JETStream H3ORBITER User manual

H3ORBITER™ | PARTS PLACEMENT
Jetstream of Houston LLP • 5905 Thomas Road Houston, TX 77041
www.waterblast.com • 832-590-1300
H3ORBITER™ | NOZZLE FLOW RATES
QSG-177_H3Orbiter_Rev01/22
H3ORBITER™
QSG-177
QUICK START GUIDE
Model Name H3Orbiter
Maximum Operating Pressure (psi) 22,000
Minimum Operating Pressure (psi) 2000
Maximum Flow (gpm) 80
Maximum Operating Pressure (bar) 1500
Minimum Operating Pressure (bar) 138
Maximum Flow (l/min) 307
Inlet Connection 1” NPT, ¾” NPT, 1” MP, ¾” MP
Power Range 30-1000 hp
Cycle Time 4-24 minutes
Rotation Speed Adjustable
Nozzle Type Accepted HHTC Carbide
Nozzle Port Size ¼” NPT(P4)
Diameter (in) 4
Length (in) 16.65
Weight (lbs) 35
Diameter (mm) 100
Length (mm) 423
Weight (kg) 16
* INCLUDED IN PREMIUM KIT
† ONE MANIFOLD ASSEMBLY INCLUDED IN STARTER KIT
12" NOZZLE EXTENSIONS*
65456-12 R150 MANIFOLD ASSEMBLY*†
65678
6" NOZZLE EXTENSIONS*
65456-06
R90 MANIFOLD ASSEMBLY*†
65677
R50 MANIFOLD ASSEMBLY*†
65676
R30 MANIFOLD ASSEMBLY*†
65675
2" NOZZLE EXTENSIONS
65456-02
24" NOZZLE EXTENSIONS*
65456-24
1" MEDIUM PRESSURE ADAPTER
65665
H3ORBITER
65367
BLUE ANTISIEZE - 27721
11/16" WRENCH - 65311
9/16" WRENCH - 66082
3/8" HEX KEY - 66083
SEAL KIT*
65681
65633-030 R30 STARTER KIT 65633-050 R50 STARTER KIT 65633-090 R90 STARTER KIT 65633-150 R150 STARTER KIT 65634 PREMIUM KIT
AVAILABLE KITS
SEAL REMOVAL TOOL
66050
QUICK CONNECT COUPLING FEMALE HALF
1/2" NPT FEMALE
52684
QUICK CONNECT COUPLING MALE HALF
1/2" NPT FEMALE
50990
1" MP MALE X 1/2" NPT MALE ADAPTER
28335
1" MP MALE X 1" TYPE M ADAPTER
28433
NOZZLE CONTAINERS
64249
TOW RING
65729

DANGER
!!
THIS PRODUCT CAN BE DANGEROUS IF NOT USED PROPERLY! Always wear
appropriate Personal Protective Equipment (PPE). Detailed PPE information can be found
at: www.fsesgsafety.com and clicking on the JETSTREAM name or by referring to the
yellow JETSTREAM SAFETY WARNING pamphlet (PI-082).
The following Quick-Start Guide is intended to provide the customer with an
expedient reference for H3Orbiter installation and operation. It does not replace
the complete product instructions (PI-177).
This product is sold with the understanding that the purchaser agrees to
thoroughly train all operators and maintenance personnel in the correct and
safe installation, operation, and maintenance of the product and to provide
adequate supervision of personnel at all times. JETSTREAM urges customers to
make complete instructions available to all personnel and ensure they are read
thoroughly before installing, connecting or using the H3Orbiter. Retain these
instructions for future reference. If this product is resold or otherwise conveyed,
the purchaser must pass on these instructions to the new user. If any questions
remain, or to request additional copies, call JETSTREAM at [phone] or
[phone].
Read the yellow JETSTREAM SAFETY WARNING pamphlet (PI-082) included with
the shipment of the product.
CONNECTING THE H3ORBITER
Prior to the start of any job, make sure only high pressure rated ttings and
hoses are used in the waterblasting system.
