Jensen JCR-310 User manual

AM/FM Stereo Dual Alarm Clock Radio
With Top Loading CD Player
US R MANUAL
JCR-310
PL AS R AD THIS US R M
ANUAL COMPL T LY B FOR OP RATING
THIS UNIT AND R TAIN THIS BOOKL T FOR FUTUR R F R NC .

1
D AR J NS N® CUSTOM R
Selecting fine audio equipment such as the unit you've just purchased is only the start of
your musical enjoyment. Now it's time to consider how you can maximize the fun and
excitement your equipment offers. This manufacturer and the lectronic Industries
Association's Consumer lectronics Group want you to get the most out of your
equipment by playing it at a safe level. One that lets the sound come through loud and
clear without annoying blaring or distortion and, most importantly, without affecting your
sensitive hearing.
Sound can be deceiving. Over time your hearing "comfort level" adapts to higher
volumes of sound. So what sounds "normal" can actually be loud and harmful to your
hearing. Guard against this by setting your equipment at a safe level B FOR your
hearing adapts.
To establish a safe level:
• Start your volume control at a low setting.
• Slowly increase the sound until you can hear it comfortably and clearly, and without
distortion.
Once you have established a comfortable sound level:
• Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing damage or loss in the future.
After all, we want you listening for a lifetime.
We Want You Listening For a Lifetime
Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment.
Since hearing damage from loud noise is often undetectable until it is too late, this
manufacturer and the lectronic Industries Association's Consumer lectronics Group
recommend you avoid prolonged exposure to excessive noise.
Customer's Record:
The serial number of this product is found on its bottom cover. You should note the
serial number of this unit in the space provided as a permanent record of your purchase
to aid in identification in the event of theft of loss.
Model Number: JCR-310 Serial Number: ____________________

2
WARNINGS
WARNING:
To reduce the risk of fire or electric shock, do not expose this
appliance to rain or moisture.
CAUTION:
Use of controls or adjustments or performance of procedures other
than those specified may result in hazardous radiation exposure.
CAUTION - TO R DUC TH RISK OF L CTRIC SHOCK, DO
NOT R MOV COV R (OR BACK). NO US R-S RVICING TO
QUALIFI D S RVIC P RSONN L.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
IMPORTANT SAF TY INSTRUCTIONS
1) Read these Instructions.
2) Keep these Instructions.
3) Heed all Warnings.
4) Follow all Instructions.
5) Do not use this apparatus near water.

3
6) Clean only with a dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions. The appliance should be situated so that its location or position does not
interfere with its proper ventilation. For example, the appliance should not be situated
on a bed, sofa, rug, or similar surface that may block the ventilation openings; or
placed in a built-in installation, such as a bookcase or cabinet that may impede the
flow of air through the ventilation openings.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9) Do not overload wall outlet. Use only power source as indicated.
10) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the third prong are provided for
your safety. When the provided plug does not fit into your outlet, consult an electrician
for replacement of the obsolete outlet.
11) Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
12) Main plug is used as disconnect device and it should remain readily operable during
intended use. In order to disconnect the apparatus from the mains completely, the
mains plug should be disconnected form the mains socket outlet completely.
13) Only use attachments/accessories specified by the manufacturer.
14) Use only with a cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury
from tip-over.
15) Unplug this apparatus during lightning storms or when unused for long
periods of time.
16) This apparatus shall not be exposed to dripping or splashing and that no objects filled
with liquids, such as vases, shall be placed on apparatus.
17) Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
18). Do not attempt to dismantle, open or repair this product yourself. If a fault occurs, seek
advice from your local qualified service technician or contact the distributor via the
telephone number at the back of this instruction manual.
19) Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
20) Caution marking and nameplate are located on bottom of product.
The symbol for Class II (double insulation)
21) CAUTION
Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type.
CAUTION:
TO PR V NT L CTRIC SHOCK, MATCH WID BLAD OF
PLUG TO WID SLOT. FULLY INS RT TH PLUG TO MAIN
POW R SOCK T.

