable. Our obligation under this warranty is the repair or
replacement of the defective unit or any part thereof, except batteries, when it is returned
to the SPECTRA Service Department, accompanied by proof of the date of original consumer
purchase, such as a duplicate copy of a sales receipt.
You must pay all shipping charges required to ship the product to SPECTRA for warranty
service. If the product is repaired or replaced under warranty, the return charges will be at
SPECTRA’s expense. There are no other express warranties other than those stated herein.
This warranty is valid only in accordance with the conditions set forth below:
1. The warranty applies to the SPECTRA product only while:
a. It remains in the possession of the original purchaser and proof of purchase is
demonstrated.
b. It has not been subjected to accident, misuse, abuse, improper service, usage outside
the descriptions and warnings covered within the user manual or non-SPECTRA
approved modifications.
c. Claims are made within the warranty period.
2. This warranty does not cover damage or equipment failure caused by electrical wiring not
in compliance with electrical codes or SPECTRA user manual specifications, or
failure to provide reasonable care and necessary maintenance as outlined in the user
manual.
3. Warranty of all SPECTRA products applies to residential use only and is void when products are
used in nonresidential environment or installed outside the United States.
This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state. TO OBTAIN SERVICE please remove all batteries (if any) and pack the
unit carefully and send it freight prepaid to SPECTRA at the address shown below. IF THE
UNIT IS RETURNED WITHIN THE WARRANTY PERIOD shown above, please include a
proof of purchase (dated cash register receipt) so that we may establish your eligibility for
warranty service and repair of the unit without cost. Also include a note with a description
explaining how the unit is defective. A customer service representative may need to contact
you regarding the status of your repair, so please include your name, address, phone
number and email address to expedite the process.
IF THE UNIT IS OUTSIDE THE WARRANTY PERIOD, please include a check for $5.00 to
cover the cost of repair, handling and return postage. All out of warranty returns must be sent
prepaid.
It is recommended that you contact SPECTRA first at 1-800-777-5331 or by email at
[e-mail] for updated information on the unit requiring service. In some
cases, the model you have may be discontinued, and SPECTRA reserves the right to offer
alternative options for repair or replacement.
SPECTRA MERCHANDISING INTERNATIONAL, INC.
4230 North Normandy Avenue,
Chicago, IL60634, USA. 1-800-777-5331
To register your product, visit the link on the website below to enter your information.
http://www.spectraintl.com/wform.htm
0318 Printed in China