Prior to installing the H3Orbiter onto the hose, ush the system to clear any
debris.
• Install required inlet adapter on shaft with anti-seize.
• Flush and install Nozzle extensions onto associated Manifold Assy.
• Install Manifold assembly onto tool output shaft.
• Inlet shaft connections:
15K PSI RATED CONNECTION (3/4” & 1” NPT FEMALE INLET)
1. Apply 3-4 wraps of Teon thread sealant tape to the available male threads of
the connection.
2. Apply anti-seize compound over the sealant tape for additional protection
against galling.
3. Install by using an appropriate open-ended wrench on ats found on the
inlet shaft and adapter and tighten 1-2 turns past hand-tight. All NPT pipe
connections should have a minimum thread engagement of (4) threads.
22K PSI RATED CONNECTION (3/4” & 1” MP Female Inlet)
1. Apply anti-seize compound to the threads of the inlet connection.
NOTE: DO NOT use Teon tape on 22K PSI connections.
2. Install by using an appropriate open-ended wrench on ats found on the
body and tighten to 90 ft-lbs.
NOTE: DO NOT OVERTIGHTEN; damage to coned sealing surface could result.
OPERATION
As per the WJTA-IMCA Recommended Practices, all operators shall follow the
OSHA regulations for personal protective equipment. (OSHA guidelines for
Personal Protective Equipment are available in document number 3151-12R 2004,
which can be obtained from www.osha.gov.) All operators shall be issued suitable
head protection, eye protection, hearing protection, body protection, hand and
foot protection and respiratory protection (if needed). For detailed specications
on all protections required, refer to the WJTA-IMCA ‘Recommended Practices
for the Use of High Pressure Waterjetting Equipment’ Section 6, Protective
Equipment For Personnel.
!!CAUTION
The H3Orbiter™ can be used at a minimum service temperature of -20°C (-4°F) and a
maximum service temperature of 115°C (240°F). Use at temperatures lower or higher
than these recommended temperatures may result in premature tool failure.
1. Start by slowly increasing pressure to 500 psi and check the entire system,
including all connections, for leaks. Increase pressure in increments,
pausing at each to inspect the system for leaks, proper rotation of tool,
temperature, and other operational anomalies. If any problems are
discovered, lower pressure back to zero and turn off source of power before
making any adjustments.
2. Adjust the speed as needed for operation.
WARNING
!!
Remove the tool from service if:
a. Water is found to be exiting any of the weep holes found on the tool.
b. The rotation of the inlet shaft or outlet nozzles is binding in any way.
c. The nozzles can no longer hold pressure at water flow rate for which it was sized.
NOTE: For improved reliability and longer life, it is recommended that a lter of
at least 10 microns be used on the water supply inlet. A strainer (100 mesh
minimum) must also be used in the water tank (if equipped with tank).
H3Orbiter™ surface may exceed 200:F.
H3Orbiter™ utilizes magnets which produce strong magnetic elds. Keep the tool at least
6 inches away from any medical device.
DANGER
!!
Failure to follow the following instructions will cause unsafe conditions, severe injury
can result.
• DO NOT operate the H3Orbiter™ above its specied pressure.
• Operator must wear ear protection due to the noise generated by the spinning
nozzle.
• NEVER stand in the plane of blasting.
• At high-pressure, the water can be hot. Wear gloves and use caution to prevent
scalding.
• Place barricades with warning signs or barricade tape around work area. This
includes the waterblast unit and all high-pressure hoses.
• Operator must be outtted with proper safety apparel (refer to yellow JETSTREAM
SAFETY WARNING pamphlet). Body armor is strongly recommended.
!!CAUTION
DO NOT use the H3Orbiter™ if it has not been cleaned and inspected prior to starting the
working shift.
FOR FURTHER INFORMATION SEE:
https://www.youtube.com/user/JetstreamWaterblast
and the
Jetstream Safety Manual
Jetstream of Houston LLP • 5905 Thomas Road Houston, TX 77041 www.waterblast.com • 1-832-590-1300
H3ORBITER™ | QUICK START GUIDE QSG-177