4
SAV TH S INSTRUCTIONS
IMPORTANT NOT
Avoid installing the unit in locations described below:
• Places exposed to direct sunlight or close to heat radiating appliances such as
electric heaters.
• Places subject to constant vibration.
• Dusty, humid or moist places.
• Sources of electrical noise such as fluorescent lamps or motors.
• In case of malfunction due to electrostatic discharge, the apparatus has to be reset by
disconnecting it from mains supply and removing all the batteries. Wait at least for 30
seconds before reconnect the AC power cord or reinstall the batteries.
CAUTION
Note: This product complies with DHHS Rule 21 Subchapter J at date of manufacture.
Follow the advice below for safe operations.
ON PROT CTION AGAINST LAS R N RGY XPOSUR
o As the laser beam used in this compact disc player is harmful to the eyes, do
not attempt to disassemble the casing.
o Stop operation immediately if any liquid or solid object should fall into the
cabinet.
o Do not touch the lens or poke at it. If you do, you may damage the lens and
the player may not operate properly.
o Do not put anything in the safety slot. If you do, the laser diode will be ON
when the CD door is still open.
o This unit employs a laser. The use of controls or adjustment or performance
of procedures other than those specified here may result in exposure to
hazardous radiation.
ON PLAC M NT
• Do not use the unit in places which are extremely hot, cold, dusty, or humid.
• Place the unit on a flat and even surface.
• Do not restrict the air flow of the unit by placing it in a place with poor air flow, by
covering it with a cloth, or by placing it on a carpet.
ON SAF TY
• When connecting and disconnecting the AC power, grip the AC cord plastic plug and
not the cord itself. Pulling the cord may damage it and create hazard.
• When you are not going to use the unit for a long period of time, disconnect the AC
power cord from the wall outlet and remove all batteries.

5
ON AC VOLTAG
• Before use, check that the rated voltage of your unit matches your local voltage.
ON COND NSATION
• When left in a heated room where it is warm and damp, water droplets or
condensation may form inside the CD player.
• When there is condensation inside the unit, the unit may not function normally.
• Let it stand for 1 to 2 hours before turning the power on, or gradually heat the room up
and dry the unit before use.
Should any trouble occur, disconnect the AC power cord and refer servicing to
qualified personnel.
COMPLIANC WITH FCC R GULATIONS
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
NOT : This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
PROT CT YOUR FURNITUR !!
This system is equipped with non-skid rubber ‘feet’ to prevent the product from moving
when you operate the controls. These ‘feet’ are made from non-migrating rubber material
specially formulated to avoid leaving any marks or stains on your furniture. However
certain types of oil based furniture polishes, wood preservatives, or cleaning sprays may
cause the rubber ‘feet’ to soften, and leave marks or a rubber residue on the furniture.
To prevent any damage to your furniture we strongly recommend that you purchase small
self-adhesive felt pads, available at hardware stores and home improvement centers
everywhere, and apply these pads to the bottom of the rubber ‘feet’ before you place the
product on fine wooden furniture.

6
LOCATION OF CONTROLS
1. CD Door 14. SP AK RS
2. Power On/Standby ; FUNCTION button 15. PM Indicator
3. DISPLAY button 16. ALARM 1 - Beeping Indicator
4. TIM S T/M MORY/M M+ button 17. MUSIC 1 - Wake to CD/Radio/AUX
Alarm Indicator
5. ALARM 2/VOLUM - button 18. R P AT Indicator
6. ALARM 1/VOLUM + button 19. ALARM 2 - Beeping Indicator
7. SNOOZ /SL P button 20. MUSIC 2 - Wake to CD/Radio/AUX
Alarm Indicator
8. CD PROGRAM button 21. CD Door Open Button
9. CD R P AT button 22. AC Power Cord
10.  Tune/Skip/Search Backward button 23. FM Wire Antenna
11.  Tune/Skip/Search Forward button 24. L D Display
12. CD STOP button 25. AUX-IN Jack
13. CD PLAY/PAUS
button 26. Back-up Battery Compartment
(inside the CD compartment)

7
POW R SOURC
This unit operates using standard 120V~ 60Hz AC household power and 2 “AA” size
(UM-3) batteries (Not included) for alarm clock backup.
A. AC POW R CONN CTION
1. Plug the AC power cord into a standard 120V~ 60Hz AC wall outlet.
2. Tap the Power On/Standby button to turn on the unit.
3. Tap the FUNCTION button to change the operation mode.
4. Press and hold the Power On/Standby button to turn the unit into “STANDBY”
mode after you finish listening.
B. BATT RY BACK-UP FOR CLOCK S TTINGS
The battery back-up compartment is located inside the CD compartment.
1. Open the CD door and remove the battery compartment door.
2. Follow the polarity diagram shown inside the compartment and install 2 x AA (UM-3)
batteries (not included).
3. Replace the battery compartment door.
NOT : Only use a well-known brand of battery to ensure the longest life and best
performance.
BATT RY CAR
- Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
- Be sure that the batteries are installed correctly. Wrong polarity may damage the unit.
- Do not mix old and new batteries.
- Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium) batteries.
- Only batteries of the same or equivalent type as recommend are to be used.
- If the unit is not to be used for an extended period of time, remove all batteries. Old or
leaking battery can cause damage to the unit and may void the warranty.
- Do not dispose batteries in fire. Batteries may leak or explode.
- Danger of explosion if battery is incorrectly replaced.
CLOCK S TTING
1. With the unit in Standby mode, press and hold the TIM S T button for about 1 second
or until the “hour digits” begin to flash on the display.
2. Press the  /  buttons to adjust the hour.
NOT : Make sure the hour is set so that PM indicator is displayed correctly.
3. When the correct hour is selected, press the TIM S T button to confirm and the
“minute digits” will begin to flash on the display.
4. Press the  /  buttons to adjust the minutes.
5. When the correct minute is selected, press the TIM S T button again to complete the
setting.
ALARM OP RATION
S TTING TH ALARMS
1. With the unit in Standby mode, press the ALARM 1 or ALARM 2 button to select the
ALARM wake up sound mode - “Beeping Alarm”, “Music from CD”, “Music from your
external music player via AUX IN” or “Last AM/FM radio station you listened to (this will
depend on what you last listened to before putting the unit into Standby mode)”. The
relative alarm indicator ALARM 1/ALARM 2 or MUSIC 1/MUSIC 2 will light up to show
your selection.

8
2. If you select Wake to music, please set the volume level of music/radio with the power
ON before putting the unit into Standby mode. The volume you set will be the same
volume level that you come on when the alarm time is reached.
Note: 1.) For Wake to music from CD, please make sure a CD is inserted and can be
properly played, otherwise the unit will default to the “Beeping” alarm sound
automatically. Make sure the CD inserted can be played properly at desired
volume level before you turn the unit into Standby mode for next day wake up
alarm.
2.) For Wake to music from AUX, please make sure your external player has been
properly connected to JCR-310 and has sufficient power to maintaining it’s
continually playback before you turn the unit into Standby mode for next day
wake up alarm. The unit that is connected to the AUX-IN must be left playing
continuously in order to play properly when the wake time is reached.
3.) If you select Wake to music from Radio, make sure your AM/FM radio station is
set to the station you want to be woken up to. The JCR-310 will play the last
radio station you listened to when the wake time is reached.
3. After selecting the alarm sound mode, press and hold the respective ALARM button.
The alarm “hour digits” will begin to flash on the display. Press the  /  buttons to
adjust the alarm hour.
NOT : Make sure the hour is set so that PM indicator is displayed correctly for the chosen
wake time.
4. When the correct alarm hour is selected, press the corresponding ALARM button to
confirm and the alarm “minutes digits” will begin to flash.
5. Press the  /  buttons to adjust the alarm minute.
6. When the correct alarm minute is selected, press the corresponding ALARM button to
complete the setting.
TURNING TH ALARMS ON AND OFF
1. After you have set alarm time, tap the ALARM 1 or ALARM 2 button repeatedly to select
the alarm function.
OFF  Wake to Beeping  Wake to Music
2. Tap the respective alarm button to the wake up mode you desired and then wait for few
seconds to confirm. The alarm clock stops flashing and selected alarm indicator
ALARM 1 / ALARM 2 or MUSIC 1 / MUSIC 2 lights steadily.
3. Tap the respective alarm button to OFF mode if you want to turn off the next day alarm.
The corresponding alarm indicator goes off.
WAK TO B PING ALARM
 The Beeping Alarm will automatically turn on when the alarm time is reached. The
respective ALARM 1 or ALARM 2 indicator will blink.
 The beep alarm will sound for 60 minutes and then turn off automatically if the snooze
button is not pressed.
 To stop the beep alarm sound immediately, tap the Power button.
WAK TO MUSIC
 When the alarm time is reached, the unit will automatically turn on the CD, AUX or
Radio mode based on the last mode you were listening to before switching the unit to
Standby mode. The respective MUSIC 1 or MUSIC 2 alarm indicator will blink.
 The alarm sound level will be the last volume level you listened to.
 The music alarm will sound for 60 minutes and then turn off automatically if the
snooze button is not pressed.

9
 To stop the music alarm immediately, tap the Power button.
SNOOZ FUNCTION
 When the alarm sounds, it can be temporarily stopped by pressing the SNOOZ
button. The alarm sound will be suspended but the relative alarm indicator will keep
flashing.
 The alarm will turn off for 9 minutes and then come again.
 This manual snooze operation can be repeated again and again during alarm
sounding period.
LIST NING TO RADIO
Radio Tuning
1. Tap the / FUNCTION button repeatedly to select AM or FM radio mode.
2. To manually tune to a desired station, repeatedly tap the  /  buttons.
3. To automatically search for stations with strong signals, press and hold either of
the  /  buttons until the frequency digits on display begins to scan then release
the button. The tuner will stop on the first strong station it finds.
4. Press the Volume Up (+) and Volume Down (-) buttons to adjust the volume output
level.
5. Tap the DISPLAY button to show the current station frequency on the display. The
station frequency will revert back to show the time automatically after about 5
seconds.
6. Press and hold the / FUNCTION button to turn unit into standby mode after
listenning.
Notes:
- Manual tune to select weaker stations that might be skipped during automatic tuning.
- If the automatic tuning does not stop on the exact frequency of the station, for
example, it stops on 88.9 MHz instead of 88.8 MHz, use the manual tuning method to
"fine tune" to the exact frequency of the desired station.
HINTS FOR B ST R C PTION:
AM - The AM antenna is located inside the cabinet of the unit. If AM reception is weak,
change the position of unit until the internal antenna picks up the strongest signal.
FM - To insure maximum FM tuner reception, unwrap and fully extend the FM antenna
wire for the best FM radio reception.
Radio Station Presets
The unit allows you to store up to 10 AM and 10 FM stations for easy recall at any time.
Setting Preset Stations
1. Tap the / FUNCTION button to turn on the unit.
2. Tap the / FUNCTION button to select AM or FM radio mode.
3. Tune to the radio station you want to store in memory by using the  /  buttons.
4. Press and hold the M MORY button, the preset channel number appears on display
and blinks.
5. To select desired preset station number, tap the  /  buttons.
6. To confirm preset location, tap the M MORY button.
7. Repeat steps 3 to 6 to store other stations if necessary.
Notes:
- There is an approximate 7 seconds delay when programming, after 7 seconds, the
unit will automatically switch back to normal tuner mode.
- You can overwrite a preset station by overwriting and storing the new frequency in
its place.

10
Recalling a Preset Station
1. Tap the / FUNCTION button to turn on the unit.
2. Tap the / FUNCTION button to select AM or FM radio receiving mode.
3. To select desired preset channel, tap the M M+ button repeatedly.
CD OP RATION
This CD player not only plays commercial CDs, but also self-compiled CD-R/RW discs. Do
not attempt to play any of the following formats: CD-ROM, CDI, VCD, DVD or computer
CDs.
NOT S ON CD-R/RW DISCS
• Because of non-standardized format definition/production of CD-R/RW, playback
quality & performance are not guaranteed.
• Manufacturer is not responsible for the playability of CD-R/RW due to recording
conditions such as PC performance, writing software, media ability, etc.
• Do not attach a label or seal to either side of the CD-R/RW disc. It may cause a
malfunction.
INS RTING AN AUDIO CD DISC
1. Press the OP N button to open the CD door. Carefully place an audio CD disc with
its label side facing upward in the CD compartment and gently
close the CD door.
2. Tap the / FUNCTION button to turn on the unit.
3. Tap the / FUNCTION button to select CD mode.
4. The unit will read the CD disc automatically, display will briefly
show flashing “- -” then the total number of tracks on the CD.
5. If no disc is inserted or if the inserted disc is not recognized, the
display will show the message “NO”. If the CD door is not closed, the display will
show “OP”.
NOT S:
 Keep the CD door closed when the system is not in use to prevent dirt and dust from
entering the CD mechanism.
 Never place more than one CD in the CD tray. If two discs are loaded at the same
time, the CD mechanism may jam and / or the discs themselves may be damaged.
AUDIO CD DISC PLAYBACK
1. When the CD door is closed and a CD is inside, press the PLAY/PAUS button
to start CD playback.
2. Adjust the VOLUM control to obtain the desired sound level from the Built-in
Speakers.
IMPORTANT!!
If the disc is smudged or scratched it may skip or stop completely. This does not indicate a
problem with the player. If this occurs, try playing another disc. If that disc plays properly,
you may assume that the first disc is damaged and unplayable.
PLAY/PAUS MOD
1. To temporarily stop playback while the CD disc is playing, press the button once.
The track number playing will be flashing, playback is now paused.
2. The sound pauses, but the disc will continue to spin. To re-start playback, press the
buton again. The music will start from the exact position where it was paused.

11
3. In clock display mode, tap the DISPLAY button to show the current track number on
the display. The current track number will revert back to show the time after 30
seconds.
4. To stop the CD playback, press the STOP button once.
SKIP and S ARCH MOD
1. In play or pause mode, press the Tune/Skip/Search Forward  button once to skip
forward to the next track or repeatedly to skip multiple tracks. Press the
Tune/Skip/Search Backward  button to return to the beginning of the track, or press
the button repeatedly to skip backward several tracks.
2. During play mode, when the  or  button is pressed and held, the unit will do a
high speed audible search of the track, either forward or backward depending on
which button is pressed.
Note: Track number will change to show current time after 30 seconds if no CD operation
button being pressed.
R P AT MOD
1. Repeat One:
In the CD play mode, press the R P AT button once, the R P AT indicator will
light on the display and flash. This single track of music will be repeated.
2. Repeat All:
In the CD play mode, press the R P AT button twice, the R P AT indicator will
show on the display steadily. The whole disc will be played repeatedly.
3. To cancel repeat function
Press the R P AT button repeatedly until Repeat Indicator goes off on the display.
Standard playback mode will now resume.
PROGRAM MOD
1. In CD mode, press the STOP button to stop CD playback, total tracks
of the CD will display.
2. Press the PROGRAM button on unit, the program location and
program track number “1:00” will display and program track digits “00”
flash.
3. Press the  /  button to choose your desired musical track. For
example, track 5 is selected, “05” will show in display and flash.
4. Press the PROGRAM button again to store this track in memory. The
L D display will go to “2:00” and track number digits keep
flashing to prompt for input next track.
5. Repeat the above procedures 3 - 4 until all desired tracks are stored. A total of 20
tracks can be stored for CD playback.
6. After you finish programming 20
th
tracks, program location display will stop at 20 and
will not further advance.
7. Press the button once to start the program playback.
8. To cancel the programmed memory, press the button twice or open the CD door
during the stop mode.

12
SL P TIM R FUNCTION
The sleep timer allows you to turn the unit off after a designated time is reached.
1. To activate the sleep timer, turn the unit on and either load a CD, tune to the desired
radio station or listening to music via AUX IN.
2. Tap the SL P button and the sleep time appears on the display.
3. Repeatedly tap the SL P button to select a sleep time. The unit will turn off after 10,
20, 30, 40, 50, 60, 70, 80 or 90 minutes. Wait 5 seconds after your selection for the unit
to confirm the selection, the unit will play for the selected length of time then
automatically turn off.
4. To cancel the sleep timer, press the SL P buttons until timer shows “OFF”, the unit
will turn into standby mode after 2 seconds.
5. To turn the unit off before the selected length of time, press the Power button at any
time.
Notes:
1.) To check the remaining sleep time, tap the SL P button once.
2.) If you are falling asleep to music from an external device connected to the AUX
input, the sleep timer will shut off the power to this system but it will not turn off the
external device.
AUXILIARY INPUT OP RATION
This unit provides an auxiliary audio signal input jack for connecting external audio
devices like MP3 players, CD players and iPods (except iPod shuffle 3rd gen) and listen
to your external source through the speakers of this system.
1. Use an audio cable (not included) with one 3.5 mm stereo plug on each end of the
cable.
2. Plug one end into the AUX-IN jack located on the left hand side of the unit and the
other end of the cable into the Line-out Jack or Headphone Jack of your external
audio device.
3. Turn on the external audio device.
4. Tap the / FUNCTION button to select AUX mode, “AUH” will show on display for
few seconds before show current time.
5. The volume level can now be controlled through the main unit. Operate all other
functions on the auxiliary device as usual.
Note:
(1) If you connected the Line-out Jack of your external device then you only need to
adjust the volume control of this system. If you connected the Headphone Jack of
your external device then you may need to adjust both the volume control of your
external device and the volume control of this system to find the most desirable
volume setting.
(2) Remove the audio cable from AUX IN jack when you finish listening. Don't forget to
switch off the power on your external device as well.

13
CAR AND MAINT NANC
1. Avoid operating your unit under direct sunlight or in hot, humid or dusty places.
2. Keep your unit away from heating appliances and sources of
electrical noise such as fluorescent lamps or motors.
3. If drop-outs or interruptions occur in the music during CD
play, or if the CD fails to play at all, its bottom surface may
require cleaning. Before playing, wipe the disc from the
center outwards with a good soft cleaning cloth.
4. Unplug the unit from the electrical power outlet immediately in
case of malfunction.
Cleaning the Unit
 To prevent fire or shock hazard, disconnect your unit from the AC power source when
cleaning.
 The finish on the unit may be cleaned with a dust cloth and cared for as other
furniture. Use caution when cleaning and wiping the plastic parts.
 If the cabinet becomes dusty wipe it with a soft dry dust cloth. Do not use any wax or
polish sprays on the cabinet.
 If the front panel becomes dirty or smudged with fingerprints it may be cleaned with a
soft cloth slightly dampened with a mild soap and water solution. Never use abrasive
cloths or polishes as these will damage the finish of your unit.
CAUTION: Never allow any water or other liquids to get inside the unit while cleaning.
TROUBL SHOOTING GUID
If you experience difficulties in the use of this Docking System, please check the following
or call 1-800-777-5331 for Customer Service.
Symptom Possible Problem Solution
AC power cord is not plugged
properly into a wall outlet or
the connector is not plugged
into the AC Socket on the
back of the System.
Re-plug the AC power
cord into the wall outlet
and the connector into AC
Socket on the System.
Unit does not
respond (no power)
Wall outlet is not functioning. Plug another device into
the same outlet to confirm
the outlet is working.
Radio no sound
Unit not in RADIO function
mode.
Volume set at minimum
Tap FUNCTION button to
AM/FM RADIO position.
Increase Volume
Noise or sound
distorted on AM or
FM broadcast
Station not tuned properly for
AM or FM.
FM: Wire antenna is not fully
extended.
AM: The reception at the set
location is poor.
Retune the AM/FM broadcast
station.
FM: Fully extend or reposition
the FM wire antenna.
AM: Change the position for the
best reception.

14
CD disc does not
play
Unit not in CD function
mode.
Audio disc is installed
incorrectly.
It the disc is self-compiled, the
media used may not be
compatible with the player.
Select CD mode.
Insert audio disc with label
side up.
Use better quality blank media
and retest.
Audio disc skips
while playing
Disc is dirty or scratched. Wipe disc with clean cloth or
use another disc.
Intermittent sound
from the player
Dirty or defective disc
Dirty pick up lens
Player is subject to excessive
shock or vibration
Clean or replace the
defective disc
Use a lens cleaning disc to
clean the lens
Relocate the player away
from shock or vibration
Unit gets warm after
extended play at
high volume
This is normal. Turn the unit off a period
of time or lower volume.
SP CIFICATIONS
Power Requirement
Main Unit: 120V~ 60Hz
Backup Battery for Clock: 2 x 1.5V “AA” (UM-3)
Frequency Range
Radio Band AM 520 – 1710 KHz
FM 87.5 - 108 MHz
Power Consumption
Main Unit: 10 Watts
At Spectra, environmental and social responsibility
is a core value of our business. We are dedicated to
continuous implementation of responsible initiatives
with an aim to conserve and maintain the
environment through responsible recycling.
Please visit us at http://www.spectraintl.com/green.htm for more information on Spectra’s
green initiatives or to find a recycler in your area.

15
90 DAY LIMIT D WARRANTY AND S RVIC
VALID IN TH U.S.A ONLY
SP CTRA M RCHANDISING INT RNATIONAL, INC. warrants this unit to be free from
defective materials or factory workmanship for a period of 90 days from the date of original
customer purchase and provided the product is utilized within the U.S.A. This warranty is
not assignable or transferable. Our obligation under this warranty is the repair or
replacement of the defective unit or any part thereof, except batteries, when it is returned
to the SP CTRA Service Department, accompanied by proof of the date of original
consumer purchase, such as a duplicate copy of a sales receipt.
You must pay all shipping charges required to ship the product to SP CTRA for warranty
service. If the product is repaired or replaced under warranty, the return charges will be at
SP CTRA’s expense. There are no other express warranties other than those stated
herein.
This warranty is valid only in accordance with the conditions set forth below:
1. The warranty applies to the SP CTRA product only while:
a. It remains in the possession of the original purchaser and proof of purchase is
demonstrated.
b. It has not been subjected to accident, misuse, abuse, improper service, usage outside
the descriptions and warnings covered within the user manual or non-SP CTRA
approved modifications.
c. Claims are made within the warranty period.
2. This warranty does not cover damage or equipment failure caused by electrical wiring
not in compliance with electrical codes or SP CTRA user manual specifications, or
failure to provide reasonable care and necessary maintenance as outlined in the user
manual.
3. Warranty of all SP CTRA products applies to residential use only and is void when
products are used in a nonresidential environment or installed outside the United States.
This warranty gives you specific legal rights, and you may also have other rights which
vary from state to state. TO OBTAIN S RVIC please remove all batteries (if any) and
pack the unit carefully and send it freight prepaid to SP CTRA at the address shown
below. IF TH UNIT IS R TURN D WITHIN TH WARRANTY P RIOD shown above,
please include a proof of purchase (dated cash register receipt) so that we may establish
your eligibility for warranty service and repair of the unit without cost. Also include a note
with a description explaining how the unit is defective. A customer service representative
may need to contact you regarding the status of your repair, so please include your name,
address, phone number and email address to expedite the process.

16
IF TH UNIT IS OUTSID TH WARRANTY P RIOD, please include a check for $20.00
to cover the cost of repair, handling and return postage. All out of warranty returns must be
sent prepaid.
It is recommended that you contact SP CTRA first at 1-800-777-5331 or by email at
[email protected] for updated information on the unit requiring service. In some
cases the model you have may be discontinued, and SP CTRA reserves the right to offer
alternative options for repair or replacement.
SP CTRA M RCHANDISING INT RNATIONAL, INC.
4230 North Normandy Avenue,
Chicago, IL60634, USA.
1-800-777-5331
To register your product, visit the link on the website below to enter your information.
http://www.spectraintl.com/wform.htm
0313 Printed in China
